Cincoze DS-1000 Series User manual

CN-TB-QP22-44_V1.0
Superior Performance Fanless Computer
DS-1000(L/P)
Fanless Computing Solution
Superior Performance Fanless Computer
DS-1001(L/P)
Superior Performance Fanless Computer
DS-1002(L/P)

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 2
Contents
Prefaces
Revision …………………………………………………..……………….……….. 05
Copyright Notice …………………………………………………………………… 05
Acknowledgement …..……………………………………………….................... 05
Disclaimer ………………………………………………………………………….. 05
Declaration of Conformity ………………………………………………………… 05
Product Warranty Statement …………………………………………………….. 06
Technical Support and Assistance ………………………………………………. 07
Conventions Used in this Manual ……………………………………………….. 07
Safety Precaution ……...………………………………………………………….. 08
Package Content …..……………………………………………………………… 09
Ordering Information …………………….………………………………………… 10
Optional Accessory …………………………………………………..................... 11
Chapter 1 Product Introductions
1.1 Overview ……………………………………………………………….. 13
1.1.1 Key Feature ……..…………………………………………....... 13
1.2 Hardware Specification …..…………………………………………… 14
1.3 System I/O ……………………………………………………………… 15
1.3.1 DS-1000 …………………………………………………….…… 15
1.3.2 DS-1000(L/P) ……………………………………………….…… 17
1.3.3 DS-1001 …………………………………………………….…… 19
1.3.4 DS-1001(L/P) ……………………………………………….…… 21
1.3.5 DS-1002 …………………………………………………….…… 23
1.3.6 DS-1002(L/P) ……………………………………………….…… 25
1.4 Mechanical Dimension …..……………………………………………. 27
1.4.1 DS-1000 …………………………………………………….…… 27
1.4.2 DS-1000(L/P) ……………………………………………….…… 28
1.4.3 DS-1001 …………………………………………………….…… 29
1.4.4 DS-1001(L/P) ……………………………………………….…… 30
1.4.5 DS-1002 …………………………………………………….…… 31
1.4.6 DS-1002(L/P) ……………………………………………….…… 32
Chapter 2 Jumpers and Connectors
2.1 Jumper Setting …………………………..…………………………..... 34
2.2 Location of the Jumper and Connector ……..…………………….... 34
2.2.1 Top View ………………………………………………………… 34
2.2.2 Bottom View …………………………………………………….. 35
2.2.3 Daughterboard view ……………………………………………. 35
2.3 List of Switch / Jumper / Connector ……..,……………….………..... 36
2.4 Switch Definition …….……………………....................................... 37
2.5 Jumper Definition …………………………....................................... 38
2.6 Connector Definition …………………………................................... 39
Chapter 3 System Setup
3.1 Removing the Chassis Bottom Cover ……...………………………... 57
3.2 Removing the Chassis …………………….…..…….……………….... 58
3.3 Installing the CPU ………………………………………………………. 60
3.4 Installing a Half Size Mini PCIe Card on Top Side .……………….... 63
3.5 Installing a Full Size Mini PCIe Card on Top Side …..…………….... 65
3.6 Installing Antenna .…………………………………..….…………….... 65

