Chauvet Rogue R1 FX-B User manual

User Manual

Edition Notes
Rogue R1 FX-B User Manual Rev. 2
Edition Notes
The Rogue R1 FX-B User Manual Rev. 2 covers the description, safety precautions, installation,
programming, operation, and maintenance of the Rogue R1 FX-B. Chauvet
released this edition
of the Rogue R1 FX-B User Manual in November 2016.
Trademarks
CHAUVET, the Chauvet logo and Rogue R1 FX-B are registered trademarks or trademarks of
Chauvet & Sons LLC
. (d/b/a Chauvet and Chauvet Lighting) in the United States and other
countries. Other company and product names and logos referred to herein may be trademarks
of their respective companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all design, text
and images are owned by Chauvet.
© Copyright 2016 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information
purposes only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification,
or printing of this manual or
its content for any other purpose without written consent from
Chauvet.
Document
Printing
For better results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If
using A4 paper (210 x 297 mm), configure your printer to scale the content accordingly.
Intended
Audience
Any person in charge of installing, operating, and/or maintaining this product should completely
read through the guide that shipped with the product, as well as this manual, before installing,
operating, or maintaining this product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects.
However, Chauvet assumes no responsibility and specifically disclaims any and all liability to
any party for any loss, damage or
disruption caused by any errors or omissions in this
document, whether such errors or omissions result from negligence, accident or any other
cause. Chauvet reserves the right to revise the content of this document without any obligation
to notify any person or company of such revision, however, Chauvet has no obligation to make,
and does not commit to make, any such revisions.
Document
Revision
The Rogue R1 FX-B User Manual is the 2nd edition of this manual. Go to
www.chauvetprofessional.com for the latest version.

Table of Contents
Rogue R1 FX-B User Manual Rev. 2 -i-
Table of Contents
1. Before You Begin..........................................................................................................................1
What Is Included...........................................................................................................................................1
Claims..............................................................................................................................................................................1
Manual Conventions.....................................................................................................................................1
Symbols........................................................................................................................................................1
Product At A Glance .....................................................................................................................................1
Safety Notes.................................................................................................................................................2
Expected LED Lifespan.................................................................................................................................2
2. Introduction...................................................................................................................................3
Description....................................................................................................................................................3
Features .......................................................................................................................................................3
Overview.......................................................................................................................................................3
Dimensions...................................................................................................................................................4
3. Setup..............................................................................................................................................5
AC Power .....................................................................................................................................................5
AC Plug ...........................................................................................................................................................................5
Fuse Replacement..........................................................................................................................................................5
Power Linking..................................................................................................................................................................5
Mounting.......................................................................................................................................................6
Orientation.......................................................................................................................................................................6
Signal Connections.......................................................................................................................................7
Art-Net™ Connection ......................................................................................................................................................7
sACN Connection............................................................................................................................................................7
Kling-Net Connection ......................................................................................................................................................7
4. Operation.......................................................................................................................................8
Touchscreen Control Panel...........................................................................................................................8
Control Panel Description................................................................................................................................................8
Menu Map.....................................................................................................................................................8
Protocol Configuration ................................................................................................................................13
Single Control................................................................................................................................................................13
Single Control Protocol.................................................................................................................................................................13
Single Control Personality.............................................................................................................................................................13
Single Control Start Address.........................................................................................................................................................13
Single Control Universe................................................................................................................................................................13
Dual Control...................................................................................................................................................................14
Dual Control Movement................................................................................................................................................................14
Dual Control Movement Protocol.....................................................................................................................................................................14
Dual Control Movement Personality.................................................................................................................................................................14
Dual Control Movement Start Address.............................................................................................................................................................14
Dual Control Movement Universe ....................................................................................................................................................................14
Dual Control Pixel.........................................................................................................................................................................15
Dual Control Pixel Protocol..............................................................................................................................................................................15
Dual Control Pixel Personality..........................................................................................................................................................................15
Dual Control Pixel Start Address......................................................................................................................................................................15
Dual Control Pixel Universe.............................................................................................................................................................................15
Zones for Pixel control................................................................................................................................16
DMX Values................................................................................................................................................16
Single Control Values....................................................................................................................................................16
Tour (47-channel) .........................................................................................................................................................................16
Advanced Mode (47-channel).......................................................................................................................................................22
Standard Mode (25-channel)........................................................................................................................................................28
Basic Mode (18-channel)..............................................................................................................................................................34

