Carrier Crystal Plus 53KHFT 12 User manual

PLUS
High Wall Split Air Conditioners
53KHFT 12-18-24 Cool Only
53QHFT 12-18-24 Heat Pump
Rev. (0) - 2015
R
2
2
220-240V ~ 50Hz 1Ph
Mirac
o
Mirac
o
MISR REFRIGERATION & AIR CONDITIONING MFG. CO.
Enviromental
Management System
ISO 14001 : 2004
Certicate No : 12 104 30334 TMS
Safety
Management System
BS OHSAS 18001 : 2007
Certicate No : 12 116 30334 TMS
Quality
Management System
ISO 9001 : 2008
Certicate No.: QS-5519HH
03504165
OWNER’S MANUAL
Carrier is committed to continuously improving its products according to national and international standards
to ensure the highest quality and reliability standards, and to meet market regulations and requirements.
All specications subject to change without prior notice according to Carrier policy of continuous development.

High Wall Split Systems
12K - 18K - 24K
220V ~ 50Hz 1Ph
R
2
2
PLUS
HEAT COP
COOL EER
Mirac
o
Mirac
o
MISR REFRIGERATION & AIR CONDITIONING MFG. CO.
Easy Flexible
Installation
Easy Fast Service
& Maintenance
Cleanable
Front Panel
Washable
Air Filter
Tropical
Compressor
Efficient
AMS
AMS
Efficient
Fans
Efficient
Coils
Inner Groove
Copper Tubing
Hydrophilic
Aluminum Fins
3 Minutes
Time Delay
Anti-Freezing
Protection
Self diagnostic
function
Refrigerant
Leak Detection
3
Min.
Anti
Freezing
Auto Restart
Function
Timer
Functions
Super
Quiet
Smart LCD
Wireless Control
Smart
Airow
Horizontal Air ow
Manual Direction
Vertical Air ow
Auto Swing
Louver Position
Memory Function
Auto
Fan Speed
Auto
Independent Dehu-
midication
Auto
Mode
Turbo
Function
ECO
Function
Follow Me
Function
Efficient
Anti-dust Filters
Fashion
Design
Efficient
Operation
LCD
Display
LE
IAQ
Self Clean
Function
Formaldehyde
Filter

PLUS
High Wall Split Systems
Wireless Remote Control
Control Buttons DISPLAY OF SELECTED FUNCTIONS
MODE selection button
AUTO - COOL - DRY - HEAT - FAN
1
Decrease temperature button
Each time you press the button,
the temperature decreased by 1°C
2
Increase temperature button
Each time you press the button,
the temperature increased by 1°C
3
FAN selection button
High - Medium - Low - Auto fan speed
4
ON/OFF button
5
Vertical Air Flow Auto Swing
6
Horizontal Air Flow Auto Swing *
7
ECO function button
8
TIMER ON function button
9
TIMER OFF function button
10
Self Clean function button
11
Fresh air function button *
Follow Me function button
12
LED Display function button
13
TURBO function button
14
2
5
1
6
7
12
11
13
10
9
14
3
4
8
Note : * This function does not work with this product
but works with other products

PLUS
High Wall Split Systems
Wireless Remote Control
SET TEMP. indicator /
Error code in indicator
OPERATION indicator
TIMER function indicator
Cold Draft or Defrost indicator
( only with Heat Pump System )
Display Panel Of Indoor Unit
Heat PumpCool Only
Display Of Remote Control
AUTO
COOL
DRY
HEAT
FAN
HIGH
MED
LOW
TIMER ON OFF
SET TEMP.
㪈
㪉
㪍㪋㪎㪏
㪊
㪉
㪌
Signal transmission indicator
1
Operation MODE indicator
2
Automatic AUTO
Cooling and dehumidification COOL
Dehumidification only DRY
HeatingHEAT
Ventilation (fan only)
FAN
ON / OFF indicator
3
SET TEMP. indicator
4
FAN SPEED indicator
5
FAN SPEED indicator HIGH HIGH
FAN SPEED indicator MED MED
FAN SPEED indicator LOW LOW
FAN SPEED indicator AUTO
TIMER ON function indicator
6
TIMER OFF function indicator
7
FOLLOW ME function indicator
8

