CE+T Power BRAVO 25 User manual

Contact us: www.cet-power.com | Follow us on social media:
• DUAL INPUT INVERTER
Commercial Power as default source
• AC BACKUP IN A DC ENVIRONMENT
Leverage your existing DC infrastructure
• ONE STOP SHOP
Wide output power range
• HARSHEST AC INPUT CONDITIONS
Without compromising the quality of the AC output
BEYOND THE INVERTER
THE NEW GENERATION OF POWER CONVERTERS
BRAVO 25 - 230-277 VAC
User Manual V1.1
Copyright © 2023. Construction electroniques & telecommunications S.A.
All rights reserved. The contents in document are subject to change without notice.
The products presented are protected by several international patents and trademarks.
Address: CE+T S.a, Rue du Charbonnage 12, B 4020 Wandre, Belgium
www.cet-power.com - [e-mail]
INVERTERS
Bravo 25 - 48/230-277
Bravo 25 - 110/230-277
Bravo 25 - 380/230-277

2 - Bravo 25 - 230-277 Vac - User manual - v1.1
Table of Contents
1. Introduction to CE+T .............................................................................................................................. 6
2. Abbreviations......................................................................................................................................... 7
3. Warranty and Safety Conditions ............................................................................................................. 8
3.1 Disclaimer................................................................................................................................... 8
3.2 Technical care ............................................................................................................................. 8
3.3 Installation .................................................................................................................................. 9
3.3.1 Handling......................................................................................................................... 9
3.3.2 Surge and transients ...................................................................................................... 10
3.3.3 Other.............................................................................................................................. 10
3.4 Maintenance .............................................................................................................................. 10
3.5 Replacement and Dismantling..................................................................................................... 10
4. ECI Technology....................................................................................................................................... 11
4.1 On-line Mode .............................................................................................................................. 12
4.2 Safe Mode................................................................................................................................... 12
4.3 EPC Mode ................................................................................................................................... 12
4.4 Mix Mode & Walk-in Mode........................................................................................................... 12
5. Building Blocks ...................................................................................................................................... 13
5.1 Inverter ....................................................................................................................................... 13
5.2 Specifications.............................................................................................................................. 13
5.3 Controller - Inview S.................................................................................................................... 15
5.3.1 Inview S - Connections................................................................................................... 15
5.4 Inview X ...................................................................................................................................... 16
5.4.1 Inview X - Connections................................................................................................... 16
6. Accessories ........................................................................................................................................... 18
6.1 Cabinet ....................................................................................................................................... 18
6.2 Manual By-Pass .......................................................................................................................... 18
6.3 AC Distribution Unit ..................................................................................................................... 18
6.3.1 Miniature Circuit Breakers.............................................................................................. 18
6.3.2 MCCB............................................................................................................................. 19
7. System Design....................................................................................................................................... 20
7.1 A la Carte .................................................................................................................................... 20
8. Installation of Bravo 25 Shelf ................................................................................................................. 21
8.1 Mounting kit for Bravo 25 shelf.................................................................................................... 21
8.2 Electrical installation for Bravo 25 shelf ....................................................................................... 22
8.2.1 Pre requisites ................................................................................................................. 22
8.2.2 Bravo 25 - 230-277 Single-phase shelf - Terminations................................................... 23
8.2.3 Bravo 25 - 230-277 Three-phase shelf - Terminations ................................................... 24
8.2.4 Grounding ...................................................................................................................... 25
8.2.5 DC Connection ............................................................................................................... 25