Table of Contents
-ii- Rogue R1 FX-B User Manual Rev. 2
Dual Control Movement Values.....................................................................................................................................39
Advanced Movement Mode (23-channel).....................................................................................................................................39
Standard Movement Mode (17-channel).......................................................................................................................................42
Basic Movement Mode (10-channel) ............................................................................................................................................45
Dual Control Pixel Values..............................................................................................................................................47
RGBW Mode (20-channel)............................................................................................................................................................47
RGB Mode (15-channel)...............................................................................................................................................................47
Operating Settings Configuration................................................................................................................48
Home Screen ................................................................................................................................................................48
Test Mode......................................................................................................................................................................48
Auto Test.......................................................................................................................................................................................48
Manual Test..................................................................................................................................................................................48
Setup .............................................................................................................................................................................48
Network Settings...........................................................................................................................................................................48
Ethernet To DMX.............................................................................................................................................................................................48
IP Mode...........................................................................................................................................................................................................49
IP Address.......................................................................................................................................................................................................49
Subnet Mask ...................................................................................................................................................................................................49
Pan/Tilt Orientation.......................................................................................................................................................................50
Display Orientation........................................................................................................................................................................50
Pan/Tilt Angle Range....................................................................................................................................................................50
Blackout on Pan/Tilt Movement ....................................................................................................................................................50
Touchscreen Calibration...............................................................................................................................................................50
Touchscreen Lock.........................................................................................................................................................................50
Lock Screen..................................................................................................................................................................................51
Backlight Timer.............................................................................................................................................................................51
Loss of Data..................................................................................................................................................................................51
Color Mixing Mode........................................................................................................................................................................51
Dimmer Curve...............................................................................................................................................................................51
Dimmer Speed..............................................................................................................................................................................52
Color Balance ...............................................................................................................................................................................52
Reset Functions............................................................................................................................................................................52
Factory Reset................................................................................................................................................................................52
System Information .......................................................................................................................................................53
Offset Mode................................................................................................................................................53
5. Firmware Update.........................................................................................................................54
6. Technical Information.................................................................................................................57
Product Maintenance..................................................................................................................................57
7. Technical Specifications............................................................................................................58
Returns............................................................................................................................................59
Contact Us.......................................................................................................................................60

Before You Begin
Rogue R1 FX-B User Manual Rev. 2 -1-
1. BEFORE YOU BEGIN
What Is
Included
•Rogue R1 FX-B
•Neutrik® powerCON® power cord
•2 Omega brackets with mounting hardware
•Warranty card
•Quick Reference Guide
Claims
Carefully unpack the product immediately and check the box to make sure all the parts are in
the package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from
shipping or show signs of mishandling, notify the carrier immediately, not Chauvet
. Failure to
report damage to the carrier immediately may invalidate your claim. In addition, keep the box
and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with Chauvet within 7 days of delivery.
Manual
Conventions
Convention
Meaning
1–512
A range of values in the text
50/60
A set of mutually exclusive values in the text
<SET>
A button on the product’s control panel
Settings
A product function or a menu option
ON
A unique value to be entered or selected in a menu
Symbols
Symbols
Meaning
Critical installation, configuration, or operation information. Failure to
comply with this information may cause the product not to work,
damage third-party equipment, or cause harm to the operator.
Important installation or configuration information. Failure to comply
with this information may keep the product from working.
Useful information.
The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data
transmission protocol.
Product At A
Glance
Use on Dimmer
x
Auto Programs
x
Outdoor Use
x
Auto-Ranging Power Supply
P
Master/Slave
x
Replaceable Fuse
P
DMX
P
User-Serviceable
x

