Caple WC6112 Manual

WC6112
Caple 60cm in-column wine cabinet
Technical information

Item Part Code Description Qty
1 DG2-14 Power cord 1
2DG22-476 support bar of tank water 2
3DG13-447 water box 1
DG1-72 Compressor 1
QP2-22 1
BB35-125 DRB-16N61A1 1
5DG3-205 PCB board 1
6DG6-7 Transformer 1
7DG12-91-1 Condenser 1
8DG26-125 Cabinet 1
9DG13-268 Decorative nail 2
10 DG13-473 limiting bar(B) 1
11 DG13-472 limiting bar(A) 1
12 DG14-206 Top hinge module 1
13 DG12-44 Evaporator 1
14 DG7-33-H Evaporator fan 1
15 DG22-480 fixing board for fan 1
16 DG3-207-1-W LED light 1
17 DG13-471 Electrical box 1
18 DG13-470 lid of electrical box 1
19 DG20-260 Display panel 1
DG15-204-1 Wooden shelves 1
DG15-204 Wooden shelves 2
21 DG23-209 door 1
22 M147-003 gasket 1
23 DG22-3109 handle 1
24 DG13-3005 magnet 2
25 DG13-1.2 Humid box 1
26 DG22-472
A
ir duct board 1
DG20-1 wire clamp 2
DG8-22 Sense
r
1
DG8-23 Sense
r
1
28 DG14-207 Lower hinge module 1
29 DG13-3004 reed switch 1
30 DG22-3014 lid of reed switch 1
31 DG13-474 support ba
r
2
32 DG22-479 Electrical box cove
r
1
33 DG22-473 strengthening board 1
4
20
27
WC6112 - Caple 60cm in-column wine cabinet

1
/
23
Computer Controlled Wine Cellar
WC6111 WC6112
Service Manual
Here below we listed various faults while using the wine cellar, and the method of check-up and solve these default,
and find the information of the correspondent page.
Statement: (Fig.4 ) shows the reference figure Fig4
( →6.1.6 ) shows the reference item 6.1.6.
Warning: before attempting any cleaning or maintenance this unit MUST be disconnected from the electrical
supply, to prevent electrical shock
▲Preparation before maintenance
○Tools
1．Pliers 2．Phillips head screwdrivers
3．Process pipe 4．Electrical Multi meter
5．Amp meter (5A) (caliper cable type) 6．Electrical soldering iron
7．Wire strippers 8．Seal pliers
○Equipment
1．Vacuum pump 2．Soldering iron for copper pipes 3.Refrigerant meter
1. Safety rules on operation of repairing.(Rules must be obeyed). — 2
2. Electrical circuit diagram.—————————————————— 4
3. Cooling system diagram. ———————————————————— 5
4. Name and function on control panel. —————————————— 5

2
/
23
5. How to diagnose the fault. ——————————————————— 6
6. Gist on disassembly. ————————————————————— 8
7. How to maintain the default. ————————————————— 14
1. Safety rules on operation of repairing (Rules must be obeyed).
To avoid the accident during maintain the wine cooler, and make sure the product is safety, rules must be
obeyed list below.
○ Below we list the symbols and explain the danger if ignore it.
Danger This symbol means that the instance may have the chance to suffer
death or a serious wound.
Warning This symbol means that the instance may have the chance to suffer
death or a serious wound.’
Notice This symbol means that the instance may have the chance to suffer
a wound.’
○Below symbols’ distinguish and rules should be obeyed.
This symbol means the
instance hope to be noticed
This symbol means the
instance must be done forcibly
This symbol means the
instance forbidden

3
/
23
Danger
·Please make sure to discharge the rest refrigerant in the parts.
·When discharging refrigerant, make sure that it never go to the fire place and drain
to outdoors.
Tell the customers that they never close to the discharge place and the fire is
forbidden.
·Take apart the pipe by cutter.
Never take apart the part by soldering, otherwise it will fire the rest refrigerant in the
systems and cause blast.
·Exhaust the rest refrigerant in the systems before welding.
·After filling the refrigerant the sealing should be done by using smithing welding
nozzle.
Using the welding machine will fire the refrigerant and blast.
·Since the R600a is heavier than the air, please let the R600a on the ground go
especially for the hypogeum.
·The operation on the servicing refrigerant bottle should be done in place without fire
and outdoors.
·Use the refrigerant warner please， as the rest refrigerant will cause the fire.
·Don’t use fire in the place with rest refrigerant.
·Don’t place the default compressor in indoor.

