Chattanooga Moveo XP User manual

User Manual
Operation & Installation
Instructions for:
Moveo™ XP
8084 - 230 V AdjustableTable
8080 - 120 V AdjustableTable
Optional Equipment
80898 - LE Support Pad
80986 - Battery Backup
10-5211 - Cando® Exercise Bands
10-5330 - Cando® Handles
Exercise Platform
Chattanooga Group is an ISO 13485
Certied Company
™
Electromagnetic
Compatibility (EMC)
Tables

Moveo™ XP
TABLE OF CONTENTS
i
FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautionary Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Dangers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Indications and Contraindications . . . . . . . . . . . . . . . . . . . . 8
Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Intended Uses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Benefits of the Moveo XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Contraindications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Additional Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table Symbol Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Hand Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Hand Controller Symbol Definitions. . . . . . . . . . . . . . . . . . 17
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Battery Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Description of Device Markings . . . . . . . . . . . . . . . . . . . . . . 22
Weight Distribution Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
PATIENT PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Transferring the Patient to the Table . . . . . . . . . . . . . . . . . 24
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Starting, Interrupting, and Stopping
the Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Starting the Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Interrupting the Exercise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Stopping the Exercise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using the LE Support Pad. . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using the Cando® Exercise Bands . . . . . . . . . . . . . . . . . . . . 39
Treatment Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Exercise Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Discontinuing the Moveo XP Exercises . . . . . . . . . . . . . . . 42
Documenting the Exercises . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Patient Tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Using the Battery Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Installing the Battery Backup. . . . . . . . . . . . . . . . . . . . . . . . . 44
Charging the Battery Backup. . . . . . . . . . . . . . . . . . . . . . . . . 53
Battery Backup Service Life . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Storage of Battery Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
W
T
T
T
W
T
T

Moveo™ XP
TABLE OF CONTENTS
ii
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Preventative Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
W

Moveo™ XP
FOREWORD
1
This manual has been written for the operators of the Moveo XP. It contains general instructions for operation, precautionary instructions,
and maintenance recommendations. In order to obtain maximum life and efficiency from your Moveo XP, and to assist in the proper
operation of the table, read and understand this manual thoroughly.
The specifications put forth in this manual were in effect at the time of the publication. However, owing to Chattanooga Group's policy of
continuous improvement, changes to these specifications may be made at any time without obligation on the part of Chattanooga Group.
Before administering any treatment to a patient, you should become acquainted with the operating procedures, as well as the indications,
contraindications, warnings, and precautions.
Product Description
The Moveo XP is a dynamic exercise platform designed for patients incapable of standing due to severe muscle weakness, poor postural
control, orthostatic intolerance, and pain. This platform combines the benefits of a traditional tilt table with the benefits of exercise.
The unique design of the Moveo XP provides the patient with the ability to perform lower extremity, partial weight-bearing exercises
in a controlled environment. The mobile hi-lo platform provides an easy method to transfer the patient from their bed or directly from
a wheelchair. By gradually increasing the incline of the table, therapists are able to adjust the intensity of the weight-bearing workout
from 0% to 75% of the patient’s body weight. Additionally, a leg support pad and fold-away split Foot Plates allow unilateral leg exercise
for patients with a weight-bearing restriction or for lower extremity forced-use. The graded weight-bearing workout allows a safe and
controlled transition from bed rest to functional mobility training while empowering the patient and enhancing self-confidence.
© 2009 Encore Medical Corporation and its affiliates, Austin, Texas, USA. Any use of editorial, pictorial, or layout composition of this publication without express written consent from Chattanooga
Group of Encore Medical, L.P. is strictly prohibited. This publication was written, illustrated and prepared for print by Chattanooga Group of Encore Medical, L.P.
Cando® is a registered trademark of Fabrication Enterprises Inc..