3 - Bravo 25 - 230-277 Vac - User manual - v1.1
8.2.6 AC Input Connection....................................................................................................... 25
8.2.7 AC Output Connection .................................................................................................... 26
8.2.8 Signalling ....................................................................................................................... 26
8.2.9 Remote ON/OFF.............................................................................................................. 27
8.2.10 Internal BUS A and B ...................................................................................................... 27
8.2.11 Shelf rear cover.............................................................................................................. 27
9. Installation of Cabinet (A la Carte) .......................................................................................................... 28
9.1 Unpacking the system ................................................................................................................. 28
9.2 Module Packing........................................................................................................................... 28
9.3 Removing the cabinet rear protection .......................................................................................... 29
9.4 Hardware Connections ................................................................................................................ 29
9.5 Electrical Installation ................................................................................................................... 30
9.5.1 Positioning ..................................................................................................................... 30
9.5.2 Cabling........................................................................................................................... 31
9.5.3 Grounding ...................................................................................................................... 31
9.5.4 Surge Suppression ......................................................................................................... 31
9.5.5 AC Input (X2) and Output (X4) ......................................................................................... 32
9.5.6 DC (X1) .......................................................................................................................... 33
9.5.7 Connection table – DC 48 Vdc (X1) ................................................................................. 33
9.5.8 Connection table – DC 110 Vdc (X1) ............................................................................... 33
9.5.9 Connection table – DC 380 Vdc (X1) ............................................................................... 34
9.5.10 Connection table – AC Input (X2) & Output (X4)............................................................... 34
9.5.11 Signalling ....................................................................................................................... 35
10. Operation............................................................................................................................................... 37
10.1 Inverter module........................................................................................................................... 37
10.2 Inview S - LCD interface.............................................................................................................. 38
10.2.1 LED indications .............................................................................................................. 38
10.2.2 Menu structure............................................................................................................... 39
10.2.3 LCD interface - Terminology .......................................................................................... 40
10.3 Inview X - LCD interface.............................................................................................................. 41
10.3.1 Menu structure............................................................................................................... 46
10.3.2 LED indications .............................................................................................................. 47
10.3.3 LCD interface - Terminology .......................................................................................... 47
10.4 Inview S and X - Web Interface.................................................................................................... 48
10.4.1 Login.............................................................................................................................. 49
10.4.2 Interface Areas ............................................................................................................... 49
10.4.3 Web page Controls ......................................................................................................... 51
11. Inserting/removing/replacing - modules................................................................................................. 53
11.1 Bravo 25 Inverter......................................................................................................................... 53
11.1.1 Removal......................................................................................................................... 53
11.1.2 Inserting......................................................................................................................... 53
11.2 Inview S - Panel Mounting........................................................................................................... 54
11.3 Inview X - Panel Mounting........................................................................................................... 55
11.4 Fan replacement ......................................................................................................................... 56

4 - Bravo 25 - 230-277 Vac - User manual - v1.1
12. AC Output Distribution............................................................................................................................ 57
12.1 Miniature Circuit breaker Installation/Removal............................................................................. 57
12.2 MCCB.......................................................................................................................................... 57
13. Manual By-Pass (MBP)........................................................................................................................... 58
13.1 Pre-requisites.............................................................................................................................. 58
13.2 MBP Auxiliary Connection............................................................................................................ 58
13.3 Manual Bypass operation ............................................................................................................ 59
13.3.1 MBP - Single rotary switch............................................................................................. 59
13.3.2 MBP - Three individual switches..................................................................................... 60
14. Finishing................................................................................................................................................ 61
15. Commissioning ...................................................................................................................................... 62
15.1 Check list .................................................................................................................................... 63
16. Trouble Shooting and Defective Situations Fixing.................................................................................... 64
16.1 Trouble Shooting ......................................................................................................................... 64
16.2 Defective modules....................................................................................................................... 65
17. Maintenance.......................................................................................................................................... 66
17.1 Access Inview with Laptop .......................................................................................................... 66
17.2 Manual check.............................................................................................................................. 66
17.3 Optional ...................................................................................................................................... 66
17.4 Manual By-Pass ......................................................................................................................... 66
18. Service .................................................................................................................................................. 67
19. Appendix................................................................................................................................................ 68
19.1 Mains connection, Single phase .................................................................................................. 68
19.2 Mains connection, Three phases.................................................................................................. 69
19.3 Bravo 25 - Dimensions................................................................................................................ 70
19.3.1 Module........................................................................................................................... 70
19.3.2 Shelf .............................................................................................................................. 70

Release Note:
Version Release date
(DD/MM/YYYY) Modified page number Modifications
1.0 03/08/2022 - First release of the Manual
1.1 05/07/2023 - Added 110 and 380 Vdc details
5 - Bravo 25 - 230-277 Vac - User manual - v1.1