Before You Begin
-2- Rogue R1 FX-B User Manual Rev. 2
Safety Notes
Read all the following Safety Notes before working with this product. These notes include
important information about the installation, usage, and maintenance of this product.
This product contains no user-serviceable parts. Any reference to servicing in this User
Manual will only apply to properly trained Chauvet certified technicians. Do not open the
housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
Personal Safety
•Avoid direct eye exposure to the light source while the product is on.
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
•Do not touch this product’s housing during operation because it may be very hot.
Mounting And
Rigging
•This product is not intended for permanent installation.
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture. (IP20)
•CAUTION: When transferring product from extreme temperature environments, (e.g. cold
truck to warm humid ballroom) condensation may form on the internal electronics of the
product. To avoid causing a failure, allow product to fully acclimate to the surrounding
environment before connecting it to power.
•Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from
adjacent surfaces.
•Make sure there are no flammable materials close to this product while it is operating.
•When hanging this product, always secure to a fastening device using a safety cable.
•Never carry the product by the power cord or any moving part.
Power And Wiring
•Make sure the power cord is not crimped or damaged.
•Always make sure you are connecting this product to the proper voltage in accordance
with the specifications in this manual or on the product’s specification label.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
•Never connect this product to a dimmer pack or rheostat.
•Make sure to replace the fuse with another of the same type and rating.
•Never disconnect this product by pulling or tugging on the power cable.
Operation
•Do not operate this product if you see damage on the housing, lenses, or cables. Have the
damaged parts replaced by an authorized technician at once.
•Do not cover the ventilation slots when operating to avoid internal overheating.
•The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at a
higher temperature.
•In case of a serious operating problem, stop using this product immediately!
In the unlikely event that your Chauvet product may require service, contact Chauvet
Technical Support.
Expected LED
Lifespan
LEDs gradually decline in brightness over time, mostly because of heat. Packaged in clusters,
LEDs exhibit higher operating temperatures than in ideal, single-LED
conditions. For this
reason, using clustered LEDs at their fullest intensity significantly reduces the LEDs’ lifespan.
Under normal conditions, this lifespan can be 40,000 to 50,000 hours. If extending this lifespan
is vital, lower the operating temperature by improving the ventilation around the product and
reducing the ambient temperature to an optimal operating range. In addition, limiting the overall
projection intensity may also help to extend the LEDs’ lifespan.

Introduction
Rogue R1 FX-B User Manual Rev. 2 -3-
2. INTRODUCTION
Description
The Rogue R1 FX-B is a fully-featured RGBW LED yoke effect beam product with continuous
movement of the pan and each of the five autonomous tilt functions.
Pixel map the five beams
for unique effects. The Rogue R1 FX-B runs on DMX, Art-Net™, sACN, and Kling-Net protocols
,
and can be controlled
with lighting consoles or media servers, providing the ultimate in flexible
control integration options. Convert TCP/IP protocols in to DMX output for shorter cable runs.
Features
•5 RGBW 15 W LEDs
•Tight 7° beams.
•5,361 lux at 5 meters
•Continuous and-fast pan/tilt movement
•Control options include DMX, Art-Net™, sACN, and Kling-Net
•Neutrik® powerCON® in and out ports
•Amphenol XLRnet through ports
•DMX 3- and 5-pin in and out ports
•Built-in TCP/IP to DMX converter
•Built-in web server for remote diagnostics and firmware upgrades
Overview
Rear View
Touchscreen
Display
Menu
Buttons
Yoke
Rubber Foot
(x4)
Amphenol XLRnet
Through Ports
3-pin DMX
In/Out
5-pin DMX
In/Out
Neutrik®
powerCON® In
Fuse-
Holder
Ethernet
LED Indicators
Front View
Neutrik®
powerCON® Out

Introduction
-4- Rogue R1 FX-B User Manual Rev. 2
Dimensions
3.52 in
89 mm
7.05 in
179 mm
11.13 in
283 mm
4.8 in
122 mm
4.8 in
122 mm
25.19 in
640 mm
3.03 in
77 mm
5.83 in
148 mm
9.72 in
247 mm
17.32 in
440 mm
4.8 in
122 mm 4.8 in 122 mm