Moveo™ XP
SAFETY PRECAUTIONS
2
The precautionary instructions found in this section and throughout this manual are indicated by specific symbols. Understand these
symbols and their definitions before operating this equipment. The definition of these symbols are as follows:
Text with a “CAUTION” indicator will explain possible safety infractions that
could have the potential to cause minor to moderate injury or damage to
equipment.
Text with a “WARNING” indicator will explain possible safety infractions
that will potentially cause serious injury and equipment damage.
Text with an “Explosion Hazard” indicator will explain possible
safety infractions if this equipment is used in the presence of
flammable anesthetics.
NOTE: Throughout this manual, “NOTE” may be found. These Notes
are helpful information to aid in the particular area or function
being described.
PRECAUTIONARY DEFINITIONS
CAUTION
WARNING
Explosion Hazard
Text with a “DANGER” indicator will explain possible safety infractions that
are imminently hazardous situations that would result in death or serious
injury.
DANGER
Text with a “Dangerous Voltage” indicator serves to inform
the user of possible hazards resulting in the electrical charge
delivered to the patient in certain treatment configurations of
TENS/NMES waveforms.
Dangerous Voltage
Text with an “Accompanying Documentation” indicator serves to
refer the operator to other documentation.
h
“
”
Accompanying Documentation
Corrosive
Text with a “CORROSIVE" indicator will explain possible safety
infractions if the chemical components of the battery are
exposed to air, skin, or other materials.
Spontaneous Combustion
Text with a “SPONTANEOUS COMBUSTION" indicator will explain
possible safety infractions that could create conditions for a
Spontaneous Combustion if the material is mishandled and not
disposed of properly.

Moveo™ XP
SAFETY PRECAUTIONS
3
CAUTIONS
Read, understand, and practice the precautionary and operating•
instructions found in this manual. Know the limitations and hazards
associated with your new treatment table. Observe any and all
precautionary and operational decals placed on the table.
This table should be operated, transported, and stored in
•
temperatures between -18 °C and 60 °C (0 °F and 140 °F), with
relative humidity ranging from 30% - 80% to prevent damage to the
table or its components.
Transport of this table should always be done with the Back Rest
•
in the horizontal position. The table should be left in the horizontal
position (down) when not in use.
Support the table sections with both hands when making any
•
adjustments.
Inspect all cables and connectors before each use.
•
DO NOT exceed table weight capacity of 182 kg (400 lbs).•
The Cando® exercise bands offered as an accessory to this table•
contain dry natural rubber and may cause allergic reactions in
patients with allergies to latex.
The Battery Backup should be operated, transported, and stored
•
in temperatures between 15 °C and 40 °C (59 °F and 104 °F), with
Relative Humidity ranging from 30%-60%.
DO NOT operate this table in an environment where other devices•
are being used that intentionally radiate electromagnetic energy
in an unshielded manner. Portable and mobile RF communications
equipment can affect Medical Electrical Equipment.
This table generates, uses, and can radiate radio frequency energy
•
and, if not installed and used in accordance with the instructions,
may cause harmful interference to other devices in the vicinity.
However, there is no guarantee that interference will not occur
in a particular installation. Harmful interference to other devices
can be determined by turning this table on and off. Try to correct
the interference using one or more of the following: reorient or
relocate the receiving device, increase the separation between
the equipment, connect the equipment to an outlet on a different
circuit from that which the other device(s) are connected, and
consult the Chattanooga Group Service Department for help.
When using the Battery Pack accessory, make certain the battery is
•
charged before you attempt to use the table.
Angles and weights used in this manual are for reference only.
•
Dispose of all products in accordance with local and national•
regulations and codes.
Cando® is a registered trademark of Fabrication Enterprises Inc..

Moveo™ XP
SAFETY PRECAUTIONS
4
WARNINGS
THIS TABLE IS NOT TO BE USED FOR A TRANSPORT DEVICE. NEVER•
TRANSPORT THE PATIENT ON THE TABLE.
Make certain that the table is electrically grounded by connecting
•
only to a grounded electrical service receptacle conforming to the
applicable national and local electrical codes.
Never place your hands or feet near the working mechanism of
•
the table when making any and all adjustments to height or table
sections.
Do not sit or allow patients to sit on the end of the Back Rest or
•
anywhere on the Foot Plates.
Do not smoke on or around table.
•
The Carriage must be locked with the Key Pins before transferring•
patients to and from the table. See page 26 for more information
about locking the Carriage.
DO NOT
• lock the Carriage when the table is inclined at any angle. The
table must be completely horizontal before locking.
DO NOT
• adjust the Foot Plate angle when the table is inclined at any
angle.
DO NOT
• adjust the Foot Plate angle during exercise.
Make certain that all power cords, tubes, and hospital equipment is
•
clear from the table when the table is in use.
Make certain the patient's range of motion limit does not allow more
•
than a 90° knee flexion.
Do not allow any unsupervised patient access to the treatment table.•
When not in use, the table should be protected against unqualified•
use.
Do not leave the table unlocked and unattended at any time.
•
Care must be taken when operating this table adjacent to or•
stacked with other equipment. Potential electromagnetic or other
interference could occur to this or other equipment. Try to minimize
this interference by not using other equipment (i.e. cell phones, etc.)
in conjunction with it.
Make certain the cushions and pads of the table are protected
•
against puncture from patients that may be wearing external fixation
devices (e.g., HALO).
Use only accessories that are specially designed for this table. Do
•
not use accessories manufactured by other companies on this table.
Chattanooga Group is not responsible for any consequence resulting
from using products manufactured by other companies. The use
of other accessories or cables may result in increased emissions or
decreased immunity of this table and safety of the patient.
Patient must be cleared by a physician for mobilization.
•
Use of other parts or materials can degrade minimum safety.•
At temperatures below 0 °C (32 °F), the gas absorption reaction•
is not sufficient and causes an increase of the gas pressure inside
the battery. This condition can activate the safety vent and lead to
alkaline gas leaking and battery performance deterioration.