1. Introduction to CE+T
CE+T Power designs, manufactures, and markets a range of products for industrial operators, with mission critical
applications, who are not satisfied with existing AC backup system performances and related maintenance costs.
Our product is an innovative AC backup solution that unlike most used UPS’s
•Maximizes the operator’s applications uptime;
•Operates with lowest OPEX;
•Provides best protection to disturbances;
•Optimizes footprint.
Our systems are:
•Modular
•Truly redundant
•Highly efficient
•Maintenance free
•Battery friendly
CE+T power puts 60+ years expertise in power conversion together with worldwide presence to provide customized
solutions and extended service 24/7 - 365 days per year.
Introduction to CE+T
6 - Bravo 25 - 230-277 Vac - User manual - v1.1

2. Abbreviations
AC Alternating current
CB Circuit Breaker
DC Direct current
DHCP Dynamic Host Configuration Protocol
DSP Digital Signal Processor
ECI Enhanced Conversion Innovation
EMBS External Maintenance Bypass Switch
EPC Enhanced Power Conversion
ESD Electro Static Discharge
ETH Ethernet
G Ground / Grounding
HTTP HyperText Transfer Protocol
HTTPS Secure HyperText Transfer Protocol
LAN Local Access Network
MBB Measure Box Battery
MBP Manual By-pass
MCB Miniature Circuit Breaker
MCCB Molded Case Circuit Breaker
MET Main Earth Terminal
MIB Management Information Base
N Neutral
NTP Network Time Protocol
NUA Non-Urgent Alarm
PCB Printed Circuit Board
PE Protective Earth (also called Main Protective Conductor)
PPE Personal Protective Equipment
PWR Power
REG Regular
SNMP Simple Network Management Protocol
TCP/IP Transmission Control Protocol/Internet Protocol
TRS True Redundant Structure
PES Power Extension Shelf
UA Urgent Alarm
USB Universal Serial Bus
Abbreviations
7 - Bravo 25 - 230-277 Vac - User manual - v1.1

3. Warranty and Safety Conditions*
WARNING:
The electronics in the power supply system are designed for an indoor, clean environment.
When installed in a dusty and/or corrosive environment, indoor, it is important to:
•Install an appropriate filter on the enclosure door, or on the room’s air conditioning system.
•Keep the enclosure door closed during operation.
•Replace the filters on a regular basis.
Important Safety Instructions, Save These Instructions.
3.1 Disclaimer
•The manufacturer declines all responsibilities if equipment is not installed, used or operated according to the
instructions herein by skilled technicians according to local regulations.
•Warranty does not apply if the product is not installed, used or handled according to the instructions in the
manual.
3.2 Technical care
•This electric equipment can only be repaired or maintained by a “qualified employee” with adequate training.
Even personnel who are in charge of simple repairs or maintenance are required to have knowledge or
experience related to electrical maintenance.
•Please follow the procedures contained in this Manual, and note all the “DANGER”, “WARNING” AND “NOTICE”
marks contained in this Manual. Warning labels must not be removed.
•Qualified employees are trained to recognize and avoid any dangers that might be present when working on or
near exposed electrical parts.
•Qualified employees know how to lock out and tag out machines so the machines will not accidentally be turned
on and injure employees working on them.
•Qualified employees also know safety related work practices, including those by OSHA and NFPA, as well as
knowing what personal protective equipment should be worn.
•All operators are to be trained to perform the emergency shut-down procedure.
•Never wear metallic objects such as rings, watches, or bracelets during installation, service and maintenance of
the product.
•Maximum operating ambient temperature is 40°C (104°F).
•Insulated tools must be used at all times when working with live systems.
•When handling the system/units pay attention to sharp edges.
•This product is suitable for use in a computer room.
* These instructions are valid for most CE+T Products/Systems. Some points might however not be valid for the product
described in this manual.
Warranty and Safety Conditions
8 - Bravo 25 - 230-277 Vac - User manual - v1.1

