Canvas 088-1760-6 User manual

DASHLEY COLLECTION
GAZEBO
MODEL NO. 088-1760-6
ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.

IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8
MADE IN CHINA

3
TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONS
Caution! Always keep children under close supervision while they are playing
around this product. Never leave children unattended. Keep pets away while
setting up the gazebo.
Caution! Check municipal by-laws prior to installing the gazebo.
Table of contents 3
Important safety instructions 3
Parts list 4
General requirements 7
Assembly 8
Cleaning and maintenance 28
Specifications 28
Warranty 29
IMPORTANT: Retain for future reference, and read carefully.
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and using the gazebo.
• This product is intended for domestic outdoor use only.
• The product should be placed and assembled on flat, horizontal ground.
• Consult with your local governing authority/local municipal codes regarding installation of temporary
structures before assembly.
• Ensure there is enough clearance around the product. Before assembling the gazebo, make sure to leave
a distance of not less than 6’ (1.8 m) from any structures or obstructions, such as fences, garages, houses,
overhanging branches, laundry lines, or electrical wires.
• Anchor the gazebo to the ground with stakes for added safety. Stakes are provided to secure the gazebo
to the ground. If you wish to secure the gazebo to a concrete or wood surface, use anchors suited for these
surfaces (anchors not included). Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do
not have enough anchorage in these types of soil.
• If more than one gazebo is set up, keep a minimum distance of 10' (3 m) between the gazebos.
• Any assembly or maintenance of the product must be carried out by adults only.
• Make sure there is sucient manpower when assembling or moving the product.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• Check all nuts and bolts periodically for tightness. When required, tighten them.
• Repairing and replacing parts should be done by a qualified technician.
• This gazebo is intended for decorative and sunshade purposes only.
• The gazebo is not designed to withstand harsh weather, including high winds, rain and snow. Always remove
the gazebo in such heavy weather conditions, otherwise it might tip over and cause damage to the product
or injuries to bystanders.
• During snow days, remove the snow at the top when the snow is thicker than 4" (10 cm).
• After a period of time, usually in 2–3 months, tighten all the bolts.
• After a period of use, rinse the ash on top of the gazebo using water. Avoid using acid or alkali wash lotion.
• Do not hang any weights on the roof frame.
• Do not climb onto the roof of the gazebo. Falling o the gazebo can result in serious injury.
• After a few years, if the paint peels o, use paint of similar colour. It is recommended to use outdoor paint.
• Retain the original packaging to store the gazebo.
• If the product will not be used for a long period of time (e.g. winter time), it should be disassembled and
stored in a clean, dry environment.

4 5
PRODUCT NO. 088-1760-6
PARTS LIST
Post - 4
Base - 4
Small roof top beam (long side) - 2
Frame for short side under big roof - 2
Base cover - 4
Small roof top beam (short side) - 2
Beam for long side - 2
Big roof top short beam (short side) 1 - 2
Beam for short side - 2
Decorative groove for long side - 2
Decorative groove for short side - 2
Decorative groove for corner - 4
Slanting bar for large roof - 4
Slanting bar for small roof - 4
Middle bar for large roof - 4
Lower beam connector 1 - 4
Lower beam connector 2 - 4
Lower middle beam connector - 4
Frame for long side under big roof - 2
A
B
K1
C
D1
E1
L1
D2
K2
E2
E3
F1
F2
G
H1
H2
I
J1
Big roof top short beam (short side) 2 - 2
Big roof top long beam (long side) 1 - 2
Big roof top long beam (short side) 1 - 2
Big roof top long beam (long side) 2 - 2
Big roof top long beam (short side) 2 - 2
Small top roof cover - 1
Big roof top short beam (long side) 1 - 2
Small top cover for slanting bar - 4
Big roof top short beam (long side) 2 - 2
L2
M3
L3
M4
L4
N1
M1
N2
M2
J2

4 5
PRODUCT NO. 088-1760-6
PARTS LIST
Hook - 1
Small roof cover (long side) - 2
Big top roof right middle panel - 4
Big top roof left middle panel - 4
Small roof cover (short side) - 2
Big top roof left small panel - 4
Big roof left cover - 4
Big top roof right small panel - 4
Big roof right cover - 4
Big roof middle cover - 2
Lower middle beam connector - 4
Cutting sleeve - 4
Bae - 4
Arc support - 8
Small top roof panel (short side) - 2
Small top roof panel (long side) - 2
Big cover (long side) - 2
Big top roof left big panel - 4
Big top roof right big panel 2- 4
P
Q1
X5
Q2
R1
R3
X7
R2
X6
S
T
U
V
W1
W2
X1
X2
X3
Left long pipe - 2
Wall - 1
Right long pipe - 2
Left short pipe - 2
Right short pipe - 2
Mosquito netting - 1
Big top cover for slanting bar - 4
Connector for small top - 1
Y1
Q
Y2
Y3
Y4
R
N3
O
X4

