CEECO SSP-530-X User manual

WPP-530-X OR SSP-510-X-LPSPKRPCB-ISSUE4.0
SERVICE MANUAL
FOR
MODEL WPP-530-X
HANDS FREE EMERGENCY
WEATHERPROOF TELEPHONE
OR
MODEL SSP-510- X
HANDS FREE STAINLESS STEEL
PANEL TELEPHONE
EQUIPPED WITH
LOW-POWER SPEAKER BOARD
Serving the Telephone Industry Since 1930
Communication Equipment 1580 NW 65th Avenue
& Engineering Company Plantation, FL 33313
Voice: 954-587-5430
Fax: [phone]
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]

ISSUE 4.0
IMPORTANT INFORMATION
FOR
CUSTOMER
Please fill in before you continue.
The following information is necessary when calling CEECO for assistance.
MODEL NUMBER MODEL WPP-530-X OR SSP-510-X, EQUIPPED
WITH LOW-POWER SPEAKER BOARD
SERIAL NUMBER
DATE MANUFACTURED
LOCATION INSTALLED
For us to better serve you, please have this information available when calling for technical
support.
CEECO
Communication Equipment and Engineering
Company
1580 NW 65th Avenue
Plantation, FL 33313
[phone] Voice
[phone] Fax
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
2

ISSUE 4.0
TABLE OF CONTENTS
SECTION PAGE
1.0 INTRODUCTION................................................................................................... 4
2.0 GENERAL............................................................................................................... 4
3.0 PROGRAMMING .................................................................................................. 5
4.0 TESTING/OPERATION ....................................................................................... 7
5.0 RECOMMENDED TOOLS AND TEST EQUIPMENT .................................... 7
6.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ..................... 8
7.0 SPECIFICATIONS............................................................................................... 10
8.0 PARTS LIST: ........................................................................................................ 11
9.0 FCC NOTICE........................................................................................................ 12
10.0 REPAIR AND RETURN INFORMATION....................................................... 13
11.0 WARRANTY POLICY ........................................................................................ 14
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
3

ISSUE 4.0
1.0 INTRODUCTION
The practices in this manual provide installation and maintenance information for
the CEECO Model WPP-530-X hands free weatherproof Telephone or the SSP-
510-X hands free stainless steel panel telephone.
The information in this manual is subject to change without notification.
For information not included in this manual, please call or write:
CEECO
Customer Service
1580 NW 65th Avenue
Plantation, FL 33313
[phone]
[phone] (FAX)
2.0 GENERAL
2.1 The CEECO Model WPP-530-X or SSP-510-X Hands Free Telephone is a
sturdy, vandal resistant, stainless steel panel speakerphone. Instead of a
hookswitch and handset, the WPP-530-X or SSP-510-X has a Press to
start/Press to stop button for the initiation and termination of phone calls.
The telephone provides an “off hook” condition to the serving line, when
the button is pushed. External “Ring-down” equipment or central office
ring down service must be provided, in order for the telephone to initiate
calls or automatically dial the numbers. Otherwise, the phone may only be
used to receive incoming calls. Manual volume control is also provided
inside the phone, by way of an adjustable “POT”. This should only be
attempted by a qualified technician.
2.2 Programming is accomplished via DTMF keypad.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
4

ISSUE 4.0
3.0 PROGRAMMING
NOTE: It is recommended that you ground yourself to prevent ESD damage
to the PCB(s).
3.1 The phone can be programmed to automatically disconnect a phone call
after the elapse of a selected period of time (1, 3 or 5 minutes). This is
accomplished through the manipulation of mini-jumpers on the Printed
Circuit Board.
3.2 Remove the telephone from the package and place it on a suitable
protective surface so that the internal components may be accessed.
3.3 The Printed Circuit Board, has two plastic mini-jumpers on it. These
mini-jumpers are used to program the Time Out Disconnect feature.
Locate the plastic mini-jumper that has “JP3” written above it in small
white print on the PC board. Below it, in small white print, appear the
words “ON” and “OFF”. Place the mini-jumper across the middle and
far-left copper pins. This is the "ON" position, which activates the Time
Out Disconnect feature. When the automatic call disconnect feature is
not desired, the jumper should be in the “OFF” position (jumper bridges
the middle and far right copper pins). Please refer to the diagram on the
following page for assistance in locating the mini-jumpers.
3.3 When utilizing the Automatic Call Disconnect feature (Call Time-out), a
choice of 1, 3, or 5 minutes is available. Locate the plastic mini-jumper
on the Printed Circuit Board, which has above it “JP2” in small white
print. Below it are “5”, “3” and “1” also in small white print. Place the
jumper so that it bridges the two copper pins corresponding with your
selection of 1, 3, or 5 minutes. Please refer to the diagram on the
following page for assistance in locating the mini-jumpers.
3.4 Programming is now complete and the telephone is ready for
testing/operation.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
5

