Caraudio-Systems v.LOGiC Intelligent Solution V5-NTG46 User manual

Version 18.11.2016 V5-NTG46
v.LOGiC Intelligent Solution
Interface
V5-NTG46
compatible with Mercedes Benz vehicles with
COMAND Online NTG4.5 navigation and Audio20
NTG45 system with 4pin HSD LVDS connector

Version 18.11.2016 V5-NTG46
Page1
Product features
Interactive lane lines
Control by factory infotainment
Own on-screen display and setup
2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC,
rear-view camera, reverse gear)
Rear-view camera input
Front camera input
Automatic switching to rear-view camera input on engagement of reverse gear from
all operation modes
Manual switching to rear-view camera
Manual return from rear-view and front camera (cancellation of automatic switching)
Compatible with all factory video accessories (e.g. rear-view camera, DVD-changer,
TV-tuner)
USB update-port for software-updates by consumer

Version 18.11.2016 V5-NTG46
Page2
Contents
1. Prior to Installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Setting the dip switches of the interface-box V5C-M613
1.4. LED’s of the interface-box V5C-M613
2. Connection schema
3. Installation
3.1. Connecting interface-box and harnesses
3.2. LVDS connection
3.2.1. After-market front camera
3.2.1.1. Connection to the after-market front camera
3.2.1.2. Settings for connecting an after-market front camera
3.2.2. Rear-view camera
3.2.2.1. Connection to the after-market rear-view camera
3.2.2.2. Settings for connecting an after-market rear-view camera
3.2.2.3. Settings for OEM rear-view camera
3.2.3. Configurable trigger outputs
3.3. Interactive lane lines
3.4. Picture settings
4. Operation
4.1. OSD –On-screen display
4.1.1. OSD –Operation
4.1.2. OSD –Additional setting options
4.2. Selecting the interface as current video source
5. Specifications
6. Connections (interface-box)
7. Technical support

Version 18.11.2016 V5-NTG46
Page3
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.
Interface-box
V5C-M613
HW_____ SW_____
LVDS cable
CAB-HSD-DD075-O
V5C-UNI01
harness
LVDS cable
CAB-HSD-MR-060-OZ

Version 18.11.2016 V5-NTG46
Page4
1.2. Check compatibility of vehicle and accessories
1.3. Setting the dip switches of the interface-box V5C-M613
Dip 1 on the back of the interface-box V5C-M613 is used to set the monitor type.
Device
Dip 1
COMAND Online NTG4.5
ON
Audio20 NTG4.5
OFF
After each change of the dip switch settings you have to execute a power reset of the
interface interface-box!
1.4. LED‘s of the interface-box V5C-M613
Requirements
Vehicle Mercedes Benz with 6”/ 7“ monitor and 4pin HSD LVDS connector
Device COMAND Online NTG4.5, Audio20 NTG4.5
Validinput source
CAN ok
Power

Version 18.11.2016 V5-NTG46
Page5
2. Connection schema
Rear-view camera
Interface-box
V5C-M613
REAR
LVDS cable
CAB-HSD-DD075-O
Back of
head unit
4-Pin HSD
LVDS female
vehicle harness
LVDS cable
CAB-HSD-MR-060-OZ
Interface-box
V5C-M613
FRONT
Quadlock female
vehicle harness
Front camera
Ground
+12V
+12V switching
outputs
Rear gear signal
input (+12V)
V5C-UNI01
harness
CAN (2)
CAN (1)

Version 18.11.2016 V5-NTG46
Page6
3. Installation
Switch off ignition and disconnect the vehicle’s battery! The interface needs a permanent
12V source. If according to factory rules disconnecting the battery is to be avoided, it is
usually sufficient to put the vehicle is sleep-mode. In case the sleep-mode does not show
success, disconnect the battery with a resistor lead.
If power source is not taken directly from the battery, the connection has to be checked
for being start-up proven and permanent.
Prior to wire and device installation we suggest to connect and test correct function of all
after-market and factory infotainment equipment!
The interface is installed on the backside of the head unit.
3.1. Connecting interface-box and harnesses
CAN-LOW (2)
Interface-box
V5C-M613
FRONT
Quadlock female
vehicle harness
Ground
+12V
CAN-HI (2)
V5C-UNI01
harness
CAN-HI (1)
CAN-LOW (1)
Back of
head unit
1
2
3
4
Cut off the 8 pin Molex connector from V5C-UNI01
harness (is not needed).