Setup
Rogue R1 FX-B User Manual Rev. 2 -5-
3. SETUP
AC Power
Each Rogue R1 FX-B has an auto-ranging power supply that works with an input voltage range
of 100 to 240 VAC, 50/60 Hz. To determine the power requirements for each Rogue R1 FX-B
,
refer to the label affixed to the product. You can also refer to the Technical Specifications
chart
in this manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, you may download Sizing Circuit Breakers from the Chauvet website
:
www.chauvetprofessional.com.
•Always connect this product to a protected circuit with an appropriate electrical
ground to avoid the risk of electrocution or fire.
•Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
AC Plug
The Rogue R1 FX-B comes with a power input cord terminated with a Neutrik® powerCON®
connector on one end and an Edison plug on the other end (U.S. market). If the power input
cord that came with your product has no plug, or if you need
to change the Edison plug, use the
table below to wire the new plug.
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow or Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Fuse
Replacement
Disconnect this product from the power outlet.
1. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.2. Remove the blown fuse and replace with another fuse of the same type and rating3. (F 3 A, 250 V).
Screw the fuse holder cap back in place and reconnect power.
4.
Make sure to disconnect the product’s power cord before replacing a blown fuse. Always
replace the blown fuse with another of the same type and rating.
Power Linking
The Rogue R1 FX-B supports power linking. You can power link up to 8 products at
120 V; up to 14 at 208 V; or up to 15 at 230 V.
This product comes with a power input cord. Power linking cables are available from Chauvet
for purchase.
Power Linking
Diagram
Power
Source
1st Product
2nd Product
3rd Product
Additional Products

Setup
-6- Rogue R1 FX-B User Manual Rev. 2
Mounting
Before mounting this product, read and follow the Safety Notes. For our CHAUVET
Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position and make sure there is adequate room for
ventilation, configuration, and maintenance. The Rogue R1 FX-B
can be suspended upright or
upside down using the 2 Omega brackets included, or it can be placed on its rubber feet on a
flat level surface.
Chauvet recommends using the following general guidelines when mounting this product:
•When selecting an installation location, consider easy access to this product for operation,
programming adjustments, and routine maintenance.
•The product is not intended for permanent installation.
•Make sure to mount this product away from any flammable material as indicated in the
Safety Notes.
•Never mount in places where rain, high humidity, extreme temperature changes, or
restricted ventilation may affect the product.
•If hanging this product, make sure that the mounting location can support the product’s
weight. See the Technical Specifications for the weight-bearing requirements of this
product.
•When hanging this product, always secure to a fastening device using a safety cable. For
our CHAUVET Professional line of safety cables, go to http://trusst.com/products/.
•When mounting the product on the floor, make sure that the product and cables are away
from people and vehicles.
•Place the Rogue R1 FX-B so that it can move freely without hitting anything or anybody.
•Leave enough slack on the cabled to prevent tension and pull on the plugs.
Mounting Diagram
Safety Cable
Overhead Mounting
Floor Mounting
Rubber Feet (x4)
Mounting Clamp
Omega Bracket

Setup
Rogue R1 FX-B User Manual Rev. 2 -7-
Signal Connections
The Rogue R1 FX-B can receive DMX, Art-Net™, sACN, or Kling-Net signal. The Rogue R1
FX-B has 2 Neutrik® etherCON® through ports, and 3- and 5-pin DMX in and out ports. For
more information about DMX, read the DMX primer at:
http://www.chauvetlighting.com/downloads/DMX_Primer_Rev9_ML_WO.pdf.
Art-Net™
Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP which transfers a large amount of DMX512
data using an Neutrik® etherCON® RJ45 connection over a large network. An Art-Net™
protocol document is available from www.chauvetprofessional.com.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN
Connection
Also known as ANSI E1.31, streaming ACN is an Ethernet protocol that uses the layering and
formatting of Architecture for Control Networks to transport DMX512 data over IP or any other
ACN compatible network. ACN is maintained by the Professional Lighting a
nd Sound
Association (PLASA).
Kling-Net
Connection
Kling-Net is a network protocol that allows auto configuration of display devices using a
Neutrik® etherCON® RJ45 Ethernet connection. Refer to the ArKaos software manual for
detailed instructions on programming this product.
ArKaos Kling-Net does not support the pan and tilt functions, and must be paired with
another protocol for full functionality with the Rogue R1 FX-B.
Connection
Diagram
The three LED indicators in between the Amphenol XLRnet ports indicate a connection to a
network and activity on that network. They do not indicate whether or not the
Rogue R1 FX-B is receiving a signal from a controller.
Switch or Router
(such as the NET-Switch
from CHAUVET Professional)
Rogue R1 FX-B
Computer/Controller
(running Art-Net™,
sACN, or Kling-Net
protocol)
To other Art-Net™, sACN,
or Kling-Net Devices