3.3 Installation
•This product is intended to be installed only in restricted access areas as defined by local regulations and in
accordance with the National Electric Code, ANSI/NFPA 70, or equivalent agencies.
•The Inverter System may contain output over current protection in the form of circuit breakers. In addition to
these circuit breakers, the user must observe the recommended upstream and downstream circuit breaker
requirements as defined in this manual.
•Please use extreme caution when accessing circuits that may be at hazardous voltages or energy levels.
•The modular Inverter rack is a dual input power supply. The complete system shall be wired in a way that both
input and output leads can be de-energized when necessary.
•REG systems and EPC systems that have no AC input wired and connected can be seen as independent power
sources. To comply with local and international safety standards N (input) and PE shall be bonded. The bonded
connection between N (input) and PE must be removed once the AC input is connected.
•AC and DC circuits shall be terminated with no voltage / power applied (de-energized).
•The safety standard IEC/EN62040-1-1 requires that, in the event of an output short circuit, the Inverter must
disconnect in 5 seconds maximum. The parameter can be adjusted on Inview; however, if the parameter is set at
a value > 5 seconds, an external protection must be provided so that the short circuit protection operates within
5 seconds. Default setting is 60 seconds.
•The system is designed for installation within an IP20 environment. When installed in a dusty or humid
environment, appropriate measures (air filtering) must be taken.
•Environment Conditions:
Storage Conditions: -40 to 70°C
Relative Humidity: 95%, non-condensing
Altitude above sea without de-rating: Less than 1500 m
Greater than 1500 m – de-rating at 0.8% per 100 m
•All illustrations in the manual are for general reference, refer to the technical drawing which is received along
with the system for exact information.
3.3.1 Handling
•The cabinet shall not be lifted using lifting eyes.
•Remove weight from the cabinet by unplugging the Inverters. Mark Inverters clearly with shelf and position for
correct rebuild. This is especially important in dual or three phase configurations.
•Empty Inverter positions must not be left open. Replace with module or dummy cover.
•Before working on the system, Isolate Uninterrupted Power Supply (UPS) and check for hazardous voltage
between all terminals including the protective earth.
Warranty and Safety Conditions
9 - Bravo 25 - 230-277 Vac - User manual - v1.1

3.3.2 Surge and transients
The mains (AC) supply of the modular Inverter system shall be fitted with Lightning surge suppression and Transient
voltage surge suppression suitable for the application at hand. Manufacturer’s recommendations of installation shall
be adhered to. Selecting a device with an alarm relay for function failure is advised.
Indoor sites are considered to have a working lightning surge suppression device in service.
•Indoor sites Min Class II.
•Outdoor sites Min Class I + Class II or combined Class I+II. The modular Inverter system/rack can reach
hazardous leakage currents. Grounding must be carried out prior to energizing the system. Grounding shall be
made according to local regulations.
Note:
Choosing and installing surge arrestors must obey to precise technical rules. Distance to equipment to protect, cable
gage and cable routing have significant influence on proper device service.
Some areas are more susceptible to be hit by electrical strikes, especially when altitude increases.
Good earthing is also crucial for surge arrestors to work properly.
CE+T declines any liability in regard to damaged caused to equipment not correctly or not sufficiently protected.
3.3.3 Other
•Insulation test (Hi-Pot) must not be performed without instructions from the manufacturer.
3.4 Maintenance
•The Inverter system/rack can reach hazardous leakage currents. Earthing must be carried out prior to energizing
the system. Earthing shall be made according to local regulations.
•Prior to any work conducted to a system/unit, make sure that AC input voltage and DC input voltage are
disconnected.
•Prior to accessing the system or modules, make sure all source of supply is disconnected.
CAUTION – Risk of electric shock. Capacitors store hazardous energy. Do not remove cover until 5 minutes after
disconnecting all sources of supply.
•Some components and terminals carry high voltage during operation. Contact may result in fatal injury.
3.5 Replacement and Dismantling
•ESD Strap must be worn when handling PCB’s and open units.
•The Inverter system/rack is not supplied with internal disconnect devices on input nor output.
•CE+T cannot be held responsible for disposal of the Inverter system and therefore the customer must segregate
and dispose of the materials which are potentially harmful to the environment, in accordance with the local
regulations in force in the country of installation.
•If the equipment is dismantled, to dispose of its component products, you must comply with the local regulations
in force in the country of destination and in any case avoid causing any kind of pollution.
Note: To download the latest documentation and software, please visit our website at www.cet-power.com
Warranty and Safety Conditions
10 - Bravo 25 - 230-277 Vac - User manual - v1.1

