Casio V-REGI Series User manual

V-REGI series
Store support system
Standard package
Sales management
Programming and Reference Manual
V-R7000
V-R100
1

2
Preface
Document warranty
The information contained in this document is subject to change without notice.
CASIO Computer Co., Ltd. makes no warranty of any kind with regard to this material,
including, but not limited to the implied warranties of marketability and fitness for a
particular purpose. CASIO Computer Co., Ltd. shall not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this manual.
This manual was written for the following equipment.
•Casio V-R7000 (Display: 15.6 in. WXGA color TFT LCD 1366 × 768)
•Casio V-R100 (Display: 10.4 in. SVGA color TFT LCD 800 × 600)
And illustrations of the screen described, may differ from the actual product in this
document. Icon or key has been described in a simplified manner.
* In this document, a common specification part is described as "V-REGI terminal".
This manual includes confidential information of Casio Computer Co., Ltd.
Carefully handle it.
Images and statements contained in this book may differ from what is actually displayed, depending on the software
version.

i
Table of Contents
1............................................................................................................................ 1BEFORE USING
1.1 ...........................................................................................1ABOUT V-REGI SALES MANAGEMENT
1.2 ..................................................................................................................2SALES DATA LOCATION
1.3 .............................................................................................................................3MAINTENANCE
1.4 ..................................................................................................................................3OPERATION
1.5 .....................................................................................................................4TROUBLE SHOOTING
2........................................................................................................................................ 6INSTALL
2.1 ............................................................................................................................6ABOUT INSTALL
2.2 ......................................................................................................................7START INSTALL APP
2.3 ......................................................................................................................9NEW INSTALLATION
2.4 ...................................................................................................................................15UPGRADE
2.5 .................................................................................................................16INITIALIZE DATABASE
2.6 .......................................................................................................................18UNINSTALLATION
2.7 .................................................................................................19V-T500 INSTALL AND FUNCTION
3...................................................................................................................................... 24SETTING
3.1 ..........................................................................................................................24ABOUT SETTING
3.2 ...................................................................................................................25SETTING OPERATION
3.3 ......................................................................................................26USEFUL SETTING OPERATION
3.4 .............................................................................................................................27RESTART APP
4............................................................................................................................ 28ITEM SETTING
4.1 .................................................................................................................28ABOUT ITEM SETTING
4.2 ..........................................................................................................................28ITEM SETTINGS
4.3 .....................................................................................................................29ITEM DEPARTMENT
4.4 ...............................................................................................................................30ITEM GROUP
4.5 .....................................................................................................................31ITEM PARAMETERS
4.6 ..................................................................................................................................33SET MENU
4.7 .........................................................................................................................34MIX AND MATCH
4.8 ...................................................................................................................................36NON PLU
4.9 .......................................................................................................................37NOT FOUND PLU
5.................................................................................................................. 38FUNCTION SETTING
5.1 ......................................................................................................................38ABOUT FUNCTION
5.2 ..........................................................................................................................38FUNCTION KEY
5.3 .........................................................................................................................54FUNCTION CODE
6......................................................................................................................... 57CLERK SETTING
6.1 ..............................................................................................................57ABOUT CLERK SETTING
6.2 .........................................................................................................................57CLERK SETTING
6.3 ............................................................................................................................58CLERK GROUP
6.4 ..............................................................................................................60CLERK CONSOLIDATION

