Chauvet LED Techno Strobe User manual

CHAUVET, 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A
[phone] – [phone]
FAX [phone]
www.chauvetlighting.com
LED Techno Strobe
™
ST-
3000LED
USER MANUAL

LED Techno Strobe™ User Manual 2 Rev. 5
©CHAUVET, 2013, All Rights Reserved
Information and specifications in this User Manual are subject to change without
notice. CHAUVET assumes no responsibility or liability for any errors or
inaccuracies that may appear in this manual.
Table of Contents
1. BEFORE YOU BEGIN............................................................................................................................................................3
WHAT IS INCLUDED............................................................................................................................................................................................. 3
UNPACKING ....................................................................................................................................................................................................... 3
SAFETY NOTES .................................................................................................................................................................................................. 3
2. INTRODUCTION ....................................................................................................................................................................4
FEATURES......................................................................................................................................................................................................... 4
DMXCHANNEL SUMMARY................................................................................................................................................................................... 4
PRODUCT OVERVIEW.......................................................................................................................................................................................... 5
3. SETUP ....................................................................................................................................................................................6
ACPOWER........................................................................................................................................................................................................ 6
MOUNTING......................................................................................................................................................................................................... 6
FIXTURE LINKING................................................................................................................................................................................................ 7
STANDALONE/MASTER-SLAVE FIXTURE LINKING .................................................................................................................................................... 7
4. OPERATING INSTRUCTIONS..............................................................................................................................................8
STANDALONE MODE............................................................................................................................................................................................ 8
Single-Fixture Mode..................................................................................................................................................................................... 8
Master-Slave Mode...................................................................................................................................................................................... 8
Setup..................................................................................................................................................................................................... 8
DIPswitch Options....................................................................................................................................................................................... 8
5. APPENDIX..............................................................................................................................................................................9
RETURNS........................................................................................................................................................................................................... 9
CLAIMS.............................................................................................................................................................................................................. 9
MAINTENANCE.................................................................................................................................................................................................... 9
BINARY ADDRESSING QUICK REFERENCE CHART................................................................................................................................................. 10
DMXCHANNEL VALUES.................................................................................................................................................................................... 11
PHOTOMETRIC.................................................................................................................................................................................................. 11
TECHNICAL SPECIFICATIONS.............................................................................................................................................................................. 12
CONTACT US................................................................................................................................................................................................... 12

Before You Begin
LED Techno Strobe™ User Manual 3 Rev. 5
1. Before You Begin
What is Included
•1 x LED Techno Strobe™ ST-3000LED
•1 x Power cable
•2 x Flush Mount Brackets with screws
•Warranty Card
•User Manual
Unpacking
Immediately upon receiving a product, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned, it is important that the fixture be returned in the original factory box and packing.
Safety Notes
This product is designed for professional use. It is not intended for use in a household
environment. Read this manual before installing or powering the fixture, follow the safety
precautions listed below and observe all warnings in this manual.
•Always disconnect from AC power source before servicing or replacing lamp or fuse and be sure
to replace with same lamp source.
•All Class I fixtures must be connected to circuits with asuitable Earth Ground.
•To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
•Do not operate the fixture if covers are open or if any internal component is missing or damaged:
an unshielded discharge lamp emits dangerous UV radiation that can cause burns and eye
damage.
•Make sure power cord is never crimped or damaged.
•Never disconnect power cord by pulling or tugging on the cord.
•This product is designed to be used with very specific lamp(s). Use of any other type of lamp not
stated in this manual may create a fire hazard due to possible risk of lamp explosion. Using the
wrong type of lamp in this product VOIDS the warranty.
•Always make sure that you are connecting to the proper voltage and that the line voltage you are
connecting to is not higher than that stated on decal or rear panel of the fixture.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Maintain a minimum distance of 1 meter (3.28 feet) from combustible materials.
•Allow this product to cool for a minimum of 15 minutes before opening, handling or removing the
lamp in this product.
•Maximum ambient temperature is Ta: 40°. Do not operate fixture at temperatures higher than
this.
•Avoid direct eye exposure to lamp while it is on.
•Do not operate the fixture if covers are open or if any internal component is missing or damaged.
•Secure fixture to fastening device using a safety chain.
•A hot lamp is an explosion hazard. Do not open fixture for a minimum of 15 minutes after
switching off. Wear eye and hand protection when re-lamping.
•Fixture surface may reach temperatures of up to 160° C (320° F). Handle fixture after it cools.
•In the event of serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center. Always use the same type
spare parts.
Caution! There are no user-serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET®.