ISSUE 4.0
3.5 PROGRAMMING DIAGRAM
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
6

ISSUE 4.0
4.0 TESTING/OPERATION
Action: Connect the phone to the desired telephone line. Place a call to the
telephone from another telephone.
Reaction: The telephone rings. Press the “CALL” button to answer the call.
The red LED illuminates (if equipped). A normal speakerphone
conversation is allowed.
Action: Finish the conversation and press the "CALL" button to hang up.
Reaction: The red LED goes out. (If equipped) and the call is terminated. If
the phone is not hung up, it will automatically disconnect if it has
been programmed it as such (refer to section 3.0).
Action: If the phone is mated with a ring-down circuit or other external call
equipment, press the “CALL” button.
Reaction: Dial tone is received and the red LED illuminates (if equipped).
External call equipment should provide desired operation.
Action: The called party answers.
Reaction: A normal speakerphone conversation is allowed.
Action: Finish the conversation and press the "CALL" button to hang up.
Reaction: The red LED goes out. (If equipped) and the call is terminated. If
the phone is not hung up, it will automatically disconnect if it has
been programmed it as such (refer to section 3.0).
5.0 RECOMMENDED TOOLS AND TEST EQUIPMENT
Security Tool, CEECO part number 301-064
Insulated Needle Nose Pliers
Flat Blade/Phillips Head Screwdriver
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
7

ISSUE 4.0
6.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS
6.1 Using a 301-064 security tool (sold separately), loosen and remove the
security screws.
6.2 The security tool is for a standard 5/32" button head screw generally used
on the framework of the phone booths.
6.3 Separate the faceplate assembly from the weatherproof housing by pulling
the faceplate forward.
6.4 Run the inside station wire into the enclosure and terminate on the RJ11C
terminal block inside, as depicted on the following page. The CEECO
provided terminal block (jack) must be used, as it contains required over-
voltage protection circuitry.
6.5 The use of a gas tube station protector is recommended. The station
ground should not exceed 50 ohms.
6.6 Plug the modular line cord from the faceplate assembly into the RJ11C
terminal block.
6.7 Dress the telephone line cord and AC cable away from the security screws
and seat the faceplate into the weatherproof housing.
6.8 Secure the cover assembly by tightening the security screws.
WARNING
A. Never install telephone wiring during a lightning storm.
B. Never install telephone jacks in wet locations unless the
jack is specifically designed for wet locations.
C. Never touch uninsulated telephone wires or terminals,
unless the telephone line has been disconnected at the
network interface.
D. Use caution when installing or modifying telephone lines.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
8

ISSUE 4.0
6.9 OVER-VOLTAGE PROTECTION DIAGRAM
CONFIDENTIAL
This drawing and all information contained
therein is confidential and is the exclusive
property of CEECO and may not be copied,
reproduced or disclosed to anyone, in any
manner whatsoever, or used for any purpose
other than for which it is provided to you,
without the prior written permission of
CEECO.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
9

ISSUE 4.0
7.0 SPECIFICATIONS
1. INPUT POWER C.O. Line powered
2. LOOP CURRENT 28ma. min. 80ma. max.
3. IMPEDANCE 600 ohms
4. SIGNALING DTMF, 70ms tone, 50ms spacing
5. OUTPUT -4.0 to -6.0dbm
6. ENVIRONMENTAL Temperature 0c to 50c Humidity 20%-90%
non condensating
7. PROGRAMMING Via DTMF keypad.
8. DIMENSIONS:
Stainless Steel Panel (SSP)
7 1/6wide x 11 1/4high x 4 1/4deep
(handset on hook).
9. PANEL MOUNTING (SSP) Vertical Surface Mount
10. WEIGHT ( SSP) Approximately 4lb.
11. DIMENSIONS:
Weatherproof Housing (WPP)
9 1/2" wide x 12 5/8" high x 8" deep
(including door).
12. WEATHERPROOF
HOUSING (WPP)
Cast aluminum
13. HOUSING MOUNTING (WPP) 4 holes spaced 8" x 5 7/8" x 13/32"
14. HOUSING WEIGHT (WPP) Approximately 12 pounds
15. MEMORY RETENTION Non-volatile memory retention
16. FCC REGISTRATION NO. BW-88T7-13716-TE-N
17. TYPE JACK RJ11C
18. U.L. LISTED NO. 6OF5
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
1
0

