Chauvet Eclipse RGB User manual

LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
CLASSIFIED PER EN/IEC 60825-1:2007
Complies with FDA performance standards
for laser products except for deviations
pursuant to Laser Notice No. 50, dated
June 24, 2007.

Rev. 7 2 Eclipse™ RGB User Manual
TABLE OF CONTENTS
.............................................................................................................................................................................................................................1
1. BEFORE YOU BEGIN...............................................................................................................................................3
WHAT IS INCLUDED.................................................................................................................................................................................................3
UNPACKING INSTRUCTIONS......................................................................................................................................................................................3
CLAIMS ...............................................................................................................................................................................................................3
MANUAL CONVENTIONS...................................................................................................................................................................................3
ICONS..................................................................................................................................................................................................................3
SAFETY NOTES..................................................................................................................................................................................................4
NON INTERLOCKED HOUSING WARNING.......................................................................................................................................................4
LASER SAFETY NOTES ....................................................................................................................................................................................4
LASER SAFETY LABEL REPRODUCTION .....................................................................................................................................................................6
LASER EMISSION DATA............................................................................................................................................................................................7
LASER COMPLIANCE STATEMENT .............................................................................................................................................................................7
2. INTRODUCTION........................................................................................................................................................8
PRODUCT OVERVIEW ..............................................................................................................................................................................................8
PRODUCT DIMENSIONS............................................................................................................................................................................................8
.......................................................................................................................................................................................9
3. SETUP.....................................................................................................................................................................10
ACPOWER ..........................................................................................................................................................................................................10
MOUNTING ...........................................................................................................................................................................................................10
Orientation ...................................................................................................................................................................................10
Rigging.........................................................................................................................................................................................10
PROPER USAGE....................................................................................................................................................................................................10
4. OPERATING INSTRUCTIONS................................................................................................................................11
CONTROL PANEL OPERATION ................................................................................................................................................................................11
MENU MAP...........................................................................................................................................................................................................11
CONFIGURATION (DMX)........................................................................................................................................................................................11
STARTING ADDRESS..............................................................................................................................................................................................11
DMXCHANNEL ASSIGNMENTS AND VALUES............................................................................................................................................................12
CONFIGURATION (STANDALONE)............................................................................................................................................................................13
AUTOMATIC MODE ................................................................................................................................................................................................13
SOUND ACTIVE MODE ...........................................................................................................................................................................................13
LEDCOLOR MIXING .............................................................................................................................................................................................13
LEDCOLOR FADING.............................................................................................................................................................................................13
MASTER/SLAVE MODE ..........................................................................................................................................................................................14
GENERAL TROUBLESHOOTING................................................................................................................................................................................14
TECHNICAL SPECIFICATIONS..................................................................................................................................................................................15
RETURN PROCEDURE............................................................................................................................................................................................16
CONTACT US........................................................................................................................................................................................................16

Eclipse™ RGB User Manual 3 Rev. 7
1.BEFORE YOU BEGIN
What Is Included
•1 x Eclipse™ RGB
•1 x Power Cable
•1 x Warranty Card
•1 x User Manual
Unpacking Instructions
Immediately upon receipt, carefully unpack this product and check the container to make sure you
have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (this product and any other accessory
included) appears damaged from shipping, or shows signs of mishandling, notify the carrier
immediately, not CHAUVET®, upon receipt of the damaged merchandise. Failure to do so in
a timely manner may invalidate your claim with the carrier. In addition, retain the container
and all the packing material for inspection.
For other issues such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with CHAUVET® within seven (7) days of receiving the
merchandise.
Manual Conventions
CHAUVET® manuals use the following conventions to differentiate certain types of
information from the regular text.
Convention
Meaning
<Menu>
A key to be pressed on the product’s control panel
1~512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified (for example, showing the
operating mode/current status)
MENU >
Settings
A sequence of menu options to be followed
ON
A value to be entered or selected
Icons
This manual uses the following icons to indicate information that requires special attention
on the part of the user.
Icons
Meaning
Critical installation, configuration or operation information.
Failure to comply with this information may render the product
partially or completely inoperative, cause damage to the
product or cause harm to the user.
Important installation or configuration information. Failure to
comply with this information may prevent the product from
functioning correctly.
Useful non-critical information.