Moveo™ XP
SAFETY PRECAUTIONS
5
WARNINGS (CONTINUED)
Charging efficiency of the Battery Backup drops at temperatures•
above 40 °C (104 °F) and can disrupt full charging and lead to
deterioration in performance and battery cell leakage.
Disconnect Battery Backup if table is not to be used for an extended
•
period.
When the integrity of the external protective conductor in the
•
installation or its arrangement is in doubt, the table shall be operated
from its internal electrical power source.
Disconnect the table from the power source (outlet and Battery
•
Backup if installed) before attempting any maintenance, installation,
removal, or replacement procedures to prevent electrical shock and
possible damage to table.
Before, during, and after exercise, do the following:•
Monitor vital signs closely (i.e., heart rate, oxygen saturation, blood•
pressure, and respiratory pattern).
Monitor rate of perceived exertion and watch for outward signs of
•
distress.
Be constantly aware of correct body alignment.
•
Ensure proper draping of patient (e.g., sheet or towel between the•
patient's legs).
If the patient is on mechanical ventilation, transfer to the ventilator
•
side and closely monitor tubing length to prevent tugging.

Moveo™ XP
SAFETY PRECAUTIONS
6
Never, under any circumstances, open the battery housing•
or cells. Should an individual cell from a battery become
disassembled, spontaneous combustion of the negative
electrode is possible. There can be a delay between
exposure to air and spontaneous combustion.
Charge the Battery Backup according to the instructions
•
found in this manual. Never attempt to charge the Battery
Backup on any other charging mechanism.
Do not reverse the polarity of the Battery Backup. Doing so
•
can increase the individual cell temperature and cause cell
rupture or leakage.
Dispose of NiMH batteries according to national, state and
•
local codes and regulations.
Never dispose of Battery Backup in fire. Never short circuit
•
the battery. The battery may explode, ignite, leak or get hot
causing serious personal injury.
Do not move or elevate any cushion section while the
•
patient’s weight is on that section.
Do not reposition or allow the patient to get on or off table
•
while the table is in any position other than completely
horizontal.
Do not allow anything to be under the table while the table
•
is descending.
Do not make any adjustment to the table while the table is
•
in any position other than completely horizontal.
Equipment not suitable for use in the presence of a•
flammable anesthetic mixture with air, oxygen, or nitrous
oxide.
Do not use with Oxygen tents. Use oxygen administering
•
equipment of the nasal, mask, or ventilator type only.
This table should only be operated under the prescription
•
and supervision of a licensed medical practitioner that is
familiar with the precautionary measures and operational
functions associated with the table being used.
DO NOT connect the unit to an electrical supply without
•
first verifying that the power supply is the correct voltage.
Incorrect voltage may cause unit damage, malfunction,
electrical shock, fire, or personal injury. Your unit was
constructed to operate only on the electrical voltage
specified on the Voltage Rating and Serial Number Plate.
Contact your Chattanooga Group dealer if the unit is not
properly rated.
NiMH Batteries contain Class E Corrosive materials. In the
•
event of battery cell rupture or leakage, handle battery
housing wearing neoprene or natural rubber gloves.
Contents of a ruptured or leaking battery can cause
respiratory irritation. Hypersensitivity to nickel can cause
allergic pulmonary asthma. Contents of cell coming in
contact with skin can cause skin irritation and/or chemical
burns.
Use the Battery Backup only with the Moveo XP.
•
DANGERS

