Canvas 188-1320-6 User manual

ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684 Scan the QR
code for online
assembly
instruction video.
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
HORIZON
PULL-DOWN SHADE
PRODUCT NO. 188-1320-6

To the trend seekers and design mavens,
CANVAS™ is the furniture and décor brand
that helps you imagine and create a space
you can be proud of.
That’s because CANVAS™
made for real life
and Canadian inspired.
at canadiantire.ca to tell us about your
using #myCANVASstyle.
CANVAS™ products

IMPORTANT
LINK
Scan the QR
code for online
assembly
instruction video.
HOW TO USE OUR QR CODES
Follow the steps below to scan our QR codes and access helpful assembly videos.
1
Open the
camera on
your smart
device and
point it at
the QR code.
2
Wait for the
camera to
recognize
and scan
the QR code.
3
Tap the
when it
appears on
screen.
4
The video
will load
automatically.

HORIZON PERGOLA
ACCESSORIES
PRODUCT # 188-1319-2
HORIZON MODULAR PERGOLA
PRIVACY PANEL
PRODUCT # 188-1318-4
HORIZON MODULAR PERGOLA
BAR COUNTER
PRODUCT # 188-1320-6
HORIZON MODULAR PERGOLA
PULL-DOWN SHADE
PRODUCT # 188-1321-4
HORIZON MODULAR PERGOLA
EXPANSION KIT
PRODUCT # 188-0204-2
(SOLD SEPARATELY)
10' X 10' HORIZON
MODULAR PERGOLA
Scan the QR
code for
more details.

HORIZON PULL-DOWN SHADE5
TABLE OF CONTENTS
Caution! Always keep children under close supervision while they are playing
around this product. Never leave children unattended. Keep pets away while
setting up the pull-down shade
Caution! Check municipal by-laws prior to installing the pull-down shade.
• This product is intended for domestic, outdoor use only.
• The product should be placed and assembled on flat, horizontal ground.
• Consult with your local governing authority/local municipal codes regarding installation of
temporary structures before assembly.
• Any assembly or maintenance of the product must be carried out by adults only.
• Make sure there is sufficient manpower when assembling or moving the product.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• Check all nuts and bolts periodically for tightness. When required, tighten them.
• Repairing and replacing parts should be done by a qualified technician.
• After a period of time, usually in 2–3 months, tighten all the bolts.
• Use paint of similar colour for touch-ups. It is recommended to use outdoor paint.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY, READ
THE FOLLOWING SAFETY INFORMATION.
Warnings 5
Required and Recommended Tools 6
Important Safety Information 7
Parts List 9
Hardware List 10
General Preparations 12
Step-by-Step Guide 13
Caring for Your Item 20
Warranty 21
Before You Begin Assembly 11

6
TOOLS REQUIRED
RECOMMENDED TOOLS
4 mm hex bit
Socket wrench with
10 mm socket
Cordless drill or
driver with 4 mm
hex head bit
2
people
Driver bit extension
(4" recommended)
15' (4.6 m) tape
measure
8' (2.4 m) ladder
(Qty. 2 recommended)
HORIZON PULL-DOWN SHADE

7
• Keep children under close supervision while they are playing around this product.
This product contains small parts which can be swallowed by children.
• Keep fingers away from places where they can be pinched or trapped.
• Do not attempt to assemble the pull-down shade if any part is missing.
IMPORTANT: Please read and understand this manual before any assembly.
Before beginning the assembly of product, make sure all parts are available.
Compare parts list with packaging contents. If any part is missing, or if you have
any questions, contact the service centre at 1-888-670-6684 (toll-free). Unpack
and place all the parts from the packaging box in an open area and position them
on the floor. Remove all packing materials and place them back into the box.
Do not dispose of the packing materials until assembly is complete. Read each
step carefully before beginning any assembly and make sure you understand
each step. If you are missing a part, please call our toll-free number for assistance:
1-888-670-6684.
If you have questions regarding your product, require warranty assistance, or
have damaged or missing parts, please call our customer service toll-free helpline.
Contact us for assistance; we’re here to help.
CAUTION!
LET US HELP YOU! DO NOT RETURN YOUR PRODUCT TO THE STORE.
CALL US FIRST! 1-888-670-6684
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ
CAREFULLY.
IMPORTANT SAFETY INFORMATION
HORIZON PULL-DOWN SHADE

8
EXPLODED PARTS VIEW
HORIZON PULL-DOWN SHADE
19
17
18
20
33

PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
17 Roller shade 1
18 Bracket 1 1
19 Bracket 2 1
20
33
Ball clip 3
Crank wand 1
9HORIZON PULL-DOWN SHADE