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 3
3.7 Installing a SATA Hard Drive on Top Side ……………………………. 69
3.8 Installing a Half Size Mini PCIe Card on Bottom Side …..…….….... 70
3.9 Installing a Full Size Mini PCIe Card on Bottom Side …..………...... 72
3.10 Installing SODIMM ………….……………………..….……………....... 74
3.11 Installing the PCI/PCIe Cards on Expansion Module ……………….. 76
3.12 Installing the Fan for Expansion Module ……………………………… 79
3.13 Installing the Chassis ………….…………..………..….…………….... 80
3.14 Installing the Chassis Bottom Cover …..…………..….…………….... 82
3.15 Installing a SATA Hard Drive on Front Side ….…..….…………….... 82
3.16 Installing a SIM Card ………………………………..…………………. 85
3.17 Installing a CFast Card ………………………………………………… 86
3.18 Installing a CMOS Battery ….………………………………………….. 87
3.19 Fasten the Cover …...……….………………….…..….……………….. 89
3.20 Wall Mount Brackets ..……….………………….…..….…………….... 90
Chapter 4 BIOS Setup
4.1 BIOS Introduction ……..……….………………….…..….…………... 93
4.2 Main Setup ……..……….………………….…..….…………………... 94
4.2.1 System Date ….………………………………………………….. 94
4.2.2 System Time ….………………………………………………….. 94
4.3 Advanced Setup ...……….………………….…..….…..……………... 95
4.3.1 PCI Subsystem Settings ……………………….……………….. 95
4.3.2 ACPI Settings …..…….………………………………………….. 98
4.3.3 CPU Configuration ………………………………………………. 99
4.3.4 SATA Configuration ……………………………………………… 99
4.3.5 AMT Configuration ………………………………………………. 102
4.3.6 USB Configuration ………………………….....………………… 103
4.3.7 Embedded Controller Configuration …………………………… 104
4.3.8 Serial Port Configuration …………………………………………105
4.3.9 PC Health Status ………………………………………………… 109
4.3.10 Serial Port Console Redirection ……………………………….. 109
4.4 Chipset …………………………………………………………………….110
4.4.1 PCH-IO Configuration …………………………………………… 110
4.4.2 System Agent (SA) Configuration ……………………………… 113
4.5 Boot ………………………………………………………………………. 116
4.5.1 Setup Prompt Timeout ………………………………………….. 116
4.5.2 Bootup NumLock State …………………………………………. 116
4.5.3 Quiet Boot ……………………………………………………….. 116
4.5.4 Launch PXE OpROM Policy …………………………………… 116
4.5.5 Boot Option Priorities …………………………………………… 116
4.6 Security …………...……….………………….…..….…..……………... 117
4.6.1 Administrators Password …….………………………………….. 117
4.6.2 User Password …….……………………………………,,………. 117
4.7 Save & Exit …...……….….………………….…..….…..….…………... 118
4.7.1 Save Changes and Exit …………………………………………. 118
4.7.2 Discard Changes and Exit ………………………………………. 118
4.7.3 Save Changes and Reset ……………………………………..... 118
4.7.4 Discard Changes and Reset ……………………………………. 118
4.7.5 Save Changes ……………………………………………………. 118
4.7.6 Discard Changes ………………………………………………….118
4.7.7 Restore Defaults …………………………………………………. 118
4.7.8 Save as User Defaults ……………………………………………118
4.7.9 Restore User Defaults ………………………..…………………. 118

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 4
Chapter 5 Product Application
5.1 Digital I/O (DIO) application..….…………….…….…..….…………... 119
5.1.1 Digital I/O Programming Guide……………………………….... 120
5.2 Digital I/O (DIO) Hardware Specification…………………………….. 125

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 5
Revision
Copyright Notice
© 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified,
or reproduced in any form or by any means for commercial use without the prior written permission of
Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and
remain subject to change without prior notice.
Acknowledgement
Cincoze is a registered trademark of Cincoze Co., Ltd. All registered trademarks and product names
mentioned herein are used for identification purposes only and may be trademarks and/or registered
trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to change
without notice. It does not represent a commitment on the part of Cincoze. This product might include
unintentional technical or typographical errors. Changes are periodically made to the information
herein to correct such errors, and these changes are incorporated into new editions of the publication.
Declaration of Conformity
Prefaces
FCC
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
CE
The product(s) described in this manual complies with all application European Union
(CE) directives if it has a CE marking. For computer systems to remain CE compliant,
only CE-compliant parts may be used. Maintaining CE compliance also requires proper
cable and cabling techniques.
Revision Description Date
1.0 Manual Released 2014/10/07
1.1 New DS models Released 2015/01/12
1.2 DIO PIN Define Revision 2015/04/02
1.3 MINIPCIE1 PIN Define Revision 2015/05/06
1.4 Add 1.2 support dimension of add-on card 2017/06/21
1.50 Correction Made 2018/11/20
1.51 Correction Made 2019/11/21
Prefaces

