CaryMart S1XB-DC06 User manual

SHENZHENGUIYUANINDUSTRYDEVELOPMENTCO.,LTD
Http://www.
carymart
.com
E
-
Mail:sale@
carymart
.com
RFWireless Remote Control RadioController/ Transmitter& Receiver
PackageInclude:
6xReceiver: S1XB-DC06 / S1XB-DC09 / S1XB-DC12 / S1XB-DC24(1 Channel/ Three ControlModes)
1xTransmitter: CV-6
1xUser manual
Feature:
Wireless control,easy toinstall
Direct power output; controlLights, Motors, Fans,electricallyoperatedDoors/Locks/Windows/Blinds/Cars or Other Appliances.
You can turn on/off thereceiver withtransmitter(remotecontrol)fromanyplacewithinareliabledistance;the wirelessRFsignalcanpass
through walls, floorsand doors.
Withcharacteristics of reversepower protection and over currentprotection
Audible/ visualindication
Usemicrocontroller modelof EM78P156, an 8-bitmicroprocessor designed and developed withlow-power and high-speed CMOS technology.
Reliablecontrol: The transmitter (Encoding) and the receiver (Decoding) usean8-bitcode.
One/severaltransmitterscancontrolone/severalreceiverssimultaneously.
If you usetwoor more receiversinthe sameplace, you can setthemwithdifferentcodes.
Transmitting Frequency: 315MHz /433MHz
Receiver:
ModelNo.: S1XB-DC06 / S1XB-DC09 / S1XB-DC12 / S1XB-DC24
Channel: 1CH
ControlModes: Toggle, Momentary, Latched
Coding Type: Fixed code
Coding Setting:Bylearning
Power Supply(Operating Voltage): DC6V(S1XB-DC06), DC12V 1V(S1XB-DC12), DC9V 1V (S1XB-DC09), DC24V 1V(S1XB-DC24)
Output:DC6V (S1XB-DC06), DC12V (S1XB-DC12), DC9V (S1XB-DC09), DC24V (S1XB-DC24)
PCBSize:67mm x50mm x18mm
CaseSize: 75mm x54mm x27mm
StaticCurrent: ≤6mA
MaximumWorkingCurrent: 10A
Transmitter:
ModelNo.: CV-6
Channel: 6CH
RemoteControlDistance: 500m/ 1500ft (theoretically)
Encode:Fixed code by Soldering
Unitsize: 110mm x50mm x18mm
Power Supply: 1x23A-12V battery(Included,canbe used for12 months)
Usage:
Setting differentcontrolmodes(We havesetthe receiver asTogglecontrolmode before delivery.Ifyou wanttouseother controlmodes,do as
following):
1) Setting controlmode Toggle:OnlyconnectJumper-2.
Press button 1:Turn on the relay,terminalA&Bof receiver 1outputs DC power.
Press button 1again: Turn off therelay, terminalA&B of receiver 1nooutput.
…
Press button 6:Turn on the relay,terminalA&Bof receiver 6outputs DC power.
Press button 6again: Turn off therelay, terminalA&B of receiver 6nooutput.
2) Setting controlmode Momentary: Only connect Jumper-1.
Press and holdbutton 1:Turn on the relay, terminalA&Bofreceiver 1outputs DC power.
Releasebutton 1:Turn offthe relay, terminalA&Bofreceiver 1nooutput.
…
Press and holdbutton 6:Turn on the relay, terminalA&Bofreceiver 6outputs DC power.
Releasebutton 6:Turn offthe relay, terminalA&Bofreceiver 6nooutput.
3) Setting controlmode Latched: Do notconnectJumper-1 and Jumper-2.
Press button 1:Turn on the relay,terminalA&Bof receiver 1outputs DC power.
Press otherbuttons:Turn offthe relay, terminalA&Bofreceiver 1nooutput.
…
Press button 6:Turn on the relay,terminalA&Bof receiver 6outputs DC power.
Press otherbuttons:Turn offthe relay, terminalA&Bofreceiver 6nooutput.
Wehavelearned remotecontroltothe receiver. If you don’t wantthe receiver towork withtheremotecontrol, you can deleteallcodesofremote

SHENZHENGUIYUANINDUSTRYDEVELOPMENTCO.,LTD
Http://www.
carymart
.com
E
-
Mail:sale@
carymart
.com
controls,whichare stored inthe receiver.
Operation:Press andholdthe button of receiver untilsignalLEDflashesslowly; releasethe button,LEDkeeps slowflash.That meansallstored
codeshavebeen deleted successfully.
LEARNINGthe remotecontrol:
1) Pressthe button of receiver;signalLEDonthe receiver keepsshining.Thereceiver enters intostatus ofLEARNING.
2) Press anyone buttonon remotecontrol.IfsignalLEDflashesquickly15 times and turnsoff,it means learning issuccessful.
3) Press anybutton onthe transmitter;the receiver will learn thecorresponding button on the transmitter.
4) When receiver isinthe statusofLEARNING,press againthe buttonofreceiver,signalLEDturnsoff,itmeanslearning process isdiscontinued.
5) The receiver can learn severalremotecontrols withdifferent codes.
Application Circuit
Powersupply
Lamp
_
+
Relay
A B C
Jumper-2
Jumper-1
Button
SignalLED
PowerLED
Antenna
RFmodule
IC
+
_
