Cateye CC-RS100W Troubleshooting guide

Appendix
3
1
4
2
CATEYE
QUICK
CYCLOCOMPUTER
CC-RS100W
1
•
This instruction manual is subject
to change without notice. See our
website for the latest instruction
manual (PDF).
• For details on mounting and
setup, see the Quick Start Manual
(Web).
Setting up the QUICK
Mounting the QUICK
Starting measurement
Changing settings
Warning / Caution
Product Warranty, etc.
SearchCATEYE QUICK

Appendix
3
4
2
1
(1/3)
2.5
Tightening torque
recommendation
0.5 N•m (50 N•cm)
2
Mounting the QUICK
1 Mount the bracket
Adjust the mounting angle so that the
back side of the QUICK faces the speed
sensor.
Correct Wrong
Bracket Bracket rubber pad Speed sensor
Sensor rubber pad
ø25 to 26 mm
Bracket
+
Bracket rubber pad
Bracket
Handlebar diameter
ø31.8 mm
Nylon tie (x 2)Magnet

Appendix
3
4
2
1
(2/3)
3
SENSOR ZONE
SENSOR ZONE
Max.
70 cm
Mounting the QUICK
2 Mount the speed sensor
Mount the speed sensor in a po-
sition where the distance from
the QUICK to the speed sensor is
within the signal range.
3 Mount the magnet
Speed sensor
CutSensor rubber pad
Nylon tie
Pull tight
• Mounting on left front fork
• Mounting on right front fork
To sensor zone
Spoke
Magnet

Appendix
3
4
2
1
(3/3)
4
SENSOR ZONE
SENSOR ZONE
5 mm
Mounting the QUICK
5 Attach/detach the QUICK
6 Test operation
After attaching the QUICK, rotate the front wheel gently to check that current speed
is displayed on the QUICK.
If the speed is not displayed, refer to the attachment conditions in steps 1, 2, and 4
again.
4 Adjust the speed sensor and the magnet
The magnet passes through
the speed sensor zone.
The clearance between the
speed sensor and the magnet
is within 5 mm (3/16”).
* The magnet may be mounted at any position on spoke as long as attachment
conditions are satisfied.
Click
Magnet
Sensor zone
Speed sensor
Speed sensor
Magnet
Release button
Mount Detach

Appendix
3
1
4
2
(1/2)
When using the
QUICK for the
first time, con-
figure the initial
settings.
5
AC
MODE
MENU
AC
Battery
case cover
MODE
MODE
1 Clear all data.
Press the AC button on the back of the QUICK.
* All data is deleted and the QUICK is reset to its
factory default settings.
2 Select the measurement unit.
Select “km/h” or “mph”.
3 Set tire circumference.
Enter the tire circumference of the front
wheel in mm. (100 – 3999 mm)
* Refer to “Tire circumference” (page 6).
4 Set the clock.
Each time MODE is pressed and held,
settings switch from time display mode,
to hours, to minutes.
5 Press MENU to complete setup.
Setup is completed and the QUICK switches to the measure-
ment screen.
For instructions on how to start measurement, refer to
“Starting measurement” (page 7).
MODE
MODE
(Back side)
MENU
(Back side)
MENU
(Back side)
MENU
MODE
MODE
MODE
Setting up the QUICK
km/h ↔mph
Confirm
Increase numbers
Move to next digit
(Press and hold)
Confirm
Setup complete
Switch between 24h and
12h or increase numbers
Switch setting item or
move to next digit
(Press and hold)
Time display mode
MinutesHours
Short press
Long press
(2 sec.)

Appendix
3
1
4
2
(2/2)
6
Tire circumference
Tire circumference can be determined by either of the following two methods:
• Measure the actual tire circumference (L)
After ensuring that the tire pressure is appropriate, sit on your
bike, roll it forward so that the tire makes one full revolution (use
the valve or other marking as a reference), and measure the dis-
tance traveled on the road.
• Tire size chart
* The tire size or ETRTO code is indicated on the side of the tire.
ETRTO Tire size L (mm)
47-203 12x1.75 935
54-203 12x1.95 940
40-254 14x1.50 1020
47-254 14x1.75 1055
40-305 16x1.50 1185
47-305 16x1.75 1195
54-305 16x2.00 1245
28-349 16x1-1/8 1290
37-349 16x1-3/8 1300
32-369 17x1-1/4 (369) 1340
40-355 18x1.50 1340
47-355 18x1.75 1350
32-406 20x1.25 1450
35-406 20x1.35 1460
40-406 20x1.50 1490
47-406 20x1.75 1515
50-406 20x1.95 1565
28-451 20x1-1/8 1545
37-451 20x1-3/8 1615
37-501 22x1-3/8 1770
40-501 22x1-1/2 1785
47-507 24x1.75 1890
50-507 24x2.00 1925
54-507 24x2.125 1965
25-520 24x1(520) 1753
24x3/4 Tubular 1785
28-540 24x1-1/8 1795
32-540 24x1-1/4 1905
25-559 26x1(559) 1913
32-559 26x1.25 1950
37-559 26x1.40 2005
40-559 26x1.50 2010
47-559 26x1.75 2023
50-559 26x1.95 2050
54-559 26x2.10 2068
57-559 26x2.125 2070
58-559 26x2.35 2083
ETRTO Tire size L (mm)
75-559 26x3.00 2170
28-590 26x1-1/8 1970
37-590 26x1-3/8 2068
37-584 26x1-1/2 2100
650C Tubular 26x7/8 1920
20-571 650x20C 1938
23-571 650x23C 1944
25-571 650x25C 26x1(571) 1952
40-590 650x38A 2125
40-584 650x38B 2105
25-630 27x1(630) 2145
28-630 27x1-1/8 2155
32-630 27x1-1/4 2161
37-630 27x1-3/8 2169
40-584 27.5x1.50 2079
50-584 27.5x1.95 2090
54-584 27.5x2.1 2148
57-584 27.5x2.25 2182
18-622 700x18C 2070
19-622 700x19C 2080
20-622 700x20C 2086
23-622 700x23C 2096
25-622 700x25C 2105
28-622 700x28C 2136
30-622 700x30C 2146
32-622 700x32C 2155
700C Tubular 2130
35-622 700x35C 2168
38-622 700x38C 2180
40-622 700x40C 2200
42-622 700x42C 2224
44-622 700x44C 2235
45-622 700x45C 2242
47-622 700x47C 2268
54-622 29x2.1 2288
56-622 29x2.2 2298
60-622 29x2.3 2326
Setting up the QUICK
L mm

