Casio 2128 Configuration guide

2128-1
Module No. 2128
GENERAL GUIDE
•Press CC
CC
Cto change from mode to mode.
•In any mode (except when making settings) press LL
LL
Lto illuminate the display for about 1.5 seconds.
TIMEKEEPING MODE
•Press BB
BB
Bto switch the display as shown below.
Time and Date Hands (Analog) Time and pendulum
•The display type you select is used until you change it.
To set the time and date
1.While in the Timekeeping Mode, hold down AA
AA
Auntil the seconds digits flash on the
display.
2.Press CC
CC
Cto change the selection (flashing) in the following sequence.
Seconds DST City Code Hour Minutes
Day Month Year 12/24-Hour Format
3.While the seconds setting is selected (flashing), press BB
BB
Bto reset it to 00. If you
press BB
BB
Bwhile the seconds setting is in the range of 30 to 59, the seconds are reset
to 00 and 1 is added to the minutes. If the seconds setting is in the range of 00 to
29, the minutes count is unchanged.
•While the DST (Daylight Saving Time) setting is select-
ed, press BB
BB
Bto toggle it on and off.
•While the 12/24-hour format setting is selected, press
BB
BB
Bto toggle it between 12 and 24.
•While any other setting (besides seconds) is selected
(flashing), press BB
BB
Bto increase it or LL
LL
Lto decrease it.
•Holding down either button changes the setting at high
speed.
4.After you set the time and date, press AA
AA
Ato return to the
Timekeeping Mode.
•The day of the week is automatically set in accordance
with the date.
•The date can be set within the range of January 1, 1995 to December 31, 2039.
•If you do not press any button for a few minutes while a setting is flashing, the
flashing stops and the watch goes back to the Timekeeping Mode automatically.
•The current time for all other World Time cities are adjusted in accordance with the
Timekeeping Mode settings you make.
ABOUT THE BACKLIGHT
•In any mode (except when making any settings), press LL
LL
Lto illuminate the display
for about 1.5 seconds.
•The backlight of this watch employs an electro-luminescent (EL) light, which loses
its illuminating power after very long term use.
•Frequent use of the backlight shortens the battery life.
•The watch emits an audible sound whenever the display is illuminated. This does
not indicate malfunction of the watch.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
Timekeeping Mode World Time Mode Data Bank Mode Stopwatch Mode
Seconds
Hour : Minutes
Seconds Hour Minutes Pendulum
Seconds
Day of weekDay
AM/PM indicator
(
AM: not flashing
PM: flashing
)
DST on indicator
WORLD TIME MODE
The World Time Mode shows the current time in any one of 27 different cities. See
the “CITY CODE TABLE” for information about city codes, time zones, etc.
You cannot use the World Time Mode to change the time setting. The time, city, and
DST (Daylight Saving Time) on/off settings you make in the Timekeeping Mode are
applied to all the World Time cities.
•Press BB
BB
Bto scroll through the city codes. Holding down
BB
BB
Bscrolls at high speed.
•Pressing AA
AA
Acauses the upper part of the screen to tog-
gle between the date and time.
•Holding down AA
AA
Atoggles DST (Daylight Saving Time)
for the displayed city on and off.
DATA BANK MODE
The Data Bank Mode lets you store up to 30 name and telephone number records.
You can recall data by scrolling it on the display.
You can input up to eight characters for the name and 14 digits for the number. When
the name is longer than five characters or when the phone number is longer than
seven digits, the data automatically scrolls across the display.
The scroll operation continues for about two or three minutes and then stops. To start
scrolling again, press BB
BB
B.
•When you enter the Data bank Mode, the initial screen appears first, followed by
the number of empty record areas remaining, and then the data record that was
displayed when you last exited the Data bank Mode.
•If memory is full, the message “FULL” appears in place of the number of empty
record areas. When this happens, you can input more data only if you first delete
records no longer need.
Mode indicator Hour : Minutes Seconds Month - Day Year
Press AA
AA
A.
City code
DST on indicator
Number area
Name area
Mode indicator Remaining memories

2128-2
To input new Data Bank data
1.In the Data Bank Mode, press BB
BB
Buntil the screen showing the number of empty
record areas appears.
•If there is no Data Bank data stored in memory yet, the screen showing the number
of empty record areas appears as soon as you enter the Data Bank Mode.
2.Hold down AA
AA
Aand a cursor appears.
3.Use BB
BB
Bor LL
LL
Lto input a character at the cursor position. The character changes in
the following sequence. Holding down either button changes the character at high
speed.
A ~ Z 0 ~ 9 (Space) Press . Press .
4.After you select the character you want, press CC
CC
Cto advance the cursor to the right.
•Repeat 3 and 4 until you complete name input.
•You can input up to 8 characters in the name area.
5.After the name input is through, use CC
CC
Cto move the cursor to the telephone number
area.
6.While the cursor is in the telephone number area, use BB
BB
Bor LL
LL
Lto input a number
you want. The character changes in the following sequence. Holding down either
button changes the character at high speed.
0 ~ 9 (Space)
Press . Press .
7.After you select the character you want, press CC
CC
Cto advance the cursor to the right.
•Repeat 6 and 7 until you complete telephone number input.
8.After inputting your data, press AA
AA
Ato store it.
