Chauvet Q-WASH 360Z-LED User manual

User Manual

Edition Notes
Q-Wash 360Z-LED User Manual Rev. 01g
Edition Notes
The Q-Wash 360Z-LED User Manual Rev. 01g covers the description, safety
precautions, installation, programming, operation, and maintenance of the Q-Wash
360Z-LED. CHAUVET® released this edition of the Q-Wash 360Z-LED User Manual
in June 2011.
Trademarks
CHAUVET® is a registered trademark of CHAUVET & Sons Inc. (d/b/a CHAUVET®
or Chauvet). The CHAUVET® logo in its entirety including the Chauvet name and
the dotted triangle, and all other trademarks on this manual pertaining to services,
products, or marketing statements (example: It’s Green Thinking™) are owned or
licensed by CHAUVET®. Any other product names, logos, brands, company names,
and other trademarks featured or referred to within this document are the property of
their respective trademark holders.
Copyright Notice
CHAUVET® owns the content of this user manual in its entirety, including but not
limited to pictures, logos, trademarks, and resources.
© Copyright 2011 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America.
Manual Usage
CHAUVET® authorizes its customers to download and print this manual for
professional information purposes only. CHAUVET® expressly prohibits the usage,
copy, storage, distribution, modification, or printing of this manual or its content for
any other purpose without its written consent.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 inches),
double sided. If using A4 paper (210 x 297 mm), configure your printer to scale the
content accordingly.
Intended Audience
Any person in charge of installing, operating, and/or maintaining this product should
read the guide that shipped with it as well as this manual in their entirety before
installing, operating, or maintaining this product.
Disclaimer
CHAUVET® believes that the information contained in this manual is accurate in all
respects. However, CHAUVET® assumes no responsibility for any error or
omissions in this document. CHAUVET® reserves the right to revise this document
and to make changes from time to time in the content hereof without obligation of
CHAUVET® to notify any person or company of such revision or changes. This
does not constitute in any way a commitment by CHAUVET® to make such
changes. CHAUVET® may issue a revision of this manual or a new edition of it to
incorporate such changes.
CHAUVET®
Publications Hot Line If you have any comments about the accuracy of this document or general
suggestions regarding how we can improve it, please call us at [phone] (US
callers) or [phone] (international callers). You can download the latest
versions of all CHAUVET® products’ manuals from www.chauvetlighting.com.
Document Revision
The Q-Wash 360Z-LED User Manual Rev. 01g supersedes all previous versions of
this manual. Please discard any older versions of this manual you may have,
whether in printed or electronic format, and replace them with this version.
Author Editor Manager PD Manager
O. Desmonteix D. Couppe M. Graham F. Sellers

Table of Contents
Q-Wash 360Z-LED User Manual Rev. 01g -a-
Table of Contents
1. Before You Begin...............................................................................................1
What is Included ............................................................................................................ 1
Unpacking Instructions................................................................................................... 1
Typographic Conventions............................................................................................... 1
Icon Meaning................................................................................................................. 1
Product at a Glance ....................................................................................................... 1
Safety Notes.................................................................................................................. 2
Expected LED Lifespan.................................................................................................. 2
2. Introduction........................................................................................................3
Product Description........................................................................................................ 3
Features ........................................................................................................................ 3
Additional Features.................................................................................................................3
Product Overview........................................................................................................... 4
Product Dimensions....................................................................................................... 5
3. Setup...................................................................................................................6
AC Power ...................................................................................................................... 6
AC Plug .................................................................................................................................6
Fuse Replacement.................................................................................................................6
DMX Linking .................................................................................................................. 7
DMX Modes...........................................................................................................................7
Master/Slave Connectivity.......................................................................................................7
Mounting........................................................................................................................ 8
Orientation.............................................................................................................................8
Rigging ..................................................................................................................................8
4. Operation............................................................................................................9
Control Panel Description............................................................................................... 9
Control Options.............................................................................................................. 9
Programming................................................................................................................. 9
DMX Operation ......................................................................................................................9
Stand-alone Operation............................................................................................................9
Master/Slave........................................................................................................................10
Display Mode.......................................................................................................................10
Software Version..................................................................................................................10
Keylock................................................................................................................................10
Fan......................................................................................................................................10
Reset...................................................................................................................................10
Dimmer Curve......................................................................................................................11
Fader Reversal.....................................................................................................................11
Range Limitation ..................................................................................................................11
Reset Control.......................................................................................................................11
Move-in Black.......................................................................................................................12
Power ..................................................................................................................................12
Color Settings.......................................................................................................................12
Fan Control..........................................................................................................................12
Color Calibration...................................................................................................................12
White Calibration..................................................................................................................13
System Default.....................................................................................................................13
Edit Custom.........................................................................................................................13
Menu Map.....................................................................................................................14
Extra Menu...................................................................................................................15
DMX Values..................................................................................................................16
BASIC..................................................................................................................................16
ADVANCED.........................................................................................................................17

