Challenger Lifts BT3300 Instruction manual

Rev 22-03-17
Installation, Operation & Maintenance Manual
Battery Lift
MODEL: BT3300
1500 KG / 3300 LBS. CAPACITY
IMPORTANT: READ THIS MANUAL COMPLETELY
BEFORE
INSTALLING OR OPERATING LIFT
2311 South Park Road, Louisville, KY 40219
Email:
[email protected]
Website:
www.challengerlifts.com
Office 800-648-5438 / 502-625-0700
Fax [phone]

Battery Lift
Installation, Operation and Maintenance
1
TABLE OF CONTENTS
1.0 OWNER / EMPLOYER OBLIGATIONS.............................................................................................. 2
2.0 IMPORTANT SAFETY INSTRUCTIONS ............................................................................................. 3
3.0 SAFETY WARNING DECALS ............................................................................................................ 5
4.0 GENERAL SPECIFICATIONS............................................................................................................. 6
5.0 TOOLS REQUIRED FOR INSTALLATION OF LIFT .............................................................................. 7
6.0 RECEIVING..................................................................................................................................... 8
7.0 INSTALLATION AND OPERATION INSTRUCTIONS........................................................................... 8
7.1 INSTALLATION INSTRUCTIONS......................................................................................................... 8
7.2 OPERATION INSTRUCTIONS .......................................................................................................... 12
7.2.1 PALLET JACK........................................................................................................................ 12
7.2.2 FLEXIBLE LIFTING PLATFORM ............................................................................................. 12
7.2.3 CONTROL SYSTEM DESCRIPTIONS...................................................................................... 15
7.2.4 CONTROL BUTTON DESCRIPTIONS..................................................................................... 16
7.2.5 CONSOLE RELATED DESCRIPTIONS..................................................................................... 16
7.2.6 HYDRAULIC PRINCIPLE ....................................................................................................... 17
7.3 OWNER/OPERATOR CHECKLIST..................................................................................................... 18
8.0 OPERATION PROCEDURE............................................................................................................. 19
8.1 SAFETY NOTICES AND DECALS ...................................................................................................... 19
8.2 OWNER/EMPLOYER RESPONSIBILITIES .........................................................................................19
8.3 IMPORTANT SAFETY INSTRUCTIONS ............................................................................................. 19
8.4 LIFTING A BATTERY........................................................................................................................ 20
8.5 LOWERING A BATTERY .................................................................................................................. 20
9.0 RECOMMENDED MAINTENANCE................................................................................................ 21
10.0 EMERGENCY OPERATION ............................................................................................................ 22
11.0 TROUBLESHOOTING.................................................................................................................... 23
12.0 ORD OF MAINTENANCE/TRAINING............................................................................................. 24
13.0 BATTERY LIFT ASSEMBLY ............................................................................................................. 25
13.1 LIFT ASSEMBLY ............................................................................................................................ 25
13.2 BASE FRAME ASSEMBLY .............................................................................................................. 27
13.3 SCISSOR ASSEMBLY ..................................................................................................................... 28
13.4 PLATFORM ASSEMBLY ................................................................................................................. 29
13.5 CONSOLE BOX ASSEMBLY............................................................................................................ 31

Battery Lift
Installation, Operation and Maintenance
2
1.0 OWNER /EMPLOYER OBLIGATIONS
1. The Owner/Employer shall ensure that lift operators are qualified and that they are trained in the safe use and
operation of the lift using the manufacturer’s operating instructions; ASME PASE-2019, Safety Standard for
Portable Automotive Service Equipment;National Standard for Automotive Lifts - Safety Requirements
for Operation, Inspection and Maintenance.
2. The Owner/Employer shall establish procedures to periodically inspect the lift in accordance with the lift
manufacturer’s instructions and ASME PASE-2019, Safety Standard for Portable Automotive Service
Equipment; National Standard for Automotive Lifts - Safety Requirements for Operation, Inspection and
Maintenance; and the Employer shall ensure that the lift inspectors are qualified and that they are adequately
trained in the inspection of the lift.
3. The Owner/Employer shall establish procedures to periodically maintain the lift in accordance with the lift
manufacturer’s instructions and ASME PASE-2019, Safety Standard for Portable Automotive Service
Equipment;National Standard for Automotive Lifts - Safety Requirements for Operation, Inspection and
Maintenance; and the Employer shall ensure that the lift maintenance personnel are qualified and that they are
adequately trained in the maintenance of the lift.
4. The Owner/Employer shall maintain the periodic inspection and maintenance records recommended by the lift
manufacturer’s instructions and ASME PASE-2019, Safety Standard for Portable Automotive Service
Equipment;National Standard for Automotive Lifts - Safety Requirements for Operation, Inspection and
Maintenance.
5. The Owner/Employer shall display the lift manufacturer’s operating instructions; ASME PASE-2019, Safety
Standard for Portable Automotive Service Equipment;National Standard for Automotive Lifts - Safety
Requirements for Operation, Inspection and Maintenance.
6. The Owner/Operator shall provide necessary lockout/tagout means for energy sources per ANSI Z244.1-1982
(R1993), Safety Requirements for the Lockout/Tagout of Energy Sources, before beginning any lift repairs
and maintenance.

