CCS LNSP-UV3-FN Series Manual

LNSP-UV3-FN / LNSP-VL3-FN Series
Ultraviolet LED Lights
Instruction Guide
Conrming Product Information2
Caution
Do not drop the Light Unit or
subject it to impact. Doing so may
cause the Light Unit to malfunction.
PROHIBITED
Do not use any cable other than
the dedicated cable. Doing so
may cause malfunctioning. MANDATORY
ACTIO NS
Be careful of static electricity.
Damage to the LED light may
occur, if a person charged with
static electricity touches it. Keep
the product away from all items
charged with static electricity.
PROHIBITED
Always ground the FG line. If you
do not ground the FG line, the
Light Unit may be damaged by
static electricity.
MANDATORY
ACTIO NS
Due to the structure of the Light Unit, leak current may be produced as the
result of AC amplitude noise. This may cause the LEDs to radiate incorrectly.
Separate the Light Unit from sources of noise.
MANDATORY
ACTIO NS
These products have been designed with full consideration of safety.
However, incorrect usage of the products may result in re, electric shock,
or other serious damages. Please ensure to follow the conditions below.
Always use the specied Control Unit for this product. Operation will not
be possible if you connect to any other power supply or Control Unit.
The following symbols are used in this instruction guide to indicate and
classify the relative importance of warnings and cautions.
Warning
Indicates that incorrect
usage may result in
serious injury or death.
Caution
Indicates that incorrect
usage may result in injury
or property damage.
Important Information for Equipment Safety
- Read Before Use -
1
The following symbols in the instruction guide indicate and classify the precautions.
These symbols indicate prohibited actions. This symbol indicates required actions.
DISASSEMBLY
PROHIBITED
DO NOT SUBJECT
TO MOISTURE
DO NOT TOUCH
WITH WET HANDS
MANDATORY
ACTIO NS
PROHIBITED
Please install the Light Unit to locations with following conditions.
Incorrect installation location may cause Light Unit failure.
• In a flat and stable location with
minimal vibration.
• Well-ventilated places with minimal dust.
• Places that are not subject to sudden
temperature changes.
• Places away from water faucets, boilers, humidiers, air conditioners, heaters, or stoves.
• Places free from any water, oil, liquid,
chemical, or steam.
• Places with su󰀩cient airow to cool the product.
• Places free from corrosive or combustible
gas.
Do not use the Light Unit in the following situations.
• Under conditions or in an environment not described in this Instruction Guide.
• In nuclear energy control systems, railroad systems, aviation systems, vehicles,
combustion equipment, medical equipment, amusement machines, or safety equipment.
• In applications involving serious risk to life or property, particularly applications
demanding a high level of safety.
Ultraviolet Curing and
Industrial Inspection
Thank you for purchasing a CCS product. To ensure proper use of the product,
please read this instruction guide before use and keep it for your future reference.
Warning
Do not disassemble or modify the
Light Unit. Doing so may result in
re or electric shock.
DISASSEMBLY
PROHIBITED
Do not look at the radiating surface
of the light directly while it is turned
on. Also, do not turn it towards
others. Doing so may cause a pain
in the eye or impaired eyesight.
MANDATORY
ACTIO NS
Do not touch the Light Unit with
wet hands. Doing so may result in
electric shock.
DO NOT TOUCH
WITH WET HANDS
Keep the naked skin away from the
radiating surface of the light while
it is turned on. Failure to do so may
cause a inammation of the skin.
MANDATORY
ACTIO NS
Make sure that the Light Unit is
free of moisture or any liquid.
Exposure to water may result in
fire, electric shock, or Light Unit
failure.
DO NOT SUBJECT
TO MOISTURE
This Light Unit generates high
temperatures. Do not touch the Light
Unit while it is turned on or immediately
after it is turned off, or burning may
result. Provide cooling with a fan or
other ventilation if the Light Unit is to
be used in a closed space.
MANDATORY
ACTIO NS
If abnormal condition occurs such as
fuming, heat, smell, noise, or so on,
stop using the Light Unit immediately,
turn the power off, and unplug the
power cord. A fire or electric shock
may result if the Light Unit is kept used.
MANDATORY
ACTIO NS
Connect or disconnect the cable
only after turning off the Control
Unit for the LED light.
Failure to do so may result in
circuit damage, fire caused by a
minute spark, or electric shock.
MANDATORY
ACTIO NS
Turn o󰀨 the Control Unit for the LED
light when installing, unmounting or
cleaning the
Light Unit . Failure to
do so may cause a pain in your eye,
impaired eyesight or electric shock.
MANDATORY
ACTIO NS
Make known to all personnel
concerned the risk of ultraviolet
radiation. Failure to do so may
cause incorrect handling.
MANDATORY
ACTIO NS
The following label is attached to the LED Light. The color of the
label indicates the luminescence color of the Light. The name label
species the model name, power consumption, and serial number.
Be sure to check the contents before using the product and handle
the label with care. If the label is missing or damaged and the
contents cannot be checked, please contact CCS Inc.
