USER’S GUIDE G’MIX 5A
1
•If you do not perform any operation for a few minutes while a setting screen (with
flashing digits) is on the display, the watch automatically exits the setting screen.
•If you do not perform any operation for a few minutes in any mode besides Stop-
watch Mode, the watch automatically reverts to the normal timekeeping screen.
Alarm Mode Stopwatch Mode Memo Mode
General Guide
•Press Cto change from mode to mode.
•Pressing Ein any mode besides the Alarm Mode illuminates the display for about
three seconds. The backlight is disabled while a setting screen is on the display.
Timekeeping Mode Day Counter Mode
Press C.
Timekeeping Mode
Press Dto toggle between 12-hour and 24-hour time-
keeping.
•With 12-hour timekeeping, times between midnight and
noon are indicated by A(am), while times between noon
and midnight are indicated by P(pm).
•The Aand Pindicators do not appear for 24-hour time-
keeping.
•Pressing Bplays a randomly selected melody. To stop
a playing melody, press any button besides E.
•Pressing Ewhile a melody is playing toggles the dis-
play between an animated character and the name of
the melody.
•Press Eto illuminate the display for about three sec-
onds. When 12-hour timekeeping is being used, press-
ing Ealso displays an animated character.
Month
Day of week
Day
PM indicator
Hour
Minutes
Seconds
DST indicator 2
Timekeeping Mode Settings
In addition to settings for the current time and date, the Timekeeping Mode setting
screen also lets you turn button tones and melody play on and off, adjust tones and
melody volume, and adjust display contrast.
To make Timekeeping Mode settings
1. While in the Timekeeping Mode, hold down Auntil the second’s digits flash on the
display, indicating the setting screen.
2. Press Cto move the flashing in the sequence shown below. Press Eto move
the flashing in the opposite direction.
Seconds DST Hour Minutes Year
Contrast
(CNT)Volume (VOL)Sound (SOUND)MonthDay
Press . Press .
3. While the second’s setting is selected (flashing), press
Dor Bto reset it to 00.
•If you press Dor Bwhile the second’s setting is in the
range of 30 to 59, the seconds are reset to 00 and 1 is
added to the minutes. If the second’s setting is in the
range of 00 to 29, the minute’s count is unchanged.
•While the DST∗(Daylight Saving Time) setting is se-
lected, press Dor Bto toggle it on and off.
•DST indicator 1 is displayed in the Timekeeping Mode
setting screen only when the DST setting is selected. It
shows ON when the DST setting is on, and OFF when
the DST setting is off.
•DST indicator 2 is displayed in the Timekeeping Mode,
Day Counter Mode and Alarm Mode when the DST set-
ting is turned on.
∗Daylight Saving Time (DST), which is also sometimes
called “summer time” advances the time for one hour, as
is the custom in some areas during the summer. Re-
member that not all countries or even local areas use
Daylight Saving Time.
•While the SOUND (button tones) setting is selected, press Dor Bto turn the
beep and musical tone on and off, as shown below.
•Changing the SOUND also changes the Hourly Time Signal tones.
Beep Musical tone Off
Press . Press .
• While the VOL setting is selected, press D or B to toggle it between loud and soft.
Loud Soft
Press or .
•With some models, changing the volume setting affects volume very little.
•While the CNT setting is selected, press Dto make the display darker, or Bto
make it lighter.
•While any other setting is selected (flashing), press Dto increase it or Bto de-
crease it. Holding down either button changes the setting at high speed.
4. After you make the settings you want, press Ato exit the setting screen.
•The day of the week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 2000 to December 31, 2039.
•The watch's built-in full automatic calendar automatically makes allowances for dif-
ferent month lengths and leap years.
Once you set the date, there should be no reason to change it except after the
replacement of the watch's battery.
DST indicator 2
DST indicator 1
About the Backlight
Pressing Ein any mode besides the Alarm Mode illuminates the display for about
three seconds. The backlight is disabled while a setting screen is on the display.
•The backlight of this watch employs an electro-luminescent (EL) light, which loses
its illumination power after very long term use.
•Frequent use of the backlight shortens battery life.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The backlight automatically turns off an alarm sounds.
•The watch emits an audible sound whenever the display is illuminated. This does
not indicate malfunction.