Table of Contents
-b- Q-Wash 360Z-LED User Manual Rev. 01g
5. Technical Information......................................................................................18
Fixture Maintenance......................................................................................................18
Troubleshooting Guide..................................................................................................19
Returns Procedure........................................................................................................20
Claims ..........................................................................................................................20
Contact Us....................................................................................................................20
Technical Specifications................................................................................................21

Before You Begin
Q-Wash 360Z-LED User Manual Rev. 01g -1-
1. Before You Begin
What is
Included
•One Q-Wash 360Z-LED
•One IEC power cord with Edison plug (US market)
•One safety cable
•Two omega brackets
•Warranty Card
•Quick Reference Guide
Unpacking
Instructions
Immediately upon receiving this product, carefully unpack it and check the container in
which you received it. Make sure that you have received all the parts indicated above and
that they are all in good condition. If the material inside the container (this product and any
other accessory included with it) appears damaged from shipping, or if the container shows
signs of mishandling, notify the shipper immediately. In addition, retain the container and
all the packing material for inspection.
See the Claims section in the Technical Information chapter.
Typographic
Conventions
Convention Meaning
1~512 A range of values in the text
50/60 A set of mutually exclusive values in the text
Claims A new term, or a section or chapter in this document
“COLORado™ 1 UM” The name of another publication or manual
<SET>
A button on the fixture’s control panel
Settings
A fixture function or a menu option
MENU > Settings
A sequence of menu options
1~10
A range of menu values from which to choose in a menu
Yes/No
A set of two mutually exclusive menu options in a menu
ON
A unique value to be entered or selected in a menu
Icon Meaning
Icon Meaning
This icon indicates critical installation, configuration, or operation
information. Failure to comply with this information may render the
fixture partially or completely inoperative, damage third-party
equipment, or cause harm to the user.
This icon indicates important installation or configuration
information. Failure to comply with this information may prevent
the fixture from functioning correctly.
This icon indicates useful, although non-critical information.
The term “DMX” used throughout this document refers to the USITT DMX512-A
transmission protocol.
Product at a
Glance
Use on Dimmer
x
Auto Programs
P
Outdoor Use
x
Auto-ranging Power Supply
P
Sound Activated
x
Replaceable Fuse
P
DMX
P
User Serviceable
x
Master/Slave
P
Duty Cycle
x

