Caraudio-Systems c.LOGiC CI-C2-E65-TV User manual

Version 20.09.2017 CI-C2-E65-TV
c.LOGiC-Interface
CI-C2-E65-TV
Compatible with BMW E65 Professional
navigation systems
with old iDrive (E65) and menu button,
without factory rear-seat entertainment
Vehicles with factory TV-tuner port
(Factory TV-tuner must be uninstalled)
Product features
• Full plug and play multimedia interface
• 2 AV-inputs with separate IR-control channels
• control of after-market devices, e.g. DVB-T tuner, DVD-player, DVD-changer, …
• after-market rear-view camera input
• automatic switching to after-market rear-view camera input (only from interface mode)
• rear-view camera power (+12V max 1A)
• Rear-seat-entertainment video-output for Video-sources connected to the c.LOGiC
• power-on remote-out trigger-signal (+12V max 1A) to switch on connected devices
• video-in-motion

Version 20.09.2017 Ci-C2-E65-TV
Page1
Contents
1. Prior to Installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Setting the dip switches of the CAN-box TV-436
1.4. Setting the dip switches of the MOST®-box C2C-M336
1.4.1. Automatic switching to rear-view camera
1.4.2. Deactivating c.LOGiC AV2-input
2. Installation
2.1. Installation of CAN-box TV-436
2.2. Installation of MOST®-box C2C-M336
2.3. Connecting peripheral devices
2.3.1. AV-source(s)
2.3.2. Installing AV-source’s IR-sensor additionally
2.3.3. After-market rear-view camera and rear-seat-entertainment
2.3.4. Factory nightvision, factory DVD-changer, factory rear-view camera
3. Operation
3.1. Activation of the video-in-motion function
3.2. Selecting the c.LOGiC as current AV-source
3.3. Assigning device controls
3.4. Switching to AV1, AV2 or after-market rear-view camera
3.5. Button assignment table iDrive
4. Specifications
Appendix A –Device control table

Version 20.09.2017 Ci-C2-E65-TV
Page2
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
If remote function for the connected devices shall be used, additional an IR-
Remote cable and Y-adapter are needed, see chapter AV-source(s).
CAN-box
TV-436
HW_____
SW _____
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.
MOST®-box
C2C-M336
HW_____ SW_____
Harness
C2C-BM01
Harness C2C-IR
Harness
TV-BM65

Version 20.09.2017 Ci-C2-E65-TV
Page3
1.2. Check compatibility of vehicle and accessories
1.3. Setting the dip switches of the CAN-box TV-436
1.4. Setting the dip switches of the MOST®-box C2C-M336
The default dip switch settings of the MOST®-box
need to be changed ONLY if a rear-view camera is
or shall be connected or if the AV2 of the c.LOGiC
shall be deactivated. The dip switches are located
inside the MOST®-box . For changes it is necessary
to open the box. Default settings are:
dip1 = ON, dip2 = OFF, dip3 = OFF
Requirements
Vehicle 7series (E65/E66)
Navigation Navigation system Professional E65 with old iDrive and menu
button, without factory rear-seat entertainment
Vehicles with factory TV-tuner port
Limitations
factory-TV-tuner Must NOT be installed. If uninstalled, optical ring must be closed.
factory DVD-changer After-market rear-view camera cannot be connected to
or factory nightvision the c.LOGiC interface.
After-market rear-view cam Only works from c.LOGiC mode, not from OEM.
Alle vehicles dip 1 ON, dip 2 OFF, dip 3 OFF

Version 20.09.2017 Ci-C2-E65-TV
Page4
1.4.1. Automatic switching to rear-view camera
If an after-market rear-view camera shall be connected or a factory
rear-view camera is connected, in order for the c.LOGiC to
automatically switch to its camera input, when reverse is engaged
set dip2 = ON (up).
Note: Automatic switching works only from c.LOGiC mode.
1.4.2. Deactivating c.LOGiC AV2-input
If omly one AV-source shall be connected to the c.LOGiC, we
recommend to disable the AV2-input, to avoid customers switching by
mistake to black/no picture of the AV2-input. In order to disable the
AV2-input of the c.LOGiC,
set dip1 = OFF (down).
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in
sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a
resistor lead.
Complete and correct function of the c.LOGiC is possible only when CAN and MOST® (tuner)
connections are made properly. On vehicles without TV-icon, it will be coded automatically
after installation.
Place of installation is at the rear of the navigation screen and at the rear of the navigation
computer.
Note: The loose white and green cable of harness TV-BM65 are not required and must be
isolated.
dip switches
of MOST®-box

Version 20.09.2017 Ci-C2-E65-TV
Page5
2.1. Installation of CAN-box TV-436
The CAN interface is connected to
the backside of the OEM screen.
Remove 3 TORX screws at the OEM screen.
Remove cover grill (only plugged). Place soft
towel beneath the navigation monitor
to avoid scratches
Flip down the board monitor. NOTE: The OEM
screen gets stuck with its connector at the upper
side of the cockpit. Insert a hard plastic sheet like
a credit card to prevent cockpit from
taking damage.
Remove the black connector at the backside of
the screen as shown below.