Rev. 7 4 Eclipse™ RGB User Manual
Safety Notes
Please read the following notes carefully because they include important safety
information about the installation, usage, and maintenance of this product.
•Keep this User Manual for future consultation. If you sell this product to another user,
be sure that they also receive this document.
•Always make sure that the voltage of the outlet to which you are connecting this
product is within the range stated on the decal or rear panel of the product.
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
•Make sure there are no flammable materials close to the unit while operating.
•Always install this product in a location with adequate ventilation, at least 20 in (50
cm) from adjacent surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect this product from the power source before cleaning it or replacing
fuse.
•Make sure to replace the fuse with another of the same type and rating.
•If mounting it overhead, always secure this product to a fastening device using a
safety chain.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate this
product at higher temperatures.
•In the event of a serious operating problem, stop using the unit immediately. Never
try to repair the unit. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center.
•Never connect this product to a dimmer pack.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Never carry a product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
•Always avoid direct eye exposure to the light source when this product is on.
•Lasers can be hazardous and have unique safety considerations. Permanent eye
injury and blindness is possible if lasers are used incorrectly. Pay close attention to
each safety statement in this User Manual. Read all instructions carefully BEFORE
operating this device.
Non Interlocked Housing Warning
•This unit contains high power laser devices internally.
•Do not open the laser housing, due to potential exposure to unsafe levels of laser
radiation.
•The laser power levels, accessible if the unit is opened, can cause instant blindness,
skin burns, and fires.
Laser Safety Notes
STOP AND READ ALL THE LASER SAFETY NOTES BELOW
Laser Light is different from any other light sources with which you may be familiar. The light
from this product can potentially cause eye injury if not set up and used properly. Laser light
is thousands of times more concentrated than light from any other kind of light source. This
concentration of light can cause instant eye injuries, primarily by burning the retina (the light
sensitive portion at the back of the eye). Even if you cannot feel “heat” from a laser beam, it
can still potentially injure or blind you or your audience. Even very small amounts of laser light
are potentially hazardous even at long distances. Laser eye injuries can happen quicker than
you can blink.
It is incorrect to think that because these laser entertainment products split the laser into
hundreds of beams that the laser beam is scanned out in high speed, that an individual laser

Eclipse™ RGB User Manual 5 Rev. 7
beam is safe for eye exposure. This laser product uses dozens of milliwatts of laser power
(Class 3B levels internally) before it splits into multiple beams (Class 3R levels). Many of the
individual beams are potentially hazardous to the eyes.
It is also incorrect to assume that because the laser light is moving, it is safe. This is not true.
Nor, do the laser beams always move. Since eye injuries can occur instantly, it is critical to
prevent the possibility of any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This is true even if it is aimed
below people’s faces, such as on a dance floor.
•Do not operate the laser without first reading and understanding all safety and technical
data in this manual.
•Always set up and install all laser effects so that all laser light is at least 3 meters (9.8
feet) above the floor on which people can stand. See “Proper Usage” section later in this
manual.
•After set up, and prior to public use, test laser to ensure proper function. Do not use if
any defect is detected. Do not use if laser emits only one or two laser beams rather than
dozens/hundreds, as this could indicate damage to the diffraction grating optic, and
could allow emission of higher laser levels above Class 3R.
•Do not point lasers at people or animals.
•Never look into the laser aperture or laser beams.
•Do not point lasers in areas in which people can potentially get exposed, such as
uncontrolled balconies, etc.
•Do not point lasers at highly reflective surfaces, such as windows, mirrors and shiny
metal. Even laser reflections can be hazardous.
•Never point a laser at aircraft, this is a federal offense.
•Never point un-terminated laser beams into the sky.
•Do not expose the output optic (aperture) to cleaning chemicals.
•Do not use laser if the laser appears to be emitting only one or two beams.
•Do not use the laser if the housing is damaged, open, or if the optics appear damaged in
any way.
•Never open the laser housing. The high laser power levels inside of the protective
housing can start fires, burn skin and will cause instant eye injury.
•Never leave this device running unattended.
•The operation of a class 3R laser show is only allowed if the show is controlled by a
skilled and well-trained operator, familiar with the data included in this manual.
•The legal requirements for using laser entertainment products vary from country to
country. The user is responsible for the legal requirements at the location/country of use.
•
Always use appropriate lighting safety cables when hanging lights and effects overhead.

