Case 595SLE User manual

Copyright 1999 Case France
Printed in France
Case Cre 7-22470GB November 1999
595SLE/595LSP LOADER BACKHOE SERVICE MANUAL
Table of contents
DIVISION/SECTION SECTION N°REFERENCE N°
1 GENERAL
Standard torque specifications and loctite product chart.................................1001 7-79451GB
Fluids and lubricants........................................................................................1002 7-22480GB
2ENGINE
Engine and radiator removal and installation...................................................2000 7-21290GB
Specifications details .......................................................................................2401 7-26610GB
3 FUEL SYSTEM
4 ELECTRICAL
Electrical schematic .........................................................................................4001 7-26620GB
Battery..............................................................................................................4003 7-21330GB
Starter motor....................................................................................................4004 7-21340GB
Removal and installation of electrical components..........................................4005 7-21350GB
Alternator .........................................................................................................4007 7-23790GB
Steering, loader and backhoe calibration.........................................................4008 7-26530GB
5STEERING
Removal and installation of steering components ...........................................5000 7-23810GB
Steering specifications, pressure checks and troubleshooting ........................5001 7-21900GB
Steering control valve ......................................................................................5002 7-21390GB
Steering cylinder ..............................................................................................5003 7-21400GB
Front axle, four wheel drive machine/four wheel steer machine......................5007 7-21890GB
6POWERTRAIN
Removal and installation of power train components ......................................6000 7-22540GB
Transmission specifications, pressure checks and troubleshooting ................6002 7-21430GB
Wheels and tyres.............................................................................................6003 7-22550GB
Gear box ..........................................................................................................6007 7-22560GB
Rear axle-four whell steer................................................................................6008 7-21600GB
7 BRAKES
Removal and installation of brake components ...............................................7000 7-23840GB
Disassembly and assembly of brake components...........................................7003 7-23190GB
8 HYDRAULICS
Removal and installation of hydraulic components..........................................8001 7-23210GB
Hydraulic specifications, troubleshooting and pressure checks.......................8002 7-26630GB
Cleaning the hydraulic system.........................................................................8003 7-21520GB
Hydraulic pump and unloader valve.................................................................8004 7-23250GB
Loader control valve.........................................................................................8005 7-23280GB
Cylinders..........................................................................................................8006 7-26120GB
Backhoe control valve......................................................................................8007 7-23290GB
Extending dipperstick control valve..................................................................8008 7-21560GB
Priority demand valve ......................................................................................8010 7-21570GB
9 MOUNTED/EQUIPMENT
Pedals and levers ............................................................................................9001 7-23360GB
Loader..............................................................................................................9006 7-26140GB
Cab and Rops..................................................................................................9007 7-26600GB
Backhoe...........................................................................................................9008 7-26710GB
Seat and seat belt............................................................................................9009 7-23830GB
Removal and installation of components.........................................................9011 7-23850GB

Cre 7-22470GB Issued 11-99

Case Copyright 1999 Case France
Printed in France
November 1999
Cre 7-79451GB
1001
STANDARD TORQUE SPECIFICATIONS
AND LOCTITE PRODUCT CHART
Section
1001