6 7
PRODUCT NO. 088-1760-6
PARTS LIST
M6X55 screw - 28 M6X55 screw - 1
M6 nut - 28 M6 nut - 1
M6X40 screw - 18 M6X40 screw - 1
Ф8X260 stake - 16
Ring - 104
Ring - 20
M6 wrench - 2
FF FF
GG GG
HH HH
II
Z
JJ
JJ
* Cumulative numbers of the hardware
are listed in the manual.
Spare Parts List
M6X15 bolt - 80* M6X15 bolt - 4
M6 washer - 378* M6 washer - 19
M6X15 screw - 160* M6X15 screw - 8
M6X25 screw - 16 M6X25 screw - 2
M6X45 bolt - 64 M6X45 bolt - 2
AA AA
BB BB
CC CC
DD DD
EE EE

6 7
PRODUCT NO. 088-1760-6
GENERAL REQUIREMENTS
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance; we’re here to help.
IMPORTANT: Please read and understand this manual before any assembly. Before beginning
the assembly of product, make sure all parts are available. Compare parts list with packaging
contents. If any part is missing, or if you have any questions, contact the service centre at
1-888-670-6684 (toll-free).
Unpack and place all the parts from the packaging box in an open area and position them on
the floor. Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete. Read each step carefully before beginning any
assembly and make sure you understand each step. If you are missing a part, please call our toll-
free number for assistance: 1-888-670-6684.
Needed for assembly:
Hammer Screwdriver Ladder 5 people
CAUTION!
• Proper placement of the gazebo is essential. Do not place the product
underneath electrical lines.
• Keep children under close supervision while they are playing around this
product. This product contains small parts which can be swallowed by
children.
• Keep fingers away from places where they can be pinched or trapped.
• Do not attempt to assemble the gazebo if any part is missing.
• Do not light any fires inside or near the product!
• Stay calm if fire breaks out. Search for the nearest exit. Do not return to the
gazebo before firemen allow you to do so.

8 9
PRODUCT NO. 088-1760-6
8PRODUCT NO. 088-1760-6
ASS E MBLY
A
C
Step 1
Requires A, B, C, BB, CC
(1a) Insert Post (A) into Base cover (C).
(1b) Attach Base (B) to the bottom of Post (A) using M6x15 screw (CC) and M6
washer (BB). Repeat the same procedure for the other bases.
BB CC
NOTE:
When using screws and nuts to assemble the product, always use a flat washer between
the frame and the screws and/or nuts. This will protect the parts from wear and tear.
BBBB B
C
A
CCCC
A

8 9
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 2
Requires D1, D2, T, BB, CC
Slide the Cutting sleeve (T) into the centre of each Beam for long side (D1) and
each Beam for short side (D2). Attach in the centre aligning the outer holes
using M6x15 screws (CC) and M6 washers (BB).
BB CC
BB
CC
T
D2
CC
BB
T
D1
D1 D2
Step 3
Requires A, D1, D2, BB, EE, Z
Attach Beam for long side (D1) and Beam for short side (D2) to Posts (A) using
M6x45 bolts (EE) and M6 washers (BB). Tighten the bolts using the wrench (Z).
D2
D1
BB
BB
BB
BB
EE
EE
EE
EE
D1 A
A
D2
EE Z
BB

10 11
PRODUCT NO. 088-1760-6
ASS E MBLY
E2
E3
E1
AA
AA
BB
BB
Step 5
Requires E1, E2, E3, AA, BB, Z
Insert Decorative groove for long side (E1) and Decorative groove for short side
(E2) into each Decorative groove for corner (E3) using M6x15 bolts (AA) and M6
washers (BB). Tighten the bolts using the wrench (Z).
Step 4
Requires A, H1, BB, DD
Attach each Lower beam connector 1 (H1) to the top of each Post (A) using
M6x25 screws (DD) and M6 washers (BB).
DD
D2
D1
A
DD
H1
DD DD
BB DD
BB Z
AA

10 11
PRODUCT NO. 088-1760-6
ASS E MBLY
AA
H1
AA
BB
BB
D1 D2
E3
I
D1 D2
AA
BB
Step 6
Requires E3, H1, AA, BB, Z
Align the holes of the assembled Decorative grooves (E3) with the holes of the
Lower beam connector 1s (H1). Attach the Decorative groove (E3) in all four
corners to the Lower beam connector 1s (H1) using M6x15 bolts (AA) and M6
washers (BB). Tighten the bolts using the wrench (Z).
BB
BB
Z
Z
AA
AA
Step 7
Requires D1, D2, I, AA, BB, Z
Attach the Lower middle beam connectors (I) to beams (D1, D2) using M6x15
bolts (AA) and M6 washers (BB). Tighten the bolts using the wrench (Z).