Before You Begin
-2- Q-Wash 360Z-LED User Manual Rev. 01g
Safety Notes Please read the following notes carefully because they include important safety
information about the installation, usage, and maintenance of this product.
It is important to read all these notes before starting to work with this product.
There are no user serviceable parts inside this product. Any reference to servicing
it you may find from now on in this User Manual will only apply to properly
CHAUVET® certified technicians. Do not open the housing or attempt any repairs
unless you are one of them.
Please refer to all applicable local codes and regulations for the proper installation
of this product.
Personal Safety
•Avoid direct eye exposure to the light source while the fixture is on.
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
•Do not touch this product’s housing when operating because it may be hot.
Mounting and Rigging
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
•Make sure there are no flammable materials close to this product while operating.
•When hanging this product, always secure it to a fastening device using a safety cable
(included).
•Do not carry this fixture from the head; use the handles instead.
Power and Wiring
•Always make sure that you are connecting this product to the proper voltage, as per
the specifications in this manual or on the product’s sticker.
•Never connect this product to a dimmer pack or rheostat.
•Never disconnect this product by pulling or tugging on the power cable.
Operation
•Do not operate this fixture if you see damage on the housing, lenses, or cables. In any
of these cases, have the damaged parts replaced by an authorized technician at once.
•Do not cover the ventilation slots when the fixture is operating to avoid internal
overheating.
•Do not aim this fixture toward the Sun. Otherwise, the lenses could concentrate the
solar energy and cause internal overheating.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate this product
at a higher temperature.
•In case of a serious operating problem, stop using this product immediately!
In the unlikely event that your CHAUVET® product may require service, please
contact CHAUVET® Technical Support.
Expected LED
Lifespan
LEDs gradually decline in brightness over time, mostly because of heat. Packaged in
clusters, LEDs exhibit higher operating temperatures than in ideal, single LED conditions.
For this reason, using clustered LEDs at their fullest intensity significantly reduces the
LEDs’ lifespan. Under normal conditions, this lifespan can be of 40,000 to 50,000 hours. If
extending this lifespan is vital, lower the operational temperature by improving the fixture’s
ventilation and reducing the external temperature. In addition, limiting the overall
projection intensity may also help to extend the LEDs’ lifespan.

Introduction
Q-Wash 360Z-LED User Manual Rev. 01g -3-
2. Introduction
Product
Description
The Q-Wash 360Z-LED is an RGBW LED moving yoke, wash fixture.
It consists of a base section and a moving yoke with a pan range of up to 540º. The
moving head, which has a tilt range of 270º, contains the 91 RGBW LEDs and the zoom
motors. The base section has the 3- and 5-pin DMX input and output sockets, the IEC
power input connector and the LCD based control panel.
Features
•11 or 15-channel
•Pan: 540°
•Tilt: 270°
•RGBW color static mixing with or without DMX control
•Continuously variable zoom (9º~26°)
•Electronic strobe (0~20 Hz)
•Electronic dimmer (0~100%).
•High power setting
•Built-in automated programs
•Remote fixture reset and vector speed channel
•255-step fully customizable program
•Recall auto or custom programs via control panel or DMX
•Color temperature presets (3,200~10,000 K)
•Color calibration
•Fan speed control
Additional
Features •3- and 5-pin DMX input and output connectors
•LCD display with password protection

Introduction
-4- Q-Wash 360Z-LED User Manual Rev. 01g
Product Overview
Power Input
IEC Socket
Power Switch
Fuse holder
3-pin DMX In
3-pin DMX Out
5-pin DMX Out
5-pin DMX In
Control panel

Introduction
Q-Wash 360Z-LED User Manual Rev. 01g -5-
Product Dimensions

Setup
-6- Q-Wash 360Z-LED User Manual Rev. 01g
3. Setup
AC Power The Q-Wash 360Z-LED has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Make sure that you are connecting this product to the proper voltage, as per the
specifications in this guide, the product’s user manual, or on the product’s sticker.
Always connect this product to a protected circuit with an appropriate electrical
ground to avoid the risk of electrocution or fire.
To determine the power requirements for the Q-Wash 360Z-LED see the label affixed to
the side of the fixture. Alternatively, you may refer to the Technical Specifications chart in
the Technical Information chapter of this manual.
The listed current rating indicates the maximum current draw during normal operation. For
more information, you may download the “Sizing the Circuit Breakers” document from the
CHAUVET® Web site.
Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The Q-Wash 360Z-LED comes with a power input cord terminated with an IEC connector
on one end an Edison plug on the other end (US market). If the power input cord that came
with your product has no plug or you need to change the Edison plug, use the table below
to wire the new plug.
Connection Wire (US) Wire (Europe) Screw Color (US)
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
Make sure to disconnect the fixture’s power cord before replacing a blown fuse, and
always replace it with a fuse of the same type and rating.
Fuse Replacement 1) Wedge the tip of a flat head screwdriver into the slot of the fuse holder and pry it out of
its housing.
2) Remove the blown fuse from its holder and replace it with a fuse of the exact same
type and rating (T 5 A, 250 V).
2) Insert the fuse holder back in its place, and reconnect power.
The fuse is located
inside this compartment.
Remove it using a flat
head screwdriver.