- 1 -
Radiation aperture seal (only for LNSP-UV3-FN series)
(Example)
Name label (Example)
Label (Example)
INVISIBLE LED RADIATION APERTURE
不可視LED放射の出口
AVOID EXPOSURE-INVISIBLE LED RADIATION IS EMITTED FROM THIS APERTURE
注意 - ここから不可視LEDの光が出ます
LNSP-xxxUV3-365-FN
xxA/xxW xxV xxW(FAN)
0123 456789
MADE IN JAPAN
MODEL
INPUT
S/N
CCS Inc.
The product is provided with a
Radiation aperture seal of LED
light. In any case, do not turn ON
the LED with the aperture for
LED emission pointing upward.
Installation Precautions3
• Provide at least 50 mm of space around the Light Unit. In some cases,
however, more space will be required depending on the environmental
conditions of the Light Unit.
• Do not install anything that would block the airow in the exhaust direction.
50 mm or
more.
50 mm or
more.
50 mm or
more.
Air intake
Air exhaust
• Provide proper airow to ensure that the temperature around
the Light Unit does not exceed the operating temperature
range during irradiation.
• Provide sufficient space around the Light Unit so that the vent
holes and fan are not blocked.
• Make sure that the airow does not cause the exhausted warm air
to be drawn into the Light Unit again.
Caution
Note:
Operating Environment
Installation Example
The Light Unit may heat during irradiation.
Higher temperatures will cause the LEDs to deteriorate and
reduce the output intensity. It will also shorten the service life of
the Light Unit and may cause Light Unit failure. When you install
the Light Unit, observe the following precautions to keep the Light
Unit in good condition for a longer time.

Insert the frame nut into the nut slot.
1
Fix the Light Unit with M5 screw.
2
Installation
There are no restrictions in the installation direction of
the Light Unit.
4
Connect the Light Unit and the dedicated Control Unit with one
of the dedicated cables.
1
4
Read the Instruction Guide of the dedicated Control Unit before use.
For details, refer to the Instruction Guide of the dedicated Control Unit.
Adjust radiant quantity and others for the irradiated object.
Adjust the radiant quantity at the dedicated Control Unit.
3Turn ON the dedicated Control Unit and the Light Unit.
POWER
OUTPUT
L1-1
Side View
Operating Instructions5
Light Unit
Install the FG line with M3 mounting screw.
3
Required Parts
Frame
nuts
M5 screws *
(Commercially
available) FG line
M3 mounting
screw
(Accessories)
Dedicated
cable
Dedicated Control Unit (Sold Separately)6
E󰀩cient Use of LED Lights
LED lights generate heat that decreases radiant quantity and speeds
degeneration. Follow the instructions below in order to suppress the heat of
LED lights and prevent decreases radiant quantity and speeds degeneration.
• Use the light with the light level as low as possible.
• Turn ON the light unit only when needed.
• Install a fan or provide air ow for heat dissipation at the place of Light Unit
installation.
• Mount the product on a bracket or surface which readily dissipates heat.
Use a PSCC-series dedicated Control Unit.
For details of the dedicated cable, refer to the instruction guide of
the Control Unit.
The Light Unit emits ultraviolet radiation even when the light
intensity on the dedicated control unit is set to 0.
Prevent exposure to ultraviolet radiation.
Caution
Make sure that the dedicated Control Unit is turned OFF.
2Connect the cables.
Warning
To the
Light
To the
Light
To the
Control Unit
To the
Control Unit
Pull the ring.
RemovingConnecting
Adjust the position of the notch, and then insert
the connector straightforwardly until it clicks.
• Do not twist the cable or apply excessive force to the cable where
it connects to the Light Unit. It may cause Light Unit failure.
• Pay attention to the plug and socket combination to connect the
cable. Improper connection may damage the connector pins.
Caution
To avoid exposure to ultraviolet radiation, all workers around the
product must use protective equipment. Also, make known to all
personnel concerned the risk of ultraviolet radiation.
Caution
- 2 -
Dedicated Control Unit
Refer to 6. Dedicated Control Unit (Sold Separately) for details.
Light Unit
Irradiation object
M3 mounting screw,
FG xing hole
FG line
Nut slot
M5 screw
* Use M5 screws that are 5 mm longer than the thickness of the mounting surface.
You can see the
metal base inside the
xing holes.
There are two fixing
holes, including one
on the opposite side.
Use the one that is
more convenient.
Always connect the end of the FG line to ground. If you do not ground the FG
line, the Light may be damaged by static electricity.
Frame nut

Specications by Model
Connector Metal connector PRC04-12A26S-37M18 (Tajimi Electronics co., ltd.)
Cooling method Forced air-cooling
Operating environment
(indoors only) Temperature: 0 to 40°C, Humidity: 20 to 85%RH (with no condensation)
Storage environment Temperature: -20 to 60°C, Humidity: 20 to 85%RH (with no condensation)
CE marking Safety standard: Conforms to EN 62471
EMC standard: Conforms to EN61000-6-2, EN61000-6-4
Case material Aluminum alloy, steel sheets
Accessories Instruction Guide x1, radiation aperture seal* x1, UV DANGER seal* x1,
frame nuts x4, FG line(2 m) x1, M3 mounting screw x1
Common Specications
Main Specications
7
* These seals are included only with LNSP-UV3-FN series. If you set the Light Unit into other machinery, put the seals on them for
warning notice.