Rev. 7 6 Eclipse™ RGB User Manual
Laser Safety Label Reproduction
LASER HAZARD
WARNING LABEL
LASER APERTURE LABEL
EXPLANATORY,
MANUFACTURER’S ID &
CERTIFICATION LABEL
NON INTERLOCKED
HOUSING LABEL

Eclipse™ RGB User Manual 7 Rev. 7
Laser light - Avoid direct eye contact!
Further guidelines and safety programs for safe use of lasers can be found in the ANSI
Z136.1 Standard “For Safe Use of Lasers”, available from the Laser Institute of America:
www.laserinstitute.org. Many local governments, corporations, agencies, military and
others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser Display
guidance can
be obtained via the International Laser Display Association:
www.laserist.org.
Laser Emission Data
Laser Classification Class 3R
Red Laser Medium LD GaAlAs 650nm, typical
Green Laser Medium DPSS Nd:YVO4, 532nm
Beam Diameter <5mm at aperture
Pulse Data All pulses < 4Hz (>0.25sec)
Divergence (each beam) <2 mrad
Divergence (total light) <160 degrees
Laser Power of Each
Beam from Aperture*
<5mW
*As measured under IEC measurement conditions for classification.
Laser Compliance Statement
This laser product complies with EN/IEC 60825-1 Ed 2, 2007-03, and US FDA/CDRH
FLPPS via the terms of Laser Notice No. 50 dated June 24, 2007. This laser device
is classified 3R. (Class 3R is the international equivalent of US Class IIIa). No
maintenance is required to keep this product in compliance with laser performance
standards.
LASER EXPOSURE
WARNING

Rev. 7 8 Eclipse™ RGB User Manual
2.INTRODUCTION
Product Overview
Bracket
adjustment
knob (1 of 2)
LED output
Laser Aperture

Eclipse™ RGB User Manual 9 Rev. 7
Product Dimensions

Rev. 7 10 Eclipse™ RGB User Manual
3.SETUP
AC Power
This product has an auto-ranging power supply that can accommodate a wide range of input
voltages. The only thing necessary to do before powering on the unit is to make sure the line
voltage you are applying is within the range of accepted voltages. This product will accommodate
between 100~240V AC 50/60 Hz. All products must be powered directly off a switched circuit and
cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
Mounting
Orientation This product may be mounted in any safe position, provided there is adequate room for ventilation.
Rigging It is important never to obstruct the fan or vents pathway. Mount the product using, a suitable “C” or
“O” type clamp. Adjust the angle of the product by loosening both knobs and tilting the product.
After finding the desired position, retighten both knobs.
•When selecting installation location, take into consideration access and routine maintenance.
•Safety cables must always be used.
•Never mount in places where the product will be exposed to rain, high humidity, extreme
temperature changes or restricted ventilation.
Proper Usage
This product is for overhead mounting only. For safety purposes, CHAUVET®
recommends mounting your lighting effect products on steady elevated platforms or
sturdy overhead supports using suitable hanging clamps. In all cases, you must use
safety cables. You can obtain appropriate mounting hardware from your lighting
vendor.
International laser safety regulations require that laser products must be operated in
the fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical separation
between the floor and the lowest laser light vertically. Additionally, 3 meters of
horizontal separation is required between laser light and audience or other public
spaces.
CAUTION - USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THA
N THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE

Eclipse™ RGB User Manual 11 Rev. 7
4.OPERATING INSTRUCTIONS
Control
Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display. Please refer to the Product Overview to see the button locations on the control
panel.
Button Function
<MENU> Press to find an operation mode or to back out of the current menu
option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER> Press to activate a menu option or a selected value
Menu Map
Mode
Programming Steps
Description
Automatic
Programs
AuF Automatic Mode, Fast
AuS Automatic Mode, Slow
Sou Sound Active Mode
rdn Random Effect Mode
Sound
Sensitivity S 0 S 0-S 9 Adjust sound sensitivity for Sound Active
Mode
Manual LED
Control LEd
rgb
(r 0-r 9)
(g 0-g 9)
(b 0-b 9)
(Sr0-Sr9)
Manually adjust the LED color and strobe
rate
FdE
(Sp0-Sp9) Manually adjust the LED color fade speed
DMX
Addressing
001 001-509 Set DMX starting address
Slave Mode
SLA
Sets Slave Mode
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting
Address
When selecting a starting DMX address, always consider the number of DMX channels
the selected DMX mode uses. If you choose a starting address that i
s too high, you
could restrict the access to some of the product’s channels.
The Eclipse™ RGB uses up to 12 DMX channels in its 12-channel DMX mode, which
defines the highest configurable address to 500.
If you are not familiar with the DMX protocol, download the DMX Primer f
rom the
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU> repeatedly until 001 shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select the starting address.
4. Press <ENTER>.