Setup
Q-Wash 360Z-LED User Manual Rev. 01g -7-
DMX Linking
You may link the Q-Wash 360Z-LED to a DMX controller using a standard DMX serial
connection. If using other DMX compatible fixtures with this product, it is possible to control
them individually with a single DMX controller.
If you are not familiar with the DMX standard, or if you need information about the DMX
cables needed to link this product to a DMX controller, you may download the “DMX
Primer” document from the CHAUVET® Web site.
DMX Modes
The Q-Wash 360Z-LED uses the standard DMX data connection for its Basic and
Advanced DMX modes. You will find information about these DMX modes in the Operation
chapter (configuration details), and the DMX Values section (individual channel values).
Master/Slave
Connectivity
The Master/Slave mode allows a Q-Wash 360Z-LED fixture to control one or more fixtures
of the same model without a DMX controller. The controlling fixture becomes the “master
fixture” when running the Auto1, Auto2, or Custom programs. You must configure the
controlled (slave) fixtures to operate in “SLAVE” mode from their respective control panels.
During the Master/Slave operation, the slave fixtures will operate in unison with the master
fixture.
The master links to the slave fixtures using the standard DMX serial connection. If you are
not familiar with the Master/Slave connectivity, you may download the “DMX Primer”
document from the CHAUVET® Web site.
DO NOT connect a DMX controller to the fixtures operating in Master/Slave mode.
Otherwise, the signals from the DMX controller may interfere with the signals from
the master fixture.
The Operation chapter of this manual provides detailed instructions on how to
configure the Master and Slave units.

Setup
-8- Q-Wash 360Z-LED User Manual Rev. 01g
Mounting
Before mounting this product, read and follow the safety recommendations indicated in the
Safety Notes section (page 2 of this manual).
Orientation
Always mount this product in any safe position while making sure that there is adequate
room around it for ventilation, head motion, configuration, and maintenance.
Rigging CHAUVET® recommends following the general guidelines below when mounting this
product.
•When selecting an installation location, consider ease of access to the fixture for
operation, programming adjustments, and routine maintenance.
•Make sure to mount this product away from any flammable material, as indicated in the
Safety Notes section, or obstructions that may block the moving head.
•Never mount the product in places where rain, high humidity, extreme temperature
changes, or restricted ventilation may affect it.
•If hanging this product, make sure that the location where you are mounting it can
support its weight. Please see the Technical Specifications section of this manual for
the weight requirement of this fixture.
Procedure The Q-Wash 360Z-LED comes with two omega brackets to which you can attach “C” or “O”
clamps. You must supply your own “C” or “O” clamps and make sure that they are capable
of supporting the weight of this fixture. You will have to use two mounting points per fixture.
The omega brackets also serve to anchor this product to a panel. For floor standing
operation, this product has built-in rubber feet.
Product Mounting
Diagram
Safety Cable (included)
C clamp (not included)
Omega bracket (included)
Overhead Mounting Floor Standing

