CEM MARS Series User manual

• Determine the line voltage from outlet:
60 Hz - 208 V or 230 V
50 Hz - 200 V, 220 V or 240 V
• Select the line voltage.
• Restart system.
10 • Go to www.cem.com/register to
register your system.
• See back of this sheet for details.
12
• After restart, select “Settings”, then
“Video”, then “Welcome” for a short
introduction. (Not available on all
systems)
11
• Remove the box from inside of the
system cavity.
• Write down the serial number located
on the back left side of the system.
7
• Lay the sides of the box at.
• Remove the foam from the top of
the system.
4
• Pull plastic tab, swing handle open.
• Remove plastic assembly from box.
• Repeat process on other 3
assemblies.
1
• Push the power button on the side of
the system to turn it on.
9
• Remove the plastic and discard.
Do not leave the plastic under
the system.
6
• Carefully cut the tape on both sides
of the inner box.
3
• Attach the exhaust hose, and connect
to back of the system.
• Plug power cord into the system and
a dedicated, grounded outlet.
8
• Lift the system, from the sides, onto
bench top near exhaust service (two
people required). Do not place the
system in a fume hood.
5
• Use top handles to pull up and
remove outer box.
2
Installation Location
1. Designate an area with a sturdy work-
bench within 8' (2.5 m) of a hood or
suitable fume disposal mechanism.
2. Provide at least 8" (20.3 cm) space
on each side and 3" (7.6 cm) space
in the rear for ventilation.
System Dimensions:
21" (53.3 cm) W x 25" (63.5 cm) D x
25" (63.5) H
140 lb in weight (without vessels)
3. Allow space for sample handling
4. The system must be free from the
vibration of large equipment or
walk-through trafc
5. The system must be away from the
primary exits and walk-through trafc
6. Location should have a temperature
of 41°F (5 °C) – 104 °F (40 °C).
7. The system should be connected to
a dedicated, grounded outlet.
Ventilation Requirements
The system comes with 8' (2.5 m) of
exible exhaust hose (3 1∕8" OD x 2 13∕16"
ID). The built-in exhaust system will push
fumes through the hose at 125 CFM.
To properly vent the system, your hood
or exhaust line must draw at least 125
CFM at the point of connection.
Electrical Requirements
The MARS unit requires 208/230 V, 60
Hz, 15A @ 230 V, or 200/220/240 V, 50
Hz, 15A @ 240 V, single phase power. It
requires a 250 V 15 A rated receptacle
(NEMA 6-15R) or a 250 V - 20 A rated re-
ceptacle (NEMA 6-20R). It is non-locking.
MARS Series
Installation Guide

Don’t forget to
register your system.
Go to www.cem.com/register
We’re here to keep you
up and running.
ser[email protected] • 800-726-5551
Already have an account?
Update your prole with your new serial number to
gain access to more owner content.
Need help?
Contact us at websuppor[email protected]
CEM Service is committed to providing the highest level of technical
support and service to our customers. We measure our success
by one standard -- customer satisfaction.
All maintenance and service are performed by technicians trained at the
CEM factory and certied through the CEM Service certication process.
The experienced network of technical support representatives and
service technicians are available for routine
maintenance, calibration, and/or repair.
“Our commitment to you doesn’t end when
your system is shipped; it begins.”
Michael J. Collins
President & CEO, CEM
Download new
method notes
Download software
updates
Get user manuals
and literature
600286
Rev.7
0919
