Cisco Unified IP Phone Settings
•Phone Settings Overview, page 1
•Cisco Unified IP Phone Menus, page 1
•Phone Setup Options, page 4
•Network Configuration Menu, page 6
•Device Configuration Menu, page 26
•Security Configuration Menu, page 50
Phone Settings Overview
Cisco Unified IP Phones include many configurable network and device settings that you may need to modify
before the phone is functional for your users. You can access these settings, and change many of them, through
menus on the phone.
Cisco Unified IP Phone Menus
The Cisco Unified IP Phone includes the following configuration menus:
•Network Configuration: Provides options for viewing and making a variety of network settings.
•Device Configuration: Provides access to sub-menus from which you can view a variety of non
network-related settings.
•Security Configuration: Provides options for displaying and modifying security settings.
Before you can change option settings on the Network Configuration menu, you must unlock options for
editing.
You can control whether a phone user has access to phone settings by using the Settings Access field in the
Cisco Unified Communications Manager Administration Phone Configuration window.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
1

Display Settings Menu
To display a configuration menu, perform the following steps.
You can control whether a phone has access to the Settings menu or to options on this menu by using the
Settings Access field in the Cisco Unified Communications Manager Administration Phone Configuration
window. The Settings Access field accepts these values:
Note
•Enabled—Allows access to the Settings menu.
•Disabled—Prevents access to the Settings menu.
•Restricted—Allows access to the User Preferences menu and allows volume changes to be saved.
Prevents access to other options on the Settings menu.
If you cannot access an option on the Settings menu, check the Settings Access field.
Procedure
Step 1 Press Settings to access the Settings menu.
Step 2 Perform one of these actions to display the desired menu:
•Use the Navigation pad to select the desired menu and then press the Select.
•Use the keypad on the phone to enter the number that corresponds to the menu.
Step 3 To display a submenu, repeat Step 2.
Step 4 To exit a menu, press Exit.
Related Topics
Unlock and Lock Options, on page 2
Value Input Guidelines, on page 3
Phone Setup Options, on page 4
Network Configuration Menu, on page 6
Device Configuration Menu, on page 26
Unlock and Lock Options
Configuration options that can be changed from a phone are locked by default to prevent users from making
changes that could affect the operation of a phone. You must unlock these options before you can change
them.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
2
Cisco Unified IP Phone Settings
Display Settings Menu

When options are inaccessible for modification, a locked padlock icon appears on the configuration menus.
When options are unlocked and accessible for modification, an unlocked padlock icon appears on these
menus.
To unlock or lock options, press **#. This action either locks or unlocks the options, depending on the previous
state.
If a Settings Menu password has been provisioned, SIP Phones present an “Enter password”prompt after
you enter **#.
Note
Make sure to lock options after you have made your changes.
Do not press **# to unlock options and then immediately press **# again to lock options. The phone
interprets this sequence as **#**, which resets the phone. To lock options after unlocking them, wait at
least 10 seconds before you press **# again.
Caution
Related Topics
Display Settings Menu, on page 2
Value Input Guidelines, on page 3
Phone Setup Options, on page 4
Network Configuration Menu, on page 6
Device Configuration Menu, on page 26
Value Input Guidelines
When you edit the value of an option setting, follow these guidelines:
•Use the keys on the keypad to enter numbers and letters.
•To enter letters by using the keypad, use a corresponding number key. Press the key one or more times
to display a particular letter. For example, press the 2key once for “a,”twice quickly for “b,”and three
times quickly for “c.”After you pause, the cursor automatically advances to allow you to enter the next
letter.
•To enter a period (for example, in an IP address under IPv4 Configurations), press the .(period) softkey
or press *on the keypad.
•To enter a colon (for example, in an IP address under IPv6 Configurations), press the : (colon) softkey
or press * on the keypad.
•Press the << softkey if you make a mistake. This softkey deletes the character to the left of the cursor.
•Press Cancel before pressing the Save softkey to discard any changes that you have made.
The Cisco Unified IP Phone provides several methods that you can use to reset or restore option settings,
if necessary.
Note
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
3
Cisco Unified IP Phone Settings
Value Input Guidelines