4
/
23
Danger
·During repairing, the power plug should be disconnected.
Before remove, install, replace parts disconnect the power plug.
·Attention don’t get electric shock.
When checking current, voltage or charging never touch the connectors.
When changing the parts, don’t touch the charged parts within three minutes after
disconnect the plug.
The capacitor will discharge for some time.
·Don’t damage the cooling pipe, sine the refrigerant is flammable, the damage will
cause the fire or blast.
·Don’t smoking in the service car.
·Discharge the refrigerant entirely in the place without fire before disusing the
refrigerant bottle.
·Don’t touch the wine cooler when the cooling pipe damaged, don’t fie inside the wine
cooler, keep the windows open to exchange the air.
·Disusing the default compressor should be done outdoor without fire.
·The maximum weight of the refrigerant bottle loaded in the vehicle should be comply
to stated, the bottle should be place upright, the maximum leaning angle is 40°.
·Do use the appointed part, otherwise it have chance to smoke fire or default.
·Please put the default compressor into plastic bag and seal the peristome, then pack
it with strip, as the rest compressor oil may leak in the vehicle and cause fire or blast.
·Check if all the snails, parts, wiring are install in it’s place, if the area around the
service part worsen.
When measuring the grounding resistance make sure that the test range is more than

5
/
23
1MΩ.
Make sure the power cord and plug never be pinched on rear of the wine cooler.
Exchange the power cord when it damaged.
Clean the flake of the plug when it dirty.
Notice
·Attention the hot.
The running or just stop compressor and the pipe sometimes are very hot. And the
heating or just stop heater is very hot. The hot will cause scald.
·Attention the hot parts of the pipe after the welding.
·Attention the refrigerant during charge and discharge it, as it will frostbite the skin
when touch it.
·Attention the burr.
The burr on the metal or plastic part may hurt the hand.
·Attention the fins of the evaporator.
The fins of the evaporator may hurt the hand.
·Drive up the wine cooler when moving it. Pushing it may damage the floor. Cover a
protector board on the easy damage floor.

6
/
23
2. Electrical circuit diagram.
3. Cooling system diagram.

7
/
23
4. Name and function on control panel.
•“ ” Press ‘▲’，the setting temp will raise up in 1.
•
•“ ” Press ‘▼’，the setting temp will lower down in 1.
•
•“”Press one time, the light on, press again, the light off, it is not effect by the door switch. Press it and hold on
for three seconds will enter the time adjustment. Press ‘▲’ adjust the hour, press ’▼’ adjust the minute.
•“”Press it one time, the power on, press it and hold on for three seconds, the power off.
•“Power” Power on/off indication light.
zThe default setting temp of this wine cooler is 12, but when restart the wine cooler after power off, it will
back to the former setting temp before power off.
zAccording to customers’ requirement, this wine cooler can be set to that the readout display actual temp or
setting temp.
a.In the readout display actual temp mode, press the ‘▲’ or ‘▼’, the systems enter the temperature setting
mode and the setting temperature twinkling. Five seconds twinkling after stopping adjust temperature, the
readout stop twinkling and the readout show actual temperature, the temperature setting mode end.

