CDA SL400BL User guide

SL400BL
Twelve function electric oven with timer
Use and maintenance

IMPORTANT: Please read the user instructions carefully before
using the appliance for the first time and before installing it.
Failure to install the oven, or to have it installed, as per the
instruction manual could invalidate the warranty. Any service
calls relating to misue or incorrect installation could incur a
service charge.
2| Instruction Manual
3
5
5
6
8
8
9
9
10
11
12
12
13
14
15
16
Important information
First use of the oven
Standby mode
Control panel
Function indicator symbols
Setting the time
Minute minder
Child lock
Semi automatic cooking
Automatic cooking
Using the grill
ECO heating
Operations
Preset programmes
Practical tips
Steam cleaning function
Contents
16
17
17
17
17
18
25
26
28
30
31
32
33
34
Rapid preheating
Oven preheat
Temperature
Cooling fan and residual heat
Lighting
Cleaning and maintenance
Changing the oven light bulbs
Installation
Mains electrical connection
Technical assistance
Error codes
Specifications
Product fiche
Product information

Instruction Manual | 3
Important information
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd. cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserves the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information
• The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements
• The appliance can be used by children aged from 8 years
and above. Persons with reduced physical, sensory or mental
capabilities must be given instruction or supervision
concerning safe operation of the appliance and understand the
hazards involved
• Do not allow anyone unfamiliar with the contents of this instruction
manual to operate the oven
• Do not use harsh cleaning agents or sharp metal objects to clean
the door as they can scratch the surface potentially resulting in
cracking or shattering of the glass
• Take care when opening the oven door during or after a cooking
cycle as hot steam may escape
• Do not use the oven in the event of a technical fault. Any faults
must be fixed by an appropriately qualified and authorised person
• In the event of an incident due to a technical fault, disconnect the
power and report the fault to CDA Customer Care
• The appliance has been designed only for cooking, any other use
may invalidate your warranty and cause danger
• Do not place anything weighing over 15kg on the opened oven
door
16 Rapid preheating
17 Oven preheat
17 Temperature
17
17
Cooling fan and residual heat
Lighting
18 Cleaning and maintenance
25 Changing the oven light bulbs
26 Installation
28 Mains electrical connection
30
31
Technical assistance
Error codes
32 Specifications
33 Product fiche
34 Product information

Appliance information
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin .
4| Instruction Manual

Instruction Manual | 5
First use of the oven
In order to remove oil residues accumulated during the manufacturing
process and dust accumulated during storage and transport, we
recommend a preliminary cleaning before first use. This is to protect
your health and provide optimum quality in cooking.
IMPORTANT!
Remove the protective foil from the telescopic runners before using
the oven.
Preliminary heating
1. Remove any packaging elements from the oven cavity
2. Turn on ventilation or extractor fan in the room or open a window
3. Set the oven to 250°C using the rapid preheating function
4. Allow to heat for approximately 30 minutes
5. Turn oven o and allow to cool
6. To clean the oven use a well wrung-out cloth with warm water and
a small amount of washing up liquid
7. Dry with a clean cloth
A slightly unpleasant smell may be emitted during this process due to
the vaporising of oil residue used to protect the oven during storage.
Standby mode
Switching the appliance to standby mode resets all functions settings,
times, temperature and automatic programmes. All heating elements
are deactivated and the display is dimmed except for the timer.
To enter standby mode, press the sensor for 3 seconds at any time
(this is applicable even if the oven is locked). A beep will be heard
indicating the mode is active. To exit standby mode simply press the
sensor for 3 seconds, a dierent beep will be heard to indicate the
oven is now ready for operation.

6| Instruction Manual
Control panel
The control panel is equipped with an LED display and backlit touch
sensors.
Fan cooking with lower heat
With this setting the convection fan and bottom heater are on,
which increases the temperature at the bottom of the cooked
dish. Intense heat from the bottom is ideal for moist cakes and
pizza.
Fan assisted oven
This setting is most suitable for baking cakes.
Conventional oven
The thermostat enables the user to set the temperature within
a range of 30°C to 280°C. This setting is ideal for baking cakes,
meat, fish, bread. For best results preheat the oven and use a
baking tray on one level.
Half grill
This function radiates heat from the grill element. This fully
temperature variable grill can be set between 30°C and 280°C
maximum.
Full grill
In this setting both the grill and top element are engaged. This
increases the temperature in the top part of the oven chamber
making it suitable for browning and grilling larger portions of
food. It can be set between 30°C and 280°C maximum.

