Caraudio-Systems TF-RTI11 User manual

Version 05.11.2012 TF-RTI11
TV-Free
Video-in-motion Interface
TF-RTI11
for Volvo
RTI 2011 navigation systems
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.

Version 05.11.2012 TF-RTI11
Page1
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Setting the Dip-switches of the CAN-Box TV-500
1.4. Pin-assignments
2. Installation
3. Activation of the video-in-motion function
3.1. Vehicles without extra equipment
3.2. Vehicles with extra equipment
4. Specifications
5. Technical support
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
CAN-box TV-500
HW_____ SW_____
Harness
TV-VOL01
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.

Version 05.11.2012 TF-RTI11
Page2
1.2. Check compatibility of vehicle and accessories
1.3. Setting the Dip-switches of the Can-Box TV-500
Fahrzeug/ Navigation
Dip
1
Dip
2
Dip
3
Dip
4
Dip
5
Dip
6
Vehicles WITHOUT extra equipment (lane pilot,
distance assistant, city safety system)
ON
OFF
OFF
OFF
ON
ON
Vehicles WITH extra equipment (lane pilot, distance
assistant, city safety system)
OFF
OFF
OFF
OFF
ON
ON
Note: Dip switch functions of the TV-500
Dip 1 –activation TV-free
Dip 2 –no function
Dip 3 –no function
Dip 4 –no function
Dip 5 –CAN-bus termination resistor on the vehicle side
Dip 6 –CAN-bus termination resistor on the head-unit side
Requirements
Vehicle Volvo S-series, V-series, XC60
Navigation RTI 2011
Limitations
Vehicles with lane pilot, The included green cable is used to activate the video-in-motion
distance assistant and function (+12V = activated).
city safety system
Lane pilot, distance assistant and city safety system do not work while TV-free is activated!

Version 05.11.2012 TF-RTI11
Page3
1.4. Pin-assignments
Pin-assignment factory monitor connector
Pin-assignment of the CAN-Box TV-500 (Molex 8pin)
●Red +12V battery power Pin 4
●Black Ground Pin 8
●Yellow CAN High Navi Pin 1
●Blue CAN Low Navi Pin 2
●●Yellow/Black CAN High Vehicle Pin 5
●●Blue/Black CAN Low Vehicle Pin 6
2. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in
sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a
resistor lead.
Place of installation is at the back of the factory monitor.
3. Activation of the video-in-motion function
3.1. Vehicles without extra equipment
On vehicles without extra equipment and Dip1 to ON (see chapter “Setting the Dip-switches
of the Can-Box TV-500”) the video-in-motion function is activated permanently without
disturbing the navigation performance.
Cable colour
Assignment
●●Purple/Red
+12V Permanent
●●Black/Grey
Ground
●●Grey/Orange
CAN HIGH Pin 10
●●Purple/Orange
CAN LOW Pin 09
Back factory monitor

Version 05.11.2012 TF-RTI11
Page4
3.2. Vehicles with extra equipment
On vehicles with extra equipment and Dip1 to OFF (see chapter “Setting the Dip-switches of
the Can-Box TV-500”) the included green cable is used to activate the video-in-motion
function.
Connect a switch to the green cable and connect the green cable to +12V ACC.
●+12V = TV-Free is activated
●0V = TV-Free is not activated
Note: As long as the video-in-motion function is activated, the navigation will NOT be
working!
4. Specifications
Operation voltage 10.5 –14.8V
Stand-by power drain <2mA
Operation power drain ~60mA
Power consumption ~0,08W
Temperature range -30°C to +80°C
Weight 44g
Measurements (box only) W x H x D 76 x 27 x 54 mm
5. Technical Support
Caraudio-Systems Vertriebs GmbH NavLinkz GmbH
manufacturer/distribution corporate sales/tech dealer-support
Rheinhorststr. 22 Eurotec-Ring 45
D-67071 Ludwigshafen am Rhein D-47445 Moers
phone [phone]
email [email protected]
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