Related Topics
Display Settings Menu, on page 2
Unlock and Lock Options, on page 2
Phone Setup Options, on page 4
Network Configuration Menu, on page 6
Device Configuration Menu, on page 26
Security Configuration Menu, on page 50
Cisco Unified IP Phone Reset or Restore
Phone Setup Options
The settings that you can change on a phone fall into several categories, as shown in the following table. For
a detailed explanation of each setting and instructions for changing them, see Network Configuration Menu,
on page 6.
There are several options on the Network Configuration menu and on the Device Configuration Menu
that are for display only or that you can configure from Cisco Unified Communications Manager. These
options are also described in this chapter.
Note
Table 1: Settings Configurable from the Phone
Network Configuration Menu OptionDescriptionCategory
General Network Settings
Admin. VLAN ID
PC VLAN
Admin. VLAN ID allows you to
change the administrative VLAN
used by the phone. PC VLAN allows
the phone to interoperate with
third-party switches that do not
support a voice VLAN.
VLAN settings
SW Port ConfigurationAllows you to set the speed and
duplex of the network and access
ports.
Port settings
PC Port Configuration
IPv4 Network Settings
DHCPDynamic Host Configuration
Protocol (DHCP) automatically
assigns IP address to devices when
you connect them to the network.
Cisco Unified IP Phones enable
DHCP by default.
DHCP settings
DHCP Address Released
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
4
Cisco Unified IP Phone Settings
Phone Setup Options

Network Configuration Menu OptionDescriptionCategory
Domain NameIf you do not use DHCP in your
network, you can make IP settings
manually.
IP settings
IP Address
Subnet Mask
Default Router 1-5
DNS Server 1-5
Alternate TFTPIf you do not use DHCP to direct the
phone to a TFTP server, you must
manually assign a TFTP server. You
can also assign an alternative TFTP
server to use instead of the one
assigned by DHCP.
TFTP settings for
TFTP IPv4 servers
TFTP Server 1
TFTP Server 2
IPv6 Network Settings
DHCPv6Dynamic Host Configuration
Protocol (DHCP) automatically
assigns IP address to devices when
you connect them to the network.
Cisco Unified IP Phones enable
DHCP by default.
DHCP settings
DHCPv6 Address Released
Domain NameIf you do not use DHCP in your
network, you can make IP settings
manually.
IP settings
IPv6 Address
IPv6 Prefix Length
IPv6 DNS Server 1-2
IPv6 Alternate TFTPIf you do not use DHCP to direct the
phone to a TFTP server, you must
manually assign a TFTP server. You
can also assign an alternative TFTP
server to use instead of the one
assigned by DHCP.
TFTP settings for
TFTP IPv6 servers
(SCCP phones only) IPv6 TFTP Server 1
IPv6 TFTP Server 2
Related Topics
Display Settings Menu, on page 2
Unlock and Lock Options, on page 2
Value Input Guidelines, on page 3
Network Configuration Menu, on page 6
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
5
Cisco Unified IP Phone Settings
Phone Setup Options

