CASPR CATransit21 User manual

Owner’s Manual
CAUTION: Read manual carefully for proper procedures and operation.
TRANSIT
Air & Surface Disinfection
4155 S ROBERT TRL
SAINT PAUL MN 55123
[email protected]
Phone / Fax: [phone]

2
About TRANSIT
Congratulations on your purchase of the CASPR TRANSIT!
CASPR TRANSIT eectively renders bacteria, viruses, mold, mildew and other
contaminants in the air, and on surfaces, harmless. CASPR TRANSIT has the added
benet of eliminating odors to help create a cleaner, safer environment.
CASPR TRANSIT is powered by 24VDC and was designed to be used in motor
coaches or any other vehicle that requires 24VDC. If requested, CASPR TRANSIT
can be outtted with a 120-240VAC power adapter.
CASPR TRANSIT utilizes Natural Catalytic Converter (NCC) technology that
generates advanced oxidation products (AOPs), primarily consisting of hydro-
peroxides, or vaporized hydrogen peroxide. NCC technology replicates natures
purifying process through the use of ultraviolet energy to activate a multi-metal
catalyst, converting water vapor into oxidizers including peroxide and hydroxyls.
These oxidants will either inactivate the microbe by the process of cell lysing which
compromises the cellular integrity by oxidation penetrating the cell wall, or by
changing the molecular structure rendering the contaminant harmless.
In this owner’s manual, you will nd instructions for installation, usage and
maintenance. If you have any additional questions, please do not hesitate to reach
out to your CASPR authorized distributor, or contact [email protected].
Table of Contents
Specications.............................................................................................. 3
Warnings.................................................................................................... 3
Unit Diagrams............................................................................................. 4
Installation ................................................................................................. 5
Filter Replacement....................................................................................... 6
Cleaning the Unit......................................................................................... 6
NCC Cell Replacement.................................................................................. 7
Cell Disposal ............................................................................................... 8
Troubleshooting........................................................................................... 8
Replacement parts (purchased separately): .................................................... 8
Warranty Information................................................................................... 9

3
Specications
TRANSIT 120V TRANSIT 12V
Weight 3.5 lbs 3.5 lbs
Dimensions
(WxLxH)
9” x 10” x 2.6”
11” x 12” x 2.6” (ush mount)
9” x 10” x 2.6”
11” x 12” x 2.6” (ush mount)
Electrical Input
100-240VAC 50/60Hz 1.8A
277VAC 50/60Hz 0.9A
(277VAC - North America only)
9-36VDC 1.5A
Air ow (CFM) 17.9 17.9
Noise (dBA) 48 48
Please record the name and phone number of your CASPR Distributor.
Name:
Phone#:
Please record the serial number of your product:
Serial #:
Warnings
WARNING: Electrical shock may occur. Hard-wired Installations should be
handled by a licensed professional.
WARNING: Never service the unit while it is connected to a power source.
Electrical shock or injury may occur.
NOTE: A slight odor may be noticeable when the unit is rst installed
and operated. This is due to the newness of the UV bulb being used and
the initial cleaning of the contaminated space. The odor is completely
harmless.

4
Unit Diagrams
Unit Front
Air Outlet
Filter
Unit Back
Security
Mounting Holes
Unit Internals
NCC Cell
Flush Mounting Bracket

5
WARNING
Risk of property damage, injury, or death.
Installation, adjustments, alterations, and service must be
performed by a qualied electrician.
WARNING
Electrical Shock Hazard.
Can cause injury or death. Disconnect all electrical
power supplies before servicing.
Installation
Before installation, identify wiring routes in order to select the most optimal
location for this install.
All electrical wiring should be done by a licensed technician or mechanic that has
experience locating and wiring low voltage.
Flush Mount Installation
1. Cut hole where the unit will be inset into the wall.
Unit is 9” x 10” x 2.6”.
2. Place unit into the cut hole.
3. Use self-tapping screws to attach the unit to the
surface.
4. Connect wiring into the 24VAC or the 12VAC power source.
Surface Mount Installation
1. Identify where the unit will be placed / Cut hole for wire (If needed)
2. Attach the unit ush to the surface that is being installed.
3. Connect wiring into the 24VAC or 12 VAC power sources.

6
Filter Replacement
Filter replacement is recommended every 90 days or when noticeably
contaminated. Service should only be performed by a qualied technician.
WARNING: Never service the unit while it is connected to a power source.
Electrical shock or injury may occur. Make sure the power switch is turned
OFF and the unit is unplugged prior to handling.
1. Disconnect unit from power source.
2. Remove the Filter Cover Plate from the unit.
Filter
3. Remove the used Filter.
4. Replace with the new Filter (Red side facing out).
5. Replace the Filter Cover Plate.
6. Reconnect unit to power source.
Cleaning the Unit
The unit will need to be cleaned occasionally, We recommend wiping it down each
time you replace the lter.
WARNING: Never service the unit while it is connected to a power source.
Electrical shock or injury may occur. Make sure the power switch is turned
OFF and the unit is unplugged prior to handling.
1. Disconnect unit from power source.
2. Remove the Cover from the unit.
3. Wipe everything down with a damp cloth.
4. Replace the Cover of the unit.
5. Reconnect unit to power source.