Operation
Q-Wash 360Z-LED User Manual Rev. 01g -9-
4. Operation
Control Panel
Description
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value
in to the current function
<UP> Navigates upwards through the menu list and increases the numeric value
when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric
value when in a function
Control Options You can set the Q-Wash 360Z-LED start address in the 001~512 DMX range. This allows
for the control of up to 34 fixtures in the 15-channel ADVANCED personality.
Programming
Refer to the Menu Map on page 14 to learn how the menu options relate to each other.
The menu map has a Menu Level and a variable number of programming levels for each
option.
To go to an option in the Menu Level, press <MENU> repeatedly until the option shows on
the display. Press <ENTER> to select it. This will take you to the first programming level for
that option.
To select an option or value within the current programming level press <UP> or <DOWN>
until it shows on the display. Press <ENTER> to accept it. In this case, if there is another
programming level, you will see its first option. Otherwise, you will see the selected value.
To exit to the previous menu level, press <MENU>.
In the EDIT menu, <UP> and <DOWN> will only change the value of the current
option. To change to the next option, press <ENTER>.
DMX Operation 1) Select DMX operation.
a) Go to MENU > INTRO > RUN.
b) Select DMX512.
2) Select a DMX mode.
a) Go to MENU > INTRO > CHANNELS.
b) Select BASIC or ADVANCED.
3) Select the starting address.
a) Go to MENU > INTRO > ADDRESS.
b) Select a starting address, 001~498 (Advanced) or 001~502(Basic).
The highest recommended starting address for each of the two DMX modes are as
follows:
BASIC: 502
ADVANCED: 498
Stand-alone
Operation
1) Go to MENU > INTRO > RUN.
2) Select a stand-alone operation mode (AUTO 1, AUTO 2, CUSTOM, or TEST).
Of all the stand-
alone operation modes indicated above, only “CUSTOM” is editable
(see Edit Custom).
Continues on the next page

Operation
-10- Q-Wash 360Z-LED User Manual Rev. 01g
Continued from previous page
Master/Slave
The Master/Slave mode allows a group of Q-Wash 360Z-LED fixtures (the slaves) to
simultaneously duplicate the output of another Q-Wash 360Z-LED (the master), whether
static mode settings or auto/custom programs, without a DMX controller.
1) Set the master unit:
a) Select a stand-alone mode, as indicated above.
2) Set each of the slave units:
a) Go to MENU > INTRO > RUN.
b) Select SLAVE.
•Do not connect a DMX controller to the master or slave fixtures.
•The master unit should be the first in the DMX string.
Display Mode This mode defines how the LCD’s backlight will work.
1) Go to MENU > INTRO > DISPLAY.
2) Select a display mode (60 CLOSE or BRIGHT).
•When in the “60 CLOSE” setting, the LCD’s backlight will turn off after 60 s.
•When in the “BRIGHT” setting, the LCD’s backlight will stay on.
Software Version This option will show the installed software version.
1) Go to MENU > INTRO > INFO.
2) The display will show Edition.
3) Press <ENTER> to see the installed software version.
Keylock This option enables or disables the LCD key.
1) Go to MENU > INTRO > KEYLOCK.
2) Select YES or NO.
When in the “YES” setting, the user will have to enter the password after 30 seconds
of control panel inactivity or each time he/she turns the fixture on.
The default (non-modifiable) password is
<UP>, <DOWN>, <UP>, <DOWN>, and <ENTER>.
Fan
You can select the fan operation mode, as follows:
1) Go to MENU > INTRO > FAN.
2) Select HIGH, NORMAL, LOW, or AUTO.
The fixture’s controller will force the fan to High if the fixture’s internal temperature
becomes too high, despite any manual or DMX setting.
Reset
This option allows you to reset all custom settings to their default values.
1) Go to MENU > INTRO > RESET.
2) Select YES or NO.
Continues on the next page