Moveo™ XP
SAFETY PRECAUTIONS
7
DANGERS (CONTINUED)
DO NOT adjust the angles of the•
Foot Plates while the patient has
any weight resting on them.
Both plungers (mechanical locking
•
devices) on the Foot Plates should
always be kept at an angle. When
adjusting the Foot Plates, never
allow the plungers to be straight
up and down. Failure to observe
this DANGER will result in tipping
of Foot Plate and patient injury.
Correct
Incorrect

Moveo™ XP
SAFETY PRECAUTIONS
8
INDICATIONS & CONTRAINDICATIONS
Indications
The Moveo XP is indicated for redeveloping muscles or restoring
motion to joints.
Intended Uses
The table is intended for patients medically cleared by a physician
to begin mobilization, but incapable of standing without maximal
assistance from a therapist due to:
Severe lower extremity weakness•
Poor postural control•
Decreased weight bearing tolerance•
Poor endurance•
Decreased LE ROM•
Poor muscle control•
Fear of falling due to weakened condition•
Risk of deep vein thrombosis•
Benefits of the Moveo XP
To increase lower extremity strength•
To increase knee and ankle ROM (Range of Motion)•
As an exercise device•
For graded weight bearing•
To optimize activity tolerance•
To promote urinary drainage•
For preambulatory activity•
Contraindications
The Moveo XP has been contraindicated for the following:
Patient has not been medically cleared by a physician to•
mobilize.
Bilateral lower extremities have a "non-weight bearing"•
restriction.
Patient with complete lower extremity paralysis.•
Additional Precautions
Make certain that the patient is able to follow simple commands.
The Moveo XP is a dynamic tilt table that allows patients to participate in partial weight-bearing strength training for the preparation of
functional mobility.

Moveo™ XP
SETUP
9
After removing top and side panels of shipping crate, you may notice metal bands and plastic straps. These are used to secure various
sections of the table and must be removed.
Do not lift table by Back Rest, Mid Section, or Foot Plates.•
Do not use any kind of lifting mechanism on the table.•

Moveo™ XP
NOMENCLATURE
10
TABLE
Caster Lock Bar (2)
Caster (4)
Key Pin (2)
LE Support
Pad
(Optional)
Transfer Pad
Pelvic Section
Back Rest
Foot Plate
Release
Hand
Controller
(
see page 16
see page 16
& 17
& 17)
Drawer
Storage
Back Rest
Release
Bar
Cando Exercise Band
Winding Cleats
Carriage
}
Side Panel (2)
Foot Plate
Lock Knobs
Head Rest
Foot
Plates
Ankle Support
Pad
Left Side of
Table
Right Side of
Table

Moveo™ XP
NOMENCLATURE
11
TABLE (CONTINUED)
Head Rest
During exercise, the Head Rest pillow supports the head and neck of the patient.
LE Support Pad (Optional)
The LE (Lower Extremity) Support Pad is an optional accessory that allows patients with a single amputated or exercise-restricted lower
extremity to perform exercises.
Storage Drawer
The Storage Drawer is used to keep accessories for the table such as Cando Exercise Bands and Cando Handles.
Side Panel
The Side Panels display the Moveo XP logo and conceal the cords and mechanical and electrical working parts of the table.
The Carriage must be locked with the Key Pins before transferring•
patients to and from the table. See page 26 for more information
about locking the Carriage.
Do not lock the Carriage when the table is inclined at any angle. The
•
table must be completely horizontal before locking.
Key Pin
The Key Pins serve to prevent the carriage from sliding past a certain point, or to prevent the carriage from moving at all.
Ankle Support Pad
These pads provide comfortable support for the patient before, during, and after exercise.

Moveo™ XP
NOMENCLATURE
12
TABLE (CONTINUED)
Caster
Four independently moving caster wheels allow the table to be positioned close to the patient's bed or wheelchair before transfer and
away from the patient's bed before exercise. Depending on the position of the Caster Lock Bar, the casters have the following three
settings:
All Free
All 4 casters move independently and turn in all directions. The Caster Lock Bar will be in the horizontal position.
All Locked
All 4 casters are locked. To lock the casters, step on the part of the Caster Lock Bar closest to the Head Section (Red).
3 free/1 locked
All 4 casters roll, but one is locked so that the table rolls either straight forward or straight back. To use this setting, step on the part of the
Caster Lock Bar closest to the Foot Plates (Green).
Caster Lock Bar
Depending upon the side of the Caster Lock Bar on which you step, you can choose to lock the wheels and prevent the table from moving
during patient transfer and exercise and unlock the wheels for table transport.
Foot Plate Lock Knob
The practitioner uses the Foot Plate Lock Knob to lower the Foot Plates when using the LE Support Pad.
Foot Plate Release
While holding the Foot Plate with one hand, the practitioner can use a finger of the free hand to pull the Foot Plate Release lever to
position the Foot Plates and allow for the appropriate angle.