Day Counter Mode
Mode indicator
Day counter
record number
Text
Number of days DAYS indicator
Year
Month
Day
Target Date
The Day Counter Mode lets you count the number of days from the Timekeeping
Mode’s current date to a specific target date.
•There are five Day Counter records, each of which can be assigned up to 12 char-
acters of text and a target date.
•When a target date is reached, the DAYS indicator flashes on the display in the
Timekeeping Mode. The DAYS indicator also flashes in the Day Counter Mode
when the screen for the target date is on the display.
•The DAYS indicator flashes on the target date each year, regardless of the year
setting of the target date.
•The initial default date for a Day Counter record is 2001/1/1, and the text area
contains All spaces. (All spaces for the text display a series of hyphens “–––––”.)
Recalling Day Counter Data
In the Day Counter Mode, press Dto scroll through the Day Counter record screens.
•The day count is a negative value whenever the target date comes before the cur-
rent date.
To set the target date
1. In the Day Counter Mode, press Dto display a record number you want to set.
2. Hold down Auntil the first (leftmost) text character starts to flash on the display.
This indicates the input screen.
3. Press Cto move the flashing in the sequence shown below. Press Eto move
the flashing in the opposite direction.
Press . Press .
Character 1
Day
Character 12
YearMonth
4. While the flashing is located within the text area, use Dor Bto scroll through
characters at the current location of the flashing. Holding down either button scrolls
through characters at high speed.
Press . Press .
Space A to Z Punctuation Japanese
characters
Hyphen SymbolsNumbers
∗See the “CHARACTER LIST” for details.
5. While any other setting is selected, press Dto increase it or Bto decrease it.
Holding down either button changes the setting at high speed.
•Pressing Dand Bat the same time while the flashing is located within the text
area clears any input text and resets the date setting to the current date. At this
time the message “CLEAR” appears on the display.
•Pressing Dand Bat the same time while the flashing is located within the date
area resets the date setting to the current date without affecting the text.
6. After you make the settings you want, press Ato exit the input screen.
•The date can be set within the range of January 1, 1940 to December 31, 2039.

USER’S GUIDE G’MIX 5A
2
Alarm Mode
Mode indicator
Alarm number
Melody name
Hour Minutes
Current time
You can set up to five melody alarms. When a daily alarm is turned on, its melody
alarm sounds for about 20 seconds at the preset time each day. In the Timekeeping
Mode, press any button (except E) to stop the melody alarm after it starts to sound.
Pressing Ewhile a melody is playing toggles the display between an animated char-
acter and the name of the melody that is playing. When the Hourly Time Signal is
turned on, the watch beeps every hour on the hour.
To set the alarm time
1. While in the Alarm Mode, press Dto display the alarm number you want to set.
Alarm 1 Alarm 5Alarm 2 Alarm 3 Alarm 4
SIG: 00 (Hourly Time Signal)
2. Hold down Auntil the melody setting starts to flash on the display, indicating the
setting screen. The alarm is automatically turned on at this time.
3. Press Cto change the selection in the sequence shown below.
Melody Setting Hour Minutes
4. While melody setting is selected, use Dor Bto scroll through melody names.
Setting Alarm Sound
– 0
– 1
– 2
– 3
– 4
– 5
–
Random play of melodies 1, 2, 3, 4 and 5
Melody 1
Melody 2
Melody 3
Melody 4
Melody 5
Beeper
Press .
Press .
∗See the “MELODY LIST” for the names of melodies.
∗Some melody alarms tune names may be displayed in abbreviated format.
•While any other setting is selected, press Dto increase it or Bto decrease it.
Holding down either button changes the setting at high speed.
5. After you make the settings you want, press Ato exit the setting screen.
•The format (12-hour and 24-hour) of the alarm time matches the format you select
for normal timekeeping.
•When setting the alarm time using the 12-hour format, take care to set the time
correctly as morning or afternoon.
To stop a melody alarm
•Press any button (except E) to stop a melody alarm after it starts to sound.
To turn a daily alarm or the Hourly Time Signal on and off
1. Use Dto display the alarm you want to turn on or off, or the screen for turning the
Hourly Time Signal on or off.
2. Press Bto toggle the displayed alarm or Hourly Time Signal on and off.
•Alarm indicator 1 is displayed in the Alarm Mode only.
It indicates the on/off status of the currently displayed
alarm only. Note that this indicator is used for different
purposes in other modes.
•Alarm indicator 2 is displayed in all modes when any of
the five alarms is turned on.