Thank you for selecting Carrier
Air Conditioner
Carrier Split is the optimum air conditioning
solution for places which require high wall installation, elegant
appearance and ultimate comfort combined with efficient, quiet
operation, optimum air distribution, and efficient Indoor Air
Quality (IAQ).
CONTENTS
PAGENO.
1. GENERAL INFORMATION 1
2. SYSTEM SAFETY PROTECTIONS 2
3. TIPS OF ENERGY SAVING AND OPTIMUM COMFORT 3
4. SPLIT SYSTEM DESCRIPTION 5
5. CONSIDERATIONS FOR REMOTE CONTROL 6
6. EMERGENCY BUTTON 9
7. USE OF REMOTE CONTROL 10
8. AIR FILTERS CLEANING 25
9. INDOOR UNIT CLEANING 26
10. PERIODICAL CHECKS 27
11. CONSIDERATIONS BEFORE A LONG SHUTDOWN PERIOD OF AIR CONDITIONER 28
12. OPERATION TIPS 29
13. TROUBLE SHOOTING TIPS 30

( )1
1. GENERAL INFORMATION
PRECAUTIONS
Installing and servicing of air conditioning equipment can be hazardous due to system
pressure and electrical components. Only trained and qualified service personnel should
install or service this equipment.
Untrained personnel can perform basic maintenance function such as cleaning coil and
filters. Trained service personnel should perform all other operations.
When working on air conditioning equipment, observe precautions in the literature, tags
and labels attached to the unit.
WARNINGS
•The operating voltage of electrical power supply should be within the voltage mentioned on unit
nameplate data.
•The capacity of electrical kWh counter should be larger than the operating currents required for
air conditioner(s) and any other electrical domestic appliances in use simultaneously from the
same supply.
•The installation of electrical distribution box after the electrical KWH counter is necessary to
properly distribute the electrical loads. The electrical distribution box should be equipped with
circuit breakers according to the electrical loads. For each installed air conditioner, a separate
circuit breaker with its own overload should be installed on the electrical distribution box.
•The installation of two-pole automatic circuit breaker is necessary to operate the air conditioner.
The circuit breaker must be installed to be far away from any flammable materials (curtains…etc.).
The circuit breaker size must be suitable for air conditioner.
•Disconnect the electrical mains supply prior to any maintenance operations or prior to handling
any internal unit parts.
•The manufacturer declines any liability for damage resulting from modifications or errors in the
electrical or refrigerant connections, made during the installation, or from the improper use of this
equipment. This will void the unit warranty immediately.
•Failure to observe electrical safety codes may cause a fire hazard in case of short circuits.
•This system will only work safety and correctly, if installed and tested by qualified personnel.
•Do not open the electronic remote controller to avoid possible damage. In case of malfunction
contact a qualified service engineer.
•The unit contains rotating equipment (fan). Ensure that this is out of reach for children.
•Be conscious of the room temperature and general comfort, particularly when this is used near
children, senior or handicapped people.
•For correct use, the air conditioner must operate within the temperature limits indicated in the
table “Operating Limits” included in the installation manual. Incorrect use of the system outside
these limits may cause malfunction and dripping water.
•Controller batteries contain polluting elements. When exhausted, they must be disposed of in
accordance with local requirements.
•Do not switch off the split system by disconnecting the electric power supply.
The system must always be switched off using the remote control.

( )2
2. SYSTEM SAFETY PROTECTIONS
The air conditioner is equipped with complete safety protections to ensure safe
operation of air conditioner at different operating conditions :
2.1 Safety protections for Cool Only System
Auto Restart Feature with backup memory.
When the power failure is happened during the air conditioner operation, the microprocessor
of printed circuit board will memorize the operation setting. After the power is recovered, the
air conditioner operates automatically ( without remote control after elapse of compressor
time delay ), according to the previous operation settings.
3 (Three) minutes time delay between compressor turning off and turning on for compressor
protection against cycling.
Anti-freezing protection of indoor coil when the system is operating in cool mode with
excessive dirt on the indoor coil and / or clogged air filters and when the air conditioner is
operating in cool mode at low ambient temperature.
Smart self-diagnostic function for malfunctions detection for fast easy service and
maintenance.
Smart refrigerant leak detection by sensitive sensors mounted on the indoor and outdoor
coils for fast easy service and maintenance.
2.2 Safety protections for Heat Pump System
Auto Restart Feature with backup memory.
When the power failure is happened during the air conditioner operation, the microprocessor
of printed circuit board will memorize the operation setting. After the power is recovered, the
air conditioner operates automatically ( without remote control after elapse of compressor
time delay ), according to the previous operation settings.
3 (Three) minutes time delay between compressor turning off and turning on for compressor
protection against cycling.
Anti-freezing protection of indoor coil when the system is operating in cool mode with
excessive dirt on the indoor coil and / or clogged air filters and when the air conditioner is
operating in cool mode at low ambient temperature.
High temperature protection of outdoor coil when the air conditioner is operating in cool
mode.
Cold draft protection when the system is operating in heat mode.
When starting heat mode, the fan speed is regulated automatically from the lowest grade to
the preset level, according to the temperature rise of indoor coil. This function can prevent
cold air blowing out at the beginning of heat modem which avoids the discomfort to the
user.
High temperature protection of indoor coil when the air conditioner is operating in heat
mode.
Defrost protection of outdoor coil when the air conditioner is operating in heat mode
at very low ambient temperature.
Smart self-diagnostic function for malfunctions detection for fast easy service and
maintenance.
Smart refrigerant leak detection by sensitive sensors mounted on the indoor and outdoor
coils for fast easy service and maintenance.

