Model 90814
ASSEMBLY AND OPERATING INSTRUCTIONS
CARVING / CHIPPING TOOL
REV 01/04

PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and as-
sembly diagram. Keep your invoice with this manual. Write the invoice number
on the inside of the front cover. Keep this manual and invoice in a safe and dry
place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock,fire,and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
SKU 90814 PAGE 2
Motor 115Volt / 60 Hz
Chuck Round Bit With Lock, 0.39” Capacity
Cord 16AWG /2C SJTwith a 2-prongplug
Overall Dimensions 2.75” x 12.25” x 4”
Weight 4.55 Lbs.
Included Chisel Bits: 2”Chisel, 5/8” Chisel, 1/2”Cold Chisel, Bull Point
Features: 3 Position Switch
REV 01/04 REV 02/04

ELECTRICAL SAFETY
4. Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tools should electrically malfunction or
break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools
or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,
sharp edges, or moving parts. Replace damaged Power Cords immedi-
ately. Damaged Power Cords increase the risk of electric shock.
9. When operating a power tool outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
10. Stay alert. Watch what you are doing, and use common sense when oper-
ating a power tool. Do not use a power tool while tired or under the influ-
ence of drugs, alcohol, or medication. A moment of inattention while operat-
ing power tools may result in serious personal injury.
11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught in moving parts.
SKU 90814 PAGE 3

12. Avoid accidental starting. Be sure theTrigger (7) is not engaged before
plugging in. Carrying power tools with your finger on the Trigger (7), or plugging
in power tools with the Trigger (7) on, invites accidents.
13. Remove adjusting keys or wrenches before turning the power tool on. A
wrench or a key that is left attached to a moving part of the power tool may result
in personal injury.
14. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the power tool in unexpected
situations.
15. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
TOOL USE AND CARE
16. Use clamps (not included) or other practical ways to secure and support
the workpiece to a stable platform. Holding the work by hand or against your
body is unstable and may lead to loss of control.
17. Do not force the tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
18. Do not use the power tool if the Power Switch does not turn it on or off.
Any tool that cannot be controlled with the Power Switch is dangerous and must
be replaced.
19. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the tool. Such preventive
safety measures reduce the risk of starting the tool accidentally.
20. Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
21. Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools with a sharp cutting edge are less likely to bind and are easier
to control. Do not use a damaged tool. Tag damaged tools “Do not use”until
repaired.
22. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool’s operation. If damaged, have
the tool serviced before using. Many accidents are caused by poorly main-
tained tools.
SKU 90814 PAGE 4

23. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool. SERVICE
24. Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
25. When servicing a tool, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Maintain labels and nameplates on the Carving/ChippingTool. These carry
important information. If unreadable or missing, contact Harbor FreightTools for a
replacement.
2. Always wear ANSI approved safety impact eye goggles, ear protection, and
heavy work gloves when using the Carving/ChippingTool. Using personal
safety devices reduce the risk for injury. ANSI approved safety impact eye
goggles, ear protection, and heavy work gloves are available from Harbor Freight
Tools.
3. Maintain a safe working environment. Keep the work area well lit. Make sure
there is adequate surrounding workspace. Always keep the work area free of
obstructions, grease, oil, trash, and other debris. Do not use a power tool in areas
near flammable chemicals, dusts, and vapors. Do not use this product in a damp
or wet location.
4. When using a hand-held power tool, always maintain a firm grip on the tool
with both hands.
5. Always keep the extension cord away from moving parts on the tool.
6. Avoid unintentional starting. Make sure you are prepared to begin work
before turning on the tool.
7. Do not force the tool. This tool will do the work better and safer at the speed
and capacity for which it was designed.
SKU 90814 PAGE 5 REV 01/04

