cecotec Power Espresso 20 Professionale User manual

Manual de instrucciones
Instruction manual
Manuel d’instructions
Bedienungsanleitung
Manuale di istruzioni
Manual de instruções
Power Espresso 20 Professionale
Cafetera espresso/Espresso coee machine
01556_Power Espresso 20 Professionale_Manual_DS.indd 1 20/12/18 9:27

ÍNDICE
1. Piezas y componentes / 04
2. Instrucciones de seguridad / 07
3. Antes de usar / 08
4. Funcionamiento / 08
5. Limpieza y mantenimiento / 10
6. Resolución de problemas / 11
7. Especificaciones técnicas / 12
8. Reciclaje de electrodomésticos / 13
9. Garantía y SAT / 13
6. Problemlösung / 34
7. Technische Spezifikationen / 35
8. Entsorgung von alten Elektrogeräten / 35
9. Technischer Kundendienst und Garantie / 36
INHALT
1. Teile und Komponenten / 04
2. Sicherheitshinweise / 29
3. Bevor dem ersten Gebrauch / 30
4. Betrieb / 30
5. Reinigung und Wartung / 33
INDEX
1. Parts and components / 04
2. Safety instructions / 14
3. Before use / 15
4. Operation / 15
5. Cleaning and maintenance / 17
6. Troubleshooting / 18
7. Technical specifications / 19
8. Disposal of old electrical appliances / 20
9. Technical support service and warranty / 20
INDICE
1. Parti e componenti / 04
2. Istruzioni di sicurezza / 37
3. Prima dell’uso / 38
4. Funzionamento / 38
5. Pulizia e manutenzione / 40
6. Soluzioni dei problemi / 41
7. Specifiche tecniche / 43
8. Riciclaggio degli elettrodomestici / 43
9. Garanzia e SAT / 43
SOMMAIRE
1. Pièces et composants / 04
2. Instructions de sécurité / 21
3. Avant utilisation / 22
4. Fonctionnement / 22
5. Nettoyage et entretien / 25
6. Résolution des problèmes / 26
7. Spécifications techniques / 27
8. Recyclage des électroménagers / 27
9. Garantie et SAV / 28
ÍNDICE
1. Peças e componentes / 04
2. Instruções de segurança / 44
3. Antes de usar / 45
4. Funcionamento / 45
5. Limpeza e manutenção / 47
6. Resolução de problemas / 48
7. Especificações técnicas / 49
8. Reciclagem de eletrodomésticos / 50
9. Garantia e SAT / 50
INDEX
1. Onderdelen en componenten / 04
2. Veiligheidsinstructies / 51
3. Voor het gebruik / 52
4. Werking / 52
5. Schoonmaak en onderhoud / 54
6. Probleemoplossing / 55
7. Technishe specificaties / 56
8. Recycling van huishoudelijke apparaten / 57
9. Garantie en SAT / 57
01556_Power Espresso 20 Professionale_Manual_DS.indd 3 20/12/18 9:27

1. PIEZAS Y COMPONENTES
Parts and components/Pièces et composants/Ersatzteile und Komponenten/
Parti e componenti/Peças e componentes/ Onderdelen en componenten
01556_Power Espresso 20 Professionale_Manual_DS.indd 4 20/12/18 9:27

ES
1. Botón de encendido
2. Botón de preparación de café
3. Botón de vapor
4. Indicador luminoso rojo
5. Indicador luminoso verde
6. Selector de vapor
7. Tapa del depósito de agua
8. Depósito de agua
9. Tapa superior
10. Manómetro
11. Vaporizador
12. Tubo espumador
13. Cuerpo principal
14. Soporte para vasos
15. Bandeja de goteo desmontable
16. Cubierta inferior
17. Filtro de malla de acero inoxidable
18. Cuchara medidora y prensa
19. Embudo metálico
20. Brazo de la cafetera
21. Lengüeta de sujeción
EN
1. On/o button
2. Coee button
3. Steam button
4. Red indicator light
5. Green indicator light
6. Steam knob
7. Water tank cover
8. Water tank
9. Top cover
10. Manometer
11. Steam wand
12. Frothing tube
13. Main body
14. Cup support
15. Removable drip tray
16. Bottom cover
17. Stainless-steel mesh filter
18. Measuring spoon and press
19. Metal funnel
20. Portafilter
21. Fixing tab
FR
1. Bouton de connexion
2. Bouton de préparation du café
3. Bouton de la vapeur
4. Témoin lumineux rouge
5. Témoin lumineux vert
6. Sélecteur de vapeur
7. Couvercle du réservoir d’eau
8. Réservoir d’eau
9. Couvercle supérieur
10. Manomètre
11. Buse vapeur
12. Distributeur de mousse
13. Unité principale
14. Support pour verres
15. Plateau gouttes démontable
16. Cache inférieur
17. Filtre maille en acier inoxydable
18. Cuillère mesureuse et presse
19. Entonnoir métallique
20. Bras de la machine à café
21. Languette de fixation
DE
1. Ein/Ausschalter
2. Kaeetaste
3. Dampfschalter
4. Rote Betriebs-Beleuchtung
5. Grüne Betriebs-Beleuchtung
6. Dampfregler
7. Deckel des Wassertanks
8. Wassertank
9. Oberer Deckel
10. Manometer
11. Dampfgarer
12. Milchschäumer
13. Hauptgerät
14. Becherhalter
15. Abnehmbare Abtropfschale
16. Untere Abdeckung
17. Filter aus Edelstahl
18. Messlöel und Presse
19. Metall-Trichter
20. Siebträger
21. Halterung Zubehör
IT
1. Tasto d’accensione
2. Tasto di preparazione del caè
3. Tasto del vapore
4. Indicatore luminoso rosso
5. Indicatore luminoso verde
6. Manopola del vapore
7. Coperchio del serbatoio d’acqua
8. Deposito d’acqua
9. Coperchio superiore
01556_Power Espresso 20 Professionale_Manual_DS.indd 5 20/12/18 9:27