Rev. 7 12 Eclipse™ RGB User Manual
DMX Channel Assignments and Values
12-CH
Channel Function Value Setting
1 Auto Mode
000 ó049
DMX Mode
050
ó
099
Automatic Slow
100 ó149
Automatic Fast
150 ó199
Sound Active
200 ó255
Random Effect
2 Color
000 ó004
Blackout
005 ó028
Red
029 ó056
Green
057 ó084
Red + Green
085 ó112
Red off + Green strobe
113 ó140
Red strobe + Green off
141 ó168
Red on + Green strobe
169 ó197
Red strobe + Green on
198 ó224
Red + Green strobe
225 ó255
Red + Green alternating strobe
3 Strobe (laser)
000 ó004
No function
005 ó249
Strobe (slow to fast)
250 ó255
Strobe (sound active)
4 Rotation (laser)
000 ó004
No function
005 ó127
Clockwise rotation (slow to fast)
128 ó133
No function
134 ó255
Counterclockwise rotation (slow to fast)
5 Vibration
000 ó004
No function
005 ó255
Vibration (slow to fast)
6 Flash
000 ó004
No function
005 ó255
Flash (slow to fast)
7 Red
000 ó127
Red
128 ó169
Fade in (0%-100%)
170 ó209
Fade out (100%-0%)
210 ó255
Alternating fade (100%-0%-100%...)
8 Green
000 ó127
Green
128 ó169
Fade in (0%-100%)
170 ó209
Fade out (100%-0%)
210 ó255
Alternating fade (100%-0%-100%...)
9 Blue
000 ó127
Blue
128 ó169
Fade in (0%-100%)
170 ó209
Fade out (100%-0%)
210 ó255
Alternating fade (100%-0%-100%...)
10
Dimmer
000 ó255
0-100%
11 Strobe (LED)
000 ó004
No function
005 ó249
Strobe (slow to fast)
250 ó255
Strobe (sound active)
12 Rotation (LED)
000 ó004
No function
005 ó127
Clockwise rotation (slow to fast)
128 ó133
No function
134 ó255
Counterclockwise rotation (slow to fast)

Eclipse™ RGB User Manual 13 Rev. 7
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (either Static,
Automatic, or Sound) to a DMX string connected to a DMX controller. Products in
standalone mode may transmit DMX signals that could interfere with the DMX
signals from the controller.
Automatic
Mode
To enable the Automatic modes, do the following:
1. Press <MENU> repeatedly until AuF, AuS, Sou, or rdn shows on the display.
2. Press <UP>or <DOWN> to choose AuF (for a fast show), AuS (for a slow show)
or rdn (for a random show).
3. Press <ENTER>.
Sound Active
Mode
To enable the Sound Active mode, do the following:
1. Press <MENU> repeatedly until AuF, AuS, Sou, or rdn shows on the display.
2. Press <UP>or <DOWN> to choose Sou.
3. Press <ENTER>.
4. Turn the music on and adjust the microphone sensitivity knob until the product
starts responding to the beat of the music.
To adjust the sound sensitivity of the Sound Active mode, do the following:
1. Press <MENU> repeatedly until S 0 shows on the display.
2. Press <UP>or <DOWN> to choose between no sound activation and high sound
activation (S 0-S 9).
3. Press <ENTER>.
LED Color
Mixing
You are able to manually mix the colors and strobe rate of the LED portion of the
product. To do so, follow the steps below:
1. Press <MENU> repeatedly until LEd, rGb, or FdE shows on the display.
2. Press <UP>or <DOWN> to choose rGb.
3. Press <ENTER>.
4. Press <UP>or <DOWN> to adjust between full off and on for red (r 0-r 9).
5. Press <ENTER>.
6. Press <UP>or <DOWN> to adjust between full off and on for green (G 0-G 9).
7. Press <ENTER>.
8. Press <UP>or <DOWN> to adjust between full off and on for blue (b 0-b 9).
9. Press <ENTER>.
10. Press <UP>or <DOWN> to adjust the strobe rate (Sr0-Sr9).
11. Press <ENTER>.
LED Color
Fading
You are able to manually adjust the fade speed of the LED portion of the product. To
do so, follow the steps below:
1. Press <MENU> repeatedly until LEd, rGb, or FdE shows on the display.
2. Press <UP>or <DOWN> to choose FdE.
3. Press <ENTER>.
4. Press <UP>or <DOWN> to adjust the fade speed between slow and fast (SP0-
SP9).
5. Press <ENTER>.