ECI Technology
11 - Bravo 25 - 230-277 Vac - User manual - v1.1
4. ECI Technology1
Bravo 25 module built with ECI technology and it is a triple port converter (AC in, DC in, AC out). Sinusoidal output is
converted from Mains or/and DC. The block diagram below gives an explicit description of the topology and operation.
The module is built around the following sub-converters
•AC to DC at input
•DC to DC at input
•DC to AC at output
The energy can flow either from the AC source or the DC source under the control of the local DSP controller. Thanks to
internal energy buffering, the output sine wave is constant and disturbance free regardless of the active source.
The BOOST functionality multiples the nominal current for a period of 20 ms (max) in the event of down stream
failures. The upstream breakers do not have to be oversized to prevent tripping. The overload capacity is 125% for 15
seconds.
The ECI works according to True Redundant Structure (TRS) that features decentralized and independent logic,
redundant communication bus and three internal levels of disconnection to isolate a module after internal failure.
This functionality is included in every inverter module. Running them in parallel provides a modular system with, no
single point of failure, always-conditioned output, high system efficiency and 0 ms source transfer time.
1 Information and data given in this chapter is intended to serve as an overview of the ECI Technology. Detailed features and parameters for each individual
module type in the range may differ and should be referred to in the dedicated data sheet.

ECI Technology
12 - Bravo 25 - 230-277 Vac - User manual - v1.1
4.1 On-line Mode
DC is the primary source of supply whilst Mains (AC) works as the secondary source. Switching time between DC
input and AC input is 0 ms (source transfer). The power delivered by the DC source (usually a battery, but possibly any
other type of DC generator) is converted to provide regulated and transient-free power to the load. In the event of a
short circuit on the load side, the boost is automatic, timely and energized for a specific duration to trip downstream
protective devices.
4.2 Safe Mode
Safe mode uses DC as the primary source of supply while Mains (AC) is on standby.
Mains (AC) is normally disconnected through an internal inlet relay and is only connected when down stream clearance
is required (boost) or if DC is unavailable.
The transfer between DC and AC results in a typical transfer time of 10 ms.
Typically the safe mode is used in extremely harsh environments such as railways. Under such conditions, it provides
extra isolation against mains-borne disturbances.
4.3 EPC Mode
Mains input (AC) is the primary source whilst DC works as backup.
The ECI is designed to operate on Mains on a permanent basis and to deliver output voltage conditioned with low THD.
The output sine wave is physically independent of whether the source is AC (or) DC. If the Mains is out of tolerance
or goes down, the Inverter seamlessly switches to DC and the Inverter operates in “Back-up mode” (Changeover
switching time is 0 ms).
As soon as the Mains returns to its valid range, the EPC mode is automatically resumed.
The EPC mode offers higher efficiency (up to 96% depending on the model) without compromising the purity of the
output sine wave.
Remarks: REG modules:
Inverter modules carrying the ECI logo together with the REG mark work only with DC input. Sinusoidal output is
converted from DC with the module operating as a traditional inverter. EPC mode and the boost are not available with
REG modules.
4.4 Mix Mode & Walk-in Mode
Under some circumstances the DC and AC sources can be combined. The sequence is defined by a user selectable set
of parameters. Start, control and exit are fully automatic.
A specific example of Mix-mode is the Walk-in mode where the transfer from DC source to AC source is ramped up
within a fixed and adjustable period of time.

