Cateye Loop 2 SL-LD140RC-R User manual

4
3
Light unit USB cable
(MICRO USB)
WARNING!!!
• Do not use a damaged rubber band.
• Always attention to the remaining battery
power by checking the indicator periodically
while using.
CAUTION!
• Stop your bicycle to operate the switch.
• Keep the light away from children.
• This product is water-resistant under normal
daily use and can be used in the rain. However,
do not intentionally submerge it in water.
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mA (USB2.0) USB
battery charger.
•
Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 5 and 40°C (41°F and 104 °F).
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
• Do not subject the light to vibrations while
charging.
• When your PC is in sleep state, the unit
cannot be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging and lighting times are approximate
values, and will vary by environmental and
user conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place the
light inside a vehicle or near a heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service
life. Dispose of the battery as described in
“PRECAUTIONS ON DISPOSAL” .
Cautions on storage
Cool and dry storage is recommended. For long
period storage, it is important to charge the
battery 1 hours every 6 months.
Cautions for dispose
When disposing of the light unit, remove the
internal rechargeable battery and dispose of it
according to local regulations.
The light will turn on in the lighting mode previously selected.
* When the remaining battery power is low, the indicator beside the switch turns on.
Charge the product as soon as possible.
Click
ONOFF
Click
Lighting mode switch
Press and hold
Flashing Constant
Approx. 2.5 h Approx. 10 h
ClickClick
Attach securely in the mounting position.
ø22 mm〜
〜ø32 mm
HOW TO CLOSE THE CHARGE JACK COVER
2
1
USB cable
To PC or USB battery charger
Charge jack cover
Standard charging time
Approx. 3 h(USB2.0)
Always charge the product before use.
HOW TO CHARGE
1
HOW TO MOUNT
2
SWITCH OPERATION
3
Charging Charging is completed
Indicator
SL-LD140RC-R
Manual
ENG
Design Pat. Pending
Copyright© 2017 CATEYE Co., Ltd.
SLLD140RCR-170516 5
Before using the product, please thoroughly
read this manual and keep it for future
reference.

SPARE/OPTIONAL PARTS
Battery : Rechargeable lithium-ion battery (80 mAh)
Temperature range : 14 °F – 104 °F (-10 °C – 40 °C)
Recharge/discharge number of times
: About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight : 1-7/64” x 1-7/64” x 1-1/16” (28 x 28 x 27 mm) /
0.63 oz (18 g) (Including batteries)
* The specifications and design are subject to change without notice.
5442560
Attachment band
5342730
USB cable
(MICRO USB)
5441621
Rubber band and Hook
SPECIFICATIONS LIMITED WARRANTY
2-year Warranty: Light unit only
CatEye products are warranted to be free of defects from materials and
workmanship for a period of 2 years from original purchase. If the
product fails to work during normal use, CatEye will repair or replace the
defect at no charge. Service must be performed by CatEye or an
authorized retailer. To return the product, pack it carefully and enclose the
warranty certificate (proof of purchase) with instruction for repair. Please
write or type your name and address clearly on the warranty certificate.
Insurance, handling and transportation charges to CatEye shall be borne
by person desiring service.
For UK and REPUBLIC OF IRELAND consumers, please return to the place
of purchase. This does not affect your statutory rights.
Please register your CatEye product on the website.
http://www.cateye.com/en/support/regist/
2-8-25, Kuwazu, Higashi Sumiyoshi-ku,
Osaka 546-0041 Japan
Attn : CATEYE Customer Service Section
Phone : [phone]
Fax : [phone]
E-mail : [email protected]
URL : http://www.cateye.com
CO., LTD.
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200,
Boulder CO 80301-5494 USA
Phone : [phone]
Toll Free : 800.5.CATEYE
Fax : [phone]
E-mail : [email protected]