( )3
3.TIPS OF ENERGY SAVING AND OPTIMUM COMFORT
In Summer
•Keep room temperature to comfort
levels.
•Don’t remain in direct contact
with cold air for a long period.
This is harmful to health.
•Don’t wait until it is too hot.
Turn the air conditioner for cooling
before that.
•Don’t exaggerate on the temperature
intensity, too cold.
Extreme temperatures are harmful to
your health and waste energy.
COOL mode HEAT mode
In Winter
•Keep room temperature to comfort
levels.
•Don’t remain in direct contact
with warm air for a long period.
This is harmful to health.
•Don’t wait until it is too cold.
Turn the air conditioner for heating
before that.
•Don’t exaggerate on the temperature
intensity, too hot.
Extreme temperatures are harmful to
your health and waste energy.
Keep doors, windows and any other
openings closed to prevent the
conditioned air from escaping and to
prevent un conditioned air from entering
the space to be air conditioned.
When in cooling, avoid direct sun in the
room to be air-conditioned, if possible
shut curtains or shades.
Keep doors, furniture or any other
obstructions away from blocking return
air and / or supply air of the indoor unit to
assure maximum efficiency and adequate
air circulation.

( )4
TIPS OF ENERGY SAVING AND OPTIMUM COMFORT (Cont.)
Use ECO function during sleep for
energy saving, comfortable and healthy
sleep during COOL mode or HEAT mode.
COOL mode HEAT mode
With ECO function With ECO function
Ensure a uniform air circulation in the
room to be air conditioned
(1) by using Swing ↕function on the
remote control.
(2) by manual adjustment of vertical
supply air louvers to right or left as
per the requirement.
Clean periodically air filters of indoor unit
every month to assure adequate air
circulation and maximum cooling and
heating efficiency.
Periodic service and maintenance of the
air conditioner or upon customer request
through Carrier or Carrier authorized
dealer to assure maximum cooling and
heating efficiency.
Air Filters
Deflector rod
For vertical Louver

( )5
4. SPLIT SYSTEM DESCRIPTION
High Wall Split Systems 12K – 18K – 24K
1: Panel frame & Front panel
2: Chassis
3: Horizontal supply air louver
4: Vertical supply air louvers
5: Air filters
6: Manual control button
7: Power cord
8: Inter-connecting refrigerant piping and electrical cables between
indoor and outdoor units.
9: Drain hose
10: Wireless remote controller
11: Plastic holder of remote control
Indoor Unit Return Air
5
11
6
2
Outdoor Unit
13Supply Air
10
4
7
8
9

( )6
5. CONSIDERATIONS FOR REMOTE CONTROL
5-1 HOW TO INSERT BATTERIES :
(a) Remove the cover of battery compartment at the
back of the remote control by pressing the tab
toward outside, in the direction of the arrow.
(b) Mount two batteries size AAA 1.5 Volt supplied with the
remote control.
Then close the cover of the battery component.
Note:
During mounting of batteries check battery symbols (+, -)
indicated in batteries compartment.
NOTES
1. The remote control uses two alkaline batteries (1.5 Volts) .
2. Do not use old batteries or batteries of different types, as this may cause the remote control to malfunction.
3. If you do not use the remote control for more than a few weeks, please remove the batteries.
Other wise battery leakage may damage the remote control.
4. The average battery life during normal use is approximately half a year.
5. Replace the batteries when there is no receiving beep coming from the indoor unit or transmission
indicator on the remote control fails to light.
6. Batteries should only be replaced after turning OFF the air conditioner.
5-2INSTRUCTIONS OF USING WIRELESS REMOTE CONTROL
1- The remote control must be directed toward the receiver of indoor unit when pressing the buttons
of the desired functions. An acoustical acknowledgement sound (beep) will indicate that signal has
been received.
2- Avoid direct sunlight on the receiver of indoor unit, which may interfere with good signal reception
and the air conditioner may not work properly. Draw the curtains to avoid direct sunlight.
3- Avoid obstacles obstructions such as curtains, doors or other materials between the remote control
and the receiver of indoor unit to avoid blocking the signals from the remote control to the indoor unit.
4- The maximum operating distance for the remote control is approximately 8 meters.
5- Keep the remote control away from water. Do not let the remote control fall down.
6- Never use objects with sharp point to press the button on the remote control.
7- Prevent any liquid from falling into the remote control.
8- If other electric applications react to the remote control, move these applications.
8 meter