Setup
LED Techno Strobe™ User Manual 4 Rev. 5
1
2
3
DMX Channel
(Columns)
Dimmer 000~029
Strobe
Slow ~ Fast
Intensity
100% ~ 0%
Preset Programs
(1 ~ 6)
030~209
Speed
Slow ~ Fast
Sound Mode
225~255
No Function
CONTROL MODES & OPTIONS
(Rows)
For a detailed view of DMX values turn to the Appendix section in this manual. Control mode parameters are
set by DMX values in Channel # 1.
2. Introduction
Features
•3-channel DMX-512 LED white strobe light
•Blackout/static/dimmer/strobe
•Built-in automatic programs
•Adjustable flash rate, dimmer and static via stand-alone
•Automatic built-in programs with sound activation
•Linkable with LED Techno Strobe™ & LED Shadow™ in stand-alone
•Low power consumption
•Additional power output for daisy chaining units together
DMX Channel Summary

Introduction
LED Techno Strobe™ User Manual 5 Rev. 5
DMX Input
DIP-switches
DMX Addressing
IEC Plug for AC Input
& Fuse Compartment
DMX Output
LED Front Panel
Hanging Yoke
Audio Sensitivity
Rotary knob
Red LED: Power Indicator
Blue LED: Signal Indicator
Power Link Out
Flush Mounting Bracket
Product Overview

Setup
LED Techno Strobe™ User Manual 6 Rev. 5
Hanging Clamp
Flush Mounting Bracket
3. Setup
AC Power
Warning! Verify that the power requirement label on your unit matches the line voltage
applied. All fixtures must be connected to circuits with a suitable Earth Ground.
•To determine the power requirements for a particular fixture, see the label affixed to the back plate
of the fixture or refer to the fixture’s specifications chart.
•A fixture’s listed current rating is its average current draw under normal conditions.
•All fixtures must be powered directly off a switched circuit and cannot be run off a rheostat
(variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0 to
100% switch.
•Before applying power to a fixture, check that the source voltage matches the fixture’s
requirement.
•All fixtures must be connected to circuits with a suitable Earth Ground.
Power Cable Configuration
CABLE
Pin
International
Screw Color
BROWN
Live
L
Yellow or Brass
BLUE
Neutral
N
Silver
YELLOW/GREEN
Earth
EG (Ground)
Green
Mounting
Orientation
This fixture can be mounted on a truss using a clamp in any position or against a flat surface using
the brackets provided.
Rigging
The fixture includes a mounting yoke to which 1 rigging clamp can
be bolted and (2) Flush Mount Brackets for flush mounting to flat
surfaces. You must supply your own clamp and make sure the
clamp is capable of supporting the weight of this fixture. You can
order C-clamps from any CHAUVET dealer or distributor.
1. Block access below the work area and use suitable and
stable platform when installing or servicing fixture.
2. Align the clamp screw with the center hole on the yoke
and tighten.
3. Verify the structure can hold 10 times the weight of all to-
be installed fixtures.
4. Adjust the angle on the yoke arm as necessary.
5. Always use a safety cable or chain as a secondary source
of attachment. The safety cable must hold 10 times the
weight of the fixture. If safety cable attachment point is
provided that is permanently affixed to the surface or body
of the fixture, use that instead of looping through a hanging yoke/arm.
Flush Mounting
1. Draw a screw hole template on a large piece of vellum or transparent paper for best
alignment.
2. Place paper against the mounting surface and drill holes or mark the surface for drilling.
3. Hang Panel.

Setup
LED Techno Strobe™ User Manual 7 Rev. 5
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller
or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The
combined number of channels required by all the fixtures on a serial data link determines the number
of fixtures the data link can support.
The ST-3000LED Techno Strobe uses 3 channels of DMX control.
Important: Fixtures on a serial data link must be daisy chained in one single line. To
comply with the EIA-485 standard no more than 32 devices should be
connected on one data link. Connecting more than 32 fixtures on one serial
data link without the use of a DMX optically isolated splitter may result in
deterioration of the digital DMX signal.
Maximum recommended serial data link distance: 500 meters (1640 ft.)
Maximum recommended number of fixtures on a serial data link: 32 fixtures
Standalone/Master-Slave Fixture Linking
1. Connect the (male) 3-pin connector side of the DMX cable to the output (female) 3-pin connector
of the first fixture.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3-pin
connector to the input connector of the next fixture consisting of a (male) 3-pin connector. Then,
proceed to connect from the output as stated above to the input of the following fixture and so on.