Device Configuration Menu, on page 26
Network Configuration Menu
The Network Configuration menu provides options for viewing and making a variety of network settings.
The following tables describe these options and, where applicable, explain how to change them.
For information about how to access the Network Configuration menu, see Display Settings Menu, on page
2.
The phone also has a Network Configuration menu that you access directly from the Settings menu. For
information about the options on that menu, see the table below.
Note
Before you can change an option on this menu, you must unlock options as described in the Unlock and Lock
Options, on page 2. The Edit,Yes, or No softkeys for changing network configuration options appear only
if options are unlocked.
For information about the keys you can use to edit options, see Value Input Guidelines, on page 3.
Table 2: Network Configuration Menu Options
To ChangeDescriptionOption
Set IPv4 Configuration Fields,
on page 16
Internet Protocol v4 address menu.
In the IPv4 Configuration menu, you can do
the following:
•Enable or disable the phone to use the
IPv4 address that is assigned by the
DHCPv4 server.
•Manually set the IPv4 Address, Subnet
Mask, Default Routers, DNSv4 Server,
and Alternate TFTP servers for IPv4.
For more information on the IPv4 address
fields, see the specific field within this table.
IPv4 Configuration
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
6
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set IPv6 Configuration Fields,
on page 17
Internet Protocol v6 address menu.
In the IPv6 Configuration menu, you can do
the following:
•Enable or disable the phone to use the
IPv6 address that is assigned by the
DHCPv6 server or to use the IPv6 address
that it acquires through Stateless Address
Autoconfiguration (SLAAC).
•Manually set the IPv6 Address, Subnet
Prefix Length, DNSv6 Server, and IPv6
TFTP Servers.
For more information on the IPv6 address
fields, see IPv6 Configuration Menu Options.
For more information on SLAAC, see
Deploying IPv6 in Unified Communications
Networks with Cisco Unified Communications
Manager, located at http://www.cisco.com/en/
US/docs/voice_ip_comm/cucm/srnd/ipv6/
ipv6srnd.html.
IPv6 Configuration
Display only—Cannot configure.
Unique Media Access Control (MAC) address
of the phone.
MAC address
Display only—Cannot configure.
Unique host name that the DHCP server
assigned to the phone.
Host Name
Set Domain Name Field, on page
17
Name of the Domain Name System (DNS)
domain in which the phone resides.
If the phone receives different domain
names from the DHCPv4 and
DHCPv6 servers, the domain name
from the DHCPv6 will take
precedence.
Note
Domain Name
The phone obtains its Operational
VLAN ID via Cisco Discovery
Protocol (CDP) from the switch
to which the phone is attached.
To assign a VLAN ID manually,
use the Admin VLAN ID option.
Auxiliary Virtual Local Area Network (VLAN)
configured on a Cisco Catalyst switch in which
the phone is a member.
If the phone has not received an auxiliary
VLAN, this option indicates the Administrative
VLAN.
If neither the auxiliary VLAN nor the
Administrative VLAN are configured, this
option is blank.
Operational VLAN ID
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
7
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set Admin VLAN ID Field, on
page 18
Auxiliary VLAN in which the phone is a
member.
Used only if the phone does not receive an
auxiliary VLAN from the switch; otherwise it
is ignored.
Admin. VLAN ID
Set SW Port Configuration Field,
on page 18
Speed and duplex of the network port. Valid
values:
•autonegotiate
•10 Half—10-BaseT/half duplex
•10 Full—10-BaseT/full duplex
•100 Half—100-BaseT/half duplex
•100 Full—100-BaseT/full duplex
•1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure
the port on the switch to the same speed/duplex
as the phone, or configure both to
auto-negotiate.
If you change the setting of this option, you
must change the PC Port Configuration option
to the same setting.
SW Port Configuration
Set PC Port Configuration Field,
on page 18
Speed and duplex of the access port. Valid
values:
•autonegotiate
•10 Half—10-BaseT/half duplex
•10 Full—10-BaseT/full duplex
•100 Half—100-BaseT/half duplex
•100 Full—100-BaseT/full duplex
•1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure
the port on the switch to the same speed/duplex
as the phone, or configure both to
auto-negotiate.
If you change the setting of this option, you
must change the SW Port Configuration option
to the same setting.
PC Port Configuration
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
8
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set PC VLAN Field, on page 19Allows the phone to interoperate with
third-party switches that do not support a voice
VLAN. The Admin VLAN ID option must be
set before you can change this option.
PC VLAN
Display only—Cannot configure.
Shows the virtual private network (VPN) Client
state:
•Connected
•Not Connected
(Supported only for the Cisco Unified IP Phone
7942G, and 7962G.)
VPN
The following table describes the IPv4 configuration menu options.
Table 3: IPv4 Configuration Menu Options
To ChangeDescriptionOption
Set DHCP Field, on page 19Indicates whether the phone has DHCP
enabled or disabled.
When DHCP is enabled, the DHCP server
assigns the phone anIPv4 address. When
DHCP is disabled, you manually assign
an IPv4 address to the phone.
DHCP
Set IP Address Field, on page 19Internet Protocol version 4 (IPv4) address
of the phone.
If you assign an IPv4 address with this
option, you must also assign a subnet
mask and default router. See Subnet Mask
and Default Router 1 options in this table.
IP Address
Set Subnet Mask Field, on page 20Subnet mask used by the phone.Subnet Mask
Set Default Router Fields, on page 20Default router used by the phone (Default
Router 1) and optional backup routers
(Default Router 2–5).
Default Router 1
Default Router 2
Default Router 3
Default Router 4
Default Router 5
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
9
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set DNS Server Fields, on page 20Primary Domain Name System (DNS)
server (DNS Server 1) and optional
backup DNS servers (DNS Server 2–5)
used by the phone.
DNS Server 1
DNS Server 2
DNS Server 3
DNS Server 4
DNS Server 5
Display only—Cannot configure.
IP address of the Dynamic Host
Configuration Protocol (DHCP) server
from which the phone obtains its IPv4
address.
DHCP Server
Set DHCP Address Released Field, on
page 21
Releases the IPv4 address assigned by
DHCP.
DHCP Address
Released
Set Alternate TFTP Field, on page 21Indicates whether the phone is using an
alternative TFTP server.
Alternate TFTP
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
10
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set TFTP Server 1 Field, on page 21Primary Trivial File Transfer Protocol
(TFTP) server used by the phone. If you
are not using DHCP in your network and
you want to change this server, you must
use the TFTP Server 1 option.
If you set the Alternate TFTP option to
Yes, you must enter a non-zero value for
the TFTP Server 1 option.
If neither the primary TFTP server nor
the backup TFTP server is listed in the
CTL file or ITL file on the phone, you
must unlock the files before you can save
changes to the TFTP Server 1 option. In
this case, the phone will delete the file
when you save changes to the TFTP
Server 1 option. A new CTL or ITL file
is downloaded from the new TFTP Server
1 address.
When the phone looks for its TFTP
server, it gives precedence to manually
assigned TFTP servers, regardless of the
protocol. If your configuration includes
both IPv6 and IPv4 TFTP servers, the
phone prioritizes the order that it looks
for its TFTP server by giving priority to
manually assigned IPv6 TFTP servers and
IPv4 TFTP servers. The phone looks for
its TFTP server in the following order
1Any manually assigned IPv6 TFTP
servers
2Any manually assigned IPv4 TFTP
servers
3DHCPv6 assigned TFTP servers
4DHCP assigned TFTP servers
For information about the CTL
and ITL files, see Cisco Unified
Communications Manager
Security Guide. For information
about unlocking CTL and ITL
files, see Unlock CTL and ITL
Files, on page 52.
Note
TFTP Server 1
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
11
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set TFTP Server 2 Field, on page 22Optional backup TFTP server that the
phone with an IPv4 address uses if the
primary TFTP server is unavailable.
If neither the primary TFTP server nor
the backup TFTP server is listed in the
CTL or ITL files on the phone, you must
unlock the file before you can save
changes to the TFTP Server 2 option. In
this case, the phone will delete the file
when you save changes to the TFTP
Server 2 option. A new CTL file or ITL
file is downloaded from the new TFTP
Server 2 address.
When the phone looks for its TFTP
server, it gives precedence to manually
assigned TFTP servers, regardless of the
protocol. If your configuration includes
both IPv6 and IPv4 TFTP servers, the
phone prioritizes the order that it looks
for its TFTP server by giving priority to
manually assigned IPv6 TFTP servers and
IPv4 TFTP servers. The phone looks for
its TFTP server in the following order:
1Manually assigned IPv6 TFTP servers
2Manually assigned IPv4 TFTP servers
3DHCPv6 assigned TFTP servers
4DHCP assigned TFTP servers
For information about the CTL
and ITL files, see Cisco Unified
Communications Manager
Security Guide. For information
about unlocking CTL and ITL
files, see Unlock CTL and ITL
Files, on page 52.
Note
TFTP Server 2
Display only—Cannot configure.
Indicates whether the phone obtains its
configuration from a Bootstrap Protocol
(BootP) server instead of from a DHCP
server.
BOOTP Server
The following table describes the IPv6 configuration menu options.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
12
Cisco Unified IP Phone Settings
Network Configuration Menu