Moveo™ XP
NOMENCLATURE
13
TABLE (CONTINUED)
Foot Plates
The Foot Plates allow the practitioner to vary the angle to allow for the appropriate foot position, and also provide support for the patient
during exercise.
Transfer Pad
The transfer pad supports the middle thigh and calf areas during transfer.
Carriage
The carriage consists of both the Pelvic Section and Back Rest and is the main operational component of the Moveo XP. The sliding motion
of the carriage is what allows patients to use their own weight to exercise.
Pelvic Section
The Pelvic Section serves as the lower operational component of the Moveo XP and supports the patient's lower back.
Back Rest
Patients use the large surface area of the Back Rest to support their arms, head, and torso during exercise.
Cando Exercise Band Winding Cleats
Using these cleats, the practitioner can either tie a band to each cleat or use a single band that passes through both cleats to allow the
patient to exercise. When not in use, wind the Cando Exercise Bands around the cleat to keep them close at hand, but out of the way.
Back Rest Release Bar
While holding the Back Rest Release Bar, the practitioner can position the Back Rest to allow for the incline angle. Simply release the bar to
lock the Back Rest into place.

Moveo™ XP
NOMENCLATURE
14
TABLE (CONTINUED)
Battery Backup (Optional - Not Shown)
The Battery Backup is an optional accessory that allows the practitioner to administer exercise therapy without having to plug the table
into an outlet. To recharge the Battery Backup, simply plug it into an outlet. The Battery Backup will charge whenever the table is plugged
in.

Moveo™ XP
NOMENCLATURE
15
TABLE SYMBOL DEFINITIONS
Weight Distribution Chart
Degree of Incline
% of Body Weight
10
0
90
80
70
60
50
40
30
20
10 0 5 10 15 20 25 30
The purpose of the Weight Distribution Chart
is to illustrate the correlation between the
patient's body weight percentage and the
degree of incline on the Moveo XP. For
more information on this chart, see page 23.
6789101112 54321
Key Pin Adjustment Numbers (Right Side)
6 7 8 9 10 11 1254321
Key Pin Adjustment Numbers (Left Side)
Key Pin Location for securing Carriage
(Right Side)
Key Pin Location for securing Carriage
(Left Side)
45°- 0°
Foot Plate Adjustment for LE Support Pad
(Right Side)
45°- 0°
Foot Plate Adjustment for LE Support Pad
(Left Side)
90°- 45° Foot Plate Adjustment
Angle of Incline (Left Side)
0
5
15
25
10
20
30
Angle of Incline (Right Side)
Pinch Point

Moveo™ XP
NOMENCLATURE
16
HAND CONTROLLER
Tilt Forward (UP Arrow)
Button
LED (Illuminates Only if Battery
Backup is Present)
Lower Patient (DOWN Arrow)
Button
Raise Patient (UP Arrow)
Button
Tilt Backward (DOWN Arrow)
Button
Elevation
Tilt

Moveo™ XP
NOMENCLATURE
17
HAND CONTROLLER SYMBOL DEFINITIONS
LED
The LED (Light Emitting Diode) illuminates only if the Battery Backup is present.
The LED:
illuminates green when the Battery Backup is charging and you press a button on the Hand Controller.•
illuminates green when you press a button on the Hand Controller and the Battery Backup is fully charged.•
flashes green when the Battery Backup is charging and the table is idle.•
illuminates orange and emits a "beep" when you press a button on the Hand Controller and the charge on the Battery Backup is•
weak.
flashes orange and emits a "beep" when you press a button on the Hand Controller and the charge on the Battery Backup is very•
weak.
Raise Patient (UP Arrow) Button
Press the button to elevate the table. The maximum elevation is 97.79 cm (38.5 in).
Tilt Forward (UP Arrow) Button
Press the button to tilt the table forward. The maximum tilt angle is 30°.
Tilt Backward (DOWN Arrow) Button
Press the button to tilt the table backward.
Lower Patient (DOWN Arrow) Button
Press the button to lower the table. The table can be lowered to a height of 57.15 cm (22.5 in).