Version 20.09.2017 Ci-C2-E65-TV
Page6
Remove 12-pin insert from black vehicle
harness connector.
Insert 12-pin insert into black connector
of the CAN interface harness TV-BM65.
Insert the completed black connector into
CAN interface harness TV-BM65.
Connect 12-pin insert from CAN interface
harness TV-BM65 into black connector from
vehicle harness.
Insert completed connector into the plug on the backside of the navigation monitor.
Connect 8pin Molex connector of TV-BM65 to CAN-box TV-436.
NOTE: Pictures do NOT show the fibre optics connected in car!

Version 20.09.2017 Ci-C2-E65-TV
Page7
2.2. Installation of MOST®-box C2C-M336
The fibre optical interface installation is
made at the navigation computer, which
is located at the left side in the trunk
behind a cover and has to be removed.
The factory TV-tuner must be uninstalled.
Remove the factory optical leads of the factory
TV-tuner port (blue female connector) and connect
it to the black male MOST®-connector enclosed to
harness C2C-BM01. Pay attention to the
directional arrow on the optical lead connectors.
Connect the black male MOST®-connector to the
female MOST®-connector on the rear of the
MOST®-box C2C-M336 (OPTICAL).
Connect the blue male connector of harness
C2C-BM01 to the factory TV-tuner port
(blue female connector).
Picture exemplary

Version 20.09.2017 Ci-C2-E65-TV
Page8
2.3. Connecting peripheral devices
It is possible to connect up to 2 after-market AV-sources, after-market rear-view camera and
rear-seat-entertainment to the c.LOGiC Interface. Also factory nightvision, factory DVD-
changer or factory rear-view camera must be connected to the c.LOGiC Interface.
Before final installation of the peripheral devices, we recommend to test-run the c.LOGiC
functions to detect incompatibility of vehicle, navigation, factory accessories or peripheral
devices as soon as possible.

Version 20.09.2017 Ci-C2-E65-TV
Page9
2.3.1. AV-source(s)
The c.LOGiC interface has the possibility to connect and remotely control by navigation
buttons up to 2 pre-programmed devices. The device list in the device control table shows
the pre-programmed remote channels and the related IR-remote cables STA-xxx which must
be ordered separately for the control of the device.
Using the respective STA-xxx IR-control cable(s), interconnect the blue (yellow)
female 3pin AMP connector of harness C2C-IR and the IR-port of AV-source 1 (AV-
source 2).
Using RCA cable(s), interconnect the female RCA port AV1(AV2) of the MOST®-box
C2C-M336 with the AV-output of the AV-source 1 (AV-source 2).
The pink ACC-output wire (+12V max 1A) of harness C3C-BMW0x can be connected
to the ACC-input wires of the connected device to switch it on. It carries +12V when
the navigation computer is running.

Version 20.09.2017 Ci-C2-E65-TV
Page10
2.3.2. Installing AV-source’s IR-sensor additionally
Additionally to the control via OEM navigation, it is possible to install the original IR-sensor
of a connected device. By using the respective Y-adapter (e.g. STA-Y35MM or STA-RJ12) for
the IR-Port of the connected device, the controls of navigation AND device’s IR-sensor can be
connected and used simultaneously. Installation of the IR-sensor is recommended as the
controls via navigation are limited, and not all functions may be covered.
2.3.3. After-market rear-view camera and rear-seat-entertainment
Using RCA-cables, connect the rear-seat-entertainment to the female RCA-connector
VIDEO OUT of MOST®-box C2C-M336.
Note: As the output is a full output, not shared with the video signal for the
navigation system, splitting the video with an RCA Y-cable might give a good enough
picture for two rear-seat-entertainment monitors. If not, or if connecting more than
two monitors, use a video splitter.
Connect the video RCA of the after-market rear-view camera to thethe female RCA
connector R-CAM IN of MOST®-box C2C-M336. The green wire of harness C2C-
BMW02 can be used as +12V power (max 1A) supply for the rear-view camera.
Note: Automatic switching to the camera-input when reverse gear is
engaged works only in c.LOGiC mode.