Appendix
1
4
2
3
(1/2)
7
MODE
MODE
MODE
MODE
MODE
MODE
* The average speed displays .E instead of the measurement value when the moving
time exceeds approximately 28 hours or the trip distance exceeds 1000 km. In this
situation, the data must be reset.
Switching current function
Pressing MODE switches the current function displayed at the bottom of the screen.
Starting measurement
On the measurement screen, press MENU to go to the menu
screen. Various settings can be changed on the menu screen.
[Measurement screen]
Current speed
0.0 (4.0) – 99.9 km/h
[0.0 (3.0) – 62.0 mph]
Measurement unit
Current function
Av Average Speed (*)
0.0 – 99.9 km/h
[0.0 – 62.0 mph]
Mx Maximum Speed
0.0(4.0) – 99.9 km/h
[0.0(3.0) – 62.0 mph]
Tm Moving Time
0:00’00” – 9:59’59”
Dst Trip Distance
0.00 – 999.99 km [mile]
Odo Total distance
0.0 – 9999.9 /
10000 – 99999 km [mile]
Clock
0:00 – 23:59
or 1:00 – 12:59
(Back side)
MENU
Icon Description
Sensor signal icon
Flashes in sync with the sensor
signal.
Pace arrows
Indicates whether the current
speed is faster ( ) or slower ( )
than the average speed.

Appendix
1
4
2
3
(2/2)
8
(2 seconds)
Starting/stopping measurement
Measurement starts automatically when the
bicycle moves.
During measurement the measurement unit
(km/h or mph) flashes.
Resetting data
Pressing MODE for 2 seconds when on the measurement screen
resets all measurement data to 0 (excluding Odo).
Starting measurement [Measurement screen]
MODE
Power-saving function
If the QUICK does not receive any
signal for 10 minutes, the pow-
er-saving screen is activated and
only the clock is displayed.
If MODE is pressed or a sensor
signal is received while the pow-
er-saving screen is activated, the
QUICK returns to the measurement
screen.
* When the QUICK is left on the
power-saving screen for one
hour, the display enters the sleep
state and only shows the mea-
surement unit. When the QUICK
is in this state, you can return
to the measurement screen by
pressing MODE.
MODE
Measurement starts Measurement stops
1 hour
10 minutes
Automatic
return
Sleep
Power-saving screenMeasurement screen

Appendix
3
1
2
4
(1/4)
9
MODE
MODE
MODE
MODE
Changing settings
On the measurement screen, press MENU to go to the menu screen.
Various settings can be changed on the menu screen.
* After changing settings, always press MENU to confirm changes.
* When the menu screen is left on for 1 minute, the QUICK returns to the measurement screen.
[Menu screen]
Tire circumference
Set the tire circumference.
(0100 – 3999 mm)
* Refer to “Tire circumference” (page 6) for
tire circumferences.
Manual distance input
Clock
Select measurement
unit
MODE
Increase numbers
MODE
Increase numbers
MODE
Increase numbers
MODE
Increase numbers
Measurement
screen Menu screen Description
(Back side)
MENU
(Back side)
MENU
(Back side)
MENU
Confirm
(Press and hold)
MODE
(Press and hold)
MODE
(Press and hold)
MODE
Change setting
(Press and hold)
MODE
(Press and hold)
MODE

Appendix
3
1
2
4
(2/4)
10
MODE
MODE
MODE
MODE
Changing settings
Clock
Set the clock.
Manual distance input
Tire circumference
Select measurement
unit
MODE
MODE
Increase numbers
MODE
Increase numbers
Menu screen Description
Measurement
screen
[Menu screen]
12h ↔ 24h
Select display
Set “hours”
Set “minutes”
(Back side)
MENU
(Back side)
MENU
(Press and hold)
MODE
(Press and hold)
MODE
(Back side)
MENU
Confirm
Change setting
(Press and hold)
MODE
(Press and hold)
MODE