Building Blocks
13 - Bravo 25 - 230-277 Vac - User manual - v1.1
5. Building Blocks
5.1 Inverter
Telecom / Datacom: Input 48, 110 and 380 Vdc
230, 240 and 277 Vac, 50/60 Hz
Output 230, 240 and 277 Vac
Power 3000 VA / 2400 W @ 48 Vdc
3000 VA / 2500 W @ 110 & 380Vdc
•The Bravo 25 is a triple port inverter.
•Hot swappable and hot pluggable.
•The front LED’s indicate the converter status and output power.
•The modules is equipped with soft start.
•Module fan is field replaceable.
•435 mm (D) x 102 mm (W) x 88 mm (H).
•5 Kg.
5.2 Specications
Model Bravo 25 - 48/230-277 Bravo 25 - 110/230-277 Bravo 25 - 380/230-277
Part Number: Module/
Shelf/Shelf without Isolation
T721D30201 /
T724730000
T621D50201 /
T624D50010 /
T624D50000
T721D70201 /
T724D70010 /
T724D70000
Cooling / Audible noise Fan forced cooling / <65db @1meter
MTBF 240 000 hrs (MIL-217-F) at 30°C ambient and 80% load
Dielectric strength DC/AC 4300 Vdc 2100 Vdc
RoHS / Material (casing) Compliant / Aluzinc steel
Operating T° / Relative
Humidity (RH) non-condensing
Tested according ETS300-019-2-3 Class 3.1
-20°C to 65°C, power de-rating from 40°C to 65°C / Max RH 95% for 96 hours
per year
Storage T° / Relative Humidity
(RH) non-condensing
Tested according ETS300-019-2-1 Class 1.2
-40°C to 70°C / Max RH 95% for 96 hours per year
Public transport T°/Relative
Humidity (RH) non-condensing
Tested according ETS300-019-2-2 Class 3.1
-40°C to 70°C / Max RH 95% for 96 hours per year
Vibration GR63 office vibration 0 to 100 hz-0.1 g / transport vibration 5-100 Hz 0.5 g 100
to 500 hz-1.5 g / Drop test
Altitude above sea without de-
rating of power < 1500 m / derating > 1500 m – 0.8 % per 100 m / max 4000 m
AC Input Data
Nominal voltage (current) 230 Vac (11.8 A), 240 Vac (11.0 A) and 277 Vac (9.5 A)
Voltage range 150 - 293 Vac (derating from 195 to 150 Vac)

Model Bravo 25 - 48/230-277 Bravo 25 - 110/230-277 Bravo 25 - 380/230-277
Brownout 1600 W @150 Vac /
2400 W (48 Vdc), 2500 W (110 & 380 Vdc) @195 Vac linear decreasing
Power factor / THD > 0.99 / < 3%
Frequency (Synchronization
range) 50 Hz (47 - 53 Hz) or 60 Hz (57 - 63 Hz)
DC Input Data
Nominal voltage (range) 48 Vdc (32 - 63 Vdc) 110 Vdc (90 - 150 Vdc) 336 Vdc (200 - 430 Vdc)
Nominal current 53.4 A 24.3 A 8 A
Maximum input current (for 15
seconds) / voltage ripple 66.8 A / < 10 mV RMS 30.3 A / < 10 mV RMS 9.9 A / < 250 mV RMS
Reverse polarity protection Yes
AC Output Data
Efficiency AC to AC (EPC) / DC
to AC > 96% / > 93.7% > 96% / > 93.7% > 96% / > 94.5%
Nominal voltage (User
selectable) 230 Vac / 13.1 A, 240 Vac / 12.5 A and 277 Vac / 10.8 A (200 - 277 Vac)
Frequency / frequency
accuracy 50 or 60 Hz / 0.03%
Nominal Output power 3 kVA / 2.4 kW 3 kVA / 2.5 kW 3 kVA / 2.5 kW
Short time overload capacity 125% (15 seconds)
Admissible load power factor Full power rating from 0 inductive to 0 capacitive
Total harmonic distortion
(resistive load) < 3%
Load impact recovery time
(10% - 90%) ≤ 0.4 ms
Nominal current 13 A @ 230 Vac
Crest factor at nominal power 3 : 1 for load P.F. ≤ 0.7
Short circuit clear up capacity
at AC input / On battery
109 A / 31 Arms for 20
ms 109 A / 34 Arms for 20 ms
Short circuit current after >
20 ms 22.5 A for 15 seconds
AC Output voltage stability ±1% from 10% to 100% load
Static / Dynamic voltage
regulation
±1% between 10% and 100% load / <5% from 0 to 100% to 0 load impact
(100 ms)
In Transfer Performance
Max. Voltage interruption /
total transient voltage duration
(max)
0 sec / 0 sec
Building Blocks
14 - Bravo 25 - 230-277 Vac - User manual - v1.1