1001-2
Cre 7-79451GB Issued 11-99
TABLE OF CONTENTS
TORQUE SPECIFICATIONS - DECIMAL HARDWARE ..........................................................................................2
TORQUE SPECIFICATIONS - METRIC HARDWARE.............................................................................................3
TORQUE SPECIFICATIONS - STEEL HYDRAULIC FITTINGS...........................................................................4-5
LOCTITE PRODUCT CHART..................................................................................................................................6
TORQUES SPECIFICATIONS
(DECIMAL HARDWARE)
Use the torques in this chart when special torques
are not given. These torques apply to fasteners with
both UNC and UNF threads as received from
suppliers dry, or when lubricated with engine oil. Not
applicable if special graphities, Molydisulfide greases,
or other extreme pressure lubricants are used.
Grade 5 Bolts,
Nuts and Studs
Size Pound-
inches Newton
metres
1/4 inch 8 to 11 12 to 15
5/16 inch 17 to 21 23 to 28
3/8 inch 35 to 42 48 to 57
7/16 inch 54 to 64 73 to 87
1/2 inch 80 to 96 109 to 130
9/16 inch 110 to 132 149 to 179
5/8 inch 150 to 180 203 to 244
3/4 inch 270 to 324 366 to 439
7/8 inch 400 to 480 542 to 651
1.0 inch 580 to 696 787 to 944
1-1/8 inchs 800 to 880 1085 to 1193
1-1/4 inchs 1120 to 1240 1519 to 1681
1-3/8 inchs 1460 to 1680 190 to 2278
1-1/2 inchs 1940 to 2200 2631 to 2983
NOTE :
Use thick nuts with Grade 8 bolts.
Grade 8 Bolts,
Nuts and Studs
Size Pound-
inches Newton
metres
1/4 inch 12 to 15 16 to 20
5/16 inch 24 to 29 33 to 39
3/8 inch 45 to 54 61 to 73
7/16 inch 70 to 84 95 to 114
1/2 inch 110 to 132 149 to 179
9/16 inch 160 to 192 217 to 260
5/8 inch 220 to 264 298 to 358
3/4 inch 380 to 456 515 to 618
7/8 inch 600 to 720 814 to 976
1.0 inch 900 to 1080 1220 to 1465
1-1/8 inchs 1280 to 1440 1736 to 1953
1-1/4 inchs 1820 to 2000 2468 to 2712
1-3/8 inchs 2380 to 2720 3227 to 3688
1-1/2 inchs 3160 to 3560 4285 to 4827

Thanks very much for your reading,
Want to get more information,
Please click here, Then get the complete
manual
NOTE:
If there is no response to click on the link above,
please download the PDF document first, and then
click on it.
Have any questions please write to me:
admin@servicemanualperfect.com

1001-3
Cre 7-79451GB Issued 11-99
TORQUE SPECIFICATIONS
(METRIC HARDWARE)
Use the following torques when specifications are not
given.
These values apply to fasteners with coarse threads
as received from supplier, plated or unplated, or
when lubricated with engine oil. These values do not
apply if graphite or Molydisulfide grease or oil is used.
Grade 8.8 Bolts,
Nuts and Studs
Size Pound-
inches Newton
metres
M4 2 to 3 3 to 4
M5 5 to 6 7 to 8
M6 8 to 9 11 to 12
M8 19 to 23 26 to 31
M10 38 to 45 52 to 61
M12 66 to 79 90 to 107
M14 106 to 127 144 to 172
M16 160 to 200 217 to 271
M20 320 to 380 434 to 515
M24 500 to 600 675 to 815
M30 920 to 1100 1250 to 1500
M36 1600 to 1950 2175 to 2600
Grade 12.9 Bolts, Nuts and Studs
Usually the torque values specified for grade 10.9
fasteners can be used satisfactorily on grade 12.9
fasteners.
Grade 10.9 Bolts,
Nuts and Studs
Size Pound-
inches Newton
metres
M4 3 to 4 4 to 5
M5 7 to 8 9 to 11
M6 11 to 13 15 to 18
M8 27 to 32 37 to 43
M10 54 to 64 73 to 87
M12 93 to 112 125 to 150
M14 149 to 179 200 to 245
M16 230 to 280 310 to 380
M20 450 to 540 610 to 730
M24 780 to 940 1050 to 1275
M30 1470 to 1770 2000 to 2400
M36 2580 to 3090 3500 to 4200
8.8
10.9
12.9

1001-4
Cre 7-79451GB Issued 11-99
TORQUE SPECIFICATIONS
(STEEL HYDRAULIC FITTINGS)
Tube OD
Hose ID Thread
size Pound-
inches Newton
metres
37 Degree
flare fitting
1/4 inch/
6.4 mm 7/16-20 6 to 12 8 to 16
5/16 inch/
7.9 mm 1/2-20 8 to 16 11 to 22
3/8 inch/
9.5 mm 9/16-18 10 to 25 14 to 34
1/2 inch/
12.7 mm 3/4-16 15 to 42 20 to 57
5/8 inch/
15.9 7/8-14 25 to 58 34 to 79
3/4 inch/
19.0 mm 1-1/16-12 40 to 80 54 to 108
7/8 inch/
22.2 mm 1-3/16-12 60 to 100 81 to 135
1.0 inch/
25.4 mm 1-5/16-12 75 to 117 102 to 158
1-1/4 inch/
31.8 mm 1-5/8-12 125 to 165 169 to 223
1-1/2 inch/
38.1 mm 1-7/8-12 210 to 250 285 to 338
Split flange
mounting screws
Size Pound-
inches Newton metres
5/16-18 15 to 20 20 to 27
3/8-16 27 to 40 36 to 53
7/16-14 35 to 45 47 to 61
1/2-13 55 to 65 74 to 88
5/8-11 140 to 150 190 to 203
Tube OD
Hose ID Thread
size Pound-
inches Newton
metres
Straight threads
with O-ring
1/4 inch/
6.4 mm 7/16-20 12 to 19 16 to 26
5/16 inch/
7.9 mm 1/2-20 16 to 24 22 to 34
3/8 inch/
9.5 mm 9/16-18 24 to 40 34 to 54
1/2 inch/
12.7 mm 3/4-16 42 to 67 57 to 91
5/8 inch/
15.9 7/8-14 58 to 92 79 to 124
3/4 inch/
19.0 mm 1-1/16-12 80 to 128 108 to 174
7/8 inch/
22.2 mm 1-3/16-12 100 to 160 136 to 216
1.0 inch/
25.4 mm 1-5/16-12 117 to 187 159 to 253
1-1/4 inch/
31.8 mm 1-5/8-12 165 to 264 224 to 357
1-1/2 inch/
38.1 mm 1-7/8-12 250 to 400 339 to 542