Operating Instruction
LED Techno Strobe™ User Manual 8 Rev. 5
1
2
3
4
5
6
7
8
9
10
1 2 4 8
16 32 64
128 256
Option
Sound
Auto
ON
4. Operating Instructions
The ST-3000LED is a DMX-512 controllable, flash LED panel made up of highly efficient and super
bright white LEDs. The ST-3000LED can operate in Stand-Alone, Master/Slave and via DMX-512
control utilizing 3 channels.
Standalone Mode
The ST-3000LED can be operated without a DMX controller
in a standalone mode. It can be operated as a single fixture or together with several other ST-
3000LED fixtures in what is called a “Master/Slave” configuration.
Single-Fixture Mode
The ST-3000 LED Techno Strobe can be set to operate independently of other fixtures or a DMX
controller in either a sound-active or automatic mode. A serial data-link is not necessary for this mode
of operation and it is recommended that no connection to other fixtures be made at all.
1. Simply choose from any one of 10 built-in “DIPswitch Options” from the table below.
Master-Slave Mode
A master-slave mode setup consists of more than one fixture connected in a serial data link without
the use of a controller. In a master-slave operation the slave fixtures will synchronize and will behave
either identically or in a planned chase pattern to the master unit which must be the first in the serial
daisy chain. A Master-Slave ST-3000LED system can consist of an unlimited range of fixtures or at
least the number stated to conform to EIA-485 standards.
Setup
1. The ST-3000LED sets up automatically for Master-Slave, no DIP-switch settings are required
other than for selecting DIP-switch Options.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin
connector to the DMX IN input connector of the Slave fixture consisting of a (male) 3 pin
connector. Continue the loop from DMX OUT to DMX IN.
DIPswitch Options
Functions
Dipswitches ( ON )
Notes & Description
Sound Active
None
Music: Sound Activated, Rotary knob sets sound sensitivity
Flash
1
Flash Speed 1
2
Flash Speed 2
3
Flash Speed 3
4
Flash Speed 4
5
Flash Speed 5
6
Flash Speed 6
7
Flash Speed 7
8
Flash Speed 8
Full On
9
All LEDs full on
Preset Program
10
Preset Programs run in Automatic speed

Appendix
LED Techno Strobe™ User Manual 9 Rev. 5
5.Appendix
Returns
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #).
Products returned without an RMA # will be refused.
Call CHAUVET and request an RMA # prior to shipping the fixture. Be prepared to provide the model
number, serial number and a brief description of the cause for the return.
Once you have received the RMA number, please include the following information on a piece of
paper inside the box:
•Your name
•Your address
•Your phone number
•RMA number
•A brief description of the problem
Be sure to pack the fixture properly. Any shipping damage resulting from inadequate packaging will
be the customer’s responsibility. FedEx packing or double-boxing are recommended.
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within 7 days of receiving merchandise.
Maintenance
To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint. Do not to touch the lamp glass when cleaning fixture. Oil
and dirt can cause damage and premature aging of the lamp. In the event that the lamp is touched or
becomes dirty, clean the lamps with an alcohol wipe.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which thefixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.

Appendix
LED Techno Strobe™ User Manual 10 Rev. 5
Binary Addressing Quick Reference Chart
DMX & Binary Address Quick Reference Chart
DIP-switch Position
DMX DIP-SWITCH SET
#9
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0=OFF
#8
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
1=ON
#7
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
X=OFF or ON
#6
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
#1
#2
#3
#4
#5
0
0
0
0
0
32
64
96
128
160
192
224
256
288
320
352
384
416
448
480
1
0
0
0
0
1
33
65
97
129
161
193
225
257
289
321
353
385
417
449
481
0
1
0
0
0
2
34
66
98
130
162
194
226
258
290
322
354
386
418
450
482
1
1
0
0
0
3
35
67
99
131
163
195
227
259
291
323
355
387
419
451
483
0
0
1
0
0
4
36
68
100
132
164
196
228
260
292
324
356
388
420
452
484
1
0
1
0
0
5
37
69
101
133
165
197
229
261
293
325
357
389
421
453
485
0
1
1
0
0
6
38
70
102
134
166
198
230
262
294
326
358
390
422
454
486
1
1
1
0
0
7
39
71
103
135
167
199
231
263
295
327
359
391
423
455
487
0
0
0
1
0
8
40
72
104
136
168
200
232
264
296
328
360
392
424
456
488
1
0
0
1
0
9
41
73
105
137
169
201
233
265
297
329
361
393
425
457
489
0
1
0
1
0
10
42
74
106
138
170
202
234
266
298
330
362
394
426
458
490
1
1
0
1
0
11
43
75
107
139
171
203
235
267
299
331
363
395
427
459
491
0
0
1
1
0
12
44
76
108
140
172
204
236
268
300
332
364
396
428
460
492
1
0
1
1
0
13
45
77
109
141
173
205
237
269
301
333
365
397
429
461
493
0
1
1
1
0
14
46
78
110
142
174
206
238
270
302
334
366
398
430
462
494
1
1
1
1
0
15
47
79
111
143
175
207
239
271
303
335
367
399
431
463
495
0
0
0
0
1
16
48
80
112
144
176
208
240
272
304
336
368
400
432
464
496
1
0
0
0
1
17
49
81
113
145
177
209
241
273
305
337
369
401
433
465
497
0
1
0
0
1
18
50
82
114
146
178
210
242
274
306
338
370
402
434
466
498
1
1
0
0
1
19
51
83
115
147
179
211
243
275
307
339
371
403
435
467
499
0
0
1
0
1
20
52
84
116
148
180
212
244
276
308
340
372
404
436
468
500
1
0
1
0
1
21
53
85
117
149
181
213
245
277
309
341
373
405
437
469
501
0
1
1
0
1
22
54
86
118
150
182
214
246
278
310
342
374
406
438
470
502
1
1
1
0
1
23
55
87
119
151
183
215
247
279
311
343
375
407
439
471
503
0
0
0
1
1
24
56
88
120
152
184
216
248
280
312
344
376
408
440
472
504
1
0
0
1
1
25
57
89
121
153
185
217
249
281
313
345
377
409
441
473
505
0
1
0
1
1
26
58
90
122
154
186
218
250
282
314
346
378
410
442
474
506
1
1
0
1
1
27
59
91
123
155
187
219
251
283
315
347
379
411
443
475
507
0
0
1
1
1
28
60
92
124
156
188
220
252
284
316
348
380
412
444
476
508
1
0
1
1
1
29
61
93
125
157
189
221
253
285
317
349
381
413
445
477
509
0
1
1
1
1
30
62
94
126
158
190
222
254
286
318
350
382
414
446
478
510
1
1
1
1
1
31
63
95
127
159
191
223
255
287
319
351
383
415
447
479
511
DIP
-switch Position DMX Address

