Car-Interface CI-RL3-LR17 User manual

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
r.LiNK Video inserter
CI-RL3-LR17
Compatible with
Land Rover and Jaguar vehicles
with Incontrol Touch Pro Duo infotainment
and 10.2 inch monitor
Video-inserter for one rear-view camera
and two additional video inputs
Product features
Video-inserter for factory-infotainment systems
1 CVBS Input for rear-view camera
2 CVBS Video-inputs for after-market Video sources (e.g. USB-Player, DVB-T2
Tuner)
Automatic switching to rear-view camera input on engagement of the reverse gear
Activatable parking guide lines for rear-view camera (not available for all vehicles)
Video-in-motion (ONLY for connected video-sources)
Video-inputs NTSC compatible

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page2
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Checking the compatibility of vehicle and accessories
1.3. Boxes and connectors –video interface
1.4. Settings of the 8 Dip switches (black)
1.4.1. Enabling the interface’s video inputs (dip 2-3)
1.4.2. Rear-view camera setting (dip 5)
1.4.3. Monitor selection (Dip 6-8)
1.5. Settings of the 4 Dip switches (CAN function –red)
2. Installation
2.1. Place of installation
2.2. Monitor removal –example Land Rover
2.3. Connection schema
2.4. Connection - factory head unit
2.5. Analog power supply for the video interface
2.6. Connection - video-sources
2.6.1. Audio insertion
2.6.2. After-market rear-view camera
2.6.2.1. Case 1: Interface receives the reverse gear signal
2.6.2.2. Case 2Interface does not receive the reverse gear signal
2.7. Connection - video-interface and external keypad
2.8. Picture settings
3. Interface operation
3.1. By factory touch screen
3.2. By keypad
4. Specifications
5. FAQ –Trouble Shooting-Interface functions

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. Apart from using this
product in an unmoved vehicle, it should only be used to display fixed menus or rear-view-
camera video when the vehicle is moving (for example the MP3 menu for DVD upgrades).
Changes/updates of the vehicle’s software can cause malfunctions of the interface. Up to
one year after purchase we offer free software-updates for our interfaces. To receive a free
update, the interface has to be sent in at own cost. Wages for de-and reinstallation and
other expenditures involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
video interface’s place of installation must be free of moisture and away from heat sources.
Before the final installation in the vehicle of the video sources, we recommend a test-run
to ensure the compatibility of vehicle and interface. Due to changes in the production of
the vehicle manufacturer there’s always a possibility of incompatibility.
1.1. Delivery contents
Take down the serial number of the interface and store this manual for support
purposes: ____________________

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page4
Requirements
Brand
Compatible vehicles
Compatible systems
Land Rover
Range Rover since model year 2018
Range Rover Sport since model year 2018
Range Rover Velar since model year 2017
Range Rover Evoque since 04/2019
Discovery 5
and other vehicles with ICT Pro Duo
Incontrol Touch Pro Duo
with 10.2 inch 24:9 monitor (glossy)
and climate control panel via 2nd
touch monitor
XE since model year 2019
I-Pace since model year 2019
and other vehicles with ICT Pro Duo
Limitations
Video only The interface inserts ONLY video signals into the infotainment. For
inserting Audio signals either the possibly existing factory audio-AUX-
input or a FM-modulator can be used. If 2 audio sources shall be
connected to the infotainment, an additional electronic is necessary to
switch them.
Factory rear-view camera Automatically switching-back from inserted video to factory rear-view
camera is only possible while the reverse gear is engaged. To delay the
switch-back an additional electronic part is required.
Guidelines The display of the guidelines does not work in all vehicles.
Video input signal only NTSC compatible
1.2. Checking the compatibility of vehicle and accessories
Jaguar

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page5
1.3. Boxes and connectors –video interface
The video-interface converts the video signals of connected after-market sources in a factory
monitor compatible picture signal which is inserted in the factory monitor, by using separate
trigger options. Further it reads the vehicle’s digital signals out of the vehicle’s CAN-bus and
converts them for the video interface.
1.4. Settings of the 8 Dip switches (black)
Some settings have to be selected by the dip-switches on the
video interface. Dip position down is ON and position up is OFF.
See the following chapters for detailed information.
Dip
Function
ON (down)
OFF (up)
1
No function
set to OFF
2
CVBS Video 1-input
enabled
disabled
3
CVBS Video 2-input
enabled
disabled
4
No function
set to OFF
5
Rear-view cam type
after-market
factory or none
6
Guide lines
enabled
disabled
7
No function
set to OFF
8
No function
set to OFF

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page6
1.4.1.1. Enabling the interface’s video inputs (dip 2-3)
Only by dip switches enabled video inputs can be accessed by switching through the
interface’s video sources. It is recommended to enable only the required inputs. Disabled
inputs will be skipped while switching through the video interfaces inputs.
1.4.1.2. Rear-view camera setting (dip 5)
If set to OFF, the interface switches to factory picture while the reverse gear is engaged to
display factory rear-view camera or factory optical park system picture.
If set to ON, the interface switches to its rear-view camera input while the reverse gear is
engaged.
1.4.1.3. Enabling the Guide lines (dip 6)
If set to ON, the interface is activated to show the guide lines for the rear-view camera while
the vehicle is in reverse mode (not available for all vehicles).
Note: Some vehicles have a different code on the CAN-bus which the video-interface is not
compatible with. If the interface does not completely communicate with the vehicle CAN
bus, the reverse gear guide-lines can`t be shown during the vehicle’s operation, even if they
in some vehicles once appear after having switched the system to powerless!
Note: Dip 1, 4,7 und 8 are out of function and have to be set to OFF!
After each Dip-switch-change a power-reset of the video interface has to be performed!

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page7
1.5. Settings of the 4 Dip switches (CAN functions –red)
All 4 dip-switches of the video interface have no function for normal use
and have to be set to OFF.
Dip position “down”is ON and position up is OFF.
Navigation / system
Dip 1
Dip 2
Dip 3
Dip 4
Range Rover,
Range Rover Sport,
Discovery 5,
Range Rover Velar,
New Jaguar XE
ON
OFF
OFF
OFF
Jaguar XF protocol
OFF
ON
OFF
OFF
Jaguar XE 2016 protocol
OFF
OFF
OFF
OFF
If the CAN communication doesn’t succeed with the mentioned CAN positions, the other
CAN protocol can also be tried.
After each Dip-switch-change a power-reset of the video interface has to be performed!
2. Installation
To install the interface, first switch off the ignition and disconnect the vehicle’s battery.
Please read the owner`s manual of the car, regarding the battery`s disconnection! If
required, enable the car`s Sleep-mode (hibernation mode)
In case the sleep-mode does not succeed, the disconnection of the battery can be done
with a resistor lead.
If the necessary stabilized power supply for the interface is not taken directly from the
battery, the chosen connection has to be checked for being constantly stabile.
The interface needs a permanent 12V source!
2.1. Place of installation
The video interface is supposed to be installed at a suitable location behind the factory
monitor.

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page8
2.2. Moitor removal –example Land Rover

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page9

Version 29.01.2020 HW:CAM(V98)/(V31) CI-RL3-LR17
Page10
2.3. Connection schema
