INTRODUCTION
Dear Customer,
Thank you for purchasing this product.
This Owner’s Manual will guide you through the setup procedures and outline the key
features. Please keep it handy for future reference.
This product has been designed and manufactured for studio use, and even though we go
to great efforts to ensure the quality of each product, occasional errors, and/or omissions
do occur. In any event, should you find this product to be defective in any way, or to be
missing parts, please contact us.
No.12, 6th Road, Industrial Park,Taichung, Taiwan
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: http://www.circlefitness.com/

M7 –Owner’s Manual
Page4
1. SAFETY
1. 1 Important Safety Notes
IMPORTANT: Please read all instructions and warnings before assembly and operation.
To assure the correct use of the product, basic safety measures should always be
followed including the warnings and cautions listed in this Owner’s Manual.
IMPORTANT: It is essential that this equipment is used only indoors, in a climate
controlled room.
WARNING: Only one person at a time should use this equipment. If dizziness, nausea,
chest pains, or any other abnormal symptoms are experienced while using, then please
stop the workout at once.
WARNING: Always use this equipment on a clear and level surface. Do NOT use outdoors
or near water.
WARNING: Do NOT insert any object into any openings.
WARNING: Do NOT wear loose clothing or jewelry. This equipment contains moving parts.
Do NOT put fingers or other objects into the moving parts.
WARNING: Before using this equipment to exercise, always do stretching exercises first, in
order to properly warm up.
WARNING: It’s recommended to replace defective components immediately and keep the
equipment out of use until repairs have been made by a professional person.
WARNING: This equipment is designed for adults. Close supervision is necessary if the
equipment is used by children or near children. This also applies to disabled persons.
SAFETY SYMBOLS USED IN THIS OWNER’S MANUAL
WARNING
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury to the user or patient or damage to the
equipment or other property.
DANGER
Indicates a high probability that death, severe bodily injury or major
property damage could result.

M7 –Owner’s Manual
Page 5
1. 1 Important Safety Notes (Continued)
WARNING: Please consult your physician before starting a workout or a training program.
Its best to have your doctor review your training and diet programs first so that he can
advise the best workout routine for you.
WARNING: Make sure all bolts and nuts are securely tightened before operating this
equipment. Periodic maintenance is required on all exercise equipment to keep it in good
condition.
WARNING: Incorrect/ excessive training can cause health injuries. Stop using the
equipment when feeling uncomfortable.
WARNING: Turn OFF the power switch when the equipment is not in use.
WARNING: If the power cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid any hazard.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

M7 –Owner’s Manual
Page6
1. 2 Grounding Instructions
This unit must be grounded. If it should malfunction or break down, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock.
This unit is equipped with a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
DANGER! Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are in doubt as
to whether the treadmill is properly grounded. Do NOT modify the plug provided with the
treadmill. If it doesn’t fit the outlet, get a proper outlet installed by a qualified technician.
1.3 Electrical Requirements
Important Voltage Information
Before plugging the power cord into an
electrical outlet, verify that the voltage
requirements for your area match the voltage
of the treadmill that you have received. The
power requirements for the treadmill include
a grounded, dedicated circuit, rated for one
of the following figure.
See the serial number decal for the exact
voltage requirements of your treadmill.
The power requirements for the treadmill include a grounded, dedicated circuit, rated for
one of the following:
1) 115 VAC 5%, 60 Hz, 20 amps
2) 208/220 VAC, 60 Hz, 15 amps
3) 230 VAC 5%, 50 Hz, 15 amps
WARNING: Do NOT attempt to use this unit with a voltage adapter. Do NOT attempt to use
this unit with an extension cord.
115V
NEMA 5-20
EURO PLUG
CEE 7/7
208-220V
NEMA 6-15
Voltage
requirement

M7 –Owner’s Manual
Page 7
1.4 Emergency Stop Key & Emergency Stop Button
Emergency Stop Key
The Emergency Stop Key is to prevent user’s
injuries from falling down due to lack of
familiarity with the speed or usage of the
treadmill. Please always clip the Emergency Stop
Key to prevent or minimize accidents.
The Emergency Stop Key must be attached at
waist level to your clothing before your workout.
(Fig 1.4-1)
Fig 1.4-1
WARNING: Always attach the Emergency Stop Key to your clothing during your workout.
When you use the machine, only remove the Emergency Stop Key in an emergency.
WARNING: When the key is removed while the machine is in operation, it will stop quickly,
which could cause the loss of balance and possible injury.
Emergency Stop Button
This unit is equipped with an Emergency Stop
Button (Fig 1.4-2), it’s allows the user an
additional safety feature in case of emergency.
Upon pushing the button the treadmill will stop.
Fig 1.4-2
Push
Emergency
Stop Key

