Canvas SHERBROOKE 088-0095-6 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
PRODUCT NO. 088-0095-6

SHERBROOKE
5-PIECE FOLDING DINING SET—TABLE
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS®collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS®makes it easy to refresh your space
to reflect your unique style and the way you
live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS®products
to life. We can’t wait to see!
INSPIRED BY CANADA

TABLE OF CONTENTS
TOOLS REQUIRED
4
6
7
8
13
14
14
14
Parts List
Hardware List
Before You Begin Assembly
Step-by-step Guide
Technical Data
Troubleshooting
Caring for Your Item
Warranty
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE PRODUCT.
• Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
• Any assembly or maintenance of the product must be carried out by adults only.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• To prevent damage, place all parts on a level surface during assembly. Add a
layer of protective surface if needed.
• Due to the nature of steel, surface oxidation (rusting) will occur if the protective
coating is scratched. This is a natural process. To minimize this condition, it is
recommended that care be taken when assembling and handling the product in
order to prevent the paint from being scratched.
NOTE: Do not over drill/
Be aware of over-drilling
No. 2 Cross-head Screwdriver
Tip Shown Actual Size
2 people

SHERBROOKE 5-PC FOLDING DINING SET—TABLE4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1 Table leg 2
2 Support bar 2
3 Support bar 2
4 Table top 1

SHERBROOKE 5-PC FOLDING DINING SET—TABLE 5
EXPLODED PARTS
1
2x
2
2x
3
2x
4

SHERBROOKE 5-PC FOLDING DINING SET—TABLE6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
AScrew M7x60 8
BDowel Ø8x30 8
CScrew Ø5x55 8
DHex key 2

SHERBROOKE 5-PC FOLDING DINING SET—TABLE 7
BEFORE YOU BEGIN ASSEMBLY
?
MAKE SURE ALL PARTS ARE PRESENT
Compare all pieces to the parts and hardware lists, and
make sure you have all tools required for assembly.
REMOVE PACKAGING MATERIALS
Place packing materials back in the box. Do not dispose of
packaging materials until assembly is complete.
READ EACH STEP CAREFULLY
ASSEMBLE IN A CLEARED AREA
Place all parts from the box on the floor in front of you on a clean,
dry, level surface to protect the product as it is being built.
Make sure you understand each step. If you have any questions,
contact CANVAS® customer service at 1-888-670-6684 (toll free).

SHERBROOKE 5-PC FOLDING DINING SET—TABLE8
STEP-BY-STEP GUIDE
STEP 1
Insert the dowels Binto the ends of support bars 2and 3,
aligning the holes.
3x2 2x2 Bx8
BB
2
3

SHERBROOKE 5-PC FOLDING DINING SET—TABLE 9
STEP-BY-STEP GUIDE
STEP 2
Attach the table leg 1to the assembled support bar 2and 3
using the screws A, aligning the holes.
When assembled, tighten the screws with the hex key D.
Ax4 1x1 Dx1
100%
2
2
3
3
1
D
A

SHERBROOKE 5-PC FOLDING DINING SET—TABLE10
STEP-BY-STEP GUIDE
STEP 3
Connect the other table leg 1to the assembled frame
using the screws A, aligning the holes.
When assembled, tighten the screws with the hex key D.
Ax4 1x1 Dx1
100%
1
D
A

SHERBROOKE 5-PC FOLDING DINING SET—TABLE 11
STEP-BY-STEP GUIDE
STEP 4
Connect the table top 4to the assembled frame using
the screws C, aligning the holes.
When assembled, tighten the screws with the cross-head screwdriver.
Cx8 4x1
C
4

SHERBROOKE 5-PC FOLDING DINING SET—TABLE12
STEP-BY-STEP GUIDE
STEP 5
To open table leaf, swing legs open until they are angled as shown and lock into
place from the underside of the tabletop.
To close table leaf, unlock from underside of the tabletop and swing legs closed until
they are flush with the rest of the support frame, while holding the leaf in place.
Gently lower the leaf until it rests vertically against the table support legs.

SHERBROOKE 5-PC FOLDING DINING SET—TABLE 13
TECHNICAL DATA
SPECIFICATIONS
ASSEMBLED DIMENSIONS (W x D x H)
ASSEMBLED WEIGHT
MAXIMUM WEIGHT CAPACITY
36 1/2 x 36 1/2 x 29 1/2"
92.7 x 92.7 x 75 cm
35 lb 4 oz
16 kg
165 lb 6 oz
75 kg
29 1/2"
(75 cm)
36 1/2"
(92.7 cm)
36 1/2"
(92.7 cm)

ASSEMBLY TROUBLESHOOTING
CALL US;
WE CAN HELP
BEFORE RETURNING
YOUR PRODUCT If you have questions regarding your product or require
warranty assistance, please call our customer service helpline.