•Alarm indicator 3 is displayed in the Alarm Mode only.
It shows on when the currently displayed alarm is on,
and OF when the currently displayed alarm is off.
Alarm indicator 1
Alarm indicator 2
Alarm indicator 3
•Hourly Time Signal indicator 1 is displayed in the Alarm
Mode only when the Hourly Time Signal is turned on.
Note that this indicator is used for different purposes in
other modes.
•Hourly Time Signal indicator 2 is displayed in all modes
when the Hourly Time Signal is turned on.
•Hourly Time Signal indicator 3 is displayed in the Alarm
Mode only. It shows on when the Hourly Time Signal is
on, and OF when the Hourly Time Signal is off.
To test the alarm
In the Alarm Mode, display the alarm you want to sound,
and then press Eto play its melody or beep. You can
also press Eto play an alarm’s melody while setting the
alarm time.
•To stop a playing melody or beep, press any button.
Hourly Time Signal
indicator 1
Hourly Time Signal
indicator 2
Hourly Time Signal
indicator 3
Stopwatch Mode
The Stopwatch Mode lets you measure elapsed time, split
times, and two finishes. The range of the stopwatch is
23 hours, 59 minutes, 59.99 seconds. You can use the
EL backlight by pressing Eat any time while the stop-
watch is operating.
Mode indicator
Hours
Minutes
Seconds
1/100 second
Current tim
e
Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split Split release Stop Clear
Start Split Stop Split release Clear
Split time measurement
Split time and 1st-2nd place times
First runner
finishes. Second runner finishes.
Record time of
first runner.
Record time of
second runner.
Memo Mode
The Memo Mode lets you store up to five memos, each
with an eight-character title and 16 characters of data.
Recalling a Memo
In the Memo Mode, press Dto scroll through the Memo
titles. When you find the title you want, press B, and the
screen alternates between the title and data.
•The display can show only five characters at a time.
Longer text scrolls continuously from right to left. The
symbol “ ” indicates that the character or digit to the
left is the last, and the character or digit to the right is
the first.
•A series of hyphens “ – – – – – ” is displayed for a memo
that does not contain any data.
Mode indicator
Memo number
Title
To input a memo
1. In the Memo Mode, press Dto display the memo number you want to set.
2. Hold down Auntil the first (leftmost) character of the memo title starts to flash on
the display. This indicates the input screen.
3. Press Cto move the flashing in the sequence shown below. Press Eto move
the flashing in the opposite direction.
Press . Press .
Title Character 8
Data Character 1
Title Character 1
Data Character 16
4. Use Dor Bto scroll through characters at the current location of the flashing.
Holding down either button scrolls at high speed.
Press . Press .
Space A to Z Punctuation Japanese
characters
Hyphen SymbolsNumbers
∗See the “CHARACTER LIST” for details.
•Pressing Dand Bat the same time while inputting memo title or data clears all
title and data. At this time the message “CLEAR” appears on the display.
5. After you input the data you want, press Ato exit the input screen.
Character List

USER’S GUIDE G’MIX 5A
3
Melody List
2252 Displayed Melody Name Song Name
1BEST OF MY LOVE Best of my love
2SEPTEMBER September
3DSCHINGHIS KHAN Dschinghis khan
4NEVER GONNA …Never gonna give you up
5ISHOULD BE SO …I should be so lucky
2449 Displayed Melody Name Song Name
1HONEY Honey
2ALL FOR YOU All for you
3EVERYDAY IS • • • Everyday is a winding road
4BABY ONE MORE • • • …Baby one more time
5DON’T TELL ME Don’t tell me
2560 Displayed Melody Name Song Name
1DEAREST Dearest
2TRAVELING traveling
3YOU GO YOUR WAY You Go Your Way
4FRAGILE fragile
5REMAIN remain
2489 Displayed Melody Name Song Name
1PIECES OF • • • PIECES OF A DREAM
2MY ALL. . my all..
3KISS OF LIFE KISS OF LIFE
4THE ONLY ONE The Only One
5I’M HERE SAYING • I’m here saying nothing
2624 Displayed Melody Name Song Name
1IWANT YOU BACK I want you back
2I’M EVERY WOMAN I’m every woman
3MANIC MONDAY Manic monday
4DON’T GET ME • • • Don’t get me wrong
5BREAKOUT Breakout