Instruction Manual | 7
Warming oven
This function radiates heat from the bottom element, baking
cakes from underneath until done.
Defrost
This function uses the fan to circulate air at ambient temperature
within the oven which helps to accelerate the defrosting
process.
Fanned full grill
This function radiates heat from the grill element and the top
element but also uses the fan to circulate hot air. The hot air is
distributed over and under the food that you are grilling. This
fully temperature variable grill is ideal for grilling fish or other
items where the appearance could be spoiled by a normal grill
function. It can be set between 30°C and 280°C maximum.
Fan oven
This function uses the circular heating element with a
temperature between 30°C and 280°C. The fan then circulates
the hot air which helps to achieve uniform heat distribution.
On/o switch (standby) Rapid preheating
Clock / Minute minder Set Temperature
Light Plus sensor
Pre-set programmes Minus Sensor
Eco programme Confirm sensor
Steam cleaning

8| Instruction Manual
Function indicator symbols
Minute minder active
Duration
End time
Child lock active
Heating active
Setting the time
When the appliance is connected to power, the display will show the
hour digits flashing, the minute digits will be illuminated.
• Use and to set the hours. Touch to confirm the setting, the
hour digits will now be illuminated and the minutes will be flashing
• Use and to set the minutes. Touch the sensor to confirm
the setting. The appliance enters sleep mode and the time set will
be shown
Note: The time can only be set in 24 hour format
Changing the time
The time display can only be changed when no other functions are
being used.
If in sleep mode, press the on/o sensor to wake the appliance up.
Once the display has illuminated, touch and hold . The symbol
will flash on the display. Touch again and the digits will start to
flash. You can now proceed to set the time following the steps in the
'Setting the time' section above.

Instruction Manual | 9
Child lock
Child lock is intended to prevent changes to the oven settings and
the oven being turned on. When the appliance is on simultaneously
touch and hold and for 3 seconds to activate the child lock.
The symbol will be illuminated. When the child lock is activaed
in standby mode it prevents the oven from being turned on. When
the child lock is activated when the appliance is in use, it prevents
the settings from being changed but the oven can still be turned
o. To turn the child lock o simply touch and hold 3 seconds and
the and sensors and the symbol will go out.
Minute minder
During a cooking function, only the minute minder can be set or
adjusted. The clock or delayed cooking time can not be set or
adjusted during the function.
• Touch and hold and the display will show the symbol
• Touch the and sensors to adjust the the setting and touch
to confirm. Touch and hold the and sensors to clear the
setting. The symbol will be illuminated on the display, indicating
the time is set
• Once the time has elapsed you will hear a beeping and the
symbol will be flashing. Touch the sensor to silence the beep-
ing and end the function
The minute minder can be set for a maximum of 2 hours.

10 | Instruction Manual
Semi automatic cooking
This function allows for a cooking time to be set. When the set time
elapses the oven will switch the set function o and an acoustic signal
will sound to alert the user. The cooking time available ranges from
between 1 minute and 10 hours.
To switch on semi automatic cooking
• First select a heating function and temperature
• Touch and hold and the symbol will flash on the display
• Touch again and the symbol will appear on the display
• Use the and sensors to adjust the duration as needed and
touch to confirm the setting or alternatively wait 5 seconds and
the duration will automatically set
• To clear the duration setting, simultaneously touch and and
the display will show 0:00. Touch to confirm
During the cooking process the symbol will be illuminated.
Once the duration time has elapsed you will hear beeping. Touch
any sensor except to mute the beeping. The function settings and
temperature will clear and the lighting will turn on for 30 seconds.
The symbol will go out and the appliance will turn o after 60
seconds.

Instruction Manual | 11
Automatic cooking
This function allows for a duration and an end time to be set for
cooking. For example, if you set the cooking duration to 1 hour, and
the end time to 15:00, then the oven will activate the function at 14:00.
To switch on automatic cooking
• First select a heating function and temperature
• Touch and hold and the symbol will flash on the display
• Touch again and the symbol will appear on the display
• Use the and sensors to adjust the duration as needed
• Touch and the symbol will flash on the display and the end
time will also be shown
• Use the and sensors to adjust the end time and touch to
confirm the setting
During the cooking process both the and symbols will be illumi-
nated.
Once the duration time has elapsed you will hear beeping. Touch
any sensor except to mute the beeping. The function settings and
temperature will clear and the lighting will turn on for 30 seconds.
The symbol will go out and the appliance will turn o after 60
seconds.

