CFM DVK-0910 User manual

DVKDVK
Dryer Booster FansDryer Booster Fans

HHoowwWWeellllDDooeessYYoouurrDDrryyeerrPPeerrffoorrmm??
Most residential dryers are designed to vent approximately 15
feet of duct. With the introduction of main floor and second story
laundry rooms, duct runs have become complex, often exceeding
dryer manufacturers’ recommendations. The results are longer
drying times, greater wear and tear on the dryer and higher
energy costs.
DDVVKKDDrryyeerrBBoooosstteerrFFaannss
AABBeetttteerrIIddeeaa
Continental Fan’s DVK Dryer Booster Fans are designed to enhance
the drying efficiency of residential, commercial and industrial dryers.
DVK Fans feature quiet and efficient backward curved impellers that
are capable of overcoming long duct runs, and an in-line configuration
that simplifies installation. Unique design features result in a quiet and
powerful solution that is unmatched in the industry.
DDeessiiggnnFFeeaattuurreess
• External rotor motor for quiet & efficient operation
• Backward curved impeller to overcome long duct runs
• In-line construction to reduce lint build-up
• High temperature construction: 60 C/140 F
• Thermal overload protection
• Automatic reset
DDrryyeerrBBoooosstteerrKKiittss
DVK Dryer Booster Fans are available in a selection of easy-to-install kits.
• DVK100B-C Kit with Current Sensor
• DVK100B-T Kit with Timer
• DVK100B-P Kit with Pressure Switch
• DVK100B-PM Kit with Pressure Switch - Mounted
2

CCuurrrreennttSSeennssoorr(DVK100B-C Kit)
This is the preferred method for activating a dryer booster fan. When a clothes dryer
is operating and drawing at least one amp of current, the current sensor automatical-
ly activates the DVK100B dryer booster fan.
TTiimmeerr(DVK100B-T Kit)
Timers are simple to install and are maintenance free. Simply setting the fan timer to
the same period as the dryer timer activates the DVK100B dryer booster fan.
PPrreessssuurreeSSwwiittcchh(DVK100B-P Kit)
The pressure switch is designed to be mounted in the duct between the fan and the
dryer. When it senses dryer airflow, the switch activates the DVK100B dryer booster
fan.
PPrreessssuurreeSSwwiittcchh--MMoouunntteedd(DVK100B-PM Kit)
The pre-mounted pressure switch simplifies installation. Utilizing the components
found in the DVK100B-P kit, the pressure switch is pre-wired and factory mounted to
the DVK100B dryer booster fan.
NNoottee::Each of the above booster fan activation methods may be purchased as a
separate accessory item.
BBoooosstteerrFFaannAAccttiivvaattiioonnMMeetthhooddss
Lint Trap Roof CapsWall CapsMounting Clamps
AAvvaaiillaabblleeAAcccceessssoorriieess
A full range of accessories is available to suit each application.
3
DDVVKKDDrryyeerrBBoooosstteerrFFaannss

DVK-0910
Distributed By:
Continental Fan Manufacturing Inc.
203 Eggert Road
Buffalo, NY 14215
Tel: [phone] Toll: 800-779-4021
Fax: [phone]
www.continentalfan.com
Aeroflo Inc.
12–205 Matheson Blvd. East
Mississauga, Ontario, Canada L4Z 3E3
Tel: [phone] Toll: 800 -779-4021
Fax: [phone]
www.aeroflo.com
EXT
External Mount Duct Fans
AeroFan
Superior Bathroom Fans AXC In-Line Duct Fans
CX
Air Purification Systems
AAddddiittiioonnaallCCFFMMPPrroodduuccttss
MODEL
CUBIC FEET PER MINUTE
0”SP 1/8”SP 1/4”SP 3/8”SP 1/2”SP 3/4”SP 1”SP 11/4”SP 11/2”SP
DVK100B 152 146 139 131 124 106 82 66 33
MODEL WATTS AMPS RPM dBA
D
(in.)
d
(in.)
a
(in.)
B
(in.)
WT
(lbs)
DVK100B 85 0.69 2400 54 9.5 3.9 1.0 8.3 6.5
DDiimmeennssiioonnaallDDaattaa
PPeerrffoorrmmaanncceeDDaattaa
LT100 Lint Trap
DVK Kit
RC100 Roof Cap
CX
CX
Complete
Complete
Air Purification Systems
Air Purification Systems
AeroFan
AeroFan
Superior Bathroom Fans
Superior Bathroom Fans
EXT
EXT
External Mount Duct Fans
External Mount Duct Fans
AXC
AXC
In-Line Duct Fans
In-Line Duct Fans
IInnssttaallllaattiioonnTTiippss
• DVK100B fans should be mounted at least 15 linear feet from dryer.
• Each 90-degree elbow is equivalent to 5 linear feet of duct.
• DVK100B fans are designed to vent up to 110 feet of 4-inch rigid duct.
HHeellppffuullHHiinntts
An LT100 Lint Trap may be installed between the dryer and the boost-
er fan to reduce lint build-up and maintenance on the fan.