7..................................................................................................................... 61RECEIPT SETTING
7.1 .........................................................................................................................61ABOUT RECEIPT
7.2 .....................................................................................................................61RECEIPT MESSAGE
7.3 ...........................................................................................................................62PRINT LAYOUT
8............................................................................................................ 64KEY (LAYOUT) SETTING
8.1 ...................................................................................................................64ABOUT KEY LAYOUT
8.2 ..............................................................................................................................65KEY LAYOUT
9...................................................................................................................... 69OTHERS SETTING
9.1 ....................................................................................................................69GENERAL FEATURE
9.2 ................................................................................................................................82CHARACTER
9.3 .....................................................................................................................................83PRINTER
9.4 ........................................................................................................................84CUSTOMER TYPE
9.5 ..........................................................................................................................................85TARE
9.6 ......................................................................................................................86ANALYSIS REPORT
9.7 ..............................................................................................................................90TAX MASTER
9.8 .................................................................................................................................91SCHEDULE
9.9 ...............................................................................................................93CURRENCY EXCHANGE
9.10 .................................................................................................................95ITEM CLASSIFICATION
9.11 .........................................................................................................................96SELECTIVE ITEM
9.12 ...................................................................................................................97REPORT CHARACTER
9.13 ....................................................................................................................98ORDER CHARACTER
9.14 .....................................................................................................................99RECEIVE CONTROL
10 ........................................................................................................................ 100DB SETTINGS
10.1 ...............................................................................................................100ABOUT DB SETTINGS
10.2 ...........................................................................................................100DB SETTING OPERATION
10.3 ..................................................................................................102DB SETTING AND BLOB DATA
10.4 ......................................................................................103DB SETTING AND ARRANGE SCENARIO
11 ................................................................................................................ 105DB MANAGEMENT
11.1 ........................................................................................................105ABOUT DB MANAGEMENT
11.2 ........................................................................................105BACKUP,RELOAD AND FILE FORMAT.
12 .................................................................................................................. 107CONTROL PANEL
12.1 ...........................................................................................................107ABOUT CONTROL PANEL
12.2 ................................................................................................................107INLINE AND PRINTER
12.3 ..................................................................................................................................108VERSION
12.4 ....................................................................................................................................108SYSTEM
13 ..................................................................................................................... 109GRAPHIC LOGO
13.1 .............................................................................................................109ABOUT GRAPHIC LOGO
13.2 ..................................................................................................... 110HOW TO CREATE LOGO DATA
13.3 ....................................................................................................... 111COPY GRAPHIC LOGO DATA
13.4 .................................................................................................. 112SETTING GRAPHIC LOGO DATA
ii

13.5 ....................................................................................................................... 113SET TO PRINTER
13.6 ............................................................................................................ 114PRINT LAYOUT SETTING
14 .................................................................................................................... 116OPTION DEVICE
14.1 ............................................................................................................. 116ABOUT OPTION DEVICE
14.2 ....................................................................................................... 117COM (RS-232C) SCANNER
14.3 ......................................................................................................................... 118USB SCANNER
14.4 ................................................................................................................................... 119PRINTER
14.5 ..................................................................................................................121CUSTOMER DISPLAY
15 ................................................................................................................... 122APP OPERATION
15.1 ................................................................................................................................122START APP
15.2 .............................................................................................................122AUTOMATIC START APP
15.3 ...........................................................................................................................123RESTART APP
15.4 ..............................................................................................................................124FINISH APP
15.5 .........................................................................................................................124SHUTDOWN OS
15.6 ..................................................................................................................124APPS VERSION LIST
16 ............................................................................................................................. 125SET MENU
16.1 .....................................................................................................................125ABOUT SET MENU
17 ................................................................................................................... 126MIX AND MATCH
17.1 ............................................................................................................126ABOUT MIX AND MATCH
18 ............................................................................................................................. 127SCANNING
18.1 ..................................................................................127ABOUT ITEM CODE AND SCANNING CODE
18.2 .......................................................................................................127NFP（NOT FOUND PLU）
18.3 .................................................................................................................................128NON PLU
19 ................................................................................................................ 129CHECK TRACKING
19.1 ..........................................................................................................129ABOUT CHECK TRACKING
19.2 ................................................................................................................................130FUNCTION
19.3 ..............................................................................................134CHECK TRACKING MASTER DOWN
20 ................................................................................................................. 136ORDER PRINTING
20.1 ................................................................................................................................136SET MENU
21 ............................................................................................................... 139INLINE FUNCTION
21.1 .........................................................................................................139ABOUT INLINE FUNCTION
21.2 ...............................................................................................................................140INLINE X/Z
21.3 .............................................................................................................140INLINE SETTING TRANS
21.4 .......................................................................................................141TERMINAL INLINE SETTING
22 .............................................................................................................. 143CLERK OPERATION
22.1 ......................................................................................................................143TRAINING CLERK
23 ......................................................................................................................... 145ERROR CODE
iii

iv
23.1 ..........................................................................................................................145ABOUT ERROR
23.2 .................................................................................145CASH REGISTER OPERATION ERROR CODE