Operation
Q-Wash 360Z-LED User Manual Rev. 01g -11-
Continued from previous page
Dimmer Curve
To select the dimmer curve, do the following:
1) Go to MENU > INTRO > DIMMER.
2) Select DIMMER0~4.
DIMMER0: The output is proportional (linear) to the Dimmer and RGBW channel
values.
DIMMER1~4: The output follows the Dimmer and RGBW channel values based on the
corresponding dimmer curve, being DIM1 the fastest and DIM4 the
slowest.
Fader Reversal
This option allows you to define how the pan, tilt, and dimmer increase based on the
direction you move the corresponding fader.
1) Go to MENU > INVERT > PAN.
2) Select a fader direction (NORMAL or REVERSE).
3) Go to MENU > INVERT > TILT.
4) Select a fader direction (NORMAL or REVERSE).
5) Go to MENU > INVERT > DIMMER.
6) Select a fader direction (NORMAL or REVERSE).
7) Go to MENU > INVERT > USE.
8) Select YES to activate the new settings or NO to stop using them.
•When in NORMAL, the pan, tilt, and dimmer values will increase as the position
of the respective fader increases.
•When in REVERSE, the pan, tilt, and dimmer values will decrease as the position
of the respective fader increases.
Range Limitation
When it is necessary to limit the pan or tilt range, you can do the following:
1) Go to MENU > RANGE > P/START.
2) Select the starting point for the limited pan (000~255).
3) Go to MENU > RANGE > P/FINISH.
4) Select the finishing point for the limited pan (000~255).
5) Go to MENU > RANGE > T/START.
6) Select the starting point for the limited tilt (000~255).
7) Go to MENU > RANGE > T/FINISH.
8) Select the finishing point for the limited tilt (000~255).
9) Go to MENU > RANGE > USE.
10) Select YES to activate the new settings or NO to stop using them.
Reset Control
It is possible to select how you can reset the fixture, whether with the DMX controller or
only from the control panel.
1) Go to MENU > SPECIAL > RESET.
2) Select DMX or SYSTEM.
DMX: Enables the DMX controller to reset the fixture (Control function).
SYSTEM: Restricts the reset function to the control panel..
Continues on the next page

Operation
-12- Q-Wash 360Z-LED User Manual Rev. 01g
Continued from previous page
Move-in Black This option allows you to activate or deactivate the move-in black 3-seconds delay.
1) Go to MENU > SPECIAL > BLACK
2) Select YES to enable the 3 seconds delay or NO to make the blackout immediate.
Power
You may use this function to boost the output power for specific, short-term applications.
1) Go to MENU > SPECIAL > POWER.
2) Select NORMAL or HIGH.
The fixture will return to Normal if the LEDs’ temperature becomes too high.
Color Settings
The COLOR setting determines how the Q-Wash 360Z-LED generates the white color
based on various RGB settings.
1) Go to MENU > SPECIAL > COLOR.
2) Select OFF, RGBTOW, or UC.
UC: When the RGB faders are all set to “255”, the output matches that of less
efficient fixtures (Universal Color).
RGBTOW: When the RGB faders are all set to “255”, the resulting output is defined by
RGB-W (see MENU > EXTRA > CALIB).
OFF: When the RGB faders are all set to “255”, the output is maximum, although
the resulting white color may not be balanced.
Fan Control
This option defines how you can control the fan speed, whether with the DMX controller or
only from the control panel.
1) Go to MENU > SPECIAL > FAN.
2) Select DMX or SYSTEM.
DMX: Enables the DMX controller to control the fan speed (Control function).
SYSTEM: Restricts the control of the fan speed to the control panel..
Color Calibration
If necessary, you may adjust the color temperature of each of the macros (White1~11).
1) Go to MENU > EXTRA.
2) Press <ENTER> (PASSWORD) will show on the display.
3) Press <ENTER> (**** will show on the display).
4) Enter the password, as explained in Keylock (CALIB will show on the display).
5) Press <ENTER> (3200K will show on the display).
6) Use <UP> or <DOWN> to select another color temperature (3400~10000 K), or press
<ENTER> to edit the current temperature.
7) Select RED, GREEN, or BLUE.
8) Select a value (000~255).
9) Repeat for the other colors.
Continues on the next page

