CEECO WPP-531-X User manual

WPP-531-X OR SSP-511-X-SPK1.07-ISSUE4.0
SERVICE MANUAL
FOR
MODEL WPP-531-X
HANDS FREE EMERGENCY
WEATHERPROOF TELEPHONE
OR
MODEL SSP-511- X
HANDS FREE STAINLESS STEEL
PANEL TELEPHONE
EQUIPPED WITH SPK1.07 FIRMWARE
Serving the Telephone Industry Since 1930
Communication Equipment 1580 NW 65th Avenue
& Engineering Company Plantation, FL 33313
Voice: 954-587-5430
Fax: [phone]

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
2
IMPORTANT INFORMATION
FOR
CUSTOMER
Please fill in before you continue.
The following information is necessary when calling CEECO for assistance.
MODEL NUMBER MODEL WPP-531-X OR SSP-511-X
EQUIPPED WITH SPK1.07 FIRMWARE.
SERIAL NUMBER
DATE MANUFACTURED
LOCATION INSTALLED
For us to better serve you, please have this information available when calling for
technical support.
CEECO
Communication Equipment & Engineering Company
1580 NW 65th Avenue
Plantation, FL 33313
[phone] Voice
[phone] Fax

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
3
TABLE OF CONTENTS
SECTION PAGE
1.0 INTRODUCTION................................................................................................... 4
2.0 GENERAL............................................................................................................... 4
3.0 PROGRAMMING .................................................................................................. 5
PROGRAMMING CONTINUED......................................................................... 6
PROGRAMMING CONTINUED......................................................................... 7
4.0 OPERATION .......................................................................................................... 7
5.0 RECOMMENDED TOOLS AND TEST EQUIPMENT .................................... 7
6.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ..................... 8
7.0 TESTING............................................................................................................... 10
8.0 SPECIFICATIONS............................................................................................... 11
9.0 PARTS LIST ......................................................................................................... 12
10.0 FCC NOTICE........................................................................................................ 13
11.0 REPAIR AND RETURN INFORMATION....................................................... 14
12.0 WARRANTY POLICY ........................................................................................ 15
13.0 DIAGRAM............................................................................................................. 16

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
4
1.0 INTRODUCTION
The practices in this manual provide installation and maintenance information for the
CEECO Model WPP-531-X Hands free Weatherproof Telephone or Model SSP-511-X
Stainless Steel Panel Telephone, equipped with SPK1.07 firmware.
The information in this manual is subject to change without notification.
For information not included in this manual, please call or write:
CEECO
Customer Service
1580 NW 65th Avenue
Plantation, FL 33313
[phone]
[phone] FAX
2.0 GENERAL
2.1 The CEECO Model WPP-531-X Hands Free Weatherproof telephone is a
sturdy, vandal resistant, stainless steel weatherproof speakerphone. Instead
of a hookswitch and handset, the WPP-531-X has a Press to start/Press to
stop button for initiation and termination of phone calls. This Emergency
button is provided for automatic ring down applications. Ordinarily, the
telephone can only be used to receive calls. The telephone may, however,
be used to initiate calls if it is used in conjunction with external call
equipment (i.e. programmable switch, ring down circuit, etc…) The
Model SSP-511-X is the same telephone without the weatherproof
housing. Manual volume controls for the microphone and speaker are
provided inside the phones.
2.2 Incoming calls may be allowed or blocked depending on the
programming.
2.3 Programming is accomplished via the DTMF keypad.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
5
3.0 PROGRAMMING
3.1 Remove the front stainless steel panel by loosening the four security
screws with a security tool (sold separately) and remove them. Remove
the panel and attached telephone assembly.
3.2 Connect the telephone to a working telephone line or a DTMF test set.
3.2 Locate the pair of plastic mini-jumpers located near the edge of the
printed circuit board. Move them to the “ON” or innermost position, as
depicted on the last page of this manual.
3.3 Locate the programming keypad, which is either mounted on the back
panel or provided on the side. If the keypad is packaged separately, locate
the multicolored ribbon cable with white connector, which extends from
the PC Board of the phone. Connect the keypad to that connector.
3.4 Each programming location is accessed by dialing the "#" sign and the two
digit code, which corresponds to that location. The only valid program
locations for this phone is #00. The previous contents of the location are
automatically erased when the location code is dialed.
3.5 Press the “CALL & HANGUP” button and wait to hear dial tone.
3.6 Using the keypad, enter # 9 7 # 1 8 #. This will clear all user
programmable memory to begin programming.
3.7 Location "00" is the telephone options location. By entering a number of
1-9 into each of the 10 digits, the phone is customized for the particular
installation.
3.8 Enter #00 followed by ten digits, as selected on the next page. This “X”
model phone only offers selections for Digits 2, 3, and 10 on the next
page. It is recommended that a “5” be entered under Digit 10.
NOTE:
THIS EQUIPMENT IS TELEPHONE LINE POWERED.DURING PROGRAMMING THE CENTRAL
OFFICE OR PBX MAY RESPOND TO THE PROGRAMMING CODES WITH VARIOUS BUSY TONE,
REORDER TONE,RECORDINGS,ETC.THESE TONES AND RECORDINGS WILL HAVE NO
EFFECT ON THE PROGRAMMING.PLEASE IGNORE THEM.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
6
PROGRAMMING CONTINUED
LOCATION #00
Digit 1:
Always 0 for this model.
Digit 2:
0 No incoming calls allowed.
1 Incoming calls allowed.
Digit 3:
0 No time-out disconnect
1-9 Minutes time-out disconnect
Digit 4:
Always 0 for this model
Digit 5:
Always 1 for this model
Digit 6:
Always 0 for this model.
Digit 7:
Always 0 for this model
Digit 8:
Always 0 for this model
Digit 9:
Always 0 for this model
Digit 10:
00 No wink detect.
1-9 Length of the wink detect.
(1=50ms incremental to 450 ms. 5 is recommended).
•Be sure to enter your selections below for future reference.
#00= 0 __ __ 0 1 0 0 0 0 5
DIGITS: 1 2 3 4 5 6 7 8 9 10