•When you press AA
AA
Ato store data, the message “SORT” appears on the display for a
few seconds. After the sort operation is complete, the cursor appears in the name
area, ready for input next record. Input next record or press AA
AA
Ato exit the new data
input procedure.
•If you do not operate any button for a few minutes while a setting is flashing, the
message “SORT” appears on the display for a few seconds. After the sort operation
is complete, the watch goes back to the Data Bank Mode automatically.
To recall Data Bank data
In the Data Bank Mode, press BB
BB
Bto scroll forward through stored records.
•Holding down BB
BB
Bscrolls through the data at high speed.
To edit Data Bank data
1.In the Data Bank Mode, scroll through the records and display the one you want to
edit.
2.Hold down AA
AA
Auntil a cursor appears in the name area.
3.Use CC
CC
Cto move the cursor to the character you want to change.
4.Change the character using BB
BB
Bor LL
LL
L.
•See “To input new Data Bank data” for details.
5.After making the changes you want, press AA
AA
Ato store the record.
•When you press AA
AA
A, the message “SORT” appears on the display for a few sec-
onds. After the sort operation is complete, the watch goes back to the Data Bank
Mode automatically.
•If you do not operate any button for a few minutes while a setting is flashing, the
message “SORT” appears on the display for a few seconds. After the sort operation
is complete, the watch goes back to the Data Bank Mode automatically.
To delete Data Bank data
1.In the Data Bank Mode, scroll through the records and display the one you want to
delete.
2.Hold down AA
AA
Auntil a cursor appears in the name area.
3.Press BB
BB
Band LL
LL
Lat the same time to delete the record.
•At this time the message “CLEAR” appears on the display for a few seconds and
the cursor appears in the name area, ready for input.
4.Input new data or press AA
AA
Ato exit the delete procedure.
•If you do not operate any button for a few minutes while a setting is flashing, the
watch goes to the screen that shows the number of empty record areas automati-
cally.
STOPWATCH MODE
The Stopwatch Mode lets you measure elapsed
time, split times, and two finishes. The range of
the stopwatch is 59 minutes, 59.99 seconds. In
the stopwatch mode, press LL
LL
Lto illuminate the
display for about 1.5 seconds.
Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split Split release Stop Clear
Start Split Stop Split release Clear
Split time measurement
Split time and 1st-2nd place times
First runner
finishes. Second runner finishes.
Record time of
first runner.
Record time of
second runner.
Mode indicator
Rotates once per second
Minutes Seconds 1/100 second
– – –
HNL
ANC
LAX
DEN
CHI
NYC
CCS
RIO
– – –
– – –
GMT
LON
PAR
CAI
JRS
JED
THR
DXB
KBL
KHI
DEL
DAC
RGN
BKK
HKG
TYO
ADL
SYD
NOU
WLG
HONOLULU
ANCHORAGE
LOS ANGELES
DENVER
CHICAGO
NEW YORK
CARACAS
RIO DE JANEIRO
LONDON
PARIS
CAIRO
JERUSALEM
JEDDAH
TEHRAN
DUBAI
KABUL
KARACHI
DELHI
DHAKA
YANGON
BANGKOK
HONG KONG
TOKYO
ADELAIDE
SYDNEY
NOUMEA
WELLINGTON
–11
–10
–9
–8
–7
–6
–5
–4
–3
–2
–1
+00
+01
+02
+03
+3.5
+04
+4.5
+05
+5.5
+06
+6.5
+07
+08
+09
+9.5
+10
+11
+12
PAGO PAGO
PAPEETE
NOME
SAN FRANCISCO, LAS VEGAS,
VANCOUVER, SEATTLE,
DAWSON CITY
EL PASO, EDMONTON
HOUSTON, DALLAS/FORT WORTH,
NEW ORLEANS, MEXICO CITY,
WINNIPEG
MONTREAL, DETROIT, MIAMI,
BOSTON, PANAMA CITY,
HAVANA, LIMA, BOGOTA
LA PAZ, SANTIAGO,
PORT OF SPAIN
SAO PAULO, BUENOS AIRES,
BRASILIA, MONTEVIDEO
PRAIA
DUBLIN, LISBON, CASABLANCA,
DAKAR, ABIDJAN
MILAN, ROME, MADRID,
AMSTERDAM, ALGIERS,
HAMBURG, FRANKFURT,
VIENNA, STOCKHOLM, BERLIN
ATHENS, HELSINKI, ISTANBUL,
BEIRUT, DAMASCUS,
CAPE TOWN
MOSCOW, KUWAIT, RIYADH,
ADEN, ADDIS ABABA, NAIROBI
SHIRAZ
ABU DHABI, MUSCAT
MALE
MUMBAI, CALCUTTA
COLOMBO
JAKARTA, PHNOM PENH, HANOI,
VIENTIANE
SINGAPORE, KUALA LUMPUR,
BEIJING,TAIPEI,MANILA,PERTH,
ULAANBAATAR
SEOUL, PYONGYANG
DARWIN
MELBOURNE, GUAM, RABAUL
PORT VILA
CHRISTCHURCH, NADI,
NAURU ISLAND
CITY CODE TABLE
*Based on data as of June 1999.
City Code City GMT
Differential Other major cities in same time zone