Battery Lift
Installation, Operation and Maintenance
3
2.0 IMPORTANT SAFETY INSTRUCTIONS
1. When using this lift, basic safety precautions should always be followed, including the following (where
applicable).
2. Read all instructions in this manual and literature provided with lift thoroughly before installing, operating,
servicing or maintaining the lift.
3. Care must be taken as burns can occur from touching hot parts.
4. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged – until it
has been examined by a qualified service person.
5. Do not let a cord hang over the edge of the table, bench, or counter or come in contact with hot manifolds or
moving fan blades.
6. If an extension cord is necessary, a cord with a current rating equal to or more than that of the equipment
should be used. Cords rated for less current than the equipment may overheat. Care should be taken to
arrange the cord so that it will not be tripped over or pulled.
7. Always unplug equipment from electrical outlets when not in use. Never use the cord to pull the plug from the
outlet. Grasp plug and pull to disconnect.
8. Let equipment cool completely before putting away. Loop cord loosely around equipment when storing.
9. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable liquids
(gasoline).
10. Adequate ventilation should be provided when working on operating internal combustion engines.
11. Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
12. To reduce the risk of electric shock, do not use wet surfaces or exposure to rain.
13. Use only as described in this manual. Use only the manufacturer’s recommended attachments.
14. ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses only have impact-resistant lenses, they are not
safety glasses.
15. Inspect lift daily. Do not operate if it malfunctions or problems have been encountered.
16. Never attempt to overload the lift. Do not override the operating controls or the warranty will be void.
17. Only trained and authorized personnel should operate the lift. Do not allow customers or bystanders to operate
the lift or be in the lift area.

Battery Lift
Installation, Operation and Maintenance
4
18. Caution! Never work under the lift.
19. Always keep the lift area free of obstruction and debris. Grease and oil spills should always be cleaned up
immediately.
20. Before lowering check area for any obstructions.
21. Do not remove hydraulic fittings while under pressure.
For additional safety instructions regarding lifting, lift types, warning labels, preparing to lift, load spotting, load lifting,
maintaining load stability, emergency procedures, load lowering, lift limitations, lift maintenance, good shop practices,
installation, operator training and owner/employer responsibilities, please refer to “Lifting It Right” (PASE) and
“Safety Tips” (PASE).
For additional instruction on general requirements for lift operation, please refer to “Automotive Lift-Safety
Requirements for Operation, Inspection and Maintenance” (PASE).
Installation shall be performed in accordance with PASE, Safety Requirements for Installation and Service of
Automotive Lifts.
ATTENTION! This lift is intended for indoor use only. It is prohibited to use this
product outdoors. The operating environment temperature range should be 41
– 104 °F (5 – 40 °C). Failure to adhere will result in certification, loss of
warranty, and possible damage to the equipment.
SAVE THESE INSTRUCTIONS
Note: Some images in this manual are generic and may not reassemble the lift you have purchased.

Battery Lift
Installation, Operation and Maintenance
5
3.0 SAFETY WARNING DECALS
All safety warning labels are depicted on the lift to ensure that the operator is aware of and avoids the dangers of using the
lift incorrectly. The labels must be kept clean, and they have to be replaced if detached or damaged. Please read carefully
the meaning of each label and memorize them for future operation.
The instructions, cautions and warnings written above cannot cover all possible conditions and situations that may
occur. The common sense for safety must always be in the operator’s mind. The manufacturer or its distributors
are excluded from damage caused through willful misconduct or gross negligence.

