CFM WEB-0807 User manual

better AIRFLOW
by DESIGNTM
Custom Fan SolutionsTM
• Fans shipped fully assembled
• Heavy duty 16 Ga. steel venturi with tubular steel bracing
• Industrial grade gray enamel finish
• Steel blade impeller with sealed pillow block shaft bearings
• Permanently lubricated ball bearing motor
• Single or three phase continuous duty motor
• Sizes range from 24” to 60”
• Belt drive capacities to 39,000 cfm
PANEL FANS
WEB
BELT DRIVE
PANEL FANS

A D
AB
C
B DIMENSION VARIES WITH
MOTOR HP & ENCLOSURE
WWEEBBBBEELLTTDDRRIIVVEEPPAANNEELLFFAANNSS
FFEEAATTUURREESS&&BBEENNEEFFIITTSS
• Shipped fully assembled, tested and ready to install
• Heavy duty 16 Ga. steel venturi with tubular steel bracing
• Industrial grade gray enamel finish
• Steel blade impeller
• Permanently lubricated drive shaft bearings
• Permanently lubricated ball bearing motor
• Single or three phase continuous duty motor
• Sizes range from 24” to 60”
• Belt drive capacities to 39,000 cfm
• Available in the following voltages:
o 115/230V 1 phase
o 230/460V 3 phase
o 575V 3 phase
2
AACCCCEESSSSOORRIIEESS//OOPPTTIIOONNSS
• MSRG option includes:
o Mounting box
o Discharge shutter
o Rear box guard kit
MODEL A B C D
WT (LBS)
LESS MTR
WT (LBS)
WITH MTR
WEB-24 30 18 3.5 25 60 90
WEB-30 36 18 3.5 31 70 115
WEB-36 42 20 4.0 37 115 165
WEB-42 48 20 4.3 43 160 225
WEB-48 54 22 4.3 49 200 280
WEB-60 66 28 5.0 61 260 350
*DO NOT USE FOR CONSTRUCTION CONSULT FACTORY FOR CERTIFIED PRINTS
DIMENSIONS IN INCHES*

WWEEBBBBEELLTTDDRRIIVVEEPPAANNEELLFFAANNSS
MODEL RPM MTR
HP
0” S.P.
CFM
0.125” S.P.
CFM
0.25” S.P.
CFM
0.50” S.P.
CFM
0.75” S.P.
CFM
WEB-24-13 825 0.33 5300 4700 3800 2200 1400
WEB-24-12 925 0.50 6200 5700 5000 4000 2600
WEB-24-34 1050 0.75 7000 6600 6000 4400 3000
WEB-24-01 1175 1 7800 7400 6900 5700 3500
WEB-30-13 570 0.33 7500 6000 3400 700 -
WEB-30-12 625 0.50 8500 7100 4400 2700 1300
WEB-30-34 725 0.75 10000 9100 7600 5100 1800
WEB-30-01 825 1 11000 10400 9300 5500 2800
WEB-36-13 425 0.33 9000 6800 3500 500 -
WEB-36-12 500 0.50 10500 8800 5900 3600 2000
WEB-36-34 575 0.75 11900 10500 8500 5500 4000
WEB-36-01 650 1 13100 11800 10200 6900 5000
WEB-36-32 750 1.50 15000 13500 12500 8500 5500
WEB-36-02 830 2 16500 15500 14500 11000 7000
WEB-42-34 430 0.75 14000 11500 7600 4800 3300
WEB-42-01 490 1 15400 13100 10400 6400 4600
WEB-42-32 550 1.50 17200 15300 12400 7900 5300
WEB-42-02 620 2 19400 17500 15600 9700 6000
WEB-42-03 700 3 22000 20500 19000 15000 8000
WEB-48-34 350 0.75 17000 12000 7000 2000 -
WEB-48-01 400 1 19100 16000 10900 6400 4000
WEB-48-32 460 1.50 22000 19000 14000 10000 6000
WEB-48-02 520 2 24000 22000 18000 12000 7500
WEB-48-03 590 3 27500 25000 22500 16000 9000
WEB-48-05 660 5 30500 28500 26000 21000 13000
WEB-60-02 320 2 31000 26000 16000 7000 -
WEB-60-03 370 3 35000 31000 23000 11000 -
WEB-60-05 420 5 39000 35000 29000 18000 -
PERFORMANCE
MMSSRRGG––MMOOUUNNTTIINNGGBBOOXX,,SSHHUUTTTTEERR&&RREEAARRGGUUAARRDDBBOOXXKKIITT
• Available in 24”-60” sizes
• Heavy gauge fan & shutter mounting box
• Fully mounted discharge shutter
• Full rear box guard kit (assembly required)
3

WEB-0807
WEB BELT DRIVE PANEL FANS
