CEECO SSW-321-Xr1 User manual

SSW-321-X-XFD-ISSUE4.0
SERVICE MANUAL
FOR
MODEL SSW-321-Xr1
MINI WALL TELEPHONE
EQUIPPED WITH XFD PRINTED CIRCUIT BOARD
Serving the Telephone Industry Since 1930
Communication Equipment 519 W est South Park Street
& Engineering Company Okeechobee, FL.34972
Voice: 863-357-0798
Fax: [phone]

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
2
IMPORTANT INFORMATION
FOR
CUSTOMER
Please fill in before you continue.
The following information is necessary when calling CEECO for assistance.
MODEL NUMBER
MODEL SSW-321-X STAINLESS STEEL
MINI WALL TELEPHONE WITH XFD
PRINTED CIRCUIT BOARD.
SERIAL NUMBER
DATE MANUFACTURED
LOCATION INSTALLED
For us to better serve you, please have this information available when calling for
technical support.
CEECO
Communication Equipment & Engineering Company
519 West South Park Street
Okeechobee, FL. 34972
[phone] Voice
[phone] Fax

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
3
TABLE OF CONTENTS
SECTION PAGE
1.0 INTRODUCTION................................................................................................. 4
2.0 GENERAL DESCRIPTION................................................................................ 4
3.0 PROGRAMMING................................................................................................ 5
4.0 OPERATION ........................................................................................................ 6
5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS................... 6
6.0 TESTING............................................................................................................... 6
7.0 SPECIFICATIONS............................................................................................... 7
8.0 PARTS LIST ......................................................................................................... 8
9.0 FCC NOTICE........................................................................................................ 9
10.0 REPAIR AND RETURN INFORMATION..................................................... 10

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
4
1.0 INTRODUCTION
The practices in this manual provide installation and maintenance information for
Model SSW 321-X Stainless Steel Mini Wall Telephone equipped with the XFD
printed circuit board.
The information in this manual is subject to change without notification.
For information not included in this manual, please call or write:
CEECO
Customer Service
519 West South Park Street
Okeechobee, FL. 34972
[phone]
[phone] FAX
2.0 GENERAL DESCRIPTION
The CEECO Model SSW-321-X Mini Wall telephone is designed for special
applications where a telephone must be both sturdy and attractive. It is equipped
with an XFD printed circuit board and is intended for “ring down” or direct
connect operations. In such applications, the phone acts as the communication
device only and is dependent upon the phone company or the PBX (or similar
device) connecting any calls as desired. This telephone is equipped with a
receiver operated magnetic reed hookswitch, which equates to fewer moving parts
and a more “sealed” construction. Volume control is inherent to the phone. A
volume control button bearing a universal volume symbol is located on the face of
the housing next to the keypad. With each press of the button, the volume
increases one increment. On the fourth press on when the phone is hung up, the
volume resets to normal. Background noise elimination is also inherent to the
unit and may be activated during programming. Programming is performed by
calling this phone from another phone as described in the next section.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
5
3.0 PROGRAMMING
NOTE: It is recommended that you ground yourself to prevent ESD
damage to the PCB(s).
*****WARNING*****
A. Never install telephone wiring during a lightning storm.
B. Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
C. Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
D. Use caution when installing or modifying telephone lines.
*If background noise elimination is desired, proceed with the following sections of
programming. Otherwise, the phone is ready to be installed and used.
1) Connect the Ceeco XFD Series Telephone to the Telephone Line provided by your local
Telephone Company or to analog type PABX Station.
2) Using another Telephone (Different Telephone Line or cell phone) equipped with a Touch Tone
Keypad, call the CEECO XFD Series Telephone.
3) After 4 rings of the CEECO Telephone, answer it by lifting the handset off hook and keep it that
way. Three tones should be heard indicating the phone is ready for remote input.
4) With the other phone, enter # 2 3 3 2 6 *. This is the factory default 5-digit pass code.
Instructions for changing the pass code appear below. Two (2) beeps will be heard indicating a
valid Pass Code entry. Five (5) beeps will only be heard when an error occurs and programming
was not accepted. Two (2) beeps will always be given to indicate each successful programming
entry below.
Enter # 9 7 * to clear all memory. It is not necessary to do this hereafter. Individual
programming options may be changed from time to time by entering only the necessary key
presses and there is no requirement to “re-program” everything each time.
If the environment is noisy and background noise elimination is desired, enter # 5 9 1 *.
In order to change the Pass Code, enter # 3 1 x * (where x = any 5-Digit pass code).
When programming is completed, simply hang up.
Release Firmware: xfd31_v1_1