HARDWARE LIST
HARDWARE PACK
ITEM DESCRIPTION THUMBNAIL QUANTITY
BM6x10 bolt 4
4
1
DT-nut
YHex key
10
HORIZON PULL-DOWN SHADE

BEFORE YOU BEGIN ASSEMBLY
MAKE SURE ALL PARTS ARE PRESENT
?
REMOVE PACKAGING MATERIALS
READ EACH STEP CAREFULLY
ASSEMBLE IN A CLEARED AREA
on a clean,
If you have any questions,
1-888-670-6684 (toll-free)
HORIZON PULL-DOWN SHADE11

STEP-BY-STEP GUIDEGENERAL PREPARATIONS
• Save your cardboard! You can use the box as padding when assembling the pull-down
shade to prevent damage to parts during assembly.
• Lay out all parts before beginning assembly and compare the parts you have to the
parts list in this manual. If parts are missing, please call 1-888-670-6684 to have
replacement parts provided to you.
• Completely read through this assembly manual before beginning assembly so you
can become familiar with the building process.
• To further assist you with building your roller shade, a full assembly video is available
online. We highly recommend viewing the assembly video prior to beginning
• Throughout this manual there are assembly tips that provide best assembly
practices. In many cases these tips also have QR codes that will take you directly to a
video excerpt demonstrating the tip. Instructions on how to use QR codes can be
found on Page 3 of this manual.
Scan the QR
code for online
assembly
instruction video.
assembly. You can watch this video by scanning the QR code at the bottom
of this page.
12
HORIZON PULL-DOWN SHADE

2 mm
NOTE:
Loosely hand tighten bolt and T-nut before
positioning in the channel and fully
tightening.
HORIZON PULL-DOWN SHADE
X1
Leave a gap of
2-3 mm here!!
Loosely install T-nuts Din mounting bracket 1 18.
Install bracket 1 18 on the desired beam as shown below.
STE 1P
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
B X2 18 X1
DX2 YX1
2 7/8" (7.23 cm)
Y
B
B
4
3
18
18
D
D
13

STEP 2
19
19
19
D
B
3
B
4
Y
D
B X2 19 X1
DX2
14
HORIZON PULL-DOWN SHADE
NOTE:
Loosely hand tighten bolt and T-nut before
positioning in the channel and fully
tightening.
2 7/8" (7.23 cm)
Loosely install T-nuts Din mounting bracket 2 19.
Install bracket 2 19 on the same beam as bracket 1 18 was
installed as shown below.
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE

STEP 3
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
17 X1
HORIZON PULL-DOWN SHADE15
17
17
18
18
19
19
Install rollershade 17 by inserting one end onto bracket 1 18 and then
guiding the other end into Bracket 2 19.
There will be an audible click when inserted fully.

20 X2
STE 4P
16
1
1
90°
20
20
HORIZON PULL-DOWN SHADE
NOTE:
Placing the ball in the clip keeps the shade stationary.
Install toggle ball clips 20 onto legs at the desired holding height.
Ball clips 20 should be installed at the same height.
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE

STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
33 X1
HORIZON PULL-DOWN SHADE17
STE 5P
33
Turn crank wand 33 counter-clockwise to raise the shade.

18
STE 6P
33
HORIZON PULL-DOWN SHADE
Turn crank wand 33 clockwise to lower the shade.
STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE

STEP-BY-STEP GUIDESTEP-BY-STEP GUIDE
HORIZON PULL-DOWN SHADE
19
STE 7P
33
33
20
11
11
NOTE:
The crank wand can be stored on the post using the ball
clip.
Install extra toggle ball clip 20 and use a hanging hook provided
with the pergola to provide storage for the crank wand 33.
20 X1

CARING FOR YOUR ITEM
1
2
3
4
This product is intended for domestic, outdoor use only.
Check all nuts and bolts periodically for tightness. When required, tighten
them again.
Do not shake, lean or climb on the product.
5
6
Remove pull-down shade during winter.
Roll up shade when it is windy.
CLEANING:
FRAME: Washwith a mild dish soap and water, rinse with clean water, and allowto air dry.
Do not use harsh chemicals or abrasive cleaners, or any other special detergents as they may be
FABRIC: Forbest results, clean fabric withadamp clothand allowto air dry thoroughly.
Do not machine washordry.
20
HORIZON PULL-DOWN SHADE