8. Never leave the tool unattended when it is plugged into an electrical outlet.
Turn off the tool and unplug it from its electrical outlet before leaving.
9. Always unplug the tool from its electrical outlet before performing and
inspection, maintenance, or cleaning procedures.
10. Be aware of work surfaces. When chipping on walls, ceilings, or floors, make
sure that electrical wires are not below the surface of the work area. Contacting
an electrical wire can cause severe injury and possibly death.
SKU 90814 PAGE 6
11. WARNING! Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contain chemicals known (to the State of Cali-
fornia) to cause cancer, birth defects or other reproductive harm. Some ex-
amples of these chemicals are: lead from lead-based paints, crystalline silica
from bricks and cement or other masonry products, arsenic and chromium from
chemically treated lumber. Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your exposure to these chemicals:
work in a well ventilated area, and work with approved safety equipment, such as
those dust masks that are specially designed to filter out microscopic particles.
(California Health & Safety Code 25249.5, et seq.)
12. WARNING! People with pacemakers should consult their physician(s)
before using this product. Operation of electrical equipment in close proximity to
a heart pacemaker could cause interference or failure of the pacemaker.

GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric
shock. Check with a qualified electrician if you are in doubt as to whether the
outlet is properly grounded. Do not modify the power cord plug provided with
the tool. Never remove the grounding prong from the plug. Do not use the
tool if the power cord or plug is damaged. If damaged, have it repaired by
a service facility before use. If the plug will not fit the outlet, have a proper
outlet installed by a qualified electrician.
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
1. Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If
the tool should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user, reducing the risk of elec-
tric shock. (See Figure A.)
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure A.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure A.)
FIGURE A
SKU 90814 PAGE 7

FIGURE B
SKU 90814 PAGE 8
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian
Standard Association, and the National Electrical Code. (See Figure B.)
5. Double insulated tools may be used in either of the 120 volt outlets shown in the
following illustration. (See Figure B.)
EXTENSION CORDS
1. Grounded tools require a three wire extension cord. Double Insulated tools
can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible tool damage.
(See Figure C, next page.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure C.)
5. If you are using one extension cord for more than one tool, add the nameplate
amperes and use the sum to determine the required minimum cord size.
(See Figure C.)

6. If you are using an extension cord outdoors, make sure it is marked with the
suffix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
7. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified
electrician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.
SKU 90814 PAGE 9
SYMBOLOGY
Double Insulated
Canadian Standards
Association
Underwriters
Laboratories, Inc.
Volts Alternating Current
Amperes
No Load Revolutions
per Minute (RPM)
noxxxx/min.
A
V ~
RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*
25 FEET 50 FEET 75 FEET 100 FEET 150 FEET
0 - 2.0 18 18 16 16 16
2.1 - 3.4 18 18 16 14 14
3.5 - 5.0 18 18 16 14 12
5.1 - 7.0 18 16 14 12 12
7.1 - 12.0 18 14 12 10 -
12.1 - 16.0 14 12 10 - -
16.1 - 20.0 12 10 - - -
(120 VOLT)
NAMEPLATE
AMPERES
(At Full Load) EXTENSION CORD LENGTH
FIGURE C *Based on limiting the line voltage drop
to five volts at 150% of the rated amperes.

SKU 90814 PAGE 10
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 13
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
ASSEMBLY AND OPERATING INSTRUCTIONS
NOTE: For additional information regarding the parts listed in the following pages, refer to
the Assembly Diagram on page 13.The numbers in parenthesis after parts refer to the
corresponding numbers on the Parts List, also on page 13.
1. CAUTION: Always make sure the Power Cord of the Carving/Chipping Tool is
unplugged from its electrical outlet prior to making any adjustments to the tool.
2. Choose the right bit for your application. The Bull Point/Breaker Bit (9) and the 2”
Chisel (6) are designed for Light Duty use in brick, tile, and similar materials. The
1/2” Cold Chisel (4), 5/8” Chisel (5) and the 2” Chisel (6) are used for wood
applications and making slots. The 1/2” Cold Chisel (4) is used for Light Duty
cutting and dressing metal surfaces.
REV 01/04 REV 02/04