ENGLISH
14
POWER ESPRESSO 20 PROFESSIONALE
2. SAFETY INSTRUCTIONS
Read these instructions thoroughly before using the appliance. Keep this instruction manual
for future reference or new users.
1. Make sure that the mains voltage matches the voltage stated on the rating label of the
appliance and that the wall outlet is grounded.
2. Do not immerse the cord, plug, or any non-removable part of the appliance in water or
any otherliquid, nor expose the electricalconnections to water. Make sureyourhands are
dry before handling the plug or switching on the appliance.
3. Check the power cord regularly for visible damage. If the cord is damaged, it must be
replaced by the ocial Technical Support Service of Cecotec, in order to avoid any type
of danger.
4. Do not twist, bend, strain, or damage the power cord in any way. Protect it from sharp
edges and heat sources. Do not let it touch hot surfaces. Do not let the cord hang overthe
edge of the working surface or countertop.
5. Turn o and unplug the appliance from the mains supply when not in use and before
cleaning it. Pull from the plug, not the cord, to disconnect it from the outlet.
6. This appliance is intended for domestic use only. It is not suitable for commercial or
industrial use. Do not use it outdoors.
7. Place the appliance on a dry, stable, at, heat-resistant surface.
8. Do not use the appliance under the following circumstances:
- On or near a gas or electric hob, in heated ovens, or near open flames.
- On soft surfaces (such as carpets) or where it may tip over during use.
- Outdoors or in areas with high humidity levels.
9. The temperature of accessible surfaces may be high while in use and could cause burns.
Do not touch hot surfaces while in use or immediately after.
10. Do not wash the appliance in dishwashers.
11. The appliance is not intended to be used by children under the age of 8. It can be used by
children over the age of 8, as long as they are given continuous supervision.
12. This appliance is not intended to be used by persons with reduced physical, sensory,
or mental capabilities, or lack of experience or knowledge, unless they have been given
supervision or instruction concerning the use of the appliance in a safe way by a person
responsible for their safety, and understand the hazards involved.
13. Supervise young children to make sure that they do not play with the appliance. Close
supervision is necessary when the appliance is being used by or near children.
01556_Power Espresso 20 Professionale_Manual_DS.indd 14 20/12/18 9:27

ENGLISH
15
POWER ESPRESSO 20 PROFESSIONALE
3. BEFORE USE
ADVERTENCIA: clean the product before the first use in order to remove production residues.
• Pour water into the water tank, do not exceed the “MAX” mark, and place the water tank
in its correct position.
Note: the appliance is provided with a detachable tank for easy cleaning. Fill the water tank
first and then place it in the appliance.
• Place the stainless-steel mesh in the funnel (without coee).
• Place a cup on the cup support. Make sure the steam knob is turned completely
anticlockwise.
• Connect the appliance to a power supply and press . The red indicator will light up
indicating the machine is preheating.
• Press for the pumpto start pumpingwater. To stop it, press again.The preheating
process will be completed when the red and green indicator light turn steady.
• Press for the machine to dispense water.
• Once the machine has finished dispensing water, pour all remaining water away and
clean all the containers thoroughly. Now, the machine is ready to be used.
Warning: when activating the pump for the first time, the appliance may produce some noise
which will disappear after 20 seconds. This is because the machine is releasing air and is
completely normal, it does not aect to the product’s operating.
4. OPERATION
Preheating
It is suggested to preheat the appliance, including the funnel, filter and cup, so the coee flavour
is not aected by the fact of some of the pieces being cold.
1. Remove the detachable tank and open the tank cover to fill it with the desired amount of
water, do not exceed the “MAX” mark in the tank. Place the tank into the appliance properly.
2. Introduce the stainless-steel mesh filter into the funnel, pull the press bar backward, make
sure the funnel’s tube is aligned with the groove in the appliance, then insert the funnel into
the appliance and release the press bar.
3. Fix it firmly in the coee machine by turning it anticlockwise to the “lock” position.
4. Place an espresso cup on the cup support.
5. Connect the machine to the power supply and make sure the steam knob is turned
completely clockwise.
6. Press . The red light indicator will light up, indicating the machine is preheating. Press
again for the pump to start pumping water, and stop it by pressing the same button again.
This process will pump water from the tank to the boiler.
01556_Power Espresso 20 Professionale_Manual_DS.indd 15 20/12/18 9:27