Version 18.11.2016 V5-NTG46
Page7
Cut the CAN bus wires of the vehicle harness and connect them in series according to
the assignment (see below) with the CAN bus wires from the V5C-UNI01 harness.
Connect red wire with +12V (pin 15) and black wire with ground (pin 12).
Connect female 12pin AMP connector of the harness V5C-UNI01 to the
front site of the V5C-M613 interface box.
Connect the female Quadlock connector of the vehicle harness on the rear side of the
head unit.
Pin assignment:
Cable colour
Assignment
●Red
+12V permanent input - Pin15
●Black
Ground - Pin 12
●●Yellow/Black
CAN HIGH Pin 11 - to the vehicle side
●●Blue/Black
CAN LOW Pin 9 - to the vehicle side
● Yellow
CAN HIGH Pin 11 - to the head-unit side
●Blue
CAN LOW Pin 9 - to the head-unit side
●Green
+12V power output
●Pink
+12V power output
●White
Rear gear signal input (+12V)
1
2
3
Quadlock
4

Version 18.11.2016 V5-NTG46
Page8
3.2. LVDS connection
Connect the female 4pin HSD LVDS connector of the LVDS cable CAB-HSD-DD075-O
to the male 4pin HSD LVDS connector (LVDS-IN) on the rear of the
interface-box V5C-M613.
Remove the grey female 4pin HSD LVDS connector of the vehicle harness at the back
of the head unit and connect it to the male 4pin HSD LVDS of the
CAB-HSD-MR-060-OZ LVDS cable.
Connect the female 4pin HSD LVDS connector of the LVDS cable CAB-HSD-MR-060-OZ
to the male 4pin HSD LVDS connector (LVDS-OUT) on the rear of the
interface-box V5C-M613.
Connect the female 4pin HSD LVDS connector of the LVDS cable CAB-HSD-DD075-O
to the grey male 4pin HSD LVDS connector on the rear of the head unit.
1
2
3
4
Interface-box
V5C-M613
REAR
LVDS cable
CAB-HSD-DD075-O
Back of
head unit
4-Pin HSD
LVDS female
vehicle harness
LVDS cable
CAB-HSD-MR-060-OZ
13
2
4

Version 18.11.2016 V5-NTG46
Page9
3.2.1. After-market front camera
3.2.1.1. Connection to the after-market front camera
Connect the video RCA of the after-market front camera to the female RCA connector
“FRONT CAM” of the interface box V5C-M613.
-The pink wire of harness V5C-UNI01 can be used
for +12V electric power supply (max. 1A) of the
after-market front camera. Configure in the OSD-
menu “OPTION”, menu item “POWER OUT 2” the
designated electric power supply (see chapter
“Configurable switching outputs”).
-
Interface-box
V5C-M613
FRONT
Front camera
+12V camera
power
V5C-UNI01
harness
Power Out 1 (max. 1A)
1
2
1
2

Version 18.11.2016 V5-NTG46
Page10
3.2.1.2. Settings for connecting an after-market front camera
You have to configure some settings in the OSD-menus INPUTS and MISC if you want to
connect an after-market front camera (Operation of the OSD: see chapter “OSD-Operation”).
OSD-menu
Menu item
Setting
Explication
INPUT
FVC
OFF
Keine Frontkamera angeschlossen
ON
Switches to front camera if parking process is
enabled and reverse gear is released
OPTION
PARK LOGIC
RGearOnly
Enabled while parking process
RGearSpeed
Enabled while parking process and up to
30 km/h
RGearTime
Enabled while parking process and up to
20 second
Note: You can deactivate the enabled parking process by pressing the “right arrow” button
on steering wheel. After deactivation you can’t enable the parking process again until the
vehicle is diving faster than 30km/h or the ignition is switched off.

Version 18.11.2016 V5-NTG46
Page11
3.2.2. After-market rear-view camera
3.2.2.1. Connection to the after-market rear-view camera
Connect the video RCA of the after-market rear-view camera to the female RCA
connector “REAR CAM” of the interface box V5C-M613.
-The green wire of harness V5C-UNI01 can be used
for +12V electric power supply (max. 1A) of the
after-market rear-view camera. Configure in the
OSD-menu “OPTION”, menu item “POWER OUT 2”
the designated electric power supply (see chapter
“Configurable switching outputs”).
1
2
Interface-box
V5C-M613
FRONT
+12Vcamera
power
V5C-UNI01
harness
PowerOut2(max.1A)
1
2
Rear-viewcamera
Rear gear signal
input (+12V)

