CEECO MHW-341-X User manual

MHW-341-X-ISSUE4.0
SERVICE MANUAL
FOR
MODEL MHW-341-X
MAGNETIC HOOKSWITCH
WALL TELEPHONE
EQUIPPED FOR DIRECT RING-DOWN OPERATION
Serving the Telephone Industry Since 1930
Communication Equipment 1580 NW 65th Avenue
& Engineering Company Plantation, FL 33313
Voice: 954-587-5430
Fax: [phone]
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]

ISSUE 4.0
IMPORTANT INFORMATION
FOR
CUSTOMER
Please fill in before you continue.
The following information is necessary when calling CEECO for assistance.
MODEL NUMBER MODEL MHW-341-X
SERIAL NUMBER
DATE MANUFACTURED
LOCATION INSTALLED
For us to better serve you, please have this information available when calling for
technical support.
CEECO
Communication Equipment & Engineering Company
1580 NW 65th Avenue
Plantation, FL 33313
[phone] Voice
[phone] Fax
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
2

ISSUE 4.0
TABLE OF CONTENTS
SECTION PAGE
1.0 INTRODUCTION................................................................................ 4
2.0 GENERAL ............................................................................................ 4
3.0 RECOMMENDED TOOLS AND TEST EQUIPMENT ................. 4
4.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS .. 5
5.0 TESTING .............................................................................................. 6
6.0 SPECIFICATIONS.............................................................................. 7
7.0 PARTS LIST......................................................................................... 8
8.0 FCC NOTICE....................................................................................... 9
9.0 REPAIR AND RETURN INFORMATION.................................... 10
10.0 WARRANTY POLICY ..................................................................... 11
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
3

ISSUE 4.0
1.0 INTRODUCTION
The practices in this manual provide installation and maintenance information for
the CEECO Model MHW-341-X Magnetic Hookswitch Wall Telephone.
The information in this manual is subject to change without notification.
For information not included in this manual, please call or write:
CEECO
Customer Service
1580 NW 65th Avenue
Plantation, FL 33313
[phone]
[phone] FAX
2.0 GENERAL
The CEECO Model MHW-341-X Magnetic Hookswitch Wall Style Telephone is
equipped with a magnetically operated hookswitch. The MHW-341-X is
designed for special applications where a telephone must be sturdy and attractive,
and also provide ring-down operation for automatic dialing. It is equipped to
interface with a Central Office type ring down lines or independent ring-down
switches. When the handset is lifted, the external ring-down equipment detects the
telephone and automatic dialing will take place as per the external equipment
programming. The telephone is designed for this direct or point-to-point dialing,
but may receive incoming calls if so permitted by the external equipment.
3.0 RECOMMENDED TOOLS AND TEST EQUIPMENT
Volt/Ohm Meter
1/4" Nut Driver
Flat Blade Screw Driver
Security Tool, CEECO Part Number 301-037 (sold separately)
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
4

ISSUE 4.0
4.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS
4.1 Using a 301-037 security tool (sold separately), loosen (do not remove)
the locking screw on the rear of the phone. The security tool is for a
standard 5/32" button head screw, generally used on the framework of the
phone booths.
4.2 Separate the cover assembly from the backplate assembly by pulling the
bottom forward and lifting up. The backplate assembly is designed to
mount on any flat vertical surface.
4.3 Run the inside station wire into the enclosure and terminate on the RJ11C
terminal block inside. As depicted on the following page. The CEECO
provided terminal block (jack) must be used, as it contains required over-
voltage protection circuitry.
4.4 The use of a gas tube station protector is recommended. The station
ground should not exceed 50 ohms.
4.5 Plug the modular line cord from the cover assembly into the RJ11C
terminal block.
4.6 Dress the line cable away from the locking screw and install the cover
assembly by placing the two tabs into the two corresponding slots and
pushing forward until the housing slips into place for the security screw.
4.7 Secure the cover assembly by tightening the security screw on the rear of
the case.
*****WARNING*****
A. Never install telephone wiring during a lightning storm.
B. Never install telephone jacks in wet locations unless the jack
is specifically designed for wet locations.
C. Never touch uninsulated telephone wires or terminals
unless the telephone line has been disconnected at the
network interface.
D. Use caution when installing or modifying telephone lines.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
5