ENGLISH
16
POWER ESPRESSO 20 PROFESSIONALE
Espresso
1. Remove the funnel by turning it in anticlockwise. Add ground coee to the stainless-steel
filter with the measuring spoon (one spoon of ground coee powder can make about a cup
of coee), then use the measuring spoon to press down the coee.
2. Pull the press bar backward, make sure the funnel’s tube is aligned with the groove in the
appliance, then insert the funnel into the appliance and release the press bar. Fix it firmly in
the coee machine by turning it anticlockwise to the “lock” position.
3. Pour out the hot water from the cup and place the hot cup on the cup support.
4. Press , the red indicator light will turn on. Once the red and green indicators light up
steady, press . The device will start dispensing coee.
5. Press to stop when you have obtained the desired amount of coee. The indicator lights
will turn o and the machine will stop operating.
Warning: do not leave the coee machine unattended during operation as some of the steps
require manual operation.
Milk froth/Cappuccino
1. Prepare a regular espresso in a slightly larger cup. Make sure the steam knob is turned
completely anticlockwise.
2. Press and wait until the red and green indicators light up steady.
• Fill a jug with about 100 grams of milk for each cappuccino to be prepared.
• Turn the steam knob slowly clockwise, the frothing tube will start producing steam.
• Insert the frothing tube into the milk about 2 cm, froth milk while you move the vessel
around un and down.
• Turn the steam knob completely anticlockwise when the milk is frothed to your taste.
• Pourthe frothed milkinto the espresso prepared. Sweetento taste and if desired, sprinkle
the froth with a little cocoa powder.
• Press to turn the device o.
Note:
• It is suggested to use whole milk for best-quality results.
• Use a jug not smallerthan 70±5 mm diameter and enough tall,the milk volumewill increase
times 2 when it is frothed.
• Do not use hot milk, always operate the machine with warm milk.
• Do not turn the steam knob quickly, milk could spill and cause burns.
• Always clean the steam outlet with a wet sponge immediately after using it.
• Before brewing another coee, allow the machine to rest for 5 minutes.
Hot water
This function allows keeping coee warm by adding hot water or cleaning the cup.
01556_Power Espresso 20 Professionale_Manual_DS.indd 16 20/12/18 9:27

ENGLISH
17
POWER ESPRESSO 20 PROFESSIONALE
1. Press and wait until the red and green indicator lights turn on.
2. Turn the steam knob completely anticlockwise and place a jug under the steam wand.
3. Press for the machine to dispense hot water.
Warning: keep the steam wand inside the jug or cup in order avoid water from scattering and
causing burns.
Heating drinks
The steam wand (without the frothing tube) can be used to heat beverages like chocolate, water
or tea.
1. Turn the steam knob completely anticlockwise and press , wait until the red and green
indicator lights turn on steady.
2. Remove the frothing tube from the steam wand.
3. Introduce the steam wand into the liquid to be heated. Turn the steam knob gently
anticlockwise to start producing steam.
4. When the required temperature is reached, turn the steam knob completely clockwise.
5. Press the steam on/o” to turn the device o.
Note: the machine will automatically turn o after 25 minutes of no operation, unless de on/o
button is pressed.
5. CLEANING AND MAINTENANCE
• Turn the appliance o, unplug it from the power supply and allow it to cool down before
cleaning it.
• Use a soft, damp cloth to clean the product’s housing.
• Do not use anytoxic, corrosive orabrasive cleaning agents or scouring spongesto clean the
device, these can damage the surface.
• Do not immerse the appliance or any of its non-removable parts in water.
• Clean the water tank, drip tray, cup support and other removable parts periodically and dry
them before placing them in their position again.
Note: to clean the filter and funnel, turn the funnel anticlockwise, throw away all coee rests
and rinse with water.
Mineral-deposits cleaning
1. Fill the tank with water (4/5) and descaling product (1/5) to the MAX mark.
2. Place the funnel and the jug in their place without coee and carry out the preheating cycle.
3. Press and wait until the red and green light indicators turn on.
4. Press and allow the machine to dispense 2 cups of water. Then, press again to close
the pump and wait for 5 seconds.
01556_Power Espresso 20 Professionale_Manual_DS.indd 17 20/12/18 9:27