1 Before using
1.1About V-REGI Sales management
V-REGI Sales management (Cash register application) is a application that works
on V-REGI terminals. V-REGI Sales management has new concept that combines
the advantages of POS and cash register. It has following characteristics.
V-REGI Sales management works on the open platform.
V-REGI Sales management has sales detail database.
V-REGI Sales management has add-in interface.
V-REGI Sales management works on the open platform (Android OS).
V-REGI Sales management has both device control of cash register and specific
new technologies and screen, media, and network.
V-REGI Sales management has sales detail database.
Previous Cash register prints repor of summer that came from totalizer in advance.
V-REGI Sales management has saved the cash register registration history (sales
details database) instead of the totalizer. Report prints database consolidation data
came from sales detail database.
V-REGI Sales management has add-in interface.
V-REGI Sales management is not the only prepared function by Casio but also
function you developped.
V-REGI Sales management data base has two types, one is
setting and another is sales detail data. You can operate with
explanation of this document, if there is knowledge of
database applications and SQL, you can develop an
application that performs the analysis of sales data from the
detailed data yourself. Please get the datakit for your better
business.
V-REGI Sales management offers add-in kit for your original
system development. Please get add-in kit and have ideas for
your better system.

1.2Sales data location
V-REGI Sales management has setting database and sales detail database. Setting
database is located inside terminal memory. Sales detail database is located inside
terminal until Z, after Z it will be move to SD card (Internal Storage). EJ also same.
V-R100 copy Z sales data to outside SD card. Outside SD card strage mount
is ”/mnt/sdcard”.
V-R7000 or V-T500 copy Z sales data to Internal Storage. Internal Storage mount
is ” /storage/sdcard0/” that is same as ”/mnt/sdcard”.
V-R100 body
Today’s
EJ
Settings
Sales Z
SD card
EJ
Z
Z sales data
Outside
V-R7000 or V-T500 body
Today’s
EJ
Settings
Z sales data
Z
EJ
Internal Storage
Sales Z
2

1.3Maintenance
Perform unmount operation before extracting an SD card (USB memory).
Android operating system caches data when reading or writing SD card (USB
memory) data. If you do not unmount the SD card and extract it, the cache data is
not written back to the USB memory causing to damage the SD card. Android
operating system unmounts memory devices when it is shut down.
When you insert an SD card (or USB memory), make sure that it is mounted.
SD card (or USB memory) may not be mounted automatically when you insert it.
Especially in maintenance operations, please confirm whether the SD card is
mounted or not when you insert or extract it before the operation. On V-R100, Z
report data is not stored in an SD card if it is not mounted.
SD card (USB memory) is not unmounted just by the main power switch off.
SD card (or USB memory) is not unmounted when you turn the main power switch
off without unmounting it. SD card may be damaged if you turn the powe switch off
and extract it without unmounting.
Especially, the SD card (USB memory) is damaged with high probability if you
change it without unmounting after the power off.
Shut down the system after using the Machine.
If V-R100 or V-R7000 is not used for a while, do not turn the power off without
shutting down the system. Please shut the system down then turn the power off.
Otherwise an unmounted SD card or USB memory may be damaged.
1.4Operation
Do not turn the mains power off during a finalization or a Z report operation.
The unit updates the database of details during finalization operation (from
finalization key depression to receipt issue completion). Do not turn the power off
while finalization operation is in process.
Also during Z report operations (from starting Z report operation to completing Z
report print), the unit creates sum data from the database of details. Therefore
please do not turn the mains power off during Z reporting operations.
It is necessary to mount an SD card for storing Z report data.
For V-R100, Even an SD card is inserted in the card slot of the unit, Z report data is
not stored if it is unmounted. If an message noticing that an SD card is not inserted
is shown, please confirm that an SD card is inserted.
V-R7000 or V-T500 has Internal Storage then you do not have to care it.
3