Appendix
LED Techno Strobe™ User Manual 11 Rev. 5
DMX Channel Values
NOTE!
Please read all instructions carefully on fixture DMX control mode and addressing.
DMX channels 2, and 3 functions are determined by the current settings of channel 1. For example,
while Channel 1 is set between 000 and 029 the following conditions will apply;
§Channel 2 will control Strobing from 0% to 100%
§Channel 3 will control Dimming Intensity from 100% to 0%
Channel
Value
Function
Ch 2
Ch 3
1
000 ó029
Dimmer Mode
Strobe
0 ó255
Intensity
100%ó0%
030 ó059
Program 1
Speed
Slow óFast
060 ó089
Program 2
090 ó119
Program 3
120
ó
149
Program 4
150 ó179
Program 5
180
ó
209
Program 6
210 ó255
Sound
No Function
Photometric
20° Beam Angle
163
1800
1
0.304
3
0.914
6 Distance (feet)
1.828 Distance (meters)
87
980
34 Foot Candles
383 LUX
20°

Appendix
LED Techno Strobe™ User Manual 12 Rev. 5
Technical Specifications
WEIGHT & DIMENSIONS
Length.....................................................................................................................................................356 mm (14.0 in)
Width.........................................................................................................................................................248 mm (9.8 in)
Height........................................................................................................................................................165 mm (6.5 in)
Weight......................................................................................................................................................2.2 Kgs (4.9 lbs)
Master Pack...........................................................................................................................(4 pcs) 12.84 Kgs (28.3 lbs)
POWER
Operating Voltage............................................................................................................................90V ~ 240V 50/60 Hz
AC input.....................................................................................................................................................IEC 60320 C14
Current draw............................................................................................(peak <12W @ 120V), (inrush <24W @ 120V)
FUSE
Main .........................................................................................................................................20mm Glass 2A Fast Blow
LED
Quantity...................................................................................................................................................192 Total, (white)
Beam Angle .........................................................................................................................................................21° x 24°
Illuminance.........................................................................................................................................(371 lux) @ 2 meter
CONTROL & PROGRAMMING
Data input.......................................................................................................................... locking 3-pin XLR male socket
Data output ....................................................................................................................locking 3-pin XLR female socket
Data pin configuration .......................................................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols ..................................................................................................................................................DMX-512 USITT
DMX Channels..................................................................................................................................................................3
ORDERING INFORMATION
LED Techno Strobe™ ...................................................................................................................................ST-3000LED
Contact Us
World Wide
General Information CHAUVET® Lighting
5200 NW 108th Avenue
Sunrise, FL 33351
voice: 954.577.4455
fax: [phone]
toll free: 800.762.1084
Technical Support CHAUVET® Lighting
5200 NW 108th Avenue
Sunrise, FL 33351
voice: 954.577.4455 (Press 4)
fax: [phone] (Attention: Service)
World Wide Web www.chauvetlighting.com