Version 20.09.2017 Ci-C2-E65-TV
Page11
2.3.4. Factory nightvision, factory DVD-changer, factory rear-view camera
On vehicles with factory nightvision, factory DVD-changer or factory rear-view camera, pin
out the video-signal and video-signal ground from the white 18pin AMP connector of the
vehicles harness (rear of navigation computer) and connect them by male RCA-connector to
the R-CAM IN of tuner-box.
Navi Video-signal Video-signal ground
E65 Pin 1 (yellow-black) Pin 10 (green)
The factory component will work as before.
3. Operation
3.1. Activation of the video-in-motion function
Tthe video-in-motion function is permanently active without disturbing the navigation
performance.
3.2. Selecting the c.LOGiC as current AV-source
In the vehicle’s main menu, select Infotainment and then TV by iDrive to choose the c.LOGiC
as current AV-source.
3.3. Assigning device controls
After selecting the c.LOGiC as current AV source, push
iDrive knob to open the c.LOGiC control menu. Select
control levels setup “DEV1: RCxx”(“DEV2:RCxx”) and
assign related IR-code for AV1 (AV2) as described in
device control table.
Note: The IR-control channel DEVV1 is preset to RC-Code 41 compatible DVB-T tuners and
DEV2 is preset to RC-Code 09 for the usbLiNK.
If the AV2 is deactivated (see chapter Deactivating c.LOGiC AV2-input), the menu items “USE
DEV2” and “DEV2: RCxx” will not be available.

Version 20.09.2017 Ci-C2-E65-TV
Page12
3.4. Switching to AV1, AV2 or after-market rear-view camera
In the c.LOGiC control menu, choose USE DEV1 to enter AV1, USE DEV2 to enter AV2 (not
available if AV2 is deactivated, see chapter Deactivating c.LOGiC AV2-input) or REAR CAM to
switch to the c.LOGiC after-market rear-view camera-input (even if the automatic switching
to the camera input is disabled, see chapter Automatic switching to rear-view camera).
After selection the menu will close automatically and switch to the selected source. The
iDrive knob, some multi-function-steering wheel buttons (MFSW) and some navigation
buttons (HU) are now available for remote functions (see assignment table for iDrive below).
By pressing the iDrive-MENU-button, the system returns to the factory iDrive functions. By
pressing the iDrive knob again, the c.LOGiC control menu will be re-entered.

Version 20.09.2017 Ci-C2-E65-TV
Page13
3.5. Button assignment table iDrive
The button assignment table shows which functions of the connected devices can be
executed by iDrive. Once an AV-input is activated the iDrive action in the left column will
execute the function described in the corresponding device column. The function description
equals the remote control buttons of the device’s remote control. On the additional device
the writing on the remote control buttons may vary (e.g. AV instead of Source).
iDrive Aktion
Gerät
DVD
DVC
DVB-T
iPod
MENU long
Setup
Setup
Setup
Setup
MENU short
Return to factory
iDrive functions
Return to factory iDrive
functions
Return to factory
iDrive functions
Return to factory iDrive functions
OPTIONS long *2
Audio
Audio
Info
KCE: Light Bulb, Vlink: Subtitle
OPTIONS short *2
Subtitle
Subtitle
Signal strength
KCE: lower vol, Vlink: Display
ENTER long
STOP
STOP
EXIT
-
ENTER short
Power
Power
Power
Power
NORTH long
OK
OK
OK
OK
NORTH short
Menu / PBC *1
Menu / PBC *1
EPG
Shuffle
WEST long
hoch
up
up
Previous chapter
WEST short
Play/Resume
Play/Resume
Exit
Play/Resume
SOUTH long
left
left
left
left
SOUTH short
Source
Source
AV
Source
EAST long
down
down
down
Next chapter
EAST short
Zoom
Next DVD or DVD selection
menu
Channel scan
KCE: increase vol, Vlink: ESC
Left turn
right
right
right
right
Right turn
Next chapter
Next chapter
Next channel
Up
MENU long
Previous chapter
Previous chapter
Previous channel
Down
DOWN short on
MFSW *3
Previous chapter
Previous chapter
Previous channel
Previous chapter
UP short on MFSW *3
Next chapter
Next chapter
Next channel
Next chapter
RIGHT short on HU *3
Previous chapter
Previous chapter
Previous channel
Previous chapter
LEFT short on HU *3
Next chapter
Next chapter
Next channel
Next chapter
*1 DVD title menu *2 not available on all vehicles *3 multi function steering wheel and head-unit

Version 20.09.2017 Ci-C2-E65-TV
Page14
4. Specifications
Operation voltage 10.5 –14.8V DC
Stand-by power drain <1mA
Operation power drain 210mA
Power consumption 2.9W
Temperature range -30°C to +80°C
Weight 202g
Measurements (box only) B x H x T 90 x 30 x 105 mm
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