1001-5
Cre 7-79451GB Issued 11-99
TORQUE SPECIFICATIONS
(STEEL HYDRAULIC FITTINGS)
Nom. SAE
dash size Tube OD Thread
size Pound-
inches Newton
metres Thread
size Pound-
inches Newton
metres
O-ring face seal end O-ring boss end fitting
or lock nut
-4 1/4 inch/
6.4 mm 9/16-18 10 to 12 14 to 16 7/16-20 17 to 20 23 to 27
-6 3/8 inch/
9.5 mm 11/16-16 18 to 20 24 to 27 9/16-18 25 to 30 34 to 41
-8 1/2 inch/
12.7 mm 13/16-16 32 to 40 43 to 54 3/4-16 45 to 50 61 to 68
-10 5/8 inch/
15.9 mm 1-14 46 to 56 62 to 76 7/8-14 60 to 65 81 to 88
-12 3/4 inch/
19.0 mm 1-3/16-12 65 to 80 90 to 110 1-1/16-12 85 to 90 115 to 122
-14 7/8 inch/
22.2 mm 1-3/16-12 65 to 80 90 to 110 1-3/16-12 95 to 100 129 to 136
-16 1.0 inch/
25.4 mm 1-7/16-12 92 to 105 125 to 140 1-5/16-12 115 to 125 156 to 169
-20 1-1/4 inch/
31.8 mm 1-11/16-12 125 to 140 170 to 190 1-5/8-12 150 to 160 203 to 217
-24 1-1/2 inch/
38.1 mm 2-12 150 to 180 200 to 254 1-7/8-12 190 to 200 258 to 271

1001-6
Cre 7-79451GB Issued 11-99
LOCTITE PRODUCT CHART
Product
Colour
Similar products
Gap (inches)
Strength (steel/steel)
Working temperature
range-fahrenheit
Fixture/full cure
(steel/steel) time
Primer
Description
#3 Dark
brown 24 h 764 Form a Gasket (works with oil, fuel or
greas) Pliable
80 Yellow Fast 764 Weatherstrip adhesive
123 Clear - - Parts cleaner fluid
220 Blue 290 0.076 65/164
in lbs -54 to +122 6 min/24 h 747 Wicking threadlocker
221 Purple 222 0.127 86/50
in lbs -54 to +150 2 min/24 h 747 Low strength threadlocker
222 Purple 0.127 51/28
in lbs -54 to +150 10 min/24 h 747 Low strength threadlocker (small screws)
225 Brown 222 0.254 51/28
in lbs -54 to +150 7 min/24 h 747 Low strength threadlocker
242 Blue 0.127 92/57
in lbs -54 to +150 10 min/24 h 747 Medium strength threadlocker
262 Red 271 0.127 184/218
in lbs -54 to +150 5 min/24 h 747 High strength threadlocker
270 Green 271 0.177 184/368
in lbs -54 to +150 3 min/24 h 747 High strength threadlocker
271 Red 262 0.177 184/368
in lbs -54 to +150 10 min/24 h 747 High strength threadlocker
272 Red 620 0.254 207/311
in lbs -54 to +234 30 min/24 h 747 High temperature, high strength
275 Green 277 0.254 241/345
in lbs -54 to +150 3 min/24 h 747 High strength threadlocker
277 Red 0.254 241/345
in lbs -54 to +150 60 min/24 h 747 High strength threadlocker
290 Green 0.076 97/403
in lbs -54 to +150 6 min/24 h 747 Wicking threadlocker
*404 Clear 495 0.156 224 psi -54 to +82 30 sec/24 h - Instantadhesive
*406 Clear 0.101 224 psi -54 to +82 15 sec/24 h - Surface insensitive adhesive
*409 Clear 454 0.203 175 psi -54 to +82 50 sec/24 h - Gel instant adhesive
*414 Clear 0.156 175 psi -54 to +82 30 sec/24 h - Instantadhesive
*415 Clear 454 0.254 175 psi -54 to +82 50 sec/24 h - Gap filling instant adhesive (metals)
*416 Clear 454 0.254 175 psi -54 to +82 50 sec/24 h - Gap filling instant adhesive (plastics)
*420 Clear 0.05 175 psi -54 to +82 15 sec/24 h - Wicking instant adhesive
*422 Clear 454 0.05 196 psi -54 to +82 60 sec/24 h - Gap filling instant adhesive
*430 Clear 0.127 175 psi -54 to +82 20 sec/24 h - Metal bonding adhesive
* Products 404-496 (except for #445) are all instant adhesives (super glues) they differ mostly in viscosity.