SKU 90814 PAGE 11
ASSEMBLY AND OPERATING INSTRUCTIONS (continued)
Warning!! Always unplug the tool before inserting or removing bits.
3. To remove a bit, press the red Bit Release (2) near the side of the chuck all the
way down and slide the bit out. To insert a bit, press the red Bit Release (2)
insert the bit all the way, release the button and turn the bit until the button clicks
out.
See FIGURE 7.
FIGURE 7
Bit
Bit
Release (2)
Chuck
High Medium Low
Speed Control (3)
FIGURE 8
4. Tug on the bit to make sure it is securely in place. Plug in the tool. Set the Speed
Control (3) to Low, Medium or High Speed by matching up the center line on the
switch to the corresponding line.The longest line (High) refers to the fastest speed.
Do not adjust the speed while the tool is being used.
See FIGURE 8.
Note: Thisunithasacontactsafetyfeature that requires the tip of the tool be pressed onto
the workpiece or theTrigger (7) won’t activate the tool.
5. Grip the unit with both hands. After gently pulling on theTrigger (7), press the chisel
into the workpiece to activate the tool. Do not force the tool. Allow the tool to do the
work.
6. Whenyouare finished,movethebitoff of the workpiece,releasetheTrigger (7),and
unplug the unit.
REV 02/04

SKU 90814 PAGE 12
INSPECTION, MAINTENANCE, AND CLEANING
1. WARNING! Make sure theTrigger (7) of the Carver/Chipping Tool is in its
“OFF” position and that the tool is unplugged from its electrical outlet before
performing any inspection, maintenance, or cleaning procedures.
2. BEFORE EACH USE, inspect the general condition of the Carver/Chipping Tool.
Check for loose screws, misalignment or binding of moving parts, cracked or
broken parts, damaged electrical wiring, and any other condition that may affect
its safe operation. If abnormal noise or vibration occurs, have the problem cor-
rectedbeforefurther use. Do not use damaged equipment.
3. After each use, wipe down the tool with a lint free cloth. Do not immerse the tool
in liquid or use harsh solvents or bleach to clean the tool.
4. Before each use, check to see the Chuck is clear of any dirt or debris.
5. Check that the Power Cord has no frays, tears, or signs of wearing. Do not use
the unit if the Power Cord shows any signs of damage. Have it repaired by an
authorized factory technician.
6. Check the bits before you use the unit. Only use bits that are sharp. Never use
a bit that is dull, cracked, or chipped. Have dull bits sharpened by a qualified
technician. Discard chipped or cracked bits.
REV 01/04

SKU 90814 PAGE 13
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDEDTHE PARTS LIST AND ASSEMBLY
DIAGRAM INTHIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTORMAKES ANYREPRESENTATION ORWARRANTY OFANY KINDTOTHEBUYERTHAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIEDTOREPLACEANY PARTSOFTHEPRODUCT. INFACT,THEMANUFACTURERAND/OR
DISTRIBUTOREXPRESSLY STATESTHATALLREPAIRSANDPARTSREPLACEMENTSSHOULD BE
UNDERTAKENBYCERTIFIEDANDLICENSEDTECHNICIANS,ANDNOTBYTHEBUYER. THEBUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCTORREPLACEMENTPARTSTHERETO,OR ARISINGOUT OFHIS ORHER INSTALLATION
OFREPLACEMENTPARTSTHERETO.
PLEASE READ THE FOLLOWING CAREFULLY
PARTS LIST
NOTE: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts.
ASSEMBLY DIAGRAM
1
2
3
4
5
6
78
9
High MediumLow
See
Inset
Inset
Part No. Description Part No. Description
1 Body 6 2” Chisel
2 BitRelease 7 Trigger
3 SpeedControl 8 Indicator
4 1/2”Cold Chisel 9 Bull Point/Breaker Bit
5 5/8”Chisel
REV 01/04 REV 02/04