Operation
-8- Rogue R1 FX-B User Manual Rev. 2
4. OPERATION
Touchscreen
Control Panel
The Rogue R1 FX-B has a touchscreen display as well as 6 control buttons. Navigate the menu
structure
by pressing the buttons, touching the images of the buttons on the sides of the display,
or touching the desired menu option on the display directly.
The touchscreen can be locked and
calibrated through the Setup options in the menu. (see Touchscreen Calibration and
Touchscreen Lock)
Control Panel
Description
Button
Function
(<UP>)
Navigates upwards through the menu list or increases the numeric value
when in a function
(<MENU>)
Exits from the current menu or function
(<DOWN>)
Navigates downwards through the menu list or decreases the numeric
value when in a function
(<LEFT>)
Navigates leftwards through the menu list
(<ENTER>)
Enables the currently displayed menu or sets the currently
selected value
into the selected function
(<RIGHT>)
Navigates rightwards through the menu list
Menu Map
Main Level
Programming Levels
Description
Control
Settings Single Control
DMX Personality
Basic
Sets the DMX personality, from
Basic (18CH), Standard (25CH),
Advanced (47CH), or Tour (47CH)
Standard
Advanced
Tour
Start Address
001–512
Sets the DMX starting address
ArtNet Personality
Basic
Sets the Art-Net™ personality, from
Basic (18CH), Standard (25CH) ,
Advanced (47CH), or Tour (47CH)
Standard
Advanced
Tour
Start Address
001–512
Sets the Art-Net™ starting address
Universe
0–254
Sets the Art-Net™ universe
sACN Personality
Basic
Sets the sACN personality, from
Basic (18CH), Standard (25CH) ,
Advanced (47CH), or Tour (47CH)
Standard
Advanced
Tour
Start Address
001–512
Sets the sACN starting address
Universe
0–255
Sets the sACN universe
< >
< >
< >
< >
< >
< >

Operation
Rogue R1 FX-B User Manual Rev. 2 -9-
Main Level
Programming Levels
Description
Control
Settings
(cont.) Dual Control
Movement
DMX Personality
Basic
Sets the DMX personality, from
Basic (10CH), Standard (17CH), or
Advanced (23CH)
Standard
Advanced
Start Address
001–512
Sets the DMX starting address
ArtNet Personality
Basic
Sets the Art-Net™ personality, from
Basic (10CH), Standard (17CH), or
Advanced (23CH)
Standard
Advanced
Start Address
001–512
Sets the Art-Net™ starting address
Universe
0–254
Sets the Art-Net™ universe
sACN Personality
Basic
Sets the sACN personality, from
Basic (10CH), Standard (17CH), or
Advanced (23CH)
Standard
Advanced
Start Address
001–512
Sets the sACN starting address
Universe
0–255
Sets the sACN universe
Pixels
DMX Personality
RGB
Sets the DMX personality, from
RGB (15CH) or RGBW (20CH)
RGBW
Start Address
001–512
Sets the DMX starting address
ArtNet Personality
RGB
Sets the Art-Net™ personality, from
RGB (15CH) or RGBW (20CH)
RGBW
Start Address
001–512
Sets the Art-Net™ starting address
Universe
0–254
Sets the Art-Net™ universe
sACN Personality
RGB
Sets the sACN personality, from
RGB (15CH) or RGBW (20CH)
RGBW
Start Address
001–512
Sets the sACN starting address
Universe
0–255
Sets the sACN universe
KlingNet Personality
RGB
Sets the Kling-Net personality, from
RGB (15CH) or RGBW (20CH)
RGBW
In Dual Control mode, the Movement protocol and the Pixel protocol cannot be the same.