1001-7
Cre 7-79451GB Issued 11-99
*445 White/
Black 6.35 140 psi -54 to +82 5 min/24 h - Fast setting 2 part epoxy
*454 Clear 0.254 224 psi -54 to +82 15 sec/24 h - Surface insensitive gel instant adhesive
*495 Clear 0.101 175 psi -54 to +82 20 sec/24 h - General purpose instant adhesive
*496 Clear 0.127 175 psi -54 to +82 20 sec/24 h - Metal bonding adhesive
504 Brt orange 515 0.076 52 psi -54 to +150 90 sec/24 h None Rigid gasket eliminator
510 Red 0.05 70 psi -54 to +206 30 min/24 h 764 Hightemperature, gasket eliminator
515 Purple 0.254 52 psi -54 to +150 1 hr/24 h 764 Gasket eliminator 515
518 Red 515 0.076 35 psi -54 to +150 1 hr/24 h 764 Gasket eliminator 578 for aluminum
542 Brown 569 - 152/106
in lbs -54 to +150 2 hr/24 h 747 Hydraulic sealant
545 Purple - 28/23
in lbs -54 to +150 4 hr/24 h 747 Low strength pneumatic/hydraulic sealant
549 Red 504 0.05 175 psi -54 to +150 2 hr/24 h 747 Instant seal plastic gasket
554 White 277 0.381 276/240
in lbs -54 to +150 2 to 4 hr/24 h 764 Refrigerant sealant
567 Orange 592 - 35 psi -54 to +206 4 hr/24 h 764 Pipe sealant for stainless steel
568 Brown 277 0.381 175 psi -54 to +150 12 hr/24 h 764 Plastic gasket
569 Brown 545 0.254 28/46 in lbs -54 to +150 1 hr/24 h 764 Hydraulic sealant
570 Brown 592 - 28/46 in lbs -54 to +150 6 hr/24 h 764 Steam sealant
571 White 592 0.381 46/23 in lbs -54 to +150 2 to 4 hr/24 h 764 Pipe sealant
572 White 578.
575 - 92/31in lbs -54 to +150 24 hr/24 h None Gasketing
592 Black - 0.05 35 psi -54 to +206 4 hr/24 h 736 Pipe sealant with teflon
593 Green - 6.35 28 psi -54 to +206 30 min/24 h - RTV silicone
601 Green 609 0.127 210 psi -54 to +150 10 min/24 h 747 Current PIN #609
609 Green - 0.127 210 psi -54 to +150 10 min/24 h 747 General purpose retaining compound
620 Green 640 0.381 210 psi -54 to +234 30 min/24 h 747 Hightemperature. Retaining coumpound
635 Green 680 0.254 280 psi -54 to +150 1 hr/24 h 747 High strength retaining compound
638 Green 680 0.381 287 psi -54 to +150 10 min/24 h 747 High strength retaining compound
640 Green 620 0.177 210 psi -54 to +206 1 hr/24 h 747 High temperature retaining compound
660 Silver - 0.05 210 psi -54 to +150 20 min/24 h 764 Quick metal
675 Green 609 0.127 210 psi -54 to +150 20 min/24 h 747 General purpose retaining compound
680 Green 635 0.381 280 psi -54 to +150 10 min/24 h 747 High strength retaining compound
706 Clear 755 - - - - - Cleaning solvent
707 Amber - - - - - - Activator for structual adhesives
736 Amber - - - - - - Primer NF
738 Amber - - - - - - Depend activator
Product
Colour
Similar products
Gap (inches)
Strength (steel/steel)
Working temperature
range-fahrenheit
Fixture/full cure
(steel/steel) time
Primer
Description

