Alaris® SE Pump
(Models 7130/7131 and 7230/7231)
with Guardrails® Safety Software
Directions For Use
en

1000DF00480 Issue 2 1/48
Contents
• Introduction.................................................................................................................................................................. 2
• AboutthisManual........................................................................................................................................................ 2
• Features........................................................................................................................................................................ 3
• ControlsandIndicators............................................................................................................................................... 4
• SymbolDenitions....................................................................................................................................................... 5
• DisplayFeatures........................................................................................................................................................... 6
• OperatingPrecautions................................................................................................................................................. 7
• GettingStarted............................................................................................................................................................. 10
• InitialSetUp........................................................................................................................................................... 10
• PoleClampInstallation......................................................................................................................................... 10
• PriminganInfusionSet......................................................................................................................................... 11
• LoadinganInfusionSet........................................................................................................................................ 12
• StartingtheInfusion............................................................................................................................................. 13
• SecondaryInfusion...................................................................................................................................................... 16
• Options.......................................................................................................................................................................... 17
• LoadingDose......................................................................................................................................................... 17
• Multi-Dose.............................................................................................................................................................. 18
• Multi-Step............................................................................................................................................................... 19
• MonitoringOptions............................................................................................................................................... 20
• SmartSite®Needle-FreeSystemInstructions............................................................................................................ 24
• Alarms,AlertsandPrompts......................................................................................................................................... 25
• Alarms..................................................................................................................................................................... 25
• Alerts...................................................................................................................................................................... 26
• Prompts.................................................................................................................................................................. 27
• Guardrails®EventCounter.................................................................................................................................... 29
• FlowSensorOperation(optional)............................................................................................................................... 30
• CongurableSettings.................................................................................................................................................. 31
• ConguredOptionsRecord......................................................................................................................................... 33
• Specications............................................................................................................................................................... 34
• Maintenance................................................................................................................................................................. 36
• RoutineMaintenanceProcedures........................................................................................................................ 36
• BatteryOperation.................................................................................................................................................. 36
• TestRoutines.......................................................................................................................................................... 36
• CleaningandStorage........................................................................................................................................... 37
• Disposal.................................................................................................................................................................. 37
• RS232ComputerLink.................................................................................................................................................. 38
• TrumpetandStart-UpCurves..................................................................................................................................... 39
• PressureMode....................................................................................................................................................... 40
• ResistanceMode.................................................................................................................................................... 42
• HighResistanceMode........................................................................................................................................... 43
• ServiceContacts........................................................................................................................................................... 44
• Compliance................................................................................................................................................................... 45