( )7
CONSIDERATIONS FOR REMOTE CONTROL (Cont.)
5-3 Instruction for Remote Control
5-3-1 Cool Only or Heat Pump
When you press Mode button and Fan button as the
same time more than 2 seconds, then the remote
covert to operate without Heat model to work with
indoor unit cool only.
5-3-2 Control function which do not work
with this product
( A ) Horizontal Air Flow Auto Swing
( B ) Fresh Function

( )8
CONSIDERATIONS FOR REMOTE CONTROL (Cont.)
5-4 MOUNTING PLASTIC HOLDER OF REMOTE CONTROL
•Fix the plastic holder of the remote control on the wall by using screws.
Plastic holder
Screw

( )9
6. EMERGENCY FUNCTION
EMERGENCY FUNCTION
Emergency function can be used temporarily in case you cannot find the remote control or its batteries
are exhausted.
To perform Emergency function, follow below steps :
1. Open and lift the front panel up to an angle until
it remains fixed with a clicking sound.
2. Press manual control button ( AUTO / COOL )
until AUTO led illuminates on the display panel of
the indoor unit.
then the unit will work in forced AUTO mode
(the default setting temperature is 24°C).
3. Close the panel firmly to its original position.
CAUTION
•Once you press the manual control button
( AUTO / COOL ), the operation mode is shifted
in an order as : AUTO →Forced COOL →OFF
•Push the manual control button to operate in forced
COOL mode, this is used for testing purposes only.
You had better not choose it.
•The Forced COOL mode is used only for testing
purposes by the installer and serviceman.
•To restore the remote control operation, use the remote
controller directly.
Front panel

( )10
7. USE OF REMOTE CONTROL
COOL MODE
START
1. Press " Mode " button to select COOL mode
on the remote control display.
2. Press " TEMP " buttons or to select the
desired set temperature on the remote control
display.
For Egyptian Market :
Set desired temp. between 20°C and 28°C.
For Export Markets :
Set desired temp. between 17°C and 30°C.
3. Press " Fan " button to select the desired
fan speed on the remote control display.
4. Press " On/Off " button to start
the air conditioner.
ON symbol appears on the
remote control display.
OPERATION indicator will illuminate
on the display panel of indoor unit.
COOL mode starts after approximately 3 minutes
STOP
If you want to stop the air conditioner,
Press " On/Off " button again.
NOTES
•If the room temperature is higher than
the selected temperature, the system will start COOL mode.
•If the room temperature is equal to or less than
the selected temperature, the system will stop COOL mode.
•If you use AUTO fan speed with COOL mode, the fan speed changes automatically
to low or medium or high speed based on the temperature difference between
setting temperature and room temperature.
4
2
3
2
1

( )11
USE OF REMOTE CONTROL (Cont.)
HEAT MODE
START
1. Press " Mode " button to select HEAT mode
on the remote control display.
2. Press " TEMP " buttons or to select the
desired set temperature on the remote control
display.
For Egyptian Market :
Set desired temp. between 20°C and 28°C.
For Export Markets :
Set desired temp. between 17°C and 30°C.
3. Press " Fan " button to select the desired
fan speed on the remote control display.
4. Press " On/Off " button to start
the air conditioner.
ON symbol appears on the
remote control display.
OPERATION indicator will illuminate
on the display panel of indoor unit.
HEAT mode starts after approximately 3 minutes.
STOP
If you want to stop the air conditioner,
Press " On/Off " button again.
NOTES
•If the room temperature is lower than
the selected temperature, the system will start HEAT mode.
•If the room temperature is equal to or higher than
the selected temperature, the system will stop HEAT mode.
•If you use AUTO fan speed with HEAT mode, the fan speed changes automatically
to low or medium or high speed based on the temperature difference between
setting temperature and room temperature.
4
2
3
2
1