1001-8
Cre 7-79451GB Issued 11-99
747 Yellow - - - - - - Primer T
751 Clear - - - - - - Activator for structural adhesives
755 Clear - - - - - - Cleaning solvent
764 Green - - - - - - Primer N
767 Silver - - - -54 to +878 - - Anti-seize lubricant
Product
Colour
Similar products
Gap (inches)
Strength (steel/steel)
Working temperature
range-fahrenheit
Fixture/full cure
(steel/steel) time
Primer
Description

Case Copyright 1999 Case France
Printed in France
November 1999
Cre 7-22480GB
1002
FLUIDS AND LUBRICANTS
Section
1002

1002-2
Cre 7-22480GB Issued 11-99
TABLE OF CONTENTS
CAPACITIES AND LUBRICANTS.............................................................................................................................3
ENGINE OIL RECOMMENDATIONS........................................................................................................................4
Oil viscosity/Oil operating range............................................................................................................................4
FLUIDS AND LUBRICANTS .....................................................................................................................................5
Hydraulic fluid........................................................................................................................................................5
Transmission component oil .................................................................................................................................5
Grease ..................................................................................................................................................................5
Anti-freeze/anti-corrosion......................................................................................................................................5
Fuel .......................................................................................................................................................................5
Fuel storage ..........................................................................................................................................................5
ENVIRONMENT........................................................................................................................................................6
PLASTIC AND RESIN PARTS..................................................................................................................................6

1002-3
Cre 7-22480GB Issued 11-99
CAPACITIES AND LUBRICANTS
Engine Oil
Capacity with filter replacement ............................................................................................................. 10.7 litres
Type of oil................................................................................................... refer to “Engine oil recommendations”
Engine cooling system
Capacity ................................................................................................................................................. 16.5 litres
Type of collant solution ..........................................................................................refer to “Fluids and lubricants”
Fuel tank
Capacity .................................................................................................................................................. 120 litres
Type of fuel..............................................................................................................refer to “Fluids and lubricants"
Hydraulic system
Total hydraulic system capacity ................................................................................................................ 90 litres
Hydraulic reservoir filling capacity with filter replacement .........................................................................45 litres
Hydraulic reservoir filling capacity without filter replacement ....................................................................43 litres
Type of fluid ............................................................................................................refer to “Fluids and lubricants”
Transmission
Total system ......................................................................................................................................... 19 litres
Filling with or without filter replacement ............................................................................................... 15litres
Type of oil ....................................................................................................................API cd/se grade 10W30
Front and real Axle
Axle center housing ............................................................................................................................... 8 litres
Axle hubs (each).................................................................................................................................. 4.5litres
Type of oil .............................................................................................................API GL5 grade EP 85 w 140
Brake fluid
Fluid type ..................................................................................................................................LHM brake fluid

1002-4
Cre 7-22480GB Issued 11-99
ENGINE OIL RECOMMENDATIONS
The engine oil to be used depends on the ambient
temperature.
Use only oil of the API/CD category.
NOTE :
Do not put any performance additive or other
additive in the sump. Oil change intervals shown in
this manual are based on tests carried out on lubri-
cants.
Temperate climates
-15°C to +30°C
Oil type SAE 10 w 30
Hot climates
30°C and over
Oil type SAE 20 w 50
Cold climates
Below - 15°C
Oil type SAE 10W
Oil viscosity/Oil operating range
IO36LO
(A) Fahrenheit temperature
(B) Centigrade temperature
A
B