8
/
23
b. In the readout display setting temp mode, press the ‘▲’ or ‘▼’, the systems enter the temperature setting
mode and the setting temperature twinkling. Five seconds twinkling after stopping adjust temperature,
the readout stop twinkling and the readout show setting temperature, the temperature setting mode end.
5. How to diagnose the fault.
5.1 Fault finding by the self-check mode.
The wine cooler is controlled by computer, in order to maintain the wine cooler easily, there is a self-check
function in the control PCB.
If you suspect that the control system fault, you can star the self-check mode by following below:
1 >．Power on the wine cooler, it will beep one sound, the wine cooler star, within 10 seconds after it star, press
the ‘▲’and‘▼’at the same time and holding, three beep will sound, the systems enter self-check mode.
The power indication light is on.
The readout show the actual temp.
The inner fan running.
No response when press the controlled buttons.
2>．If all items tally with above description, the parts are normal. If any part fail, check the failed part and the
corresponding wiring and connection, if the wiring and connection is in good condition, replace the part and
check again, if it still failed, the default should be the control PCB, replace it with same model. ( →6.2.1)( →
6.2.2)
3 >．The self-check can be quit only disconnect the power plug.
5.2 Err code
Code Representation Checking point Solution
E1 Inner sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it open circuit.
If the connection and wiring is
normal, replace the sensor
please.
E2 Inner sensor short
circuit.
Check the wiring and connection between PCB and
sensor, if it short circuit.
If the connection and wiring is
normal, replace the sensor
E3 Anti-frost sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it open circuit.
If the connection and wiring is
normal, replace the sensor
E4 Anti-frost sensor open
circuit.
Check the wiring and connection between PCB and
sensor, if it short circuit.
If the connection and wiring is
normal, replace the sensor
HI Inner temperature too a Check if any refrigerant leakage. Repair the leakage and refill.

9
/
23
b Check it the capillary jam Clean or replace the capillary.high
c Check it the inner fan run normally Repair the wiring or replace the
fan.
a Check it the inner fan run normally Repair the wiring or replace the
fan.
LO Inner temperature too
low b Check it the PCB normal. Replace the PCB.
High temperature warning—After turning on the wine cooler ten hours, if the inner temperature is over 23ºC, the readout show HI,
after it showing for one hour, the readout twinkling and the buzzer alarm, and twenty minutes later, the buzzer
stop, the compressor stop, the readout keep twinkling. The HI alarm can be stopped by disconnect the power
plug.
Low temperature warning—After turning on the wine cooler two hours, if the inner temperature is lower than 0 ºC and lasting for 15
minutes, the readout show LO, the buzzer alarm, and the compressor stop at the same time, when the inner
temperature is over 2ºC, the LO warning stop.
*Remark: some models without the HI and LO warning function.
5.3 Diagnose the default
●There isn’t any display on the display PCB.
●Not cooling (the compressor stop)
Yes
Yes
If the inner light can be turn on
（
Check the power
）
Check the power source (power cord,
plug, socket)
If the display have power input Check the PCB circuit
Display PCB failed
No
No

10
/
23
●Not cooling (the compressor running)
No
Yes
No
Yes
No
No
Yes
The compressor run for more than 30 minutes？
If the door opened frequently
？
Don’t open the door frequently.
If the hot goods was put into the cabinet
？
If the door gasket airproof?
Cooling system default.
It can be loaded with normal temperature
wine bottle
Repair or replace the gasket.
No
Yes
Abnormality
No
No
Yes
Yes
Yes
No
If the inner light can be turn on Check the power source (power cord,
Display err code Refer to 5.2
The starter have power input?
The protector have power input?
Check the current of the compressor
The starter failed
The protector failed
Compressor fault.