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 6
Product Warranty Statement
Warranty
Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser.
During the warranty period, we shall, at our option, either repair or replace any product that proves to
be defective under normal operation.
Defects, malfunctions, or failures of the warranted product caused by damage resulting from natural
disasters (such as by lightening, flood, earthquake, etc.), environmental and atmospheric disturbances,
other external forces such as power line disturbances, plugging the board in under power, or incorrect
cabling, and damage caused by misuse, abuse, and unauthorized alteration or repair, and the product
in question is either software, or an expendable item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA
number from us. Our staff is available at any time to provide you with the most friendly and immediate
service.
◼RMA Instruction
⚫Customers must fill in Cincoze Return MerchandiseAuthorization (RMA) Request Form and
obtain a RMA number prior to returning a defective product to Cincoze for service.
⚫Customers must collect all the information about the problems encountered and note anything
abnormal and describe the problems on the “Cincoze Service Form” for the RMA number apply
process.
⚫Charges may be incurred for certain repairs. Cincoze will charge for repairs to products whose
warranty period has expired. Cincoze will also charge for repairs to products if the damage
resulted from acts of God, environmental or atmospheric disturbances, or other external forces
through misuse, abuse, or unauthorized alteration or repair. If charges will be incurred for a
repair, Cincoze lists all charges, and will wait for customer’s approval before performing the
repair.
⚫Customers agree to insure the product or assume the risk of loss or damage during transit, to
prepay shipping charges, and to use the original shipping container or equivalent.
⚫Customers can be send back the faulty products with or without accessories (manuals, cable,
etc.) and any components from the system. If the components were suspected as part of the
problems, please note clearly which components are included. Otherwise, Cincoze is not
responsible for the devices/parts.
⚫Repaired items will be shipped along with a "Repair Report" detailing the findings and actions
taken.
Limitation of Liability
Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether
based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original
selling price of the product. The remedies provided herein are the customer’s sole and exclusive
remedies. In no event shall Cincoze be liable for direct, indirect, special or consequential damages
whether based on contract of any other legal theory.
Prefaces

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 7
Technical Support and Assistance
1. Visit the Cincoze website at www.cincoze.com/support.php where you can find the latest
information about the product.
2. Contact your distributor or our technical support team or sales representative for technical support
if you need additional assistance. Please have following information ready before you call:
⚫Product name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages
Conventions Used in this Manual
Prefaces
This indication alerts operators to an operation that, if not strictly
observed, may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly
observed, may result in safety hazards to personnel or damage to
equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 8
Safety Precautions
Before installing and using this device, please note the following precautions:
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be
easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
8. Use a power cord that has been approved for using with the product and that it matches the
voltage and current marked on the product’s electrical range label. The voltage and current rating
of the cord must be greater than the voltage and current rating marked on the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the power
cord.
10.All cautions and warnings on the equipment should be noted.
11.If the equipment is not used for a long time, disconnect it from the power source to avoid damage
by transient overvoltage.
12.Never pour any liquid into an opening. This may cause fire or electrical shock.
13.Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
⚫The power cord or plug is damaged.
⚫Liquid has penetrated into the equipment.
⚫The equipment has been exposed to moisture.
⚫The equipment does not work well, or you cannot get it to work according to the user's manual.
⚫The equipment has been dropped and damaged.
⚫The equipment has obvious signs of breakage.
14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
Prefaces

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 9
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Item Description Q’ty
1DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Embedded System 1
2 Utility DVD Driver 1
3 DIO Terminal Block Connector (Female) 2
4 Power Terminal Block Connector (Female) 1
5 Remote Power Terminal Block Connector (Female) 2
6 External Fan Terminal Block Connector (Female) 1
7 DVI-I to VGA Adapter 1
8 Screw Pack 1
9 Wall Mount Kit 1
10 Heat Sink Pack 1
Note: Notify your sales representative if any of the above items are missing or damaged.
Prefaces