ISSUE 4.0
8.0 PARTS LIST:
QUANTITY PART NUMBER DESCRIPTION
4 331-006 OUTER COVER SECURITY SCREW
1 301-018 MODULAR LINE CORD
1 301-054 MODULAR CONNECTOR (RJ11C)
1 660-100 CEECO LPSPKR BOARD
1 12017 RINGER
1 6020-B MOMENTARY PANEL SWITCH
1 N/A SERVICE MANUAL
1 14123 SPEAKER
1 530-X OR 510-X FACE PLATE
1 331-005 WEATHERPROOF HOUSING
ACCESSORIES :
1 301-064 SECURITY TOOL
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
11

ISSUE 4.0
9.0 FCC NOTICE
9.1 FCC REGISTRATION AND REPAIR INFORMATION
Your new telephone has been registered with the Federal Communication
Commission (FCC) in accordance with Part 68 of its rules. The FCC
requires that you be advised of certain requirements involving the use of
this telephone.
9.2 CONNECTION AND USE WITH THE NATIONWIDE TELEPHONE
NETWORK.
The FCC requires that you connect this telephone to the Nationwide
Telephone Network through a registered jack provided by the Telephone
Company in your area. This jack is a modular outlet, which you can order
from your local telephone company.
9.3 NOTIFICATION TO THE TELEPHONE COMPANY
Before connecting this telephone, the FCC requires that you notify your
local telephone company business office. The number is in the front of
your phone book.
Tell them:
The "line" to which you will connect the telephone (that is, your phone
number), the telephone's FCC registration number and ringer equivalence
number. These numbers are listed in section 7.0
The FCC further requires that you notify your local telephone company
when permanently disconnecting this telephone.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
12

ISSUE 4.0
10.0 REPAIR AND RETURN INFORMATION
10.1 WARRANTY REPAIR
Any device returned requiring warranty service, repair or credit must be
accompanied with a "Return Material Authorization" (RMA) FORM. It
must include: return shipping instructions, original purchase order number
and special marking instruction. A description of the trouble observed
must be attached to the defective unit. This information must be inside
the shipping container.
10.2 DIRECT ALL INQUIRES TO:
CEECO
Repair Department
1580 NW 65th Avenue
Plantation, FL 33313
[phone]
10.3 NON-WARRANTY REPAIR
CEECO will repair equipment out of warranty for a set charge plus parts.
The customer must pay the shipping costs for both directions.
10.4 RETURN FOR CREDIT
Material may be returned for credit only with prior approval. Material
authorized for return is subject to a 15% restocking charge based on the
manufacturer's list price. Return Material Authorization must be
requested no later than 60 days after original shipment.
10.5 EXCHANGE POLICY
If a replacement unit is required it will be shipped in the most expedient
manner consistent with the urgency of the situation. Please contact
"Customer Service" for instructions regarding exchange of modules or
printed circuit boards.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
13

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
14
11.0 WARRANTY POLICY
11.1 GENERAL
CEECO products are guaranteed to be free of defects in material and
workmanship for a period of 365 days from the date of original purchase.
CEECO's obligation under this warranty is limited to repair or
replacement of any part found to be defective by CEECO. Under no
circumstances shall CEECO be liable for loss, damage, cost of repair or
consequential damages of any kind which have been caused by neglect,
abuse, acts of GOD or improper operation of equipment.
11.2 PRINTED CIRCUIT BOARDS
Printed circuit boards should not be field repaired. If a unit is found to be
faulty, replace it with another unit and return the faulty unit to CEECO for
repair. Modifications by anyone other than CEECO will void the
warranty.
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]