( )12
USE OF REMOTE CONTROL (Cont.)
AUTO MODE
START
1. Press " Mode " button to select AUTO mode
on the remote control display.
2. Press " TEMP " buttons or to select
desired the set temperature on the remote control
display.
For Egyptian Market :
Set desired temp. between 20°C and 28°C.
For Export Markets :
Set desired temp. between 17°C and 30°C.
3. Press " On/Off " button to start
the air conditioner.
ON symbol appears on the
remote control display.
OPERATION indicator will illuminate
on the display panel of indoor unit.
AUTO mode starts after approximately 3 minutes.
STOP
If you want to stop the air conditioner,
Press " On/Off " button again.
NOTES
1. For Cool Only System
When Auto mode is activated, the air conditioner changes the operation mode automatically to
cool or fan only mode and also changes fan speed to auto speed by sensing the temperature
difference between room temperature and set temperature.
2. For Heat Pump System
When Auto mode is activated, the air conditioner changes the operation mode automatically to
cool or heat or fan only mode and also changes fan speed to auto speed by sensing the
temperature difference between room temperature and set temperature.
3. In the Auto mode, you cannot switch the fan speed. It has already been automatically controlled.
4. If the Auto mode is not comfortable for you, the desired mode can be selected manually.
3
2
2
1

( )13
USE OF REMOTE CONTROL (Cont.)
DRY MODE
START
1. Press " Mode " button to select DRY mode
on the remote control display.
2. Press " TEMP " buttons or to select
desired the set temperature on the remote control
display.
For Egyptian Market :
Set desired temp. between 20°C and 28°C.
For Export Markets :
Set desired temp. between 17°C and 30°C.
3. Press " On/Off " button to start
the air conditioner.
ON symbol appears on the
remote control display.
OPERATION indicator will illuminate
on the display panel of indoor unit.
DRY mode starts after approximately 3 minutes.
STOP
If you want to stop the air conditioner,
Press ON/OFF button again.
NOTES
•In DRY mode, you can not switch the indoor fan speed.
The indoor fan speed will be automatically controlled.
•The DRY mode will automatically select the drying operation based on the
difference between the set temperature and the actual room temperature.
•The temperature is regulated while dehumidifying by repeating turning on
and off of the cooling operation or fan only.
3
2
2
1

( )14
USE OF REMOTE CONTROL (Cont.)
FAN ONLY MODE
START
1. Press " Mode " button to select FAN mode
on the remote control display.
2. Press " Fan " button to select the desired
fan speed on the remote control display.
3. Press " On/Off " button to start
the air conditioner.
ON symbol appears on the
remote control display.
OPERATION indicator will illuminate
on the display panel of indoor unit.
Fan mode starts immediately.
STOP
If you want to stop the air conditioner,
Press ON/OFF button again.
NOTES
•Fan mode does not control temperature.
The setting temperature is not displayed on
the remote control display.
3
1 2

( )15
USE OF REMOTE CONTROL (Cont.)
AIR FLOW DIRECTION CONTROL
Air is supplied into the room through the supply air louvers located on the bottom of the indoor unit.
Air from the room is drawn into the indoor unit through the front panel and filters which are located
behind the front panel.
Make absolutely sure that the supply and return air flow of the indoor unit are not obstructed
(even partially).
•Adjust supply air direction properly otherwise, it might
cause discomfort or cause uneven room temperatures.
•Adjust the horizontal louver using the remote control.
•Adjust the vertical louvers using manual.
CAUTION
•The ↕SWING button will be disabled when the air conditioner is not in operation
( including when the TIMER ON is set ).
•Do not operate the air conditioner for long periods with the supply air direction set downward
in cooling or dry mode. Otherwise, condensation may occur on the surface of the horizontal
louver causing moisture to drop on to the floor or on furnishings.
•Do not move the horizontal louver manually. Always use ↕Swing button.
If you move horizontal louver manually, it may malfunction during operation.
If the louver malfunctions, stop the air conditioner once and restart it.
•When the air conditioner is started immediately after it was stopped, the horizontal louver
might not move for approximately 10 seconds.
•Open angle of the horizontal louver should not be set too small, as cooling performance may
be impaired due to too restricted air flow area.
•Do not operate unit with horizontal louver in closed position.
•When the air conditioner is connected to power (initial power), the horizontal louver may
generate a sound for 10 seconds, this is a normal operation.