1002-5
Cre 7-22480GB Issued 11-99
FLUIDS AND LUBRICANTS
Fluids and lubricants must have the correct properties for each application.
Hydraulic fluid
Hydraulic fluid is specially designed for the high pres-
sure and the hydraulic system used on machines. The
type of fluid to be used depends on the ambient tem-
perature.
Temperate climates
Below + 30°C
Fluid type : ISO VG 46
Hot climates
30°C and over
Fluid type : ISO VG 68
Transmission component oil
Extreme pressure oil is used for all cased transmis-
sion components.
Extreme pressure oil type API CD/SE.
Grade 10W30
Grease
The type of grease to be used depends on the ambi-
ent temperature.
Temperate and hot climates
-5°C to + 55 °C
Extreme pressure grease EP NLGI.
Grade 2 with molybdenum disulphide.
Cold climates
-20 °C to + 30°C
Extreme pressure grease EP NLGI
Grade 0
Anti-freeze/anti-corrosion
Use anti-freeze in all seasons to protect the cooling
system from corrosion and all risk of freezing.
For environments with a temperature higher than -36°C,
use a mixture of 50% ethylene-glycol based anti-
freeze.
For environments with a temperature lower than -36°C,
a mixture of 40% water with 60% anti-freeze is rec-
ommended.
Fuel
The fuel to be used must be in conformity with the
D975 standard of the American Society for Testing
and Materials (ASTM).
Use No. 2 type fuel. The use of other fuels may cause
a loss of engine power and excessive fuel consump-
tion.
In cold weather, a mixture of No. 1 fuel and No. 2 fuel
is temporarily permitted. Consult your fuel supplier.
If the temperature falls below the fuel cloud point
(point at which wax appears), wax crystals in the fuel
will cause a loss of engine power or make it impossi-
ble to start the engine.
IMPORTANT :
In cold weather, fill the fuel tank after
each day’s work, to prevent the formation of conden-
sation.
Fuel storage
Prolonged fuel storage causes foreign bodies or con-
densation water to accumulate in the storage tank.
Many engine failures are caused by the presence of
water in fuel.
The storage tank should be placed outdoors and the
fuel should be kept at as low a temperature as possi-
ble. Condensation water should be drained off at reg-
ular intervals.
WARNING :
The condition of use for individual fluids and lubricants must be respected.
!

1002-6
Cre 7-22480GB Issued 11-99
ENVIRONMENT
Before carrying out any maintenance operation on
the machine and before disposing of used fluids or
lubricants, always think of the environment. Never
throw oil or fluid on the ground and never put them in
leaky receptacles.
Consult a local recycling or environmental centre, to
obtain information on the correct method of disposing
of these materials.
PLASTIC AND RESIN PARTS
When cleaning plastic windows, the console, the instrument panel, the gauges, etc, avoid the use of petrol, paraffin,
paint solvents, etc. Use only water, soap and a soft cloth.
The use of petrol, paraffin, paint solvents, etc will cause discoloration, cracks or deformation of these parts.

Case Copyright 1999 Case France
Printed in France
October 1999
Cre 7-21290GB
2000
ENGINE AND RADIATOR
REMOVAL AND INSTALLATION
Section
2000

2000-2
Cre 7-21290GB Issued 10-99
TABLE OF CONTENTS
SPECIFICATIONS.....................................................................................................................................................3
SPECIAL TORQUE SETTINGS................................................................................................................................3
TOOLS REQUIRED ..................................................................................................................................................3
RADIATOR REMOVAL .............................................................................................................................................4
PERSPECTIVE VIEW...............................................................................................................................................6
ENGINE REMOVAL..................................................................................................................................................7
INSTALLATION.......................................................................................................................................................13
WARNING :
This symbol is used in this manuel to indicate important safety messages. When ever you see
this symbol, carefully read the message that follows, as there is a risk of serious injury.
!

2000-3
Cre 7-21290GB Issued 10-99
SPECIFICATIONS
Cooling System capacity :
System capacity ..................................................................................................................................................9.8 L
Expansion reservoir capacity..................................................................................................................................1 L
Engine/Radiator capacity.....................................................................................................................................6.6 L
Coolant solution...............................................................................................................................See section 1002
SPECIAL TORQUE SETTINGS
Torque converter mounting bolts...................................................................................................................... 41 Nm
Engine mounting bolts............................................................................................................................ M16 280 Nm
Engine mounting nuts............................................................................................................................... M10 48 Nm
Transmission mountings......................................................................................................................... M12 140 Nm
M20 395 Nm
TOOLS REQUIRED
Engine lifting bracket
This manual suits for next models
1
Table of contents
Other Case Compact Loader manuals