Avoid using Return key of Android.
To finish the sales management system, finish it by the sales management’s ending
operation on the top menu. Do not finish the sales management system or return to
Android system using Return or Home keys of Android system.
Update the sales data periodically.
Before Z reporting, sales data of sales management system is stored in the main
unit and in an SD card (Internal Storage) after Z reporting as a database file. As a
characteristic of Android system and SD card (Internal Storage) file system, there is
a risk of inability to read stored files. Please back up important data to SD card or
USB memory periodically.
Recommendation of shutting Android system down
As a characteristic, Android system reduces the resource if it is not shut down for
long time causing troubles such as reducing operation speed. To avoid this, we
recommend to shut the Android system down at the end of business day.
Sales management system is affected by other installed applications
Sales management system is operated as one of Android system applications.
Although it is possible for Android system to install other application than sales
management system, abnormal termination may occur at finalizations or Z reporting.
It is because the application consumes a large amount of Android resources and the
sales management system cannot access to the file system.
Hardreset may damage the file system
When Android system or an application does not respond, you might hard reset the
system. However, a hardreset may cause a damage of Android system or a file
system of an SD card. Please do not hard reset the system easily.
Press Hold when an ANR dialog is shown.
When an ANR (Android Not Responding) dialog such as “xxx is not responding.” Is
shown, press Hold key. If the same message is shown repeatedly, press Forced
termination key.
1.5Trouble shooting
Operation log
Sales management system records cash register operations such as booting up of
the system, key operations, errors, or notification (Android broadcast) over time as
operation log. It is useful for trouble shooting by analyzing time or operation of
trouble occurrence.
4

Operation logs use two 2 megabytes files alternately and when the logs are stored
by a certain amount, the old logs are discarded.
Operation logs can be backed up in an SD card (Internal Storage) by the operation
log menu. When a trouble is occurred, back up the operation logs in an SD card
(Internal Storage) before trouble shoot.
Android logCat
On boot, sales management system records Android logCat in the log folder of an
SD card (Internal Storage). As Android logCat stores operation data in the OS level,
further data than the operation log may be recorded.
As the contents of Android logCat are general terms of Android system, you may
find the meaning of the log by an internet search. We recommend that you retrieve
the keyword on the internet.
Please note that the log capacity of Android logCatg is small and the log is erased
by shutdown or reboot of Android system. Latest Android version of VX-100 and
V-R700 are equipped with a feature that manages logs by an Android setting
application.
5

2 Install
2.1About install
All Installation (or initialize) is operated by the installation app (InstallTool.apk). If
cash register application is running, please once finish the application.
Installation app features the following functions.
Fresh installation of an application
Update of an application
Initialization of a database
Uninstallation of an application
Select “New Install Application and Database” for new introduction.
To upgrade an application, select “Upgrade Application”.
Use “Install Database” for data operation such as database initialization without
changing an application.
Select “Uninstall Application and Database” when you install an application.
“Application” in this manual mean the sales management
application provided from Casio Computer Co., Ltd.
Though a dialog that urge checking of Android settings will
appear on boot of the installation app, ignore it and proceed by
selecting “OK”.
V-T500 installation is different. Please see another explanatin.
6

2.2Start Install App
The following install files are necessary for installing sales management system.
InstallTool.apk : Installation app body
APL.zip : A file in which installation applications are gathered
Install applications by following the undermentioned procedures.
① Preparation of install file
Prepare the install file and copy it in a storage (SD card or USB memory). Copy
destination is either root folder or any folder.
② Insert the storage in the main unit.
Insert the SD card or USB memory in any storage of V-R100 or V-R7000.
③ Install the installation app.
Boot file manager (VX-100 or VX-110) or Open manager (V-R7000) and select
“InstallTool.apt” to install it.
④ Installation of sales management application
Boot the installation app and select APL.zip from a storage to install the sales
management application. Refer the following table for the corresponding storage.
VX-100/VX-110 storage list
Dev. Loc. File manager Android setting Device name
SD Right side /mnt/sdcard SD card /mnt/sdcard
USB Right side /mnt/usb USB storage /mnt/usb
V-R7000 storage list
Dev. Location File manager Android setting Device name
Built
-in
InternalStorate Internal storage /storage/emulated/0/...
/storage/emulated/legacy/...
/storage/sdcard0/..
SD Bottom SD Card 1 SD card 1 /storage/sdcard1/..
Left side SD Card 2 SD card 2 /storage/sdcard2/..
USB Left side USB Storage 1 USB storage 1 /storage/usb0/..
Bottom USB Storage 2 USB storage 2 /storage/usb1/..
7

it is also possible (including update, and initialize) start the
installation application on the home screen.
Once installation app is installed,
The installation app (InstallTool.apk) itself, are also included in
the APL.zip and also installation app it’s self is overwritten
automatically installed when you install the APL.zip.
The installation app Icon is displayed on the Android home
screen. It means anyone can install or initialize database who
find the icon. If you think this situation is no good, you can
uninstall installation app from Android settings.
After you uninstalled the installation app, if you want to
initialize database, please re-install the installation app and
use it.
8