Version 18.11.2016 V5-NTG46
Page12
3.2.2.2. Settings for connecting an after-market rear-view camera
You have to configure some settings in the OSD-menus INPUT and OPTION if you want to
connect an after-market rear-view camera (Operation of the OSD: see chapter “OSD-
Operation”).
OSD-menu
Menu item
Setting
Explication
INPUT
RVC
OFF
No rear-view camera connected
ON
Switches to rear-view camera if reverse gear
is engaged and/or PDC-display is displayed
OPTION
PARK LOGIC
RGearOnly
Enabled while parking process
RGearSpeed
Enabled while parking process and up to
30 km/h
RGearTime
Enabled while parking process and up to
20 second
RVC LINES
OFF
Interactive lane lines deactivated
ON
Interactive lane lines activated
Note: You can deactivate the enabled parking process by pressing the “right arrow” button
on steering wheel. After deactivation you can’t enable the parking process again until the
vehicle is diving faster than 30km/h or the ignition is switched off.
3.2.2.3. Settings for OEM rear-view camera
OSD-menu
Menu item
Setting
Explication
INPUT
RVC
OEM
If a factory rear-view camera is existing!
The interface turns off, if reverse gear is
enabled and it displays factory rear-view
camera
OPTION
PARK LOGIC
RGearOnly
Enabled while parking process

Version 18.11.2016 V5-NTG46
Page13
3.2.3. Configurable trigger outputs
You can configure the both +12V trigger outputs separately. The pink wire is POWER
OUT 1 and the green wire is POWER OUT 2.
Note: You can configure the both trigger outputs in the OSD-menu OPTION separately
(Operation of the OSD: see chapter “OSD-Operation”).
OSD-menu
Menu item
Setting
Explication
OPTION
POWER OUT1
(pink)
POWER OUT2
(green)
CAN
+12V when the interface is on (red LED on)
ACC
+12V when ignition is on
CAM
+12V when the rear-view camera input is
activated
RGEAR
+12V when reverse gear is engaged
AVS
+12V when interface video-source is active
OFF
Trigger output deactivated
1
Interface-box
V5C-M613
FRONT
+12V switching
outputs
V5C-UNI01
harness
Power Out 1 (max. 1A)
Power Out 2 (max. 1A)
1

Version 18.11.2016 V5-NTG46
Page14
3.3. Interactive lane lines
You have to configure some settings in the OSD-menu
OPTION if you want to activate interactive lane lines
(Operation of the OSD: see chapter “OSD-Operation”).
OSD-menu
Menu item
Setting
Explication
OPTION
RVC LINES
OFF
Interactive lane lines deactivated
ON
Interactive lane lines activated
CAR TYPE
A/B/C/CLA/CLS/
E/G/GLA/GLC/
GLE/GLS/SL/SLC/
V/VITO/
Vehicle type selection
3.4. Picture settings
You can change the picture settings in the OSD-menu IMAGE (activation only from interface
video level possible).
◦ Brightness
◦ Contrast
◦ Saturation
◦ Hue
◦ Sharpness
Note: The picture settings will be retained for each video-source separately.

Version 18.11.2016 V5-NTG46
Page15
4. Operation
4.1. OSD –On-screen display
You can change the basic configurations of the interface in the OSD (on screen display).
4.1.1. OSD –Operation
You can control the OSD by steering wheel buttons. Set the "radio level" in instrument
cluster before you start the OSD control.
Options
Options
Enter
Longpress=enter OSD

Version 18.11.2016 V5-NTG46
Page16
4.1.2. OSD –Additional setting options
The following settings in the OSD-menus OPTION and OSD can be configured over and above
the described settings in this manual (Operation of the OSD: see chapter “OSD-Operation”):
OSD-menu
Menu item
Setting
Explication
OSD
POS. X
0-xxx
Horizontal position of the OSD
POS. Y
0-xxx
Vertical position of the OSD
SIZE
SMALL
Small OSD menu windows
LARGE
Large OSD menu windows
OSD TIMEOUT
2-20
Time setting for automatic OSD shutoff
INFO
VERSION
X.XX.XX
Displays the current SW-version
OPTION
FACTORY RESET
Resetting to factory settings
4.2. Selecting the interface as current AV-source
Press long “left arrow” button to choose the interface as current video source.
Short press ”hang-up” button switch the video sources (cameras). Each short press will
switch to the next enabled input. If all inputs are enabled the order is:
FRONT CAM  REAR CAM  …
Inputs which are not enabled are skipped.
Longpress=enter /leave interface level Shortpress=switch video sources

Version 18.11.2016 V5-NTG46
Page17
5. Specifications
Operation voltage 10.5 –14.8V DC
Stand-by power drain <0,1mA
Operation power drain 190mA
Power consumption 2,6W
Temperature range -20°C to +80°C
Weight (box only) 285g
Measurements (box only) B x H x T 141 x 30 x 105 mm
6. Connections (interface-box)
7. Technical Support
Caraudio-Systems Vertriebs GmbH
manufacturer/distribution
In den Fuchslöchern 3
D-67240 Bobenheim-Roxheim
email [email protected]
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
Interface-box
V5C-M613
REAR
Male 4pin HSD
LVDS connector
Male 12pin AMP
connector
Rear-view
camera input
Female
update-connector
Mini USB
Interface-box
V5C-M613
FRONT
Male 4pin HSD
LVDS connector
Front camera
input
