Cherry G80-3700 User manual

Main Applications
Desktop
-Numerical input
-Control systems
-Frequent entry of numbers
Key Features
•Equally suitable for left- and
righthanded users
•Reduced space requirements
•All keys can be user-defined with
up to 24 characters per key
•4additional user-programmable function
keys, can be labeled individually
•Digits can be entered independently of
the status of the Num Lock in the
system (operation on notebook PC)
•Variable decimal separator [.], [,], [00],
or [000]
•External standard keyboard can
be connected
•Matches design of Cherry
G80/81-3000 keyboards
•Reliability: MTBF: 550,000 hours
Main Part Numbers
G80-3700 HQA..(1)
PS/2 male connector, PS/2 female
connector for external keyboard
(1) International Layouts
US Belgian/Swiss
English (US)/English (UK)
DE Germany
DK Danish/Norwegian
ES Spain
FR France
IT Italy
SF Sweden/Finland
Desktop Products
G80-3700
Programmable Keypad
Programmable keypad feature Cherry's
MX switch technology with gold
crosspoints for long life.

Main Part Numbers Technical Data
Power Supply
3.3-5.0 VDC ± 10% SELV
Current Input
typ. 50 mA
Connecting Cable
approx. 1.75 m long
Connection Diagram
Storage Temperature
-20°C to 60°C
Operating Temperature
0°C to 50°C
Weight
approx. 460 g
Dimensions of Housing
108 x 195 x 45 mm
For information on repairs or
warranty status contact:
Cherry Technical Support
Phone: [phone]
E-Mail: [email protected]
Contact
Call, fax or visit our
website for more information.
Last Update: 1/01/07 Cherry Electrical Products
11200 88th Avenue
Pleasant Prairie, WI 53158
Phone: [phone]
Web: www.cherrycorp.com
E-Mail: [email protected]
Fax: [phone]
The manufacturer accepts no
liability for errors or non-availability,
and reserves the right to change
specifications without prior notice.
Technical data relates to product
specifications only. Features may
differ from those described.
Only drawings combined with
product specifications shall be
deemed binding.