Model name
Irradiation
lens
Peak
wavelength
(t yp.)
Light power
consumption
(max.)
Fan power
consumption Weight
Dimensional diagrams
A: Radiating
surface
B: Total length
(not including
the cable)
LNSP-100UV3-365-FN
Embedded
365 nm
34 W 1.7 W Approx. 0.9 kg 100 mm 139 mm
LNSP-200UV3-365-FN 68 W 1.7 W Approx. 1.3 kg 200 mm 239 mm
LNSP-300UV3-365-FN 101 W 1.7 W Approx. 1.7 kg 300 mm 339 mm
LNSP-100UV3-365-FNNR
None
34 W 1.7 W Approx. 0.7 kg 100 mm 136.3 mm
LNSP-200UV3-365-FNNR 68 W 1.7 W Approx. 1.0 kg 200 mm 236.3 mm
LNSP-300UV3-365-FNNR 101 W 1.7 W Approx. 1.3 kg 300 mm 336.3 mm
LNSP-100VL3-385-FN
Embedded
385 nm
34 W 1.7 W Approx. 0.9 kg 100 mm 139 mm
LNSP-200VL3-385-FN 68 W 1.7 W Approx. 1.3 kg 200 mm 239 mm
LNSP-300VL3-385-FN 102 W 1.7 W Approx. 1.7 kg 300 mm 339 mm
LNSP-100VL3-385-FNNR
None
34 W 1.7 W Approx. 0.7 kg 100 mm 136.3 mm
LNSP-200VL3-385-FNNR 68 W 1.7 W Approx. 1.0 kg 200 mm 236.3 mm
LNSP-300VL3-385-FNNR 102 W 1.7 W Approx. 1.3 kg 300 mm 336.3 mm
LNSP-100VL3-395-FN
Embedded
395 nm
34 W 1.7 W Approx. 0.9 kg 100 mm 139 mm
LNSP-200VL3-395-FN 68 W 1.7 W Approx. 1.3 kg 200 mm 239 mm
LNSP-300VL3-395-FN 102 W 1.7 W Approx. 1.7 kg 300 mm 339 mm
LNSP-100VL3-395-FNNR
None
34 W 1.7 W Approx. 0.7 kg 100 mm 136.3 mm
LNSP-200VL3-395-FNNR 68 W 1.7 W Approx. 1.0 kg 200 mm 236.3 mm
LNSP-300VL3-395-FNNR 102 W 1.7 W Approx. 1.3 kg 300 mm 336.3 mm
LNSP-100VL3-405-FN
Embedded
405 nm
34 W 1.7 W Approx. 0.9 kg 100 mm 139 mm
LNSP-200VL3-405-FN 68 W 1.7 W Approx. 1.3 kg 200 mm 239 mm
LNSP-300VL3-405-FN 102 W 1.7 W Approx. 1.7 kg 300 mm 339 mm
LNSP-100VL3-405-FNNR
None
34 W 1.7 W Approx. 0.7 kg 100 mm 136.3 mm
LNSP-200VL3-405-FNNR 68 W 1.7 W Approx. 1.0 kg 200 mm 236.3 mm
LNSP-300VL3-405-FNNR 102 W 1.7 W Approx. 1.3 kg 300 mm 336.3 mm
- 3 -

Copyright© 2021 CCS Inc. All Rights Reserved.
Descriptions in this instruction guide are based on information available as of September 2021. KZ12907-T001-001
Dimensions (mm)8
Contents of this Instruction Guide may be changed without prior notice.
Illustrations used in this Instruction Guide may di󰀨er from actual products.
CCS maintains the copyright on this Instruction Guide. Unauthorized transfer or reproduction is strictly prohibited.
http://www.ccs-grp.com/
Surface C
Surface C
Air blow
Same as Surface C
Same as Surface C
Detailed Diagram D
Detailed Diagram D
E
E
41.5
41.5
19.5
16
14.3
16
6
12
6
12
9.4
(Radiating surface)
30 (Radiating surface)
25.8
15.5
B
B
34
34
(6.4)
(6.4)
A (Radiating surface)
A (Radiating surface)
62
62
For installation
4 x Nut slots
For installation
4 x Nut slots
Fan
Fan
M3
(For FG line installation)
M3
(For FG line installation)
35
27. 3
(79.8)
(74.6)
300
+35
0
+35
0
300
Air blow
LNSP- (n x 100)UV3-365-FN
LNSP- (n x 100)VL3-385-FN
LNSP- (n x 100)VL3-395-FN
LNSP- (n x 100)VL3-405-FN
(n= 1,2,3) Narrow type
LNSP- (n x 100)UV3-365-FNNR
LNSP- (n x 100)VL3-385-FNNR
LNSP- (n x 100)VL3-395-FNNR
LNSP- (n x 100)VL3-405-FNNR
(n= 1,2,3) Wide type
- 4 -