12 13
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 8
Requires A, V, D1, D2, BB, EE
Attach the lower end of Arc supports (V) to Posts (A) and upper end of Arc
supports (V) to beams (D1, D2) using M6x45 bolts (EE) and M6 washers (BB).
Step 9
Requires J1, J2, AA, BB, Z
Attach Frame for short side under big roofs (J2) to Frame for long side under
big roofs (J1) using M6x15 bolts (AA) and M6 washers (BB). Tighten the bolts
using the wrench (Z).
J2
J1
BB
AA
D1 D2
EE
V
A
BB
EE Z
BB
BB Z
AA

12 13
PRODUCT NO. 088-1760-6
ASS E MBLY
J1
H2
AA
BB
J2
BBFF
F2
O
BB
GG
Step 10
Requires H2, J1, J2, AA, BB, Z
Attach Lower beam connector 2s (H2) to Frame for long and small side under
big roofs (J1, J2) using M6x15 bolts (AA) and M6 washers (BB). Tighten the bolts
using the wrench (Z).
BB Z
AA
Step 11
Requires F2, O, BB, FF, GG
Attach one end of each Slanting bar for small roof (F2) to the Connector for small
top (O) using M6x55 screws (FF), M6 washers (BB) and M6 nuts (GG). Note: 2
single ends of the Slanting bar for small roof (F2) are attached to each end of the
Connector for small top (O).
FF GG
BB

14 15
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 12
Requires F2, H2, BB, FF, GG
Attach Slanting bar for small roofs (F2) to lower beam connector 2s (H2) using
M6x55 screws (FF), M6 washers (BB) and M6 nuts (GG).
Step 13
Requires F2, K1, K2, BB, CC
Attach Small roof top beams (K1, K2) to Slanting bar for small tops (F2) using
M6x15 screws (CC) and M6 washers (BB).
BB
CC
K2
F2
K1
BB
CC
BBFF
GG
BB
F2
H2
FF GG
BB
BB CC

14 15
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 15
Requires F1, H1, BB, FF, GG
Attach one end of Slanting bar for large roof (F1) to Lower beam connector 1
(H1) using M6x55 screws (FF), M6 washers (BB) and M6 nuts (GG).
FF BB
BB
F1
H1
GG
P
O
FF GG
BB
Step 14
Requires O, P
Attach Hook (P) to Connector for small top (O).

16 17
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 17
Requires E1, E2, G, S, AA, BB, Z
Place the Lower middle beam connectors (S) into the slot on the Middle bar for
large roofs (G) and Decorative grooves (E1, E2), then attach using M6x15 bolts
(AA) and M6 washers (BB). Tighten the bolts using the wrench (Z).
AA S
G
E1 E2
BB
Step 16
Requires G, I, BB, FF, GG
Attach the lower end of Middle bar of large roofs (G) to Lower middle beam
connectors (I) using M6x55 screws (FF), M6 washers (BB) and M6 nuts (GG).
FF
BB
G
I
BB
GG
FF GG
BB
BB Z
AA

16 17
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 18
Requires F1, G, J1, J2, AA, BB, Z
Place the assembled frame (J1, J2) over the Slanting bar for large roofs (F1),
then attach the upper end of the Slanting bar for large roof (F1) to the corner
of frame (J1, J2) using M6x15 bolts (AA) and M6 washers (BB). Tighten the
bolts using the wrench (Z).
Step 19
Requires G, J1, J2, AA, BB, Z
Attach the upper end of the Middle bar for large roofs (G) to the middle of the
frame (J1, J2) using M6x15 bolts (AA) and M6 washers (BB). Tighten the bolts
using the wrench (Z).
AA
AA BB
G
J1 J2
BB
J1
J2
AA
BB
AA
BB F1
BB
BB
Z
Z
AA
AA

18 19
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 21
Requires F1, L1, L2, L3, L4, M1, M2, M3, M4, BB, CC
Attach other end of each beam (L1, L2, M1, M2) to Slanting bar for large roof
(F1) using M6x15 screws (CC) and M6 washers (BB).
CC
CC
BB
F1
M1 L1
M2 L2
BB
Step 20
Requires G, L1, L2, M1, M2, BB, CC
Attach one end of each beam (L1, L2, M1, M2,) to Middle bar for large roof (G)
using M6x15 screws (CC) and M6 washers (BB).
M1 L1
G
CC BB
BB CC
M2 L2
BB CC
BB CC

18 19
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 23
Requires F1, L3, L4, M3, M4, BB, CC
Attach other end of each beam (L3, L4, M3, M4) to Slanting bar for large roof
(F1) using M6x15 screws (CC) and M6 washers (BB).
CC
CC
BB
F1
M3 L3
M4 L4
BB
Step 22
Requires G, L3, L4, M3, M4, BB, CC
Attach one end of each beam (L3, L4, M3, M4) to Middle bar for large roofs (G)
using M6x15 screws (CC) and M6 washers (BB).
M3 L3
G
CC BB
BB CC
M4 L4
BB CC
BB CC

20 21
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 25
Requires F1, Y1, Y2, Y3, Y4, BB, CC
Attach other end of pipes (Y1, Y2, Y3, Y4) to Slanting bar for large roof (F1)
using M6x15 screws (CC) and M6 washers (BB).
Y1 Y2
BB
CC
F1
Y3 Y4
Step 24
Requires G, Y1, Y2, Y3, Y4, BB, CC
Attach one end of pipes (Y1, Y2, Y3, Y4) to Middle bar for large roof (G) using
M6x15 screws (CC) and M6 washers (BB).
CC
CC
G
BB
BB
Y1 Y3
Y2 Y4
BB
BB
CC
CC