Table 4: IPv6 Configuration Menu Options
To ChangeDescriptionOption
Set DHCPv6 Field, on page 22Indicates whether the phone has DHCP
enabled or disabled.
When DHCPv6 is enabled, the DHCPv6
server assigns the phone an IPv6 address.
When DHCP v6 is disabled, the
administrator must manually assign an
IPv6 address to the phone.
The DHCPv6 setting along with the Auto
IP Configuration setting determine how
the IP Phone obtains its network settings.
For more information on how these two
settings affect the network settings on the
phone, see DHCPv6 and
Autoconfiguration, on page 25.
DHCPv6
Set IPv6 Address Field, on page 22Internet Protocol version 6 (IPv6) address
of the phone. The IPv6 address is a 128 bit
address.
If you assign an IP address with this option,
you must also assign the IPv6 prefix length
and default router. See IPv6 Subnet Prefix
option in this table.
IPv6 Address
Set IPv6 Prefix Length Field, on page
23
Subnet prefix length that is used by the
phone. The subnet prefix length is a
decimal value from 1-128, that specifies
the portion of the IPv6 address that
comprises the subnet.
IPv6 Prefix Length
Display only—Cannot configure.
Default router used by the phone (Default
Router 1).
The phone obtains information on
the default router from IPv6
Router Advertisements.
Note
IPv6 Default Router 1
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
13
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set IPv6 DNS Server 1 and IPv6 DNS
Server 2 Fields, on page 23
Primary Domain Name System (DNS)
server (DNS Server 1) and optional backup
DNS servers (DNS Server 2) used by the
phone.
If your configuration includes both DNSv6
and DNSv4 servers, the phone will look
for its DNS server in the following order:
1IPv6 DNS Server 1
2IPv6 DNS Server 2
3DNS Server 1-5 for IPv4 (respectively)
IPv6 DNS Server 1
IPv6 DNS Server 2
Set DHCPv6 Address Released Field,
on page 24
Releases the IPv6 address that the phone
has acquired from the DHCPv6 server or
by stateless address autoconfiguration.
This field is only editable when
the DHCPv6 option is enabled.
Note
DHCPv6 Address
Released
Set IPv6 Alternate TFTP Field, on
page 24
Indicates whether the phone is using the
IPv6 Alternate TFTP server.
IPv6 Alternate TFTP
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
14
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set IPv6 TFTP Server 1 Field, on
page 24
Primary IPv6 Trivial File Transfer Protocol
(TFTP) server used by the phone. If you
are not using DHCPv6 in your network and
you want to change this server, you must
use the IPv6 TFTP Server 1 option.
If you set the IPv6 Alternate TFTP option
to Yes or you disable DHCPv6, you must
enter a non-zero value for the IPv6 TFTP
Server 1 option.
If you make changes to the Alternate TFTP
or IPv6 TFTP servers, you must first
unlock the CTL file or ITL file on the
phone.
When the phone looks for its TFTP server,
it gives precedence to manually assigned
TFTP servers, regardless of the protocol.
If your configuration includes both IPv6
and IPv4 TFTP servers, the phone
prioritizes the order that it looks for its
TFTP server by giving priority to manually
assigned IPv6 TFTP servers and IPv4
TFTP servers. The phone looks for its
TFTP server in the following order:
1Manually assigned IPv6 TFTP Servers
2Manually assigned IPv4 TFTP Servers
3DHCPv6 assigned TFTP Servers
4DHCP assigned TFTP Servers
For information about the CTL or ITL file,
see Cisco Unified Communications
Manager Security Guide. For information
about unlocking the CTL file, see Unlock
CTL and ITL Files, on page 52.
IPv6 TFTP Server 1
(SCCP phones only)
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
15
Cisco Unified IP Phone Settings
Network Configuration Menu