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
6
4.0 OPERATION
Lift the handset.
A normal phone conversation may take place as determined by the
set up/application.
5.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS
5.1 Using a 301-037 security tool (sold separately), loosen and remove the
security screw.
5.2 The security tool is for a standard 5/32" button head screw generally used
on the framework of the phone booths.
5.3 Separate the cover assembly from the backplate assembly.
5.4 The backplate assembly may be installed on any standard backboard.
5.5 Run the inside station wire through the backplate assembly and terminate
on to the RJ11C terminal block on the backplate.
5.6 The use of a gas tube station protector is recommended. The station
ground should not exceed 50 ohms.
5.7 Plug the modular line cord from the cover assembly into the RJ11C
terminal block.
5.8 Dress the line cable away from the security screw and install the cover
assembly by inserting the tabs into the slots on top of the backplate.
5.9 Secure the cover assembly by tightening the security screw.
6.0 TESTING
6.1 Program the phone according to section 3.0.
6.2 Lift the handset.
6.5 A normal phone conversation takes place.
6.6 When the call is ended, hang up.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
7
7.0 SPECIFICATIONS
INPUT POWER: C.O. Line Powered
LOOP CURRENT: 20mA min to 80mA max
IMPEDANCE: 600 ohms
HEARING AID
COMPATIBLE: Meets EIA standards
ENVIRONMENTAL: Temperature 0oC to 50oC
Humidity 20%-90% non-condensating.
ENCLOSURE Brushed 16 ga. Stainless Steel
MOUNTING: Vertical surface mount
WEIGHT: 7 lb.
FCC REGISTRATION: BW-88T7-13717-TE-T
UL LISTED NO.: 6OF5
RINGER EQUIVALENCY: 0.1A
TYPE JACK: RJ11C

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
8
8.0 PARTS LIST
QUANTITY PART NUMBER DESCRIPTION
1 301-11909 Stainless Steel Mini Housing
1 XFD Printed Circuit Board
1 301-004-32 Handset with Armored Cord
1 401-009 Ringer
1 301-592 Receiver Operated Magnetic Hookswitch
1 301-018 Modular Cord
1 321-015 Stainless Steel Backplate
1 321-016 1/4 - 20 x 3/4 Security Screw
1 301-005 Cable Ferrule
1 301-052 Grommet
1 301-6077 Volume Control Button
ACCESSORIES:
1 301-037 Security Tool
OPTIONS:
1301-106-32 Handset with Steel Lanyard
1 301-106-18 (Prison) Short Cord Handset with Steel Lanyard

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
9
9.0 FCC NOTICE
9.1 FCC REGISTRATION AND REPAIR INFORMATION
Your new telephone has been registered with the Federal Communication
Commission (FCC) in accordance with Part 68 of its rules. The FCC
requires that you be advised of certain requirements involving the use of
this telephone.
9.2 CONNECTION WITH THE NATIONWIDE TELEPHONE
NETWORK
The FCC requires that you connect this telephone to the Nationwide
Telephone Network through a registered jack provided by the telephone
company in your area. This jack is a modular outlet, which you can order
from your local telephone company.
9.3 NOTIFICATION TO THE TELEPHONE COMPANY
Before connecting this telephone, the FCC requires that you notify your
local telephone company business office. The number is in the front of
your phone book.
Tell them:
The "line" to which you will connect the telephone (that is, your phone
number) and the telephone's FCC registration number and ringer
equivalence number. These numbers are listed in section 8.0.
The FCC further requires that you notify your local telephone company
when permanently disconnecting this telephone.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
10
10.0 REPAIR AND RETURN INFORMATION
10.1 WARRANTY REPAIR
Any device returned requiring warranty service, repair or credit must be
accompanied with a "Return Material Authorization (RMA) Number” and
must also include: return shipping instructions, original purchase order
number and special marking instructions. A description of the trouble
observed must be attached to the defective unit. This information must be
inside the shipping container.
10.2 DIRECT ALL INQUIRES TO:
CEECO
Repair Department
519 West South Park Street
Okeechobee, Florida. 34972
[phone]
10.3 NON-WARRANTY REPAIR
CEECO will repair equipment out of warranty for a set charge plus parts.
The customer must pay the shipping costs both directions.
10.4 RETURN FOR CREDIT
Material may be returned for credit only with prior approval. Material
authorized for return is subject to a 20% restocking charge based on the
manufacturer’s list price. Return Material Authorization must be
requested no later than 30 days after original shipment.

ISSUE 4.0
CEECO
Communication Equipment & Engineering Company
PROPRIETARY
11
11.0 WARRANTY POLICY
11.1 GENERAL
CEECO products are guaranteed to be free of defects in material and
workmanship for a period of 365 days from the date of original shipment.
CEECO’s obligation under this warranty is limited to repair or
replacement of any part found to be defective by CEECO. Under no
circumstances shall CEECO be liable for loss, damage, cost of repair or
consequential damages of any kind, which have been caused by neglect,
abuse, acts of God or improper operation of equipment.
CEECO will repair or replace any unit during this period if found to be
defective for reasons other than abuse and improper use or improper
installation. It is the buyer’s responsibility to return the defective unit to
the factory. CEECO will then repair or replace any defective parts and
return them to the buyer free of charge.
11.2 PRINTED CIRCUIT BOARDS
Printed circuit boards should not be repaired in the field. If a unit is found
to be faulty, replace it with another unit and return the faulty unit to
CEECO for repair. Modifications by anyone other than CEECO will void
the warranty.