Operation
Q-Wash 360Z-LED User Manual Rev. 01g -13-
Continued from previous page
White Calibration
You may calibrate the white color shown when the RGB faders are at “255” and the
MENU > SPECIAL > COLOR setting is RGBTOW.
1) Go to MENU > EXTRA.
2) Press <ENTER> (PASSWORD) will show on the display.
3) Press <ENTER> (**** will show on the display).
4) Enter the password, as explained in Keylock (CALIB will show on the display).
5) Press <ENTER> (3200K will show on the display).
6) Use <UP> or <DOWN> to select RGBW.
7) Select RED, GREEN, or BLUE.
8) Select a value (000~255).
9) Repeat for the other colors.
System Default
To default all the fixture’s parameters to their default values, do the following:
1) Go to MENU > EXTRA.
2) Press <ENTER> (PASSWORD) will show on the display.
3) Press <ENTER> (**** will show on the display).
4) Enter the password, as explained in Keylock (CALIB will show on the display).
5) Use <UP> to select DEFAULT.
6) Press <ENTER> (NO will show on the display).
7) Select YES and press <ENTER> to default the fixture or press <MENU> to exit.
Edit Custom This function allows you to program up to 255 steps in a single custom program.
1) Go to MENU > EDIT.
2) Press <ENTER> to go to STEP.
3) Press <ENTER> to select a value. The current value (001~255) will show on the LCD.
4) Press <UP> or <DOWN> to select a new value.
5) Press <ENTER> to accept the value.
6) Press <ENTER> to go to PAN.
7) Repeat steps “1” through “6” for TILT, SPEED, RED, GREEN, BLUE, WHITE,
DIMMER, STROBE, ZOOM, DIMSPEED, and TIME.
8) Press <ENTER> to go to USE.
9) Select YES to save the settings for this step or NO to delete them.
10) Repeat steps “3” to “8” for the other steps.
The fixture will execute all the steps in the CUSTOM program and it will stop.
To make the fixture start over add a last step whose duration is 0 seconds.
Example:
Step 1: Time = 5 Use = Yes
Step 2: Time = 4 Use = Yes
Step 3: Time = 6 Use = Yes
Step 4: Time = 0 Use = Yes (This step creates a loop)
Step 5: Time = 0 Use = No
(Unused steps)
Step 255 Time = 0 Use = No

Operation
-14- Q-Wash 360Z-LED User Manual Rev. 01g
Menu Map
1
st
Level 2
nd
Level 3
rd
Level Description
INTRO
ADDRESS
001~512
Selects a starting DMX address
RESET
NO/YES
Resets the fixture’s custom settings
FAN
HIGH
Select the fan’s operation mode.
NOTE: The fan will go to High
mode if the fixture’s internal
temperature becomes too high, despite any manual or
DMX setting
NORMAL
LOW
AUTO
RUN
DMX512
Selects DMX running mode
AUTO 1
Selects the first automatic program
AUTO 2
Selects the second automatic program
CUSTOM
Selects the user customizable program
SLAVE
Selects the Slave running mode
TEST
Starts the fixture’s test sequence
CHANNELS
BASIC
Selects the 11-channel DMX mode
ADVANCED
Selects the 15-channel DMX mode
DISPLAY
60 CLOSE
Turns off the display after 60 seconds
BRIGHT
Keeps the display on
KEYLOCK
NO/YES
Activates/deactivates the control panel password
DIMMER
DIMMER4~1
Slow (DIMMER4) to fast (DIMMER1) dimmer curves
DIMMER0
Linear dimmer
INFO
EDITION
Shows the version of the installed S/W
INVERT
PAN
NORMAL/
REVERSE
Defines the direction of the pan fader
TILT
Defines the direction of the tilt fader
DIMMER
Defines the direction of the dimmer fader
USE
NO/YES
Activates the changes
RANGE
P/START
000~255
Sets the pan start point (restricted range)
P/FINISH
Sets the pan end point (restricted range)
T/START
Sets the tilt start point (restricted range)
T/FINISH
Sets the tilt end point (restricted range)
USE
Activates the changes
SPECIAL
BLACKD
NO/YES
Activates the move-in black delay (3 s)
RESET
DMX
The DMX controller can reset the fixture
SYSTEM
The control panel can reset the fixture
POWER NORMAL/
HIGH
LEDs illuminate at normal or high intensity
NOTE: The fixture will return to Normal if the LEDs’
temperature becomes too high
COLOR
UC
RGBW = 255: The output matches that of older fixtures
RGBTOW
RGBW = 255: The RGBW output is set by RGB-W
OFF
RGBW = 255: The RGBW output is maximum
FAN
DMX
The DMX controller can set the fan speed
SYSTEM
The control panel can reset the fan speed
EDIT
STEP
000~255
Selects the program step
PAN
Selects the pan position
TILT
Selects the tilt position
SPEED
Selects the pan/tilt speed
RED
Combines red, green, blue, and white to obtain a custom
color
GREEN
BLUE
WHITE
Continues on the next page

