Carrier UVLCC1LP User manual

NOTE: Read the entire instruction manual before starting the installation.
This symbol →indicates a change since the last issue.
SAFETY
WARNING: EYE & SKIN BURN HAZARD
Failure to follow this warning could result in personal injury.
This unit contains high energy ultraviolet C-band (UVC) germicidal lamps which can cause serious temporary eye and skin
irritation. Never expose unprotected eyes or skin to the UVC light.
Installation and servicing of air-conditioning equipment can be hazardous due to system pressure and electrical components. Only trained and
qualified service personnel should install, repair or service HVAC equipment.
Untrained personnel can perform basic maintenance functions such as changing lamps. All other operations should be performed by trained service
personnel. When working on air-conditioning equipment, observe precautions in the literature, tag and labels attached to the unit or accessory, and
all other safety precautions that may apply.
Recognize safety information. This is the safety-alert symbol . When you see this symbol on the unit and in instructions or manuals, be alert
to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol. DANGER identifies the
most serious hazards which will result in severe personal injury or death. WARNING signifies a hazard which could result in personal injury or
death. CAUTION is used to identify unsafe practices which would result in minor personal injury or product and property damage. NOTE is used
to highlight suggestions which will result in enhanced installation, reliability, or operation.
Follow all safety codes. Wear safety glasses and work gloves. Have a fire extinguisher available if needed. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult local building codes and National Electrical Code (NEC) for special requirements.
Before proceeding with installation, inspect thoroughly for shipping damage. Notify shipper immediately if any damage is found. Check for proper
clearances of moving parts.
The qualified installer or agency must use factory-authorized kits or accessories when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Fig. 1–Two Lamp Model UV Lamp
C03009
Installation Instructions
UV Lamp
Accessory Ultraviolet (UV) Germicidal Lamp
1 & 2 Lamp Models—115-v & 208/230-v
Form: 00001398 Printed in U.S.A. FEB-2018 Catalog No. IM-UVLCR-01

INTRODUCTION
This UV Lamp system is designed to inhibit fungus and microbial growth when applied to the indoor coil/drain pan area of a central cooling
system. This system should be mounted on a flat surface. These instructions cover the installation of both the 1 and 2 lamp models. Lamps are
designed to operate for one year continuously before replacement is required.
NOTE: These UV Lamps are designed for indoor use only.
This model consists of individual UV Lamp assemblies. On 2 lamp models, the 2 assemblies are connected by a flexible cord which will allow
the installer to separate the lamps from 4-in. to 18-in.
CAUTION: UNIT DAMAGE HAZARD
Failure to follow this caution may result in damage to the product.
Do not touch glass section of UV Lamp without clean gloves. Damage to lamp will result. Oil from fingers will permanently
etch glass of lamp and weaken structure. Clean lamp with rubbing alcohol and clean cloth if necessary.
CAUTION: MERCURY EXPOSURE HAZARD
Failure to follow this caution may result in minor personal injury.
Lamp contains a small quantity of mercury. Handle with care. If a lamp breaks, clean and dispose with care.
NOTE: The health aspects associated with the use of this product and its ability to aid in disinfection of environmental air have not been
investigated by UL.
NOTE: Each lamp model kit includes cleaning kit and mounting screws.
INSTALLATION
PROCEDURE 1—UNIT MOUNTING LOCATION
WARNING: ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in electrical shock and cause injury or death.
Before installing accessory or performing maintenance or service on this or any other accessory, turn off main power to unit
and install lock-out tag. There may be more than one disconnect switch.
CAUTION: UNIT DAMAGE HAZARD
Failure to follow this caution could result in damage to unit or personal injury.
Perform visual inspection of potential mounting location by removing unit/cabinet door prior to cutting or drilling. Be careful
not to cut, drill or drive screws into coil, refrigerant lines or other objects inside the HVAC unit.
NOTE: On indoor coils 2 tons or smaller it is recommended that this UV lamp be installed in the connecting ductwork above the indoor coil and
not in the coil casing itself.
NOTE: No testing has been done to determine the effects of UV light on duct board or flex duct, metal duct is recommended.
NOTE: It is recommended that a 7/8-in. hole be used for mounting this accessory. Using a 7/8-in. hole should provide proper clearances.
NOTE: Components contained in the current furnace and fan coil equipment are resistant to UVC exposure. Color shift or chalking may occur
without affecting structural properties.
IMPORTANT: Select a mounting location that prevents direct exposure to non-fiberglass media filters. A minimum distance of 6 feet is
recommended (Non-Fiberglass media will break down from UV exposure).
1. Turn off all power to unit and install lock-out tag.
2. Remove indoor coil casing door and inspect coil casing for proper location of UV lamp mounting holes.
3. Select location for lamp(s) that gives the most exposure to coil/drain pan. Light from the lamp should “wash” the coil and pan for maximum
effectiveness (See Fig. 3A, 3B or 3C).
Table 1— Unit Data
UNIT INFORMATION 1 LAMP MODEL 2 LAMP MODEL 1 LAMP MODEL 2 LAMP MODEL
Electrical
(V-PH-Hz) 115-1-60 115-1-60 208/230–1–60 208/230–1–60
Maximum Lamp Amperage Draw 0.6 Amps 1.1 Amps 0.3 Amps 0.6 Amps
Average Power Consumption 27 Watts 53 Watts 27 Watts 53 Watts
Unit Service
Cord
6 foot cord
with ground pin plug
Average Lamp Life Approximately 1 Year or
9,000 Hours of Unit Runtime
Initial UVC Output at 1 Meter
(in microwatts per square centimeter and 70 Deg F)
and 450 FPM Airflow
105 198 105 198
Lamp Length 19-in.
—2—