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 10
Ordering Information
Prefaces
Model No. Product Description
DS-1000 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset
DS-1000L 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset
and 6x LAN
DS-1000P 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
4x PoE and 2x LAN
DS-1001-P 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset
and 1x PCI Expansion
DS-1001-E 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset
and 1x PCIe x16 Expansion
DS-1001L-P 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCI Expansion and 6x LAN
DS-1001L-E 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCIe x16 Expansion and 6x LAN
DS-1001P-P 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCI Expansion, 4x PoE and 2x LAN
DS-1001P-E 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCIe x16 Expansion, 4x PoE and 2x LAN
DS-1002-PP 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset
and 2x PCI Expansion
DS-1002-EE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCIe x1 Expansion and 1x PCIe x16 Expansion
DS-1002-PE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCI Expansion and 1x PCIe x16 Expansion
DS-1002L-PP 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
2x PCI Expansion and 6x LAN
DS-1002L-EE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCIe x1 Expansion, 1x PCIe x16 Expansion and 6x LAN
DS-1002L-PE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCI Expansion, 1x PCIe x16 Expansion and 6x LAN
DS-1002P-PP 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
2x PCI Expansion, 4x PoE and 2x LAN
DS-1002P-EE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCIe x1 Expansion, 1x PCIe x16 Expansion, 4x PoE and 2x LAN
DS-1002P-PE 4th Gen. Intel® Core™ i3/i5/i7 Superior Performance Fanless Computer Integrate Q87 Chipset,
1x PCI Expansion, 1x PCIex16 Expansion, 4x PoE and 2x LAN

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 11
Optional Accessory
Model No. Description
GS120A24-CIN Adapter AC/DC 24V 5A 120W with 3pin Terminal Block Plug 5.0mm
Pitch, GS120A24-P1M
GS220A24-CIN Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug 5.0mm
Pitch, GS220A24-R7B
SL2-SL3 US 2 heads power cord, US B type to IEC C13, SVT 18AWG/3C
Black 1.8M SL-2+SL-3
SL6-SL3 EU 2 heads power cord, EU G type to IEC C13, H05VV-F
0.75mm2/3G Black 1.8M SL-6+SL-3
QP026-SL3 UK 2 heads power cord, UK I type to IEC C13, H05VV-
F 0.75mm2/3G
Black 1.8M QP026+SL-3
59381560000E MINI-DIN(M) (PS/2 KB+MS) TO MINI-DIN(F) (PS/2 KB)+MINI-DIN(F)
(PS/2 MS) L:10CM, 59381560000E
N0307-140507-01 DVI-I(M) TO DVI-D(F) + VGA(F) Cable, L=200mm, N0307-140507-01
Prefaces