Model Bravo 25 - 48/230-277 Bravo 25 - 110/230-277 Bravo 25 - 380/230-277
Signalling & Supervision
Display Synoptic LEDs on module and touch screen with Inview S and Inview X
Supervision / Part number Inview ranges: Inview X - T602004200, Inview S - T602004100 and
Inview GW - T602004000
Remote ON/OFF At rear terminal of the shelf
Battery Monitoring / Part
number MBB (Measure Box Battery) - 6 dry contacts and 8 digital Inputs / T602006000
Safety & EMC
Electrical Safety EN60950-EN62040-1-UL1778-IEC62109/1-IEC62109/2
EMC EN300386V1.6.1 / EN61000-1-2-3-4
Environment GR3108 class 2 for outdoor
5.3 Controller - Inview S
Inview S is an advanced monitoring and controller unit for Bravo 25, Bravo 10, Sierra 25, and Sierra 10 power
systems. It allows the user to easily access the system information through inbuilt powerful touch screen graphic
display. In addition to the touch screen display, the user can also access the system information through the web
interface and SNMP protocol.
The Inview S interface provides the user to access the configuration and setup files of the modules in the system. Also,
it is a controller for DC regulation.
Inview S can monitor up to 32 inverters/converters and featured with:
•LCD touch screen display
•2 Digital Inputs
•2 Output Relay contacts
•Records 5000 events as FIFO
5.3.1 Inview S - Connections
Inview S is composed of multiple network ports and inbuilt free potential contacts.
C
-
C
+
-
NC
+Digital Input 2
Digital Input 1
Output Relay 2
Output Relay 1
Power 12 Vdc
NC
PE
NO
-
NO
+
CAN
iso RS485
ETH
USB
CE+T COM
•CE+T COM port is dedicated to establish connection between Inview S and Bravo shelf.
•ETH ( ) port is used for network connectivity and user can access the system information in the Web
Interface.
Building Blocks
15 - Bravo 25 - 230-277 Vac - User manual - v1.1

•CAN / iso RS485 port is used to establish communication between Inview S and MBB.
•USB port is used to access the Inview S configuration and setup files.
•Digital Inputs (D1 and D2): Two potential free Digital Inputs are available for customer connections.
Digital Input 1 is assigned for MBP operation if used.
Digital Input 2 is assigned for Surge Arrester if used.
•Output Relays (K1 and K2): Two output relays are available and can be used for Major and Minor Alarms.
•Power: The unregulated separate +12 V power supply is required for powering Inview S and this power should
not be shared with other devices. (CET can provide Auxiliary Power Supply converter and the part number is
T602004120).
5.4 Inview X
Inview X is an advanced monitoring and controller unit for Bravo 10, Bravo
25, Sierra 10 and Sierra 25 power systems. It allows the user to easily view,
access, configure the system information through LCD screen graphic display
and web interface. The home screen of both LCD and web interface provides a
summary of system power, modules, batteries, and events information.
The Ethernet ports in Inview X allow multiple communication points for remote
communication, Web interface, and connecting the accessories such as
Measure Box Battery, PES, and Gateway.
Inview X interface provides the user access to the configuration and setup files
of the modules that are connected in the system. It is also a controller for DC regulation.
Inview X is featured with:
•Monitor up to 32 inverters
•7” LCD touch screen display
•Two Digital Inputs and two Output Relay contacts
•Records 5000 events as FIFO
5.4.1 Inview X - Connections
Inview X composed of multiple network ports and inbuilt free potential contacts.
ETH1
ETH2
RS485
iso CAN PWR D1 D2K1 K2
CAN MB
CE+T COM
ETH
B
HNO NONC NCC C
A
L
GND
GND + PE - + - + -+ PE -
•CE+T COM port is dedicated to establish connection between Inview X and Sierra - shelf.
Building Blocks
16 - Bravo 25 - 230-277 Vac - User manual - v1.1