Battery Lift
Installation, Operation and Maintenance
6
4.0 GENERAL SPECIFICATIONS
Lifting Capacity 1500kg (3300lbs)
Lift Height [C]
Rise Height 1950mm (76.77")
Collapsed Height 750mm (29.53")
Platform Adjust Height [S] 45mm (1.77")
Platform Length [A] 1741-2066mm (68.54“-81.34")
Platform Width [E] 800mm (31.50")
Platform Height [B] 229 ±45 mm (9.02" ±1.77")
Deck Length [D] 1500mm (59.06")
Base Height [F] 205mm (8.07")
Wheel Diameter [G] Ø200mm (7.87")
Overall length [H] 2956mm (116.38")
Overall, Weight 750kg (1654lbs)
Motor 1.5 kW
Power supply 110VAC-1Ph-60Hz
Control voltage 24VAC
Hydraulic Pressure 25MPa (3626psi)
Hydraulic Oil Capacity Tank size: 4L (1 gal)
Hydraulic Oil Type ISO 32 (3L) hydraulic oil
Full stoke time (Rated Load) 45s
Full decent time (Rated Load) 55s
Shipping Weight 850 kg (1900 lbs.)
Lift capacity ratings are based on loads equally distributed.
Lifting and lowering speeds may vary depending on the weight of the load.

Battery Lift
Installation, Operation and Maintenance
7
Fig.4.1 General Specification
5.0 TOOLS REQUIRED FOR INSTALLATION OF LIFT
Self-Leveling Laser Level
SAE Wrenches and Sockets
10" Adjustable Wrench
2 lb. Hammer
Side Cutters
Screw Drivers
Funnel
Utility Knife
Needle Nose Pliers
A set of Allen wrenches (metric)
Recommended:
Impact Wrench
Engine Crane/Hoist
8’ Sling

Battery Lift
Installation, Operation and Maintenance
8
6.0 RECEIVING
The shipment should be thoroughly inspected as soon as it is received. The signed bill of lading is
acknowledged by the carrier of receipt in good condition of shipment covered by our invoice.
If any of the goods called for on this bill of lading are shorted or damaged, do not accept them until the carrier
makes a notation on the freight bill of the shorted or damaged goods. Do this for your protection.
7.0 INSTALLATION AND OPERATION INSTRUCTIONS
When the lift arrives on-site, please read the owner’s installation and operation manual completely. Check
the contents to make sure no parts are missing before starting installation. Gather all of the tools listed and
make sure that the instructions are fully understood before starting the installation.
7.1 INSTALLATION INSTRUCTIONS
After the preparations are done, please complete the simple installation according to the following steps:
A. Open the package and check if the accessories are complete.
The items in the shipping box include (Fig.7.1.1)
① 1 pc. Main structure
② 1 pc. Pallet Jack connecting bracket weldment
③ 1 pc. Pallet Jack (includes bolts and nuts)
④ 1 pc. Rear Handle (Including pins ）
⑤ 1 pc. Power connection plug
⑥ 1 pc. Control handle
⑦ 4 pcs. Clamp bracket assembly
⑧ 1 pc. Service manual
Fig.7.1.1 The Items in The Shipping Box

Battery Lift
Installation, Operation and Maintenance
9
B. Hoist the main structure of the machine onto the flat ground.
C. Remove the packing belts. (Fig.7.1.2).
Fig.7.1.2 Packing Belts Position
D. Remove the Wire Ties at the limit switch (Fig.7.1.3).
Fig.7.1.3 Wire Ties Position
E. Install the Pallet Jack and its Bracket Weldment
The Pallet Jack and its bracket weldment are installed to increase the mobility of this machine. It is best to install
them before operation. The installation steps are as follows:
a) As shown in Figure 7.1.4, assemble Part 2 with Part 1 through bolts and nuts A.

Battery Lift
Installation, Operation and Maintenance
10
Fig.7.1.4 Bracket Weldment Installation
b) Follow the steps below to connect Part 3 (already connected to Part 4) to Part 2:
1 Insert the hydraulic rod (with steel ball) on Part 3 into Part 2.
2 Connect Part 4 to Part 2 with bolts D and nuts E.
3 Tighten screw B at the position shown in Figure 7.1.5.
NOTE: Be careful not to lose the steel ball when unpacking.
Add oil to the Pallet Jack and cycle several times without load.