M7 –Owner’s Manual
Page8
2. ASSEMBLY
2.1 Specifications
Model
M7
M7L
Technical Specifications
Deck
Reversible Deck
Pre-waxed Reversible Deck
Belt
HabasitTM Commercial
Grade
SieglingTM Commercial
Grade
Running Area
1530 x 550 mm/ 60 x 22 in
Speed
0.5 ~ 20 km/ 0.3 ~12.5 MPH
Incline
1-16% (Levels)
Set Up Height
220 mm/ 8.7 in
Roller
90 mm/ 3.5 in
Max. User Weight
182 kgs / 400 lbs
Features
Display Type
6 LED + 8 x 32 Dot-Matrix
Display Feedback
Time, Distance, Heart Rate, Calories, Speed, Incline
Programs
Target, Rolling, Valley, Fat Burn, Ramp, Strength, Interval,
Fitness Test, 4 HRC
USB Data Saving & Charger
Optional
Fan
Optional
Quick Shift
-
Standard
Hand Pulse
Standard
Heart Rate Receiver
Standard
Chest Belt
Optional
Electrical Specifications
Motor (HP)
3.0 HP (Continuous) / 5.0 HP (Treadmill Duty)
Motor Control
AC inverter
Power Requirement
Powered 110Vac/220Vac ±20%, 20A, 50-60Hz
Dimensions
Diameters (L x W x H) (approx.)
2150 x 930 x 1490 mm / 85 x 37 x 59 in
Unit Weight (approx.)
165 kgs / 363 lb

M7 –Owner’s Manual
Page 9
2.2 Machine Overview
Emergency Stop Button & Key
Adjustable Fan Optional)
Handlebar
USB port (Optional)
Motor
Cover
Quick Shift (Optional)
Heart Rate Handlebar
Footpad Cover
Motor Cover
Running Belt
Bottle Holder
Console Mast
Console Set
Power Switch
Power Cord Inlet
Transportation Wheel

M7 –Owner’s Manual
Page10
2.3 Location and Transportation
Location
Place the equipment on a level surface. Do NOT place it in any area that will block any
vents or air openings. This equipment should not be located in a garage, covered patio,
near water or outdoors.
Minimum clearance is 19.7 inches (0.5 meters) on the sides of the unit and 78.7 inches
(2.0 meters) behind the unit. (Fig 2.3-1)
Fig 2.3-1
Transportation
WARNING: Be sure the equipment is unplugged before moving.
To move the equipment, carefully lift the rear end of the treadmill to allow the 2 front
transportation wheels to make contact with the surface (Fig 2.3-2). Carefully steer the
equipment to another location.
Fig 2.3-2
IMPORTANT: Be careful when moving this equipment, as it is heavy and awkward. If you
do not feel comfortable moving the unit by yourself, please get help.
NOTE: The transport wheels are designed for indoor use only and should not be used to
move the unit over rough surfaces such as concrete or asphalt.

M7 –Owner’s Manual
Page 11
2.4 Unpacking
To unpack the treadmill, please the following steps:
1. Carefully remove all staples from the carton.
2. Open the Carton 1 and remove the packing materials to take out the Console. (Fig 2.4-1)
Fig 2.4-1
3. Open the Carton 2 and remove the upper cardboard piece. (Fig 2.4-2)
Fig 2.4-2
3. Remove all parts from the Carton 2 and card board inserts.
4. Set the all the parts down near the spot where you plan to install the equipment.
5. With the help of at least one other person, remove all the packing materials and place
the main body assembly on a level flat surface.
Carton 1
Carton 2

M7 –Owner’s Manual
Page12
2.4 Unpacking (Continued)
Please verify that you have parts as per the list shown below:
NOTE: Make sure that Serial Number on Carton 1 matches that on Carton 2.
Carton 1:
Carton 2:
□
7Hardware Kit & Tools
(Refer to chapter 2.4.1 &
2.4.2)
□
5Right/ Left Console
Handlebar
Carton 1
□
1Console Set
□
2Right/ Left Console Mast
□
3Packing
□
4Right/ Left Console
Mast Cover
□
6Main Body
Carton 2