Operation
-10- Rogue R1 FX-B User Manual Rev. 2
Main Level
Programming Levels
Description
Test Mode
Auto test
Auto test all functions
Manual test
Pan
000–255 Manually control and test all settings
through the control panel
Pan Speed
Pan 360
Tilt 1
Tilt 2
Tilt 3
Tilt 4
Tilt 5
Tilt Speed
Tilt 1 360
Tilt 2 360
Tilt 3 360
Tilt 4 360
Tilt 5 360
Dimmer
Shutter
Red
Green
Blue
White
Color
LED Macro
LED Macro Speed
Setup
Network Settings
Ethernet To DMX
NO
Do not convert ethernet in to DMX out
YES
Convert ethernet in to DMX out
IP Mode
Manual
Manually set IP address
DHCP
Network sets IP address
Static
Product sets IP address
IP
_ _ _._ _ _._ _ _._ _ _
Set IP address in Manual mode
SubMask
_ _ _._ _ _._ _ _._ _ _
Set Subnet Mask in Manual mode
Pan Reverse
NO
Normal pan
YES
Reversed pan
Tilt Reverse
NO
Normal tilt
YES
Reversed tilt
Screen Reverse
NO
Normal display
YES
Inverted display
AUTO
Automatic display orientation
Pan Angle
540
540° pan range
360
360° pan range
180
180° pan range
Tilt Angle
540
540° tilt range
270
270° tilt range
180
180° tilt range
BL. O. P/T Move
NO
Do not black out while panning/tilting
YES
Black out while panning/tilting
Calibration
NO
Keep current settings
YES
Calibrate touchscreen

Operation
Rogue R1 FX-B User Manual Rev. 2 -11-
Main Level
Programming Levels
Description
Setup
(cont.)
Touchscreen Lock
NO
Display responds to touch
YES
Display does not respond to touch
Lock Screen
NO
Locks the buttons and touchscreen.
Passcode to unlock: 0920
YES
Backlight Timer
30S
Display turns off after 30 seconds
1M
Display turns off after 1 minute
5M
Display turns off after 5 minutes
ON
Display stays on at all times
Loss of Data Hold
Hold last signal received at signal
loss
Close
Black out the product at signal loss
C Mixing Mode RGBW
Additive color mixing (0=0,
255=100%)
CMY
Subtractive color mixing (0=100%,
255=0)
Dimmer Curve
Linear
Set the dimmer curve
Square
I Squa
SCurve
Dimmer Speed
Smooth
Set the dimmer speed
Fast
PWM Option
600Hz
Selects the PWM output frequency
1200Hz
2000Hz
4000Hz
6000Hz
25000Hz
Color Balance
Red
100–255
Sets red LED maximum value
Green
Sets green LED maximum value
Blue
Sets blue LED maximum value
White
Sets white LED maximum value
Reset Function
Pan
NO
Reset individual functions or all
functions from start-up
YES
Tilt
NO
YES
All
NO
YES
Factory Settings
NO
Reset to factory default settings
YES
Sys Info Fixture Information
Ver
V_
Shows firmware version
Running Mode
_ _ _
Shows current running mode
Address
_ _ _
Shows current starting address
Temperature _ _
Shows current product temperature
in °C
Fixture Hours _ _ _ _ _
Shows number of hours product has
been powered on
IP
_ _ _._ _ _._ _ _._ _ _
Shows current IP address
SubMask
_ _ _._ _ _._ _ _._ _ _
Shows current Subnet Mask
MAC
_ _._ _._ _._ _._ _._ _
Shows current MAC address
Error Information
No Error!*
Shows any errors, or No Error!

Operation
-12- Rogue R1 FX-B User Manual Rev. 2
Main Level
Programming Levels
Description
Sys Info
(cont.) Channel Information
Frequency
_ _ _ Shows all current values from input
signals, 000–255
Pan
Pan Fine
Pan 360
Tilt 1
Tilt 1 Fine
Tilt 2
Tilt 2 Fine
Tilt 3
Tilt 3 Fine
Tilt 4
Tilt 4 Fine
Tilt 5
Tilt 5 Fine
Tilt 1 360
Tilt 2 360
Tilt 3 360
Tilt 4 360
Tilt 5 360
Y Macro
Y Macro Speed
Function
Dimmer
Shutter
Color
Lamp Number
LED Macro
LED Ma. Speed
Red 1
Green 1
Blue 1
White 1
Red 2
Green 2
Blue 2
White 2
Red 3
Green 3
Blue 3
White 3
Red 4
Green 4
Blue 4
White 4
Red 5
Green 5
Blue 5
White 5