2.3New installation
2.3.1Operation
New installation of an application overwrites the existing application and initializes
the database.
To install new application, prepare “APL.zip” in a storage and boot the install app
then select “New Install Application and Database”.
When you select “New Install Application and Database”, “Select install file” screen
will be shown. Select the storage in which install file “APL.zip” is stored on “Browse”
screen.
Next, the display shows “Select industry type” screen.
Industry type selection is for choosing initial value of database settings at
installation. However, do not select demonstration in case of customer setting.
New Install Application and Database
9

Industry type list
Industry Action
Table service Demonstration For general demonstration. An item such as a beer will be
shown and you can continue the demonstration.
Support panel Demonstration For a V-R7000 demonstration with a support panel which
displays web screen on the right. Please do not use on
models V-R100.
Standard for item automatic
layout
Automatic item PLU key arrangement.
Automatic layout of item PLU keys on the screen.
It arranges PLU keys automatically according to linking
departments. Locations and layout order of keys change
automatically by department settings.
Standard for item manual
layout
Manual layout of item PLU keys.
Manual layout arranges key locations of screens
manually.
OES template Arranges a key which recalls a slip from OES.
sing Execute key displays a confirmation dialog and starts the installation.
You need to input a license after the installation.
Input item ID and license code on “License management” screen.
You can close the installation without license input. In that case, please input the
license on boot of the sales management application.
When license is inputted and new installation is overwritten, you may use the sales
management application without re-inputting the license. Item ID and license code
of the license is inherited.
10

Depending on V-R100, old version application (e.g.3.1.3.F)
may be installed. Even in such case you can overwrite the
installation as is.
If new version components are different from old version, some
old application is still in side. Please delete those application
from Android settings .
You cannot install this latest version of sales management
application (setting) to update version 3.x sales management
system. Please do not upgrade but install it newly. You can
migrate settings of version 3.x partially by using PC tool
(V-REGI setting tool). Please refer to PC tool manual.
New installation recognizes present (at the time of installation
operation ) language, hardware, and vertical/horizontal of
screen automatically. Please set language and hardware to be
used before installation. Database language is not changed
after the installation even you change Android language.
11

2.3.2About Support panel Demonstration
On V-R7000, web screen area is provided on the right side of the screen if you
install an application by “Support panel Demonstration”. By default, it accesses to
http://www.casio.com. If you wish to change the URL, change CSB021 (Screen
layout setting).
For changing URL:
In DB setting, retrieve the following layout XML BLOB data and change it. After the
change, return it to CSB021 table. Please refer “About DB setting and BLOB data”.
Data
CSB021 Screen layout setting
Control type classification：WINDOW
Control type：Register Transaction Window
Correction place
Change Label="http://www.casio.com/" to any URL.
About CASIO Web control specification.
WEB control version
WebKit 534.30
Control property
JavaScript: true (Ver4.3.0+)
mWebView.getSettings().setJavaScriptEnabled(true);
WebView for background app: true
mWebView.setBackgroundDrawable(info.mDrawable);
Other properties are WebView default.
CASIO control specification
Screen size - fixed
[Return] button – not implemented
URL entry area – not implemented
New window – not implemented
Upload files – not implemented
Download files – not implemented
Pop up – not implemented
Proxy – not implemented
Plug-in – not implemetend
Flash Player – not implemented
12

Web display of the support panel does not correspond to
proxy.
Support panel may not support all of Web screen, function.
Before using on site, please check Web screen carefully.
The Web screen of support panel uses Android WebKit
technology. Support panel Web function depends on WebKit
specification.
It cannot be used on V-R100 if it is installed by Support panel
Demonstration.
13

2.3.3About vertical screen
V-R7000 features vertical display screen by Android setting.
If V-R7000 Android OS is set as vertical screen, the application is installed with
vertical screen automatically. To restore to horizontal screen, set Android setting to
horizontal screen and then install the sales management application.
Vertical screen is a new CASIO concept. Please try it.
There is no vertical screen setting on V-R100.