To ChangeDescriptionOption
Set IPv6 TFTP Server 2 Field, on
page 25
(Optional) The backup IPv6 TFTP server
that the phone uses if the primary IPv6
TFTP server is unavailable.
Before making changes to the
Alternate TFTP or IPv6 TFTP
servers, you must first unlock the
CTL or ITL file on the phone.
Note
When the phone looks for its TFTP server,
it gives precedence to manually assigned
TFTP servers, regardless of the protocol.
If your configuration includes both IPv6
and IPv4 TFTP servers, the phone
prioritizes the order that it looks for its
TFTP server by giving priority to manually
assigned IPv6 TFTP servers and IPv4
TFTP servers. The phone looks for its
TFTP server in the following order:
1Manually assigned IPv6 TFTP Servers
2Manually assigned IPv4 TFTP Servers
3DHCPv6 assigned TFTP Servers
4DHCP assigned TFTP Servers
For information about the CTL or ITL file,
see Cisco Unified Communications
Manager Security Guide. For information
about unlocking the CTL file, see Unlock
CTL and ITL Files, on page 52.
IPv6 TFTP Server 2
(SCCP phones only)
Set IPv4 Configuration Fields
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to IPv4 Configuration and press the Select softkey.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
16
Cisco Unified IP Phone Settings
Set IPv4 Configuration Fields