Product Introductions
Chapter 1

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 13
1.1.1 Key Features
• Support 4th Gen. Intel® Core™ i3/i5/i7 Desktop Processor (LGA1150) and Intel® Q87 Chipset
•2x DDR3 / DDR3L SO-DIMM Max. up to 16GB
•Three Independent Display from 1x DVI-I and 2x DisplayPort
•2x Intel® GbE Port, Support Wake-on-LAN and PXE (DS-1000, DS-1001, DS-1002 Only)
•6x Intel® GbE Port, Support Wake-on-LAN and PXE (DS-1000L, DS-1001L, DS-1002L Only)
•6x Intel® GbE Port with 4x PoE Function, Support Wake-on-LAN and PXE (DS-1000P, DS-
1001P, DS-1002P Only)
•4x USB 3.0 and 4x USB 2.0
•6x RS232/422/485 Port with 5V/12V Power
•4x Isolated DI, 4x Isolated DO
• 2x 2.5” SATA SSD/HDD Bay, 2x mSATA(1x mSATA Shared by Mini-PCIe Socket) , 1x CFast
Card and 1x SIM Card Socket
•9~48V DC Power Input, SupportAT/ATX Mode
•2x Mini-PCIe Slot for Wi-Fi, GSM, or I/O Expansion
•1x PCI or 1x PCIe x16 Expansion (DS-1001, DS-1001L, DS-1001P Only)
•2x PCI / 1x PCIe x1 and 1x PCIe x16 / 1x PCI and 1x PCIe x16 Expansion (DS-1002, DS-
1002L, DS-1002P Only)
•Power Ignition
•Compliant with EN50155 for Rail TransportationApplications
1.1 Overview
DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) series is a fanless embedded system integrated
with 4th generation Intel® Core™ i3/i5/i7 LGA1150 socket type processor, Intel® Q87 express
chipset, rich I/O, and supports wide range (9~48V) DC power input. The front access designed
provides fast change capability of hard drive, CMOS battery, CFast card and SIM card.
With flexible installation of internal or external fan, mounting kit, and various interface
expansion modules make DS-1000 series a functional system meets versatile requirements
and different usages.
In addition, DS-1000 series is a ruggedized and safety system features completely cable-less
designed, special heat dissipation, anti-vibration, build in voltage protection, reliable DC power
input, reverse power protection, and industrial components selection.
Combining superior performance and innovative mechanical design, DS-1000 series is an ideal
choice for industrial applications.
Chapter 1: Product Introductions
Rear
Front
DS-1002(L/P)
Rear
Front
DS-1001(L/P)
Rear
Front
DS-1000(L/P)