ENGLISH
18
POWER ESPRESSO 20 PROFESSIONALE
5. Place the jug under the steam wand and turn the steam knob completely anticlockwise (at
least 135º).
6. Press for the machine to dispense 2 cups of water. Then, press again to close the
pump and wait for 5 seconds.
7. Restart the device and repeat these steps until there is no more water left in the tank (at
least 3 times).
8. Brew a coee with tap water up to the MAX mark, without coee powder, and repeat the
before steps untilthere is no more water in the tank (at least 3 times).
6. TROUBLESHOOTING
ERROR CAUSE SOLUTION
Water comes out from the
jug or from its lid
The jug is not fitted properly Make sure the centre of
the jug is aligned with the
brewing outlet.
The level of water in the tank
exceeds the MAX mark
The water level in the tank
should be within the MIN and
MAX mark
Water leaks from the bottom
of the device
There is too much water in
the drip tray
Clean the drip tray
The coee maker is defective Contact the Technical
Support Service of Cecotec
for advice or reparation
Water leaks from the filter There is coee powder on
the filter’s edge
Clean the filter edge
01556_Power Espresso 20 Professionale_Manual_DS.indd 18 20/12/18 9:27

ENGLISH
19
POWER ESPRESSO 20 PROFESSIONALE
The coee tastes like vinegar
or other acid flavour
The machine has not been
properly cleaned after the
descaling process
Follow the steps on the
“Cleaning and maintenance”
section
The coee powder has been
stored in bad conditions for
too long
Use fresh coee powder or
store it in a cool, dry place.
After opening a package
of coee powder, reseal
it tightly and store it in a
refrigerator to maintain it
fresh
The coee machine does not
operate properly
The machine is not properly
connected to the power
supply
Plug the power cord into a
wall outlet correctly, if the
appliance still does not work,
please contact the Technical
Support Service of Cecotec
The steam does not froth
milk
The steam indicator is not
lit up
The steam can be used to
froth only when the light
indicator is on
The container is too big or the
shape is not adequate
Use a tall and narrow cup
You have used skimmed milk Use whole milk
7. TECHNICAL SPECIFICATIONS
Model: Power Espresso 20 Professionale
Product reference: 01556
Power: 850 W
Voltage and frequency: 220-240 V, 50 Hz
Made in China | Designed in Spain
01556_Power Espresso 20 Professionale_Manual_DS.indd 19 20/12/18 9:27

ENGLISH
20
POWER ESPRESSO 20 PROFESSIONALE
8. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment
(WEEE), specifies that old household electrical appliances must not be disposed of
with the normal unsorted municipal waste. Old appliances must be collected
separately, in order to optimize the recovery and recycling of the materials they contain, and
reduce the impact on human health and the environment.
The crossed out “wheeled bin” symbolon the product remindsyou ofyour obligationto dispose
of the appliance correctly. If the product has a built-in battery or uses batteries, they should be
removed from the appliance and disposed of appropriately.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
9. TECHNICAL SUPPORT SERVICE AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof of
purchase is submitted, the product is in perfect physical condition, and it has been given proper
use, as explained in this instruction manual.
The warranty will not cover the following situations:
• The product has been used for purposes other than those intended for it, misused, beaten,
exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault
attributable to the customer.
• The product has been disassembled, modified, or repaired by persons, not authorised by the
ocial Technical Support Service of Cecotec.
• Faults deriving from the normal wear and tear of its parts, due to use.
The warrantyservice covers everymanufacturing defects ofyour appliancefor 2years, based on
current legislation, except consumable parts. In the event of misuse, the warranty will not apply.
If at any moment you detect any problem with your product or have any doubt, do not hesitate to
contact Cecotec Technical Support Service at [phone].
01556_Power Espresso 20 Professionale_Manual_DS.indd 20 20/12/18 9:27

Grupo Cecotec Innovaciones S. L.
C/de la Pinadeta s/n, 46930
Quart de Poblet, Valencia, Spain
www.cecotec.es
01556_Power Espresso 20 Professionale_Manual_DS.indd 60 20/12/18 9:27