12 | Instruction Manual
Using the grill
Important!
When using any grill functions the oven door should be kept
closed. When the grill is in use accessible parts can become hot
and it is advisable to keep children away from the oven. When
using the half grill, full grill or fanned grill functions the maximum
temperature that can be set is 280 °C.
ECO heating
ECO heating is an optimised heating function designed to save
energy when preparing food. You cannot reduce the cooking
time by setting a higher temperature; preheating the oven is not
recommended. Do not change the temperature setting and do not
open the oven door during cooking. The levels listed in the table
below can be found around the edge of the oven cavity when the
door is open
Type of dish Oven
function Temperature °C Level Time (min)
Sponge cake 180 - 200 2-3 50 -70
Muns 180 - 200 250 -70
Fish 190 - 210 2-3 45 - 60
Beef 200 - 220 290 - 120
Pork 200 - 220 290 - 160
Chicken 180 - 200 280 - 100

Instruction Manual | 13
Operations
Function Description
Oven Elements
Temperature
[°C] Default
Temperature [°C]
Lighting Top Grill Circular Bottom Fan
Min. Max
Heating functions
Conventional Oven ✓ ✓ ✓ 30 280 200
Fan assisted oven ✓ ✓ ✓ ✓ 30 280 180
Fan oven ✓ ✓ ✓ 30 280 180
Half grill ✓ ✓ 30 280 250
Full grill ✓ ✓ ✓ 30 280 250
Fanned full grill ✓ ✓ ✓ ✓ 30 280 200
Fan cooking with lower heat ✓ ✓ ✓ ✓ 30 280 220
Warming oven ✓ ✓ 30 240 200
Defrost ✓ ✓ - - -
Additional functions
Temperature See page 17 for info
ECO programme See page 12 for info 30 280 200
Lighting ✓ - - -
Rapid pre-heating ✓ ✓ ✓ ✓ 30 280 180
Pre-set programmes See page 14 for info
Steam cleaning ✓ - - 80
To change heating functions during cooking simply select the function you want on the control
panel and touch to confirm.

14 | Instruction Manual
Pre-set programmes
This oven features a number of preset programmes which create
the ideal cooking environment (time, temperature etc.) for certain
dishes. These can be accessed by pressing the sensor and
cycling through the programmes in the table below using the and
sensors. Touch to confirm the programme and the oven will
commence operation. The levels listed in the table below can be
found around the edge of the oven cavity when the door is open.
Progamme Description Rapid
pre-heating
Heating
Function Level Time [Min]
Temperature
[°C]
P01 Beef 2 120 180
P02 Pork 2 120 180
P03 Lamb 2 120 180
P04 Chicken 1.5kg 2 85 190
P05 Duck 1.8kg 2 90 180
P06 Goose 3kg 1 130 170
P07 Turkey 2.5kg 1 155 170
P08 Pizza ✓ 2 15 220
P09 Lasagne ✓ 2 25 200
P10 Foccacia ✓ 2 15 230
P11 Casserole with pasta ✓ 2 15 230
P12 Baked vegatables ✓ 2 35 180
P13 Sponge cake ✓ 2 45 160
P14 Muns 3 35 160
P15 Cookies 3 20 150
P16 Fruitcake ✓ 2 55 175
P17 Bread 2 60 180
P18 Dough proving 2 20 30
P19 Dry 2/3 300 50

Instruction Manual | 15
Practical tips
The times given in the table below apply to a dish that is placed in to
a cold oven. For a preheated oven the times should be reduced by
5 - 10 minutes. The figures given below are approximate and can be
altered based on your own experience and cooking preferences. The
levels listed in the table below can be found around the edge of the
oven cavity when the door is open.
Type of dish Heating Function Level Time [Min] Temperature [°C]
Sponge cake 2 - 3 30 - 50 160 - 200
Muns 3 25 - 40 160 - 170
Muns 3 25 - 40 155 - 170
Pizza 2 - 3 15 - 25 200 - 230
Fish 2 45 - 60 210 - 220
Fish 2 - 3 45 - 60 160 - 180
Fish 2 - 3 60 -70 190
Sausages 4 14 - 18 220
Beef 2 120 - 150 225 - 250
Beef 2 120 - 160 160 - 180
Pork 2 90 - 120 160 - 230
Pork 2 90 - 120 160 - 190
Chicken 2 70 - 90 180 - 190
Chicken 2 45 - 60 160 - 180
Chicken 2 60 - 70 175 - 190
Vegetables 2 40 - 50 190 - 210
Vegetables 3 40 - 50 170 - 190