M7 –Owner’s Manual
Page 13
2.4.1 Hardware Kit
Please verify the hardware kit list as shown below:
STEP 2
STEP 4
(1) M12 x 30 mm Screws (6 PCS)
(2) M12 Lock Washers (6 PCS)
(3) M13 Flat Washers (6 PCS)
(for Console Mast Set)
(1) M8 x 15mm Screws (8 PCS)
(2) M8 Lock Washers (8 PCS)
(3)Curve Washers (8 PCS)
(for Console Mast Set & Main Base)
STEP 5
STEP 6
M15 x15 mm Screws (4PCS)
(for Console Mast Cover)
(1) M8 x 25mm Screws (4PCS)
(2) M8 Flat Washers (4 PCS)
(3) M8 Lock Washers (4 PCS)
(for Console Handlebar)

M7 –Owner’s Manual
Page14
2.4.2 Tools
Please verify the tools list as shown below:
Allen Wrench (5mm)
Allen Wrench (10mm)
T-handle Allen Wrench
Power Cord
Owner’s Manual
End Caps

M7 –Owner’s Manual
Page 15
2.5 Assembly Procedures
STEP 1: Remove the Motor Cover.
Unscrew the (4) Motor Cover Screws #1 with
the provided 5mm Allen Wrench (Fig 2.5-1).
Put the Motor Cover #2 aside. (Fig2.5-1)
Fig 2.5-1
Required Tool
Required Parts/ Hardware Kit
Allen Wrench (5 mm)
N/A
Motor
Cover #2
Motor Cover
Screws #1

M7 –Owner’s Manual
Page16
STEP 2: Attach Console Mast to the Main Body.
1) Thread the Console Wire #1 on the
Guiding Wire #2 and through the Right
Console Mast #3. (Fig2.5-2A)
(The Right Console Mast is with green bag
and R label on the bag.)
NOTE: Please be careful not to pull or
crush the wires.
Fig 2.5-2A
2) Position the Right & Left Console Masts
#3 & #4 on the front corner of the Main
Body. (Fig2.5-2B)
3) Tighten (6) M12x30mm Screws#5 and (6)
S Washers #6 and (6) M13 Washers #7
with 10 mm Allen Wrench. (Fig2.5-2B)
NOTE: Do NOT secure these screws tightly
in this setp.
Fig 2.5-2B
Required Tool
Required Parts/ Hardware Kit
Allen Wrench
(10 mm)
Right/ Left
Console Mast
M12 x 30 mm
Screws
(6 PCS)
M12 Wave
Washers
(6 PCS)
M13 Flat
Washers
(6 PCS)
Right Console
Mast #3
Console Wire #1
Guiding
Wire #2
S Washer
#6
M12x30mm
Screw #5
Right
Console
Mast #3
M13 Washer
#7
Left
Console
Mast #4

M7 –Owner’s Manual
Page 17
STEP 3: Attach the Cover on the Console Mast.
Slide the Left & Right Console Mast Covers
#1 and (2) Packings #2 into two sides of
console mast. (Fig2.5-3)
NOTE: The Right Console Mast Cover is in a
green bag and the Left Console Mast Cover
is in a transparent bag.
Fig 2.5-3
Required Tool
Required Parts/ Hardware Kit
N/A
Packing (2 PCS)
Left & Right Console Mast Covers
Packings #2
Left & Right
Console Mast
Covers #1

M7 –Owner’s Manual
Page18
STEP 4: Attach the Console to the Console Mast.
1). Connect the Console Cable#1 and then
remove the guiding wire from the right
console mast.
2) Place the Console on top of the Console
Mast. Tighten (8) M8x15mm Screws #2,
(8) M8 Lock Washers #3 and (8) Curve
Washers #4 with a 5mm Allen Wrench.
(Fig2.5-4A)
3) Put (4) End Caps #5 into console lower
cover. (Fig2.5-4B)
Fig 2.5-4A
Fig 2.5-4B
4) Tighten (6) M12x30mm Screws on the
lower console mast (mentioned in STEP 2).
(Fig 2.5-4C)
Fig 2.5-4C
Required Tool
Required Parts/ Hardware Kit
Allen Wrench (5 mm)
M8 x 15mm Screws
(8 PCS)
M8 Lock Washers
(8 PCS)
Curve Washers
(8 PCS)
End Cap #5
End Cap #5
Console
Cable#1
End Caps #5
M8x15mm
Screw #2
M8 Lock
Washer #3
Curve
Washers #4

M7 –Owner’s Manual
Page 19
STEP 5: Align and Reinstall Motor Cover.
Reinstall the Motor Cover #1 by securing the
(4) M15 x15 mm Screws #2 with a 5mm
Allen Wrench. (Fig2.5-5)
Fig 2.5-5
Required Tool
Required Parts/ Hardware Kit
Allen Wrench (5 mm)
M15 x15 mm Screws (4PCS)
Motor Cover
#1
M15 x15 mm
Screw #2