TOLL-FREE:
1-888-670-6684
HAVING TROUBLE?
LET US HELP YOU!
CARING FOR YOUR ITEM
1Always keep children under close supervision while they are using or around this
product. Never leave children unattended.
2This product is intended for domestic, outdoor use only.
3Do not light any fires below or near the product.
4Check all nuts and bolts periodically for tightness. When required, tighten them
again.
OFF SEASON: Clean and dry before storing in a dry, sheltered area.
5We recommend the use of furniture covers when not in use.
CLEANING: The wood frame does not require seasonal maintenance. However, over time the colour
of the wood will fade to a grey patina colour as this is a natural property of wood. If you
would like the wood to maintain its colour, it is recommended that you treat it with a
hardwood sealer oil.
WARRANTY INFORMATION
This CANVAS® product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.

Made in Vietnam
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
PRODUCT NO. 088-0095-6
SHERBROOKE 5-PC FOLDING DINING SET—TABLE14

INSPIRED BY CANADA

PRODUIT Nº 088-0095-6

SHERBROOKE
ENSEMBLE À DÎNER PLIANT DE 5 PIÈCES
INSTRUCTIONS D’ASSEMBLAGE
VOUS RENCONTREZ DES PROBLÈMES?
SANS FRAIS :
1 888 670-6684
IMPORTANT : Veuillez lire attentivement ce guide
avant de procéder à l’assemblage de cet article.
Conservez ce guide aux fins de consultation ultérieure.

Nous croyons au pouvoir de la décoration et
à sa capacité de façonner votre maison.
C’est pourquoi nous nous inspirons des gens
du pays et de leur mode de vie pour
concevoir la collection CANVASMD.
Qu’il soit question de meubles tendance, de
décorations des Fêtes ou d’articles essentiels
pour profiter de votre jardin, CANVASMD vous
permet de rafraîchir facilement votre espace
afin qu’il soit unique et reflète votre façon de
vivre au quotidien.
Nous serions ravis de connaître votre opinion
et nous vous invitons à nous faire part de vos
commentaires. Visitez notre site Web à
l’adresse canadiantire.ca pour nous faire part
de votre expérience et partagez vos photos
en utilisant le mot-clic #MonStyleCANVAS.
Montrez-nous comment vous donnez vie aux
articles CANVASMD. Nous avons hâte de les voir!
INSPIRÉE DU CANADA

4
6
7
8
13
14
14
14
Liste des pièces
Liste de la quincaillerie
Avant de commencer l’assemblage
Guide étape par étape
Données techniques
Dépannage
Entretien de votre article
Garantie
REMARQUE : N’utilisez
pas d’outil électrique pour visser.
Faites attention de ne pas visser
excessivement.
Tournevis à tête cruciforme no2
Taille réelle de la tête
2 personnes
TABLE DES MATIÈRES
AVERTISSEMENT! POUR RÉDUIRE LE RISQUE DE BLESSURES
GRAVES, LISEZ LES CONSIGNES DE SÉCURITÉ SUIVANTES
AVANT D’ASSEMBLER OU D’UTILISER L’ARTICLE.
• Veuillez lire et comprendre tout ce guide d’utilisation avant d’essayer d’assembler,
d’utiliser ou d’installer le produit.
• L’assemblage et l’entretien de cet article ne doivent être effectués que par des
adultes.
• Certaines pièces peuvent contenir des bords tranchants. Portez des gants de
protection si nécessaire.
• Pour éviter tout dommage, placez toutes les pièces sur une surface plane pendant
l’assemblage. Ajoutez une couche de protection de surface, le cas échéant.
• En raison de la nature de l’acier, des rayures sur le revêtement de protection
pourraient entraîner l’oxydation de la surface (rouille). Ceci est un processus
naturel. Afin de minimiser cette condition, il est recommandé d’assembler et de
manipuler l’article soigneusement afin d’éviter d’égratigner la peinture.
OUTILS REQUIS

ENSEMBLE À DÎNER PLIANT DE 5 PIÈCES SHERBROOKE—TABLE4
LISTE DES PIÈCES
RÉFÉRENCE DESCRIPTION ILLUSTRATION QUANTITÉ
1 Patte de table 2
2 Barre de soutien 2
3 Barre de soutien 2
4 Dessus de table 1

ENSEMBLE À DÎNER PLIANT DE 5 PIÈCES SHERBROOKE—TABLE 5
VUE ÉCLATÉE
1
2x
2
2x
3
2x
4