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
7
PROGRAMMING CONTINUED
3.9 When you are finished programming, press the “CALL & HANGUP”
button to hang up the phone. Return the two plastic mini-jumpers to the
“OFF” or outermost position, as depicted on the last page of this manual.
Secure the telephone assembly in the housing. The phone is now ready for
use.
4.0 OPERATION
To receive a call, press the "EMER/CALL" button located on the front of the
phone, when the telephone rings. The LED (if provided) will illuminate red at this
time. In order to receive incoming calls the phone must have been programmed
with a “1” under Digit 2 in section 3.8 of this manual. When the call is answered,
a normal speakerphone conversation may take place. After the call is complete,
press the "EMER/CALL" button on the front of the panel again to hang up the
phone. If the user does not press the button on the front of the panel when he or
she is finished using the phone, then the phone will hang up after detecting a wink
(open switch interval) or the timer times out.
If the telephone has been mated with external call equipment, a call may also be
initiated by pressing the “EMER/CALL” button. The LED (if provided) will
illuminate red at this time. The external call equipment should direct the call as
intended and a normal speakerphone conversation may take place. After the call is
complete, press the "EMER/CALL" button on the front of the panel again to hang
up the phone. If the user does not press the button on the front of the panel when
he or she is finished using the phone, then the phone will hang up after detecting a
wink (open switch interval) or the timer times out.
5.0 RECOMMENDED TOOLS AND TEST EQUIPMENT
DTMF Test Set
Volt/Ohm Meter
CEECO Security Tool, 301-064

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
8
6.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS
6.1 Using a 301-064 security tool (sold separately), loosen and remove the
security screws.
6.2 The security tool is for a standard 5/32" button head screw generally used
on the framework of the phone booths.
6.3 Separate the faceplate assembly from the weatherproof housing by pulling
the faceplate forward.
6.4 Run the inside station wire into the enclosure and terminate on the RJ11C
terminal block inside, as depicted on the following page. The CEECO
provided terminal block (jack) must be used, as it contains required over-
voltage protection circuitry.
6.5 The use of a gas tube station protector is recommended. The station
ground should not exceed 50 ohms.
6.6 Plug the modular line cord from the faceplate assembly into the RJ11C
terminal block.
6.7 Dress the telephone line cord and AC cable away from the security screws
and seat the faceplate into the weatherproof housing.
6.8 Secure the cover assembly by tightening the security screws.
*****WARNING*****
A. Never install telephone wiring during a lightning storm.
B. The telephone must be grounded in accordance with local
and national electric codes.
C. Never install telephone jacks in wet locations unless the jack
is specifically designed for wet locations.
D. Never touch uninsulated telephone wires or terminals unless
the telephone line has been disconnected at the network
interface.
E. Use caution when installing or modifying telephone lines.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
9
6.9 OVER-VOLTAGE PROTECTION DIAGRAM