Operation
Rogue R1 FX-B User Manual Rev. 2 -13-
Protocol Configuration
The Rogue R1 FX-B can be set to respond to DMX, Art-Net™, sACN, Kling-Net, or a combination of
those protocols. The protocol configuration must be set for the product to respond
correctly to the
controller(s). See the Menu Map for more information.
Single Control
In Single Control mode, the Rogue R1 FX-B is controlled by a single protocol input. Choose from
DMX, Art-Net™, or sACN. In this mode, the four personalities available are Basic (18
channels),
Standard (25 channels), Advanced (47 channels), and TOUR (47CH).
Single Control
Protocol
To select the Single Control protocol, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.1. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Control Settings, or touch the display2. where it says Control Settings.
If using the buttons instead of the touchscreen, press <ENTER>.3. Use <UP> or <DOWN> to select Single Control, or touch the display where it says Single4. Control.
If using the buttons instead of the touchscreen, press <ENTER>.5. Use <UP> or <DOWN> to select from DMX, ArtNet, or sACN
, or touch the display where it says
6. the desired protocol option.
If using the buttons instead of the touchscreen, press <ENTER>.
7.
Single Control
Personality
To select the Single Control personality, set the Protocol, then do the following:
Use <UP> or <DOWN> to select Personality, or touch the display where it says Personality.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from Basic (18-channel), Standard (25-3. channel), Advanced (47-channel), or TOUR (47CH), or touch the display where it says the
desired personality.
If using the buttons instead of the touchscreen, press <ENTER>.
4.
Single Control
Start Address
To set the starting address of the Single Control mode, set the Protocol, then follow the instructions
below:
Use <UP> or <DOWN> to select Start Address, or touch the display where it says Start1. Address.
If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the starting address (001–512) with one of the following methods:3. •Type the address number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the address is set as desired.c.
Press <ENTER>.
4.
Single Control
Universe
To set the Universe address of the Single Control mode when using Art-Net™ or sACN, set the
Protocol to ArtNet or sACN, then do the following:
Use <UP> or <DOWN> to select Universe, or touch the display where it says Universe.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the universe address (0–254 for ArtNet, 0–255 for sACN) with one of the following3. methods:
•Type the universe number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the universe is set as desired.c.
Press <ENTER>.
4.

Operation
-14- Rogue R1 FX-B User Manual Rev. 2
Dual Control
In Dual Control mode, the Rogue R1 FX-B is controlled by two protocol inputs. One controls the
movement of the yoke as well as the dimmer
and shutter, while the other controls the individual LED
output.
Dual Control
Movement
The Movement protocol controls the movement of the yoke as well as the dimmer and shutter.
Choose from DMX, Art-Net™, or sACN. In this mode, the three personalities available are Basic (10
channels), Standard (17 channels), and Advanced (23 channels).
Dual Control
Movement
Protocol
To select the Dual Control Movement protocol, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.1. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Control Settings, or touch the display2. where it says Control Settings.
If using the buttons instead of the touchscreen, press <ENTER>.3. Use <UP> or <DOWN> to select Dual Control, or touch the display where it says Dual Control.
4. If using the buttons instead of the touchscreen, press <ENTER>.5. Use <UP> or <DOWN> to select Movement, or touch the display where it says Movement.6. If using the buttons instead of the touchscreen, press <ENTER>.7. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from DMX, ArtNet, or sACN, or touch the8. display where it says the desired protocol option.
If using the buttons instead of the touchscreen, press <ENTER>.
9.
Dual Control
Movement
Personality
To select the Dual Control Movement personality, set the Protocol, then do the following:
Use <UP> or <DOWN> to select Personality, or touch the display where it says Personality.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from Basic (10-channel), Standard (17-3. channel), or Advanced (23-channel), or touch the display where it says the desired personality.
If using the buttons instead of the touchscreen, press <ENTER>.
4.
Dual Control
Movement
Start Address
To set the starting address of the Dual Control Movement mode, set the Protocol, then follow the
instructions below:
Use <UP> or <DOWN> to select Start Address, or touch the display where it says Start1. Address.
If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the starting address (001–512) with one of the following methods:3. •Type the address number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the address is set as desired.c.
Press <ENTER>.
4.
Dual Control
Movement
Universe
To set the Universe address of the Dual Control Movement mode when using Art-Net™ or sACN,
set the Protocol to ArtNet or sACN, then do the following:
Use <UP> or <DOWN> to select Universe, or touch the display where it says Universe.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the universe address (0–254 for ArtNet, 0–255 for sACN) with one of the following3. methods:
•Type the universe number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the universe is set as desired.c.
Press <ENTER>.
4.