Fig.7.1.5 Pallet Jack Installation
c) Open the cover of the console and add about 3L ISO 32 Hydraulic Oil into the oil tank. Then reinstall the
cover (Fig.7.1.6).
d) NOTE: Only clean hydraulic oil is allowed.
Lift must be fully lowered before changing or adding hydraulic oil.
Pay attention to the scale mark.
Fig.7.1.6 Console
F. Power on the machine, run the lift up and down for 2 or 3 cycles. Then raise the machine to a certain
height and remove four Shipping Brackets.

Battery Lift
Installation, Operation and Maintenance
11
Note: The bolts and washers related need to be reassembled after removal.
Fig.7.1.7 Shipping Brackets Position
G. Complete the Clamp Bracket Assembly (4 pcs) assembly (Fig.7.1.8).
Fig.7.1.8 Clamp Bracket Assembly
H. Lower the scissor to the lowest position, disconnect the power supply.
I. Install the Rear Handle for pushing and pulling (Fig.7.1.9).
Fig.7.1.9 Rear Handle
J. Check again after assembling the entire unit.

Battery Lift
Installation, Operation and Maintenance
12
7.2 OPERATION INSTRUCTIONS
Before using this machine formally, please read this operating instruction carefully. Only trained and authorized
personnel should operate the lift.
7.2.1PALL ETJACK
Before moving the table, the load platform must have been lowered fully.
The Pallet Jack is used to move the lift by lifting its base off the floor.
Always descend the base onto the floor before raising.
The Pallet Jack is operated by a handgrip and a lever inside the grip.
Push down the LEVER (down, ascent) and move up and down the handgrip to raise the base frame of the lift.
Keep the LEVER at a neutral position when moving the lift.
Pull up the LEVER to descend the base frame of the lift.
7.2.2FLEXIBLELIFTINGPLATFORM
Before loading operation, run the lifting table without load for a complete cycle to ensure it is in good condition.
Get familiar with lift controls by running the lift without a load through a few cycles.
The load-carrying table shall be observed by the operator throughout the motion of the lift table.
Do not try to move the lifting table when its platform is raised with the load. ONLY move when the lifting table is
completely lowered.
The flexible platform is designed with a three-layer structure, and the diagram is as follows:
Fig.7.2.2.1 Flexible Lifting Platform

Battery Lift
Installation, Operation and Maintenance
13
7.2.2.1 RETRACTABLE DECK
Use the length adjustment function when it is necessary to fix extra fixtures during maintenance service or to
carry larger loads.
Its length can be easily adjusted by adjusting the thumbscrew.
Fig.7.2.2.1.1 Retractable Deck
7.2.2.2 ADJUSTMENT MECHANISM
In case the intended load is not perfectly horizontal, tilting the platform slightly can assure better contact
between the platform and load. Through the three-layer structure, BT3300 can realize the all-around multi-angle
step-less adjustment. More support points also make its structure much more stable.
Tilt by adjusting the adjustable handle (Fig.7.2.2.2.1).
Fig.7.2.2.2.1 All-Round Multi-Angle Step-Less Adjustment

Battery Lift
Installation, Operation and Maintenance
14
7.2.2.3 MOVABLE DECK
The movable deck can be horizontally moved within 25mm by releasing the handle.
When there is a slight deviation to align the fixture, release the handle and the movable deck can be moved to a
certain position that is suitable to align the fixture with the intended load.
When the alignment is finished, push the handle back to make the platform static.
Fig.7.2.2.3.1 Movable Deck

Battery Lift
Installation, Operation and Maintenance
15
7.2.3CONTROLSYSTEMDESCRIPTIONS
Provide the circuit diagram of the control part (Fig.7.2.3.1) to the experienced service engineer for easy
maintenance.
Fig.7.2.3.1 Electrical Schematic for 1P 110V 60HZ