ISSUE 4.0
4.8 OVER-VOLTAGE PROTECTION DIAGRAM
5.0 TESTING
5.1 With the phone connected to the ring-down line or circuit, lift the handset.
Dial tone should be heard and the pre-programmed number (as per the
external equipment) should automatically dial out.
5.2 Normal phone operation should follow when the call is answered.
5.3 When the call is complete, hang up the phone.
5.4 Place a call to the phone (if permitted by the external equipment).
5.5 The phone should ring indicating the incoming call. Upon answering,
normal telephone operation should follow.
5.6 Hang up the phone. It is ready for use.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
6

ISSUE 4.0
6.0 SPECIFICATIONS
INPUT POWER: C.O. Line Powered
LOOP CURRENT: 23mA min to 80mA max
IMPEDANCE: 600 ohms
SIGNALING: DTMF, 70ms tone, 50ms spacing
HEARING AID
COMPATIBLE: Meets EIA standards
ENVIRONMENTAL: Temperature 0°C to 50°C
Humidity 20%-90% non-condensating
PROGRAMMING: N/A
TELEPHONE COVER: Brushed 16 ga. Stainless Steel
MEMORY RETENTION: N/A
WEIGHT: Approximately 5 lb.
RINGER EQUIVALENCY: 0.4A
FCC REGISTRATION: BW-88T7-13716-TE-T
UL LISTED NO.: 6OF5
TYPE JACK: RJ11C
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
7

ISSUE 4.0
7.0 PARTS LIST
PART NUMBER DESCRIPTION
11013 Stainless Steel Housing with backplate.
12027 Network.
6017 Reed Switch.
14010 Modular Cord.
9023 1/4" –20-3/4" Security Screw.
9005 Grommet.
14014 Modular Jack.
9020 Security Tool.
8093 29" Armored Cord Magnetic Handset
14018 Magnetic Assembly.
12017 Ringer.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
8

ISSUE 4.0
8.0 FCC NOTICE
8.1 FCC REGISTRATION AND REPAIR INFORMATION
Your new telephone has been registered with the Federal Communication
Commission (FCC) in accordance with Part 68 of its rules. The FCC
requires that you be advised of certain requirements involving the use of
this telephone.
8.2 CONNECTION AND USE WITH THE NATIONWIDE
TELEPHONE NETWORK
The FCC requires that you connect this telephone to the Nationwide
Telephone Network through a registered jack provided by the Telephone
Company in your area. This jack is a modular outlet, which you can order
from your local telephone company.
8.3 NOTIFICATION TO THE TELEPHONE COMPANY
Before connecting this telephone, the FCC requires that you notify your
local telephone company business office. The number is in the front of
your phone book.
Tell them:
The "line" to which you will connect the telephone (that is, your phone
number), the telephone's FCC registration number and ringer equivalence
number. These numbers are listed in section 7.0
The FCC further requires that you notify your local telephone company
when permanently disconnecting this telephone.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
9

ISSUE 4.0
9.0 REPAIR AND RETURN INFORMATION
9.1 WARRANTY REPAIR
Any device returned requiring warranty service; repair or credit must be
accompanied with a "Return Material Authorization" (RMA) FORM. It
must include: return shipping instructions, original purchase order number
and special marking instruction. A description of the trouble observed
must be attached to the defective unit. This information must be inside the
shipping container.
9.2 DIRECT ALL INQUIRES TO:
CEECO
Repair Department
1580 NW 65th Avenue
Plantation, FL. 33313
[phone]
[phone] (FAX)
9.3 NON-WARRANTY REPAIR:
CEECO will repair equipment out of warranty for a set charge plus parts.
The customer must pay the shipping costs for both directions.
9.4 RETURN FOR CREDIT:
Material may be returned for credit only with prior approval. Material
authorized for return is subject to a 15% restocking charge based on the
manufacturer's list price. Return Material Authorization must be
requested no later than 60 days after original shipment.
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
10

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
11
10.0 WARRANTY POLICY
10.1 GENERAL
CEECO products are guaranteed to be free of defects in material and
workmanship for a period of 365 days from the date of original purchase.
CEECO's obligation under this warranty is limited to repair or
replacement of any part found to be defective by CEECO. Under no
circumstances shall CEECO be liable for loss, damage, cost of repair or
consequential damages of any kind, which have been caused by neglect,
abuse, acts of GOD, or improper operation of equipment.
10.2 PRINTED CIRCUIT BOARDS
Printed circuit boards should not be field repaired. If a unit is found to be
faulty, replace it with another unit and return the faulty unit to CEECO for
repair. Modifications by anyone other than CEECO will void the
warranty.
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]