Rev. 7 14 Eclipse™ RGB User Manual
Master/Slave
Mode
The Master/Slave mode allows a single Eclipse™ RGB unit (the “master”) to control the
actions of one or more Eclipse™ RGB units (the “slav
es”) without the need of a DMX
controller. The master unit will be set to operate in either Automatic or Sound Active
mode, while the slave units will be set to operate in Slave Mode. Once set and
connected, the slave units will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1. Press <MENU> repeatedly until SLA shows on the display.
2. Press <ENTER> to accept.
3. Set the DMX address to 001.
4. Connect the DMX input of the first slave unit to the DMX output of the master unit.
5. Connect the DMX input of the subsequent slave units to the DMX output of the
previous slave unit.
6. Finish setting and connecting all the slave units.
Master unit:
1. Set the master unit to operate in either Automatic or Sound mode.
2. Make the master unit the first unit in the DMX daisy chain.
•Configure all the slave units before connecting the master unit to the DMX daisy
chain.
•
Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller may interfere with
the signals from the
master unit.
•Do not connect more than 31 slave units to the master unit.
•The lasers cannot be turned off. They can be set to a slow strobe.
•At higher rotation speeds, the operation noise may increase from the
product. This is normal.
General Troubleshooting
Symptom Solution(s)
Applies to
Lights
Foggers
& Snow Controllers
Dimmers
& Chaser
Breaker/Fuse keeps
blowing
Check total load placed on device
ü
Chase is too slow
Check users manual for speed adjustment
ü ü ü
Device has no power
Check for power on Mains.
Check device’s fuse. (internal and/or external)
ü
ü
ü
Loss of signal
Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power cables
or black lights.
üüüü
No laser output
Bounce mirror motor may have shifted during shipping;
readjust
ü
If you still have a problem, please contact CHAUVET® Technical Support.

Eclipse™ RGB User Manual 15 Rev. 7
Technical Specifications
WEIGHT & DIMENSIONS
Length..........................................................................................................................................................................7.7 in (196 mm)
Width............................................................................................................................................................................9.5 in (241 mm)
Height ..........................................................................................................................................................................6.4 in (162 mm)
Weight...........................................................................................................................................................................3.7 lbs (1.7 kg)
POWER
Autoswitching power supply ............................................................................................................................100-240 VAC 50/60 Hz
Fuse................................................................................................................................................................T 1 A 250 V (slow-blow)
Power Consumption ..................................................................................................................................43 W (0.4 A) max @ 120 V
Power Consumption ..................................................................................................................................49 W (0.6 A) max @ 230 V
Power Output........................................................................................................................22 units max @ 120 V, 42 units @ 230V
LIGHT SOURCE
LED.................................................................................................................................................. 8W 700 mA (tri-color) 50,000 hrs
LASER
Green diode................................................................................................................................................................. 532 nm 40 mW
Red diode .................................................................................................................................................................. 650 nm 100 mW
Laser Type..................................................................................................................................................................................DPSS
Cooling............................................................................................................................................................................... Fan Cooled
RANGE
Coverage Angle.............................................................................................................................................................................. 70°
THERMAL
Maximum ambient temperature.....................................................................................................................................104° F (40° C)
ORDERING INFORMATION
Eclipse™ RGB...............................................................................................................................................................ECLIPSERGB
WARRANTY INFORMATION
Warranty .......................................................................................................................................................... 2-year limited warranty

Rev. 7 16 Eclipse™ RGB User Manual
Return Procedure
Call the corresponding CHAUVET® Tech Support office and request a Return Merchandise
Authorization (RMA) number before shipping the product. Be prepared to provide the model
number, serial number, and a brief description of the cause for the return.
You must send the merchandise prepaid, in its original box, and with its original packing and
accessories. CHAUVET® will not issue call tags.
Clearly label the package with the RMA number. CHAUVET® will refuse any product returned
without an RMA number.
DO NOT write the RMA number directly on the box. Instead, write it on a properly affixed
label.
Note: If you are given an RMA #, please include the following information on a piece of
paper inside the box:
1. Your name
2. Your address
3. Your phone number
4. The RMA #
5. A brief description of the symptoms
CHAUVET® reserves the right to use its own discretion to repair or replace product(s).Proper
FedEx packing or double-boxing are recommended.
If you live outside the U.S., United Kingdom, or Ireland, contact your distributor of record
and follow their instructions on how to return CHAUVET® products to them. Visit
www.chauvetlighting.com for contact details.
Contact Us
World Headquarters United Kingdom & Ireland
CHAUVET® CHAUVET® Europe Ltd.
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Email: [email protected]
World Wide Web
www.chauvetlighting.com
World Wide Web
www.chauvetlighting.co.uk