11
/
23
6. Gist on disassembly.
Warning: Disconnect the power plug before maintain the wine cooler.
6.1 Gist on disassembling the inner cabinet.
6.1.1. How to remove the shelves.
Push the shelf to the end, and revolve the shelf on either side, make the stopper on the out of the
guiding rail, then pull the shelf out(Fig.1).
6.1.2. How to remove the air-duct board
The process of removing the air-duct board: Remove all shelves → Remove the air-duct board
1> Remove the shelves, remove the screws fixing the air-duct board, remove the air-duct board,
you can see the inner air-duct board. (Fig.2& Fig.2.1)
2>.Remove the screws fixing inner air-duct board, disconnect the connecter of the fan, and
remove the inner air-duct board, we can see the welding points around the evaporator. (Fig.3 )
Diagram show evaporator room.
Fig.2
Screws
fixing
the air-duct
board
Fig.1
Shelves
Air-duct
board
Inner air-duct
board
Screws fixing
the inner air-duct
board
Fig.2.1
Anti-frost
sensor
Inner sensor

12
/
23
A: Capillary joint B: Evaporator joint C: Fan connector D: Evaporator
6.1.3． How to remove the evaporator
The process of removing the evaporator: remove all shelves→ remove the air-duct board
→ remove the inner air-duct board→ separate the evaporator from the compressor and
dry filter on the joints.
You can see the evaporator is joint to suction pipe and capillary. （Fig.3 ）Heat the joint C,E
（Fig.12 ） in the compressor room, and disconnect the pipe from compressor by using
the plier. Then remove the evaporator and capillary and suction pipe.
6.1.4. How to remove the inner fan.
The process of remove the inner fan: remove all shelves→ remove the air-duct board →
remove the inner air-duct board→ disconnect the fan connector→ remove the fan
Remove the inner fan fixing screws, remove the inner fan（Fig.4）
Fig.3
A
B
C
D

13
/
23
6.1.5. How to remove the electrical box
The process of removing the electrical box: Remove all shelves → loose the fixing screws
→ disconnect the connectors → remove the controlled box
Remove the shelves (Fig.1); loose the fixing screws and the box loose, disconnect the
connectors, then remove the electrical box.
6.1.6. How to remove the display board
The process of removing the controlled box: Remove all shelves → loose the fixing screws
→ disconnect the connectors → remove the controlled box → remove the display PCB
Fig.4
Screws
Inner
air-duct
board
Inner fan
Screws fixing
inner fan
Fig.5

14
/
23
1>. Disconnect all connectors, remove the controlled box, prize the clasp to take the front
cover with display PCB by using the slotted screwdriver. (Fig.6)
2>．Remove four screws fixing display PCB, take away the display PCB. ( Fig.7)
6.1.7．How to remove the LED light
The process of removing the LED light: Remove all shelves → loose the fixing screws →
disconnect the connectors → remove the controlled box → remove the LED light
Remove the electrical box, then remove the screws fixing LED light, remove the LED light.(Fig.6
& Fig.7 )
Screws
Fig.6 Fig.7
Slotted
screwdrive
Controlled
box
front cover LED light Screws

15
/
23
6.2 Gist on disassembly outside the cabinet.
6.2.1．How to remove the power box and transformer.
The process of removing power box: Remove the screws fixing power box → remove the power
box.
The process of removing transformer: Remove the screws fixing power box → remove the power
box → remove the transformer.
①．Remove the screws 1, 2 fixing power box.( Fig.8)
②．Remove the power box.( Fig.9)
③．Remove the screws fixing transformer. ( Fig.9)
6.2.2．How to remove the power PCB.
Screws
Barb
Power
box
Main
PCB
Transformer
Screws
Fig.8 Fig.9

16
/
23
The process of removing the power PCB: Remove the power box → disconnect the
connectors → remove the power PCB.
Disconnect all connectors, then press the barb one by one pull the PCB upward, remove the
power PCB.(Notice:It is better to press the barbs by using the cuspate plier). ( Fig.10)
Diagram of main PCB connection ( Fig.11)
1. Anti-frost sensor (red) 2. Inner sensor (white) 3. Door switch 4. Compressor
5.Power-N 6.Transformerprimary-N 7.Transformersecondary
8. Transformer primary - L 9. Power - L 10. Display 11. Inner fan (yellow)
12. LED light
Fig.11
Fig.10
Main
PCB
Barb