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 14
Processor System
• Support 4th Generation Intel® Core™ i3/i5/i7 LGA 1150
Processor, with AMI 128Mbit SPI BIOS
- Celeron G1820TE, Dual Core, 2.2GHz, 2M Cache
-Core™ i3-4330TE, Dual Core, 2.4GHz, 4M Cache
-Core™ i5-4570TE, Dual Core, 2.7GHz, 4M Cache
-Core™ i7-4770TE, Quad Core, 2.3 GHz, 8M Cache
Chipset
•Intel® Q87 chipset
Memory
•2x 204-Pin DDR3/ DDR3L-1333MHz/ 1600MHz SO-
DIMM (un-buffered and non-ECC), max. up to 16GB
Display
Triple Display
•1x DVI and 2x DisplayPort
•1x VGA (w/ DVI to VGA Adapter) and 2x DisplayPort
•1x VGA (w/ DVI-I Split Cable), 1x DVI-D, and 1x
DisplayPort
Expansion
•DS-1001-E, DS-1001L-E, DS-1001P-E
✓1x PCIe x16
Support maximum dimension of add-on card (H x L):
111.15mm x 235mm
•DS-1001-P, DS-1001L-P, DS-1001P-P
✓1x PCI
Support maximum dimension of add-on card (H x L):
111.15mm x 235mm
•DS-1002-EE, DS-1002L-EE, DS-1002P-EE:
✓1x PCIe x1 and PCIe x16
Support maximum dimension of add-on card (H x L):
111.15mm x 235mm
•DS-1002-PE, DS-1002L-PE, DS-1002P-PE:
✓1x PCI and PCIe x16
Support maximum dimension of add-on card (H x L):
111.15mm x 235mm
•DS-1002-PP, DS-1002L-PP, DS-1002P-PP
✓2x PCI
Support maximum dimension of add-on card (H x L):
111.15mm x 235mm
•2x Full-size Mini PCIe Socket for Wi-Fi / GSM /
Expansion Module
•2x Universal I/O Bracket
•3x Universal I/O Bracket (DS-1002, DS-1002L,
DS-1002P Only)
Ethernet
•1x Intel® 82583V GbE LAN Port, Support Wake-on-LAN
and PXE (DS-1000, DS-1001, DS-1002 Only)
•1x Intel® i217LM GbE LAN Port, Support Wake-on-LAN
and PXE
•5x Intel® 82583V GbE LAN Port, Support Wake-on-LAN
and PXE (DS-1000L/P, DS-1001L/P, DS-1002L/P Only)
•4x 802.3at Compliant PoE Port, The Maximum DC
Power Delivery on Each PoE is 25W@DC 56V Input
(DS-1000P, DS-1001P, DS-1002P Only)
Audio
•Codec: Realtek ALC888S
•1x Mic-in and 1x Speak-out
Watchdog Timer
•Software Programmable Supports 1~255 sec. System
Reset
Storage
• 2x 2.5” SATA HDD Bay (1x External Removable, 1x
Internal)
•2x Internal mSATA Slot (1x Internal mSATA Shared by
Mini-PCIe Socket)
•1x External CFast Socket
•1x External SIM Card Socket
I/O Ports
•4x USB 3.0 Port
•4x USB 2.0 Port
•8x Optical Isolated DIO (4xDI, 4xDO), 10 Pin Terminal
Block Support 9~30V
•6x DB9 for COM1~6, Support RS232/422/485 with Auto
Flow Control
•1x PS/2 Port
•2x Antenna Hole
•1x Power Switch
•1x AT/ATX Switch
•1x External Battery Holder
•1x External Fan Connector
•1x Remote Power Connector
Power
•Support AT, ATX Mode
•1x 3-pin Terminal Block Connector with Power Input
9~48VDC
•1x Optional AC/DC 24V/5A, 120W Power Adapter
•1x Optional AC/DC 24V/9.2A, 220W Power Adapter
(DS-1000P, DS-1001P, DS-1002P Only)
Environment
•Operating Temperature: Ambient with Air Flow: -10°C to
60°C (with Industrial Grade Peripherals)
•Storage Temperature: -20°C to 80°C
•Relative humidity: 10%~95% (non-condensing)
Physical
•DS-1000(L/P)
✓Dimension (WxDxH, mm): 227 x 261 x 86 mm
✓Weight: 4.7 kg
•DS-1001(L/P)
✓Dimension (WxDxH, mm): 227 x 261 x 106 mm
✓Weight: 5.22 kg
•DS-1002(L/P)
✓Dimension (WxDxH, mm): 227 x 261 x 126 mm
✓Weight: 5.7 kg
•Construction: Extruded Aluminum with Heavy Duty Metal
•Mounting: Wall Mounting
Operating System
•Windows® 8
•Windows® Embedded 8 Standard
•Windows® 7
•Windows® Embedded Standard 7
Certifications
•CE
•FCC Class A
•EN 50155
•EN 50121-3-2
Chapter 1: Product Introductions
1.2 Hardware Specification

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 15
Chapter 1: Product Introductions
1.3 System I/O
1.3.1 DS-1000
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
AT/ATX Mode Select Switch
Used to select AT or ATX power mode
Power LED
Indicates the power status of the system
Temperature LED
Indicate the temperature of the system
HDD LED
Indicates the status of the hard drive
Digital I/O LED
Indicates the working status of digital
input/ output
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input
and 4 digital output
COM Port
COM 3 ~ COM 6 supports RS232/422/485 serial
device
Ethernet LED
Indicates the status of the LAN ports
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
DisplayPort
Used to connect the system with display device
CFast, SIM card, CMOS Battery, and 2.5”
Removable HDD Bay
Used to inserts a CFast card, SIM card, CMOS battery,
and 2.5” HDD

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 16
Chapter 1: Product Introductions
Rear Panel
DC IN Terminal Block
Used to plug a DC power input with terminal block
External Fan Terminal Block
Used to plug a external fan with terminal block
DVI-I Port
Used to connect a DVI monitor or connect optional
split cable for dual display mode
PS/2 Port
Used to connect the PS/2 device
LAN Port
Used to connect the system to a local area network
DisplayPort
Used to connect the system with display device
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
Antenna Hole
Used to connect an antenna for optional Mini-PCIe
WiFi module
COM Port
COM 1 ~ COM 2 support RS232/422/485 serial
device
Mic-in
Used to connect a microphone
Speak-out
Used to connect a speaker
Remote Power on/off and Remote Power
Reset Terminal Block
Used to plug a remote power on/off and remote power
reset with terminal block
Universal I/O Bracket
Used to customized I/O output