Operation
Rogue R1 FX-B User Manual Rev. 2 -15-
Dual Control
Pixel
The Pixel protocol controls the individual output of the LEDs. Choose from DMX, Art-Net™, sACN,
or Kling-Net. In this mode, the two personalities available are RGB (15 channels), and RGBW (20
channels).
Dual Control Pixel
Protocol
To select the Dual Control Pixel protocol, follow the instructions below:
Press <MENU> repeatedly until the Home Screen shows on the display. Press <ENTER>.1. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select Control Settings, or touch the display2. where it says Control Settings.
If using the buttons instead of the touchscreen, press <ENTER>.3. Use <UP> or <DOWN> to select Dual Control, or touch the display where it says Dual Control.
4. If using the buttons instead of the touchscreen, press <ENTER>.5. Use <UP> or <DOWN> to select Pixel, or touch the display where it says Pixel.6. If using the buttons instead of the touchscreen, press <ENTER>.7. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from DMX, ArtNet, sACN, or KlingNet
, or
8. touch the display where it says the desired protocol option.
If using the buttons instead of the touchscreen, press <ENTER>.
9.
Dual Control Pixel
Personality
To select the Dual Control Pixel personality, set the Protocol, then do the following:
Use <UP> or <DOWN> to select Personality, or touch the display where it says Personality.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Use <UP>, <DOWN>, <LEFT>, or <RIGHT> to select from RGB (15-channel) or RGBW (20-3. channel), or touch the display where it says the desired personality.
If using the buttons instead of the touchscreen, press <ENTER>.
4.
Dual Control Pixel
Start Address
To set the starting address of the Dual Control Pixel mode, set the Protocol, then follow the
instructions below:
Use <UP> or <DOWN> to select Start Address, or touch the display where it says Start1. Address.
If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the starting address (001–512) with one of the following methods:3. •Type the address number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the address is set as desired.c.
Press <ENTER>.
4.
Dual Control Pixel
Universe
To set the Universe address of the Dual Control Pixel mode when using Art-Net™ or sACN, set the
Protocol to ArtNet or sACN, then do the following:
Use <UP> or <DOWN> to select Universe, or touch the display where it says Universe.1. If using the buttons instead of the touchscreen, press <ENTER>.2. Enter the universe address (0–254 for ArtNet, 0–255 for sACN) with one of the following3. methods:
•Type the universe number using the number pad that shows on the touchscreen display.
or
•Using the buttons (or the button icons on the sides of the display),
Use <LEFT> or <RIGHT> to select the digit to be altered.a. Use <UP> or <DOWN> to increase or decrease the number value of that digit.b. Repeat until the universe is set as desired.c.
Press <ENTER>.
4.

Operation
-16- Rogue R1 FX-B User Manual Rev. 2
Zones for Pixel control
DMX Values
Single Control Values
Tour
(47-channel)
Channel
Function
Value
Percent/Settings
1
Pan
000ó255
0–100%
2
Fine Pan
000ó255
0–100%
3 Continuous Pan
000
No function
001ó127
Counterclockwise rotation, slow to fast
128
Stop
129ó255
Clockwise rotation, slow to fast
4 Tilt Macro
000ó047
No function
048ó055
Tilt Macro 1
056ó063
Tilt Macro 2
064ó071
Tilt Macro 3
072ó079
Tilt Macro 4
080ó087
Tilt Macro 5
088ó095
Tilt Macro 6
096ó103
Tilt Macro 7
104ó111
Tilt Macro 8
112ó119
Tilt Macro 9
120ó127
Tilt Macro 10
128ó135
Tilt Macro 11
136ó143
Tilt Macro 12
144ó151
Tilt Macro 13
152ó159
Tilt Macro 14
160ó167
Tilt Macro 15
168ó175
Tilt Macro 16
176ó183
Tilt Macro 17
184ó191
Tilt Macro 18
192ó199
Tilt Macro 19
200ó207
Tilt Macro 20
208ó215
Tilt Macro 21
216ó223
Tilt Macro 22
224ó231
Tilt Macro 23
232ó239
Tilt Macro 24
240ó247
Tilt Macro 25
248ó255
Tilt Macro 26
5
Tilt Macro Speed
000ó255
Fast to slow
1
2
3
4
5