7
NCC Cell Replacement
Your NCC Cell should be replaced every 1 year.
WARNING: Never service the unit while it is connected to a power source.
Electrical shock or injury may occur.
WARNING: Please do not throw a used NCC Cell in the garbage. See “Cell
Disposal” on page 8 for more information.
1. Disconnect unit from power source.
2. Remove the Cover from the unit.
3. Unscrew the bracket assembly
holding the NCC Cell in place and
lift it up out of the case.
4. Unscrew the Cell housing and
remove it.
5. Disconnect the bulb.
Dispose of the used bulb appropriately. Do NOT throw it in the trash. See “Cell
Disposal” on page 8 for more information.
6. Remove the new Cell Assembly from the packaging box.
7. Carefully remove bulb from cell housing.
DO NOT touch the bulb with bare hands.
8. Connect Bulb
to socket in the
Bracket Assembly.
9. Attach Cell Housing to
bracket with previously
removed screws (2).
10. Install Assembly on
TRANSIT unit and
secure with two thumb
screws.
11. Replace the Cover.
12. Reconnect unit to power source.

8
Cell Disposal
Do not throw a used NCC Cell in the garbage. The special germicidal UVC bulb
used in the unit contains a very small amount of mercury. Dispose of the spent
NCC Cell and UV Lamp at your local recycling center or by local regulations. To
learn more, visit www.lamprecycle.org.
Troubleshooting
If your NCC Cell or CASPR TRANSIT fan does not turn on, check to ensure a secure
connection. If secure, but the fan is not on, it may need to be replaced. If the
connection is secure but the cell does not light up, the NCC cell or ballast may
need to be replaced. If problems occur within one-year of purchase, contact your
CASPR authorized distributor with your serial number. If after the one-year mark,
your CASPR authorized distributor can sell replacement parts, as required. If you
are unsure of your CASPR authorized distributor, please contact info@casprgroup.
com.
Replacement parts (purchased separately):
NCC Cell (Ozone-Free) Item #CELL-HV-5-001-AP-TR
Filter Item #CA450769011

9
Warranty Information
Your CASPR TRANSIT and replacement parts, excluding the lters, are warranted
to be free from all defects in material and workmanship in normal use for a period
of one (1) year from date of purchase. The warranty is granted only to the original
purchaser.
The warranty is subject to the following provisions:
Any damages or malfunctions caused by negligence, abuse, or use not in
accordance with the Product Owner’s Manual are not covered by this warranty.
Likewise, any defects or damages caused by unauthorized service or the use of
other than CASPR Group parts are not covered.
CASPR Group will, at its option, repair or replace a defective part(s) for the CASPR
TRANSIT that is/are covered by this warranty. As a matter of warranty policy,
CASPR Group will not refund the customer’s purchase price.
Obtaining Warranty Service
To obtain warranty service you must return the defective product along with
proof of purchase to the CASPR Group. All shipping costs submitted under this
Warranty shall be borne by purchaser. Unless this Warranty is expressly renewed
or extended by the CASPR Group, any repaired or replaced part of unit shall be
warranted to the original purchaser only for the length of the unexpired portion of
the original warranty.
For more information on warranties, please email warr[email protected].
Before any product is sent for service, the customer should contact their
authorized CASPR distributor to obtain a Return Merchandise Authorization (RMA)
Number. This RMA Number should be clearly written on the box before shipping.
All components/parts including the remote (if applicable), manuals, and original
packaging should be included in the return if available.
Further Limitations and Exclusions Are As Follows
Any warranty that may be implied in connection with your purchase or use of the
CASPR TRANSIT, including any warranty of merchantability or any warranty for
Fitness For A Particular Purpose is limited to the duration of this warranty. Some
states do not allow limitations on how long an implied warranty lasts, so the above
limitations may not apply to you.
Your relief for the breach of this warranty is limited to the relief expressly provided
above. In no event shall the CASPR Group be liable for any consequential or
incidental damages loss follow instructions. The company will not be responsible
for any written or oral statements made that are inconsistent with this written
warranty, or which are misleading or inconsistent with the facts as or limitation of
incidental or consequential damages, so the above limitation or exclusion may not
vary from state to state.

10
This equipment has been tested and
found to comply with the limits for
Industrial, Scientic, and Medical
Equipment (ISM), pursuant to
Part 18 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy, and if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television,
which can be determined by turning
the equipment o and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit dierent from
that to which the receiver is
connected.
• Consult the Independent HVAC
Contractor or an experienced
radio/TV technician for help.
FCC DECLARATION OF CONFORMITY
Name: CASPR Group
Model: CATransit21
Manufacturer: CASPR Group.
This device complies with Part 18 of the
FCC Rules.
RESPONSIBLE PARTY
CASPR Group, Inc
4505 Excel Parkway, #600
Addison, TX 75001
Ph: [phone]
Date: June 2021
V. 01062021