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 17
Chapter 1: Product Introductions
1.3.2 DS-1000(L/P)
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
AT/ATX Mode Select Switch
Used to select AT or ATX power mode
Power LED
Indicates the power status of the system
Temperature LED
Indicate the temperature of the system
HDD LED
Indicates the status of the hard drive
Digital I/O LED
Indicates the working status of digital
input/ output
Ethernet LED
Indicates the status of the LAN ports
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input
and 4 digital output
COM Port
COM 3 ~ COM 6 supports RS232/422/485 serial
device
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
DisplayPort
Used to connect the system with display device
CFast, SIM card, CMOS Battery, and 2.5”
Removable HDD Bay
Used to inserts a CFast card, SIM card, CMOS battery,
and 2.5” HDD
LAN Port
Used to connect the system to a local area network
PoE Port
Used to connect the system to a local area network
with power over Ethernet (DS-1000P Only)

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 18
Chapter 1: Product Introductions
Rear Panel
DC IN Terminal Block
Used to plug a DC power input with terminal block
External Fan Terminal Block
Used to plug a external fan with terminal block
DVI-I Port
Used to connect a DVI monitor or connect optional
split cable for dual display mode
PS/2 Port
Used to connect the PS/2 device
LAN Port
Used to connect the system to a local area network
DisplayPort
Used to connect the system with display device
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
Antenna Hole
Used to connect an antenna for optional Mini-PCIe
WiFi module
COM Port
COM 1 ~ COM 2 support RS232/422/485 serial
device
Mic-in
Used to connect a microphone
Speak-out
Used to connect a speaker
Remote Power on/off and Remote Power
Reset Terminal Block
Used to plug a remote power on/off and remote power
reset with terminal block
Universal I/O Bracket
Used to customized I/O output

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 19
Chapter 1: Product Introductions
1.3.3 DS-1001
Front Panel
ATX power on/off switch
Press to power-on or power-off the system
AT/ATX Mode Select Switch
Used to select AT or ATX power mode
Power LED
Indicates the power status of the system
Temperature LED
Indicate the temperature of the system
HDD LED
Indicates the status of the hard drive
Digital I/O LED
Indicates the working status of digital
input/ output
Ethernet LED
Indicates the status of the LAN ports
Digital I/O Terminal Block
The Digital I/O terminal block supports 4 digital input
and 4 digital output
COM Port
COM 3 ~ COM 6 supports RS232/422/485 serial
device
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
DisplayPort
Used to connect the system with display device
CFast, SIM card, CMOS Battery, and 2.5”
Removable HDD Bay
Used to inserts a CFast card, SIM card, CMOS battery,
and 2.5” HDD

DS-1000(L/P) / DS-1001(L/P) / DS-1002(L/P) Series
Superior Performance Fanless Computer | User’s Manual
CN-TB-QP22-44_V1.0 20
Chapter 1: Product Introductions
Rear Panel
DC IN Terminal Block
Used to plug a DC power input with terminal block
External Fan Terminal Block
Used to plug a external fan with terminal block
DVI-I Port
Used to connect a DVI monitor or connect optional
split cable for dual display mode
PS/2 Port
Used to connect the PS/2 device
LAN Port
Used to connect the system to a local area network
DisplayPort
Used to connect the system with display device
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
Antenna Hole
Used to connect an antenna for optional Mini-PCIe
WiFi module
COM Port
COM 1 ~ COM 2 support RS232/422/485 serial
device
Mic-in
Used to connect a microphone
Speak-out
Used to connect a speaker
Remote Power on/off and Remote Power
Reset Terminal Block
Used to plug a remote power on/off and remote power
reset with terminal block
Universal I/O Bracket
Used to customized I/O output
Expansion Area
Used to plug PCI or PCIe Card