Battery Lift
Installation, Operation and Maintenance
16
7.2.4CONTROLBUTTONDESCRIPTIONS
Only an authorized person can operate the control buttons. Buttons function as shown in Fig.7.2.4.1
Note: When the control handle is not in use, please put it into the support bracket.
Description Function
Main Switch
Turn on or off the main power supply
Power Indicator
Lights up when the main switch is on
Power Port
1P 110VAC 60HZ Power Port
UP Button
Push to rise normally
DOWN Button
Control the lowering movement
Buzzer
Audible warning for a descent
Spring Wire Maximum elongated length: 4m
Support Bracket Where to store the control handle
Fig.7.2.4.1 Control Buttons Description
7.2.5CONSOLERELATEDDESCRIPTIONS
Meet UL Certification Requirements
According to the requirements of the UL standard, the height of the console from the ground must be
greater than 460mm. This machine meets this standard.
Limit Bolt & Limit Switch
We designed the limit bolts to allow the minimum height of this machine to be adjustable. Moreover, this
design can better fit the load platform according to the actual situation
Based on safety considerations, we have added limit switches. This is to prevent the console from loading
the battery with the extreme tilt deck.
Frame
To protect the power unit, we have set up a final protective barrier——Stronger Frame. This barrier will only

Battery Lift
Installation, Operation and Maintenance
17
work if all other protective measures fail and user error occurs.
Tool B ox
We use the extra space to design small storage space for users. This space can temporarily store some
tools such as wrenches.
Fig.7.2.5.1 Console Descriptions
7.2.6HYDRAULICPRINCIPLE
Provide the hydraulic diagram of the control part (Fig.7.2.6.1) to the service for easy maintenance.

Battery Lift
Installation, Operation and Maintenance
18
Fig.7.2.6.1 Hydraulic Diagram
7.3 OWNER/OPERATOR CHECKLIST
1) Demonstrate the operation of the lift to the owner/operator and review correct and safe lifting procedures using
this manual as a guide.
2) Complete the Installation Checklist/Warranty Validation questionnaire with the owner. Review the terms of the
warranty registration card and return the card and a copy of the questionnaires.

Battery Lift
Installation, Operation and Maintenance
19
8.0 OPERATION PROCEDURE
8.1 SAFETY NOTICES AND DECALS
This product is furnished with graphic safety warning labels, which are reproduced on page 5 of these instructions. Do
not remove or deface these warning labels or allow them to be removed or defaced. For your safety, and the safety of
others, read and understand all of the safety notices and decals included.
8.2 OWNER/EMPLOYER RESPONSIBILITIES
This lift has been designed and constructed according to ASME PASE-2019 standard. The standard applies to lift
manufacturers, as well as to owners and employers. The owner/employer’s responsibilities as prescribed by ASME
PASE-2019, are summarized below. For exact wording refer to the actual standard provided with this manual in the
literature pack.
The Owner/Employer shall ensure that lift operators are qualified and that they are trained in the safe use and operation
of the lift using the manufacturer’s operating instructions; ASME PASE-2019, Safety Standard for Portable Automotive
Service Equipment;National Standard for Automotive Lifts-Safety Requirements for Operation, Inspection and
Maintenance.
The Owner/Employer shall establish procedures to periodically inspect the lift in accordance with the lift manufacturer’s
instructions or ASME PASE-2019, Safety Standard for Portable Automotive Service Equipment;National Standard for
Automotive Lifts-Safety Requirements for Operation, Inspection, and Maintenance; and the employer shall ensure that
the lift inspectors are qualified and that they are adequately trained in the inspection of the lift.
The Owner/Employer shall
maintain the periodic inspection and maintenance records recommended by the
manufacturer or ASME PASE-2019, Safety Standard for Portable Automotive Service Equipment; National Standard
for Automotive Lifts-
Safety Requirements for Operation, Inspection, and Maintenance.
The Owner/Employer shall display the lift manufacturer’s operating instructions; ASME PASE-2019, Safety Standard
for Portable Automotive Service Equipment; National Standard for Automotive Lifts-Safety Requirements for Operation,
Inspection and Maintenance; in a conspicuous location in the lift area convenient to the operator.
8.3 IMPORTANT SAFETY INSTRUCTIONS
When using your garage equipment, basic safety precautions should always be followed, including the following:
1. Read all instructions.
2. Care must be taken as burns can occur from touching hot parts.
3. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable liquids (gasoline).
4. Keep hair, loose clothing, fingers, and all parts of body away from moving parts.
5. Use only as described in this manual. Use only the manufacturer’s recommended attachments.
