AIR PURIFIER AND
SMART AIR PURIFIER
Quick Start Guide
Air Purifier Models
RMAP-ST | RMAP-XL
Smart Air Purifier Models
RMAP-SST | RMAP-SXL

This guide is for quick reference only. Please see the User Manual for complete
product information and operational instructions.
How to Prepare/Change the Filter
CAUTION
• Be sure to unplug the unit before removing the filter packaging.
• Remove the plastic packaging from the filter before use.
• Keep plastic packaging away from children as it may cause suffocation.
Note
12
Hold the top cover of the product with
both hands and pull up. Remove any tape
used to secure unit during transit.
Grasp the filter cover hole on the rear and
pull cover out and then up to remove and
access filter.
3
Remove the filter from the product and
then remove the plastic packaging from
the filter.
►Failing to remove the packaging will
result in abnormal sounds and the filter
will not work properly;
and it may cause a fire
or other damage
to the product.
4
Slide the filter back into the unit with tabs
on filter facing outward.
Filter cover
hole
Plastic
packaging
5
Replace filter cover.
►Insert the cover into the fixed groove
at the bottom of the product.
►Slide the cover forward so that the
cover fits into the top grooves.
Fixed groove
at bottom
Cover-positioning
groove at top

Display
Smart Auto Mode
Sleep Mode
Filter Replacement Indicator
Wi-Fi
(Smart Air
Purifier only)
Timer
LED Indoor Air
Quality Indicator
Control Panel
Sleep
LED
Auto
Turbo
Sleep mode / Timer Increase the timer and fan speed
setting value
LED ON/OFF & Wi-Fi® connection
(LED off cycle lasts 6 hours) Smart Auto mode
Decrease the timer and fan speed
setting value Power ON/OFF
Sleep
LED
Auto
Control Panel Descriptions
6
Hold the top cover of the product with
both hands and slide it back in place,
making sure the logo appears in the front.
7
8
Place purifier in desired location and
plug into wall outlet.
For filter replacement:
When the filter installation is complete,
press the +" " button on the
control panel for five seconds or more
to reset the filter indicator light.
►The red filter light will turn off when
the product is reset.
Sleep
Auto

4
3
2
1
How to Install Casters (Optional)
Inside of the air purifier package, there is a small box containing four casters and eight screws.
Retain the removed bottom bases and screws for future use.
Replace each base with a caster, utilizing two screws per caster.
Remove the four bottom bases from the air purifier with a screw driver.
If there is no caster box inside the product box, please contact customer
service at 1-888-320-0909.
©2022 Carrier. All Rights Reserved.
Manufacturer reserves the right to discontinue, or change at any time, specifications
or designs without notice or without incurring obligations. Third-party trademarks and
Third-party trademarks and logos are the property of their respective owners.
carrierathome.com 1-888-320-0909 01-811-20535-01
2/2022
Normal Operation
Press the button to turn on.
► The previously selected operation mode will
be displayed.
Press the button on the control panel to
select your desired fan speed.
► You can adjust the fan speed from level 1 (F1) to
level 18 (F18).
Note: The default home display on Wi-Fi® models
will show a PM2.5 reading. Once the button
is pushed, the display will switch to show designated
fan speed.
Note
Note
When the air purifier turns on, the sensor is initialized and the display
shows during initialization.
Refer to the User Manual
and the Carrier Home
app for complete set up
instructions for the Smart
Air Purifier models.
2
1
Note