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
1
0
7.0 TESTING
Action: Connect the telephone to a working telephone line.
Place a call to the telephone from another phone.
Reaction: The telephone rings. Press the "EMER/CALL" button to answer
the call. Provided the phone was programmed to allow incoming
calls, a normal speakerphone conversation should transpire.
Action: Finish the conversation.
Press the "EMER/CALL" button, or wait until
time out occurs.
Action: If the telephone has been mated with external call equipment, press
the "EMER/CALL" button to initiate a call.
Reaction: The external call equipment directs the call as intended and a
normal speakerphone conversation is allowed when the called
party answers.
Action: Finish the conversation.
Press the "EMER/CALL" button, or wait until
time out occurs.
Action: If the phone was programmed to not allow incoming calls, try
making a call to the phone.
Reaction: The telephone will ring, but it will drop the line when it is
answered and not allow a conversation to take place.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
11
8.0 SPECIFICATIONS
INPUT POWER: C.O. Line powered
LOOP CURRENT: 33 mA minimum 80 mA maximum
IMPEDANCE: 600 ohms
SIGNALING: Manual on-off hook
ENVIRONMENTAL: Temperature 0o C to 50o C
Humidity 20%-90% non-condensating
PROGRAMMING: Via DTMF keypad.
MEMORY RETENTION: Non-volatile memory retention
DIMENSIONS: 7 1/6"wide x 11 1/4"high x 4 1/4"deep
(SSP) (handset on hook).
MOUNTING: Vertical surface mount.
WEIGHT: Approximately 4 lb.
WEATHERPROOF
HOUSING: Cast aluminum
DIMENSIONS: 9 1/2" wide x 12 5/8" high x 8" deep
(WPP) (including door).
MOUNTING: 4 holes spaced 8" x 5 7/8" x 13/32"
WEIGHT: Approximately 12 pounds
FCC REGISTRATION NO.: BW-88T7-68447-KX-T
TYPE JACK: RJ11C
UL LISTED NO.: 6OF5

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
12
9.0 PARTS LIST
QUANTITY PART NUMBER DESCRIPTION
4 331-006 OUTER COVER SECURITY SCREW
1 301-018 MODULAR LINE CORD
1 531-11075 FACE PLATE
1 301-054 MODULAR CONNECTOR (RJ11C)
1 700-008 KEYPAD CABLE
1 660-000 CEECO SPK BOARD
1 705-110 CONNECTORIZED KEYPAD
1 14067 MICROPHONE.
1 6020 MOMENTARY PANEL SWITCH
1 14024 SPEAKER
1 331-005 WEATHERPROOF HOUSING (WPP)
1 331-010 STAINLESS STEEL PANEL.
1 401-009 RINGER
1 N/A SERVICE MANUAL
ACCESSORIES:
1 301-064 SECURITY TOOL

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
13
10.0 FCC NOTICE
10.1 FCC REGISTRATION AND REPAIR INFORMATION
Your new telephone has been registered with the Federal Communication
Commission (FCC) in accordance with Part 68 of its rules. The FCC
requires that you be advised of certain requirements involving the use of
this telephone.
10.2 CONNECTION WITH THE NATIONWIDE TELEPHONE NETWORK
The FCC requires that you connect this telephone to the Nationwide
Telephone Network through a registered jack provided by the Telephone
Company in your area. This jack is a modular outlet, which you can order
from your local telephone company.
10.3 NOTIFICATION TO THE TELEPHONE COMPANY
Before connecting this telephone, the FCC requires that you notify your
local telephone company business office. The number is in the front of
your phone book.
Tell them:
The "line" to which you will connect the telephone (that is, your phone
number) and the telephone's FCC registration number and ringer
equivalence number. These numbers are listed in Section 8.00.
The FCC further requires that you notify your local telephone company
when permanently disconnecting this telephone.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
14
11.0 REPAIR AND RETURN INFORMATION
11.1 WARRANTY REPAIR
Any device returned requiring warranty service, repair or credit must be
accompanied with a "Return Material Authorization" (RMA) FORM. It
must include: return-shipping instructions, original purchase order number
and special marking instruction. A description of the trouble observed
must be attached to the defective unit. This information must be inside the
shipping container.
11.2 DIRECT ALL INQUIRES TO:
CEECO
Repair Department
1580 NW 65th Avenue
Plantation, FL 33313
[phone]
[phone]
11.3 NON-WARRANTY REPAIR
CEECO will repair equipment out of warranty for a set charge plus parts.
The customer must pay the shipping costs both directions.
11.4 RETURN FOR CREDIT
Material may be returned for credit only with prior approval. Material
authorized for return is subject to a 15% restocking charge based on the
manufacturer’s list price. Return RMA must be requested no later than 30
days after original shipment.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
1
5
12.0 WARRANTY POLICY
12.1 GENERAL
CEECO products are guaranteed to be free of defects in material and
workmanship for a period of 365 days from the date of original purchase.
CEECO's obligation under this warranty is limited to repair or
replacement of any part found to be defective by CEECO. Under no
circumstances shall CEECO be liable for loss, damage, cost of repair or
consequential damages of any kind, which have been caused by neglect,
acts of God, abuse or improper operation of equipment.
12.2 PRINTED CIRCUIT BOARDS
Printed circuit boards should not be repaired in the field. If a unit is found
to be faulty, replace it with another unit and return the faulty unit to
CEECO for repair. Modifications by anyone other than CEECO will void
the warranty.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
1
6
13.0 DIAGRAM
When programming is
completed, move the mini
jumpers to the OFF
position.
NOTE:
Do not leave the mini jumpers in the ON position,
this will decrease battery life.
MOVE THE MINI JUMPERS
TO THE ON POSITION
BEFORE GOING OFF-
HOOK.
Locate the mini jumpers
on the corner of the PCB.
O
N
OF
F
O
N
OF
F
O
N
OF
F