Operation
Q-Wash 360Z-LED User Manual Rev. 01g -15-
Continued from previous page
1
st
Level 2
nd
Level 3
rd
Level Description
EDIT
(Cont.)
DIMMER
000~255
Selects the dimmer value
STROBE
Selects the strobe frequency and mode
ZOOM
Select the zoom position
DIMSPEED
Selects the dimmer speed
TIME
Selects the step duration
USE
NO/YES
Activates the changes
EXTRA
PASSWORD
****
Opens the Extra menu (see below)
Extra Menu
1
st
Level 2
nd
Level 3
rd
Level 4
th
Level Description
CALIB
3200 K
RED
000~255
Sets color temperature for White 1
GREEN
BLUE
3400 K
RED
Sets color temperature for White 2
GREEN
BLUE
4200 K
RED
Sets color temperature for White 3
GREEN
BLUE
4900 K
RED
Sets color temperature for White 4
GREEN
BLUE
5600 K
RED
Sets color temperature for White 5
GREEN
BLUE
5900 K
RED
Sets color temperature for White 6
GREEN
BLUE
6500 K
RED
Sets color temperature for White 7
GREEN
BLUE
7200 K
RED
Sets color temperature for White 8
GREEN
BLUE
8000 K
RED
Sets color temperature for White 9
GREEN
BLUE
8500 K
RED
Sets color temperature for White 10
GREEN
BLUE
10000 K
RED
Sets color temperature for White 11
GREEN
BLUE
RGB-W
RED
Sets color temperature for
SPECIAL > COLOR > RGBTOW
GREEN
BLUE
DEFAULT
DEFAULT
NO/YES
N/A
Defaults the fixture to factory settings

Operation
-16- Q-Wash 360Z-LED User Manual Rev. 01g
DMX Values
BASIC
Channel Function Value Percent/Setting
1
Pan
000
ó
255
0~540º
2
Tilt
000
ó
255
0~270º
3
Red
000
ó
255
0~100%
4
Green
000
ó
255
0~100%
5
Blue
000
ó
255
0~100%
6
White
000
ó
255
0~100%
7 Power and Color
Macro
000
ó
005
006 ó010
011 ó030
031 ó050
051 ó070
071 ó090
091 ó110
111 ó130
131 ó150
151 ó170
171 ó200
201 ó205
206 ó210
211 ó215
216 ó220
221 ó225
226 ó230
231 ó235
236 ó240
241 ó245
246 ó250
251
ó
255
No function
High power
R: 100% G: Up B: 0%
R: Down G: 100% B: 0%
R: 0% G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
R: 100% G: 100% B: 100% W: 100%
White 1: 3200 K
White 2: 3400 K
White 3: 4200 K
White 4: 4900 K
White 5: 5600 K
White 6: 5900 K
White 7: 6500 K
White 8: 7200 K
White 9: 8000 K
White 10: 8500 K
White 11: 10,000 K
8
Dimmer
000
ó
255
0~100%
9 Strobe
000 ó009
010
ó
255
No function
01~20 Hz
10
Zoom
000
ó
255
9º~26º
11 Control
000
ó
019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220
ó
255
No function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No function
Reset (3 s activation delay)
No function