•ETH ports are used for network connectivity, and user can access the system information through the web
interface.
ETH Front: DHCP server, providing access to the configuration at URL https://inview.local or
https://10.250.252.1
○Intended for direct connection of a laptop computer.
Warning: Do not connect this port to the network, as it might interfere with other DHCP servers.
ETH1: Main network interface
○Default static IP address: 10.250.250.1/24
○It can be configured to other static addresses or as a DHCP client in a web-based configuration
interface
ETH2: Secondary network interface
○Static IP address: 10.250.251.100/24
○It is dedicated to CE+T accessories like Inview Gateway and do not connect to the network
•CAN MB port is used to share the system information to the Measure Box Battery. It also provides the +12 Vdc
power to three accessories which are connected in series.
•iso CAN is used for CAN communication.
•RS485 is used for Modbus communication.
•USB port is used for internal factory purpose.
•Digital Inputs (D1 and D2): Two potential free Digital Inputs are available for customer connections.
Digital Input 1 is assigned for MBP operation if used.
Digital Input 2 is assigned for Surge Arrester if used.
•Output Relays (K1 and K2): Two output relays are available and can be used for Major and Minor alarms.
•Power: The unregulated separate +48 V power supply is required for powering Inview X and this power should
not be shared with other devices.
Building Blocks
17 - Bravo 25 - 230-277 Vac - User manual - v1.1

6. Accessories
6.1 Cabinet
Powder coated (RAL 7024), 19 inch Flat Pack cabinet with 600 x 600 mm foot print. Cabinet designed for top cabling
or bottom cabling.
•1100 mm (600 x 600 mm) 21U
•1800 mm (600 x 600 mm) 37U
•2100 mm (600 x 600 mm) 44U
The cabinet comes with a separable top cover to facilitate cabling. Tie strap support at cable entrance/exit. The door
accessory is optional.
6.2 Manual By-Pass
The manual by pass operates via manually operated switches to create a short circuit from the
AC main input directly to the output AC distribution. Standard manual by-pass is “Make before
Break”. When engaged or disengaged, no disturbance is transmitted to the load.
When MBP is engaged, inverter modules are switched off and can be removed without
impacting the load. The battery supply is not physically disconnected. After disconnecting the
battery supply (by opening the battery breakers), the shelf section is safe for maintenance.
Warning:When the system is in by-pass, the load is subjected to AC main disturbances. Before engaging manual bypass,
make sure the voltage difference between AC IN and AC OUT should be less than 5 Vac to limit the inrush current.
6.3 AC Distribution Unit
6.3.1 Miniature Circuit Breakers
The standard AC output distribution unit is designed with a 35 mm
DIN rail, Multi Clip termination board and N/PE copper terminal
bars, and built as a part of the cabinet.
The Multi Clip offers unique flexibility during installation and
expansion. The terminals are spring loaded and adapt contact
pressure to the size of conductor. Only one cable can be inserted
per spring loaded terminal.
The AC distribution unit is available with 1 pole, 2 pole or 3 poles.
Max current per AC DU is 200 A, max current per terminal
connector is 40 A. Two adjacent terminal connectors shall be used
for 63 A breakers.
Accessories
18 - Bravo 25 - 230-277 Vac - User manual - v1.1

If an alarm is required for AC output breakers, a help contact attached to each individual breaker is used (OF or SD).
The alarm function is common and uses one of the digital inputs on the control unit. The help contact limits the
breakers quantity.
Single pole Double pole Three pole
w/o help
contact
With help
contact OF/
SD
w/o help
contact
With help
contact OF/
SD
w/o help
contact
With help
contact OF/
SD
Up to 40A 24 16 12 9 8 6
6.3.2 MCCB
AC output distribution via MCCB in the range
up to 400 A (1p, 2p or 3p).
Max two MCCB per inverter cabinet.
Accessories
19 - Bravo 25 - 230-277 Vac - User manual - v1.1

7. System Design
7.1 A la Carte
The A la Carte is pre-assembled and configured as a single phase or three phase system. The system comprises
cabinet, inverter sub rack, inverter modules (48, 110 and 380 Vdc), manual by-pass, monitor device and AC output
distribution.
The A la Carte is available in EPC (Enhanced Power Conversion) or REG (Regular) mode.
The A la Carte (single phase) accommodates 1 to 32 modules, for max 96 kVA.
The A la Carte (three phase) accommodates 3 to 30 modules, for max 90 kVA.
By using PES, the system can parallel up to 810 kVA
•Dual input (AC and DC) inverter modules (EPC).
•96% efficiency during normal operation (EPC).
•Always conditioned and filtered output voltage.
•Seamless transfer (0 ms) between primary and secondary source of supply.
•No single point of failure.
•Flexible AC output distribution.
•Full modularity and redundancy.
System Design
20 - Bravo 25 - 230-277 Vac - User manual - v1.1