16 | Instruction Manual
Steam clean function
When the steam clean function is selected, the programme will
start and there is no option to adjust the temperature. The function
operates as a preset programme with the oven temperature at 80°C
and a duration of 30 minutes. When the function is in progress the
and symbols will be illuminated. To use the steam clean function,
follow the steps below.
• Pour 150ml of water directly on to the bottom of the oven cavity
and close the door
• Touch the sensor and the function will start
• Once the 30 minutes has elapsed a continuous beep will be
heard, press any sensor to mute the beep
• Allow the oven to cool completely and wipe any excess water
away with a dry cloth
Please note: Excess steam may escape when the oven door is
opened and condensation may drip from the bottom of the door
Rapid preheating
The rapid preheating function allows the oven elements to work at
their maximum capability in order to get the oven to temperature as
quickly as possible. To use the rapid heating function, follow the steps
below.
• First select a heating function and temperature
• Touch the sensor and the function will start
• The sensor will be illuminated until the temperature set has
been reached, upon which the sensor will go out and the function
will stop
• The function can be turned o at any time by pressing

Instruction Manual | 17
Oven preheat
When the symbol is illuminated, it indicates the oven is heating
up towards the temperature set. The symbol will go out once
the temperature is reached. To show the set temperature is being
maintained The symbol will illuinate and go out periodically.
Temperature
At any time during a heating function, it is possible to find out what
temperature the oven is currently operating at. Simply touch the
sensor to see what the temperature inside the cavity is. Touch the
sensor a second time and the display will show the temperature which
has been set. Touch the sensor a third time and the display will revert
back to the current time.
Cooling fan and residual heat
If the oven has no active functions but the temperature inside is
still above 80°C, the cooling fan will activate automatically until the
temperature decreases. During this cooling period the display will
show the current temperature until the oven has cooled suciently.
Lighting
The lighting inside the cavity of the oven can be turned on at any time
during an active function by pressing the sensor. The light will
stay on for 30 seconds but can be switched on permanently if the
sensor is pressed for 3 seconds. To deactivate simply press the
sensor again for 3 seconds.

18 | Instruction Manual
Keeping your oven clean and well maintained helps to prolong
its fault-free lifespan. It is important that, before any cleaning or
maintenance is performed, you switch o the oven at the mains
supply. Do not start any cleaning or maintenance until the oven has
been allowed to cool completely.
We recommend always wearing PPE (Personal Protective
Equipment) when carrying out any cleaning or maintenance.
Cleaning the oven exterior
Stainless steel, aluminium and glass surfaces can all be cleaned using
a dilute solution of water and mild detergent. They must be cleaned
very carefully using a soft or microfibre cloth to avoid scratching and
abrasions. Any abrasive cleaner (including Cif) will scratch the surface
and could erase the control panel markings. Always dry thoroughly
with a soft dry cloth.
Cleaning and maintenance
Cleaning the oven interior
The oven should always be cleaned after use when it has been
allowed to cool down. The cavity should be cleaned using a mild
detergent solution and warm water and then wiped dry with a suitable
clean cloth.

Instruction Manual | 19
Cleaning and maintenance
IMPORTANT:
• Steam cleaners must not be used when cleaning this
appliance
•Once care and maintenance is complete, ensure that all parts
are correctly replaced before using the oven
Abrasive cleaning agents or scouring pads/cloths should not be used
on the cavity surface.
Removing the appliance door
In order to allow easier access into the oven cavity for cleaning, it is
possible to remove the door. Before removing the door, ensure that
you have an area prepared in which you can place the removed door.
This area should ideally be protected by something like a folded, dirt-
free, towel to help prevent damage to surfaces and the door.
• Open the door fully
• Lift and tilt the safety catch
part of the hinge (Fig. 1) so that
it is fully extended and points
towards the door
• Close the door most of the
way, lift it slightly and then pull
it, safely but firmly, towards you
Fig. 1

20 | Instruction Manual
Cleaning and maintenance
Replacing the appliance door
• Hold the door to the appliance in
the closed position and manoeuvre
the hinges so that the part of the
hinge, highlighted by the star in fig.
2, inserts into the hinge slot in the
cavity frame
• Next, ensure the notch on the
underside of the hinge sits on the
lip of the hinge slot. Open the door
fully. Each hinge should be seated
in the same way as the hinge in
fig. 3. If it is not, follow the steps for
removing the door and try replacing
it again
• Finally, lift the safety catch part of
the hinges back into place so that
they are lying flat against the hinges
Please note: If the hinge safety catches are not in the correct
place then the door and/or appliance may receive damage when
attempting to close the door.
Fig. 2
Fig. 3