PROCEDURE 2—UNIT INSTALLATION
1. Drill or cut a 7/8-in. hole for each UV lamp into the coil casing, casing door or the connecting ductwork.
2. Securely mount UV lamp base assembly to the flat surface selected in Procedure 1 (use screws provided).
3. Replace coil casing door and slide ballast/lamp assembly into the mounted base, making sure the locating stud and molex connectors are
aligned (See Fig. 2).
4. Install fastener screw to hold lamp/ballast to base.
5. Replace plastic cover(s) on UV lamp assembly base to complete the installation.
NOTE: On furnace application—Use 115-v power source other than the furnace motor circuit.
NOTE: On fan coil application—Use 208/230-v power source other than the fan coil motor circuit.
6. Adhere warning label with install date and change dates (329734-101 RevA) to indoor coil casing door. The label is included in the carton
with the lamp(s).
7. Connect electrical cord to suitable electrical receptacle.
UV LAMP START-UP PROCEDURES
1. After power is supplied to lamp(s), make sure the LEDs behind the logo are illuminated. If not, verify supply voltage.
NOTE: On 2 lamp models, both lamp/ballast assemblies need to be installed before lamps will illuminate.
2. If at any time the LED lights behind the logo are dim this is an indiction that one of the UV lamps is not working. Disconnect power and
inspect for proper lamp operation.
UV LAMP CARE AND MAINTENANCE
CAUTION: MINOR BURN HAZARD
Failure to follow this caution may result in minor personal injury.
Allow lamp to cool for 1–minute before opening UV lamp casing or HVAC unit cabinet.
NOTE: The recommended life of the lamp assembly in this UV lamp product is 1-year of constant operation or a maximum of 9,000 hours of
unit runtime.
1. When replacement of lamp is needed, order proper lamp assembly (See Table 2) from your dealer / distributor.
2. Disconnect power supply from UV lamp by unplugging the electrical cord.
3. Remove protective cover from UV lamp assembly.
Table 2—Replacement Lamp Ordering Information
REPLACEMENT LAMP ORDER NUMBERS
Quantity Lamp Voltage ODS Number
1 Lamp/Ballast Assembly 115-1-60 UVLXXRPL1020
1 Lamp/Ballast Assembly 208/230-1-60 UVLXXRPL3020
CAUTION: MERCURY EXPOSURE HAZARD
Failure to follow this caution may result in minor personal injury.
Lamp contains a small quantity of mercury. Handle with care. If a lamp breaks, clean and dispose with care.
4. Remove fastener screw(s) that holds lamp/ballast to base.
5. Gently pull lamp assembly from mounted base assembly.
6. Place old lamp assembly in a safe area before proceeding.
NOTE: Treat the disposal of these lamps as you would a standard fluorescent lamp.
7. Carefully slide new lamp/ballast assembly into base assembly until fully seated, retighten fastener screw(s) to hold new lamp in base.
8. Replace protective cover.
9. Reconnect unit power to UV lamp.
10. Observe that LEDs behind logo brightly illuminate and that the lamp(s) are operational.
NOTE: Lamp/Ballast assembly should be removed when mounted on indoor coil casing door, if door is to be removed for system maintenance.
WARRANTY STATEMENT
This UV lamp Product is covered by a limited warranty. Please see the included warranty card for clarification.
—3—
→

C03004
Fig. 2—UV Lamp Assembly (Detail View)
Lamp Base
LED Lights
Lamp/Ballast Assembly
Note: LED Lights are not lamp change indicators.
Lamps should be changed annually.
—4—

C04012
Fig. 3A—Typical Furnace Coil Mounting Locations--115-v Application
Horizontal "N" Coil
Wide 042, 048, 060 & 060A "A" Coil
Side View
Standard "A" Coil
Suggested Mounting Locations
Front of
Coil Casing
Standard "N" Coil
—5—

C03021
Fig. 3B—Alternate Furnace Coil Mounting Locations--115-v Application
Small "N" CoilSmall "A" Coil
Alternate Mounting Locations
—6—

C04014
Fig. 3C—Fan Coil Mounting Locations--208/230-v Application
Sloped Fan Coil
"A" Coil in Fan Coil
Single Lamp Application
Sloped Fan Coil
Dual Lamp Application
—7—

© 2018 CAC/BDP 7310 W. Morris St., Indianapolis, IN 46231 —8— Form No. 00001398 Catalog No. IM-UVLCR-01