1000DF00480 Issue 2 2/48
Introduction
This document provides directions for use for the Alaris® SE pump, Models 7131 and 7231.
The pump is intended for use in professional healthcare environments, including healthcare facilities, home care, and medical
transport, that utilize infusion pumps for the delivery of uids, medications, blood, and blood products. It is indicated for
continuous or intermittent delivery through clinically acceptable routes of administration; such as, intravenous (IV), intra-arterial
(IA), subcutaneous, epidural, enteral, and irrigation of uid spaces.
The Pump is available as either a single or a dual channel pump that supports the Guardrails® Safety Software. The Alaris® SE Dual
Channel Pump is a two-channel pump intended to deliver multiple infusions to a single patient.
Guardrails® Safety Software for the Pump brings a new level of medication error prevention to the point of patient care. Guardrails®
Safety Software features programming guidelines for medication dosing, delivery rate, duration, bolus dose and bolus dose
administration rate, concentration and optional initial programming values in up to 10 patient-specic care areas referred to as
proles. Each prole contains a specic Drug Library (of up to 100 drugs) as well as pump congurations appropriate for the care
area. Limits for each Guardrails® drug entry may include Hard Limits that cannot be overridden during infusion programming
and/or Soft Limits that can be overridden, based on clinical requirements.
A data set is developed and approved by the facility’s own multi-disciplinary team using the Editor Software, the PC-based
authoring tool. A data set is then transferred to the Pump by qualied personnel. Approved data sets are maintained by the
Editor Software for future updates and reference.
Information about a Guardrails® alert that occurs during use is stored within the Pump, and can be accessed using the CQI
Reporter.
The Pump may be operated with or without the Guardrails® Safety Software protection. When an approved data set is transferred
to the Pump by qualied personnel and the Proles feature is enabled (ON) in pump conguration, then Guardrails® Safety
Software protection is available.
When the Proles feature is not enabled (OFF), or when no data set has been transferred to the Pump, Guardrails® Safety Software
protection is not available. Programming and navigation may dier when Guardrails® Safety Software is not in use. Refer to the
Directions For Use for the Signature Edition® Gold Infusion Pump that is Guardrails® Safety Software compatible.
AboutthisManual
The user must be thoroughly familiar with the pump described in this manual prior to use.
All illustrations used in this manual show typical settings and values which may be used in setting up the functions of the
pump.
These settings and values are for illustrative use only. The complete range of settings and values are detailed in the specifications
section.
Conventionsusedinthismanual:
AImportant Information: Wherever this symbol is shown an Important note is found. These notes highlight an
aspect of use that is important to know about.
Denedterms:
The following table identies the dened terms used throughout this document for certain products and product features.
ProductName DenedTerm
AccuSlide® ow regulator Flow Regulator
Alaris® SE pump Pump
Guardrails® clinical advisory Clinical Advisory
Guardrails® CQI Reporter CQI Reporter
Guardrails® data set data set
Guardrails® drug library Drug Library
Guardrails® Editor Editor Software
Guardrails® hard limit Hard Limit
Guardrails® soft limit Soft Limit
SmartSite® needle-free valve Needle-Free Valve
SmartSite® positive bolus needle-free valve Needle-Free Valve

1000DF00480 Issue 2 3/48
Features
OPTIONS
SEC
PRI
POWER
RUN
HOLD
Clear Enter
PRI SEC HLD OPT KVO HLD PRI SECKVO OPT
23
456
789
•0
1
POWER
RUN
HOLD
AB
A B
ml/hrml/hr
A
BA
B
Latch
Pumping Mechanism
Pressure Transducer
Air-in-line Detector
Air-in-line Arm
Panel Lock Keypad
AC power
indicator
Rate Display(s)
Lower Display
Main Display
Flow Sensor Receptacle(s)
RS232 Connector
AC Power Connector
Pole Clamp

1000DF00480 Issue 2 4/48
ControlsandIndicators
Controls:
Symbol Description
I..... NumericKeypad keys - Enters/changes values.
ChannelSelect keys and indicators - Select channel A or B. Lights to indicate which channel is selected.
A B
SplitScreen key - Displays information for both channels when both channels are infusing.
AudioVolume key - Sets audio volume for alarms, alerts and KVO tone. Press key to adjust volume. Audio volume
level displays in the lower LCD display.
• Pump can be configured to enable only Medium and High, or only High audio volume levels.
Clear
Clear key - Clears selected numeric value.
Enter
Enter key - Accepts value or selection entered.
POWER
Power key - Turn channel(s) on and o.
OPTIONS Options key - Accesses additional features.
Silence key - Silences audible alarm or alert for 2 minutes; message remains on screen. New alarm or alert reinstates
the audible tone.
P R I
Primary key - Selects Primary mode. Channel must be selected, if applicable.
S E C
Secondary key - Selects Secondary mode. Channel must be selected, if applicable.
RUN
HOLD
Run/Hold key - Start and stop infusion on selected channel. Channel must be selected to restart, if applicable.
PanelLock key - Located behind the handle this key helps prevent unauthorised changes to the pump settings.
Softkeys - Access main display menu options. A soft key is active if there is a tick mark (y) next to the key.
Indicators:
Symbol Description
Infusing indicator(s) - Indicates a channel is infusing.
Power indicator - When illuminated Green the pump is connected to an AC power supply and the battery is being
charged. When ashing Amber the pump is running on the internal battery.
Alarm indicator(s) - Indicates a channel is in alarm and has stopped infusing.