Set IPv6 Configuration Fields
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to IPv6 Configuration and press the Select softkey.
Set Domain Name Field
Procedure
Step 1 Unlock network configuration options.
Step 2 To disable DHCP, perform one of the following actions:
•If the IP Addressing mode is configured for IPv4 only, set the DHCP option to No.
•If the IP Addressing mode is configured for IPv6 only, set the DHCPv6 option to No.
•If the IP Addressing mode is configured for both IPv4 and IPv6, set both DHCP option and DHCPv6
to No.
Step 3 Scroll to the Domain Name option.
Step 4 Press Edit.
Step 5 Enter a new domain name.
Step 6 Press Validate.
Step 7 Press Save.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
17
Cisco Unified IP Phone Settings
Set IPv6 Configuration Fields

Set Admin VLAN ID Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to the Admin. VLAN ID option.
Step 3 Press Edit.
Step 4 Enter a new Admin VLAN setting.
Step 5 Press Validate.
Step 6 Press Save.
Set SW Port Configuration Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to the SW Port Configuration option and then press Edit.
Step 3 Scroll to the setting that you want and then press Select.
Step 4 Press Save.
Set PC Port Configuration Field
To configure the setting on multiple phones simultaneously, enable Remote Port Configuration in Enterprise
Phone Configuration (System > Enterprise Phone Configuration).
If the ports are configured for Remote Port Configuration in Cisco Unified Communications Manager,
the data cannot be changed on the phone.
Note
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to the PC Port Configuration option and then press Edit.
Step 3 Scroll to the setting that you want and then press Select.
Step 4 Press Save.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
18
Cisco Unified IP Phone Settings
Set Admin VLAN ID Field

Set PC VLAN Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Make sure the Admin VLAN ID option is set.
Step 3 Scroll to the PC VLAN option.
Step 4 Press Edit.
Step 5 Enter a new PC VLAN setting.
Step 6 Press Validate.
Step 7 Press Save
Set DHCP Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Scroll to the DHCP option and press No to disable DHCP, or press Yes to enable DHCP.
Step 3 Press Save.
Set IP Address Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Set the DHCP option to No.
Step 3 Scroll to the IP Address option, press Edit and enter a new IP Address.
Step 4 Press Validate and Save.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco Unified
Communications Manager 9.0 (SCCP and SIP)
19
Cisco Unified IP Phone Settings
Set PC VLAN Field

Set Subnet Mask Field
Procedure
Step 1 Unlock network configuration options.
Step 2 Set the DHCP option to No.
Step 3 Scroll to the Subnet Mask option, press Edit, and then enter a new subnet mask.
Step 4 Press Validate and then press Save.
Set Default Router Fields
Procedure
Step 1 Unlock network configuration options.
Step 2 Set the DHCP option to No.
Step 3 Scroll to the appropriate Default Router option, press Edit, and then enter a new router IP address.
Step 4 Press Validate.
Step 5 Repeat Steps 3 and 4 as needed to assign backup routers.
Step 6 Press Save.
Set DNS Server Fields
Procedure
Step 1 Unlock network configuration options.
Step 2 Set the DHCP option to No.
Step 3 Scroll to the appropriate DNS Server option, press Edit, and then enter a new DNS server IP address.
Step 4 Press Validate.
Step 5 Repeat Steps 3 and 4 as needed to assign backup DNS servers.
Step 6 Press Save.
Cisco Unified IP Phone 7941G, 7941G-GE, 7942G, 7961G, 7961G-GE, and 7962G Administration Guide for Cisco
Unified Communications Manager 9.0 (SCCP and SIP)
20
Cisco Unified IP Phone Settings
Set Subnet Mask Field
