Caraudio-Systems TF-PCM31 User manual

Version30.01.2013TF-PCM31
TV-Free
Video-in-motionInterface
TF-PCM31
for Porsche
PCM3.1
navigation systems
Legal Information
By law,watchingmovingpictureswhiledrivingisprohibited,thedriver mustnot be
distracted.We donotacceptany liabilityformaterial damage orpersonalinjury resulting,
directlyor indirectly,frominstallationor operationofthisproduct. This productshouldonly
beusedwhile standingortodisplay fixedmenusor rear-view-cameravideowhenthe
vehicle is moving, forexample theMP3menuforDVDupgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offerfreesoftware-updates forourinterfacesforoneyearafterpurchase. Toreceive afree
update,theinterfacemust besentinatowncost.Labor costfor and otherexpenses
involvedwith thesoftware-updates will notberefunded.
www.eldibg.com
car audio & multimedia system

Version30.01.2013TF-PCM31
Page1
Contents
1. Priortoinstallation
1.1.Delivery contents
1.2.Checkcompatibilityof vehicle andaccessories
1.3.SettingtheDip-switchesoftheCAN-box TV-500
1.4.Pin-assignments
2. Installation
3. Activationofthevideo-in-motionfunction
4. Specifications
5. Technical support
1. Priortoinstallation
Readthemanual priortoinstallation. Technical knowledgeis necessary forinstallation. The
place ofinstallationmustbefreeofmoistureandaway fromheatsources.
1.1. Deliverycontents
TakedowntheSW-versionandHW-versionoftheinterface boxes, and store this
manualfor support purposes.
CAN-box TV-500
HW_____SW_____
Harness
TV-NTG2
www.eldibg.com
car audio & multimedia system

Version30.01.2013TF-PCM31
Page2
1.2. Check compatibility ofvehicleandaccessories
1.3. SettingtheDip-switchesoftheCan-BoxTV-500
Vehicle/navigation
Dip1
Dip2
Dip3
Dip4
Dip5
Dip6
Vehicles withoutrear-view cameraor
with after-market rear-view camera
ON*
OFF
OFF
OFF
ON
ON
Vehicles with factoryrear-viewcamera
ON*
ON
OFF
OFF
ON
ON
*Withdip1toOFFtheincludedgreencableis usedtoactivatethevideo-in-motionfunction.
Note:Dipswitchfunctionsof theTV-500
Dip1 –activation TV-free
Dip2 –Factoryrear-viewcamera existing
Dip3 –nofunction
Dip4 –nofunction
Dip5 –CAN-bustermination resistor onthevehicle side
Dip6 –CAN-bustermination resistoronthehead-unitside
1.4. Pin-assignments
Pin-assignmentvehicleconnector
Requirements
Vehicle CayenneE2,Panamera
Navigation PCM3.1
Limitations
Internal DVDvideocannotbewatched!
www.eldibg.com
car audio & multimedia system

Version30.01.2013TF-PCM31
Page3
Pin-assignmentoftheCAN-BoxTV-400(Molex8pin)
Cablecolour
Pin-No.
Assignment
●Yellow
Pin4
CAN-HIGH –connectiontothehead-unit
●Blue
Pin3
CAN-LOW –connection tothehead-unit
●●Yellow/Black
Pin8
CAN-HIGH –connectiontothevehicle
●●Blue/Black
Pin7
CAN-LOW –connection tothevehicle
●Red
Pin1
+12Vpermanent
●Black
Pin5
Ground
●Green
Pin6
Activationofthevideo-in-motion function
(+12V=TV-freeactivated)
●White
Pin2
Trigger output(+12VDC500mA)
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnectingthebatteryhastobeavoided,itisusuallysufficienttoputthevehicleis
sleep-mode.Incasethesleep-modedoes notshowsuccess,disconnectthebatterywitha
resistorlead.
1. Thevideo-in-motioninterfacehas tobeinstalledinthe
backofthenavigationunit.Itis necessary tounmount
thenavigationunit.
2. RemoveQuadlockconnectorfromthenavigationcomputer
andconnectittoHarness TV-NTG2.
3. Removetheboth12pininsertsfromtheoriginal Quadlock
connectorandconnectthemtogetherwiththeoptical leads
totheHarness TV-NTG2. ConnecttheTV-NTG2tothe
navigation computer.
www.eldibg.com
car audio & multimedia system

Version30.01.2013TF-PCM31
Page4
3. Activation of the video-in-motion function
Thevideo-in-motioncanbeactivatedand deactivatedbyDip1or alternatively by the
includedloose greencable inconnectionwithaswitch(notincludedindelivery).
Video-in-motion permanent
With dip1toONthevideo-in-motion functionisactivatedpermanentlywithout disturbing
thenavigation performance.
Video-in-motion selective
With dip1toOFFtheincludedgreencable isusedtoactivatethevideo-in-motionfunction.
Connectaswitchtothegreencableandconnectthegreencableto+12VACC.
●+12V= TV-Freeis activated
●0V = TV-Freeis notactivated
Note:Theloose whitecable is notrequiredandmustbeisolated.
4. Specifications
Operationvoltage10.5 –14.8V
Stand-bypowerdrain<2mA
Operationpower drain ~60mA
Powerconsumption~0,08W
Temperaturerange-30°C to+80°C
Weight44g
Measurements(box only) W xHxD76x27x54mm
Legaldisclaimer:Mentionedcompanyand trademarks, as well asproduct names/codesareregistered
trademarks ® oftheir corresponding legal owners.
