Citizen Ana-Digi Temp JG2 User manual

CITIZEN QUARTZ
ANA-DIGI TEMP
Model No. JG2-X- •:••!• Cal. 8988
'RUCTION MANUAL
; ,C|-RIEBSANLEITUNG
• MANUEL DESTRUCTIONS
• MANUAL DE INSTRUCCIONES
• MANUALE Dl FUNZIOr*
•MANUALDE INSTRUg,
CTZ-B8024

Please refer to the diagram on the left when reading this instruction manual.
Veuillez
vous reporter au schema de gauche pendant la lecture des explications
de ce mode d'emploi.
Consulte con el diagrama de la izquierda cuando lea este manual de
instrucciones
Bitte beziehen Sie sich bei der Verwendung dieser Anleitung auf das
nebenstenhende Diagramm.
Fare riferimento airillustrazione a sinistra durante la lettura delle istruzioni per
i'uso.
Na leitura deste Manual de instrucao, favor referir-se ao diagrama descrito a
esquerda.
*&mmmn&m&mmm0

Designmay differwithmodel.
Das jeweilige Uhrdesign ist modellabhangig.
Lestylepeutetre different selonlemodele.
Eldisenopuede
variar dependiendo del modelo.
II disegnopuo differire a seconda dei modelli.
Ha variedade de desenhos conforme omodelo.
ratHlUttffifl.

English

CONTENTS
1. Main Features 3
2. Name of Parts and their Functions 4
3. Switching Modes 6
4. Setting Time <TIME> 8
5. Setting Calendar<DATE> 11
6. How to Use Thermometer 13
7. How to Use Alarm <ALM> 16
8. How to Use Dual Time <DU.T> 19
9. How to Use Stopwatch <ST.W> 21
10. Low Battery Warning Function 23
11. All-Reset Function 24
12. Precautions 25
13. Specifications 31

1. Main Features
This is a combination quartz watch with a full range of functions such as Time,
Calendar, Alarm, Stopwatch and Dual Time, plus the temperature measuring
function.

2. Name of Parts and their Functions
Name of Parts
Time
Calendar
®Button ®
Press once
-
Switching temperature
measurement interval
Press for 2 seconds
or more
Switching chime
ON/OFF
-
®Button ®
Press once
Switching
Analog 2 display Switching
Analog 2 display
Press for 2 seconds
or more
ToTime
adjustment mode
To Calendar
adjustment mode
©Button ©
Press once Lamp turns on
<S>
Button (0) Press once To Calendar Mode | To Alarm Mode
©
Analog 1 [A1] Always indicates current time (hours, minutes)
©Analog 2 [A2] Indicates seconds or alarm time as reference display
(D Digital Display
Hours, Minutes,
Seconds, A/P
Date, Day,
Temperature
0
Mode Mark (arrow) TIME
DATE
(D Analog 2identification mark
(A)
Indicates either SEC (seconds), ALM(alarm),
or DU.T (dual time)

When reading from here, please do so while referring to the spread showing an illustration of
the watch at the beginning of this manual.
Alarm Dual Time Stopwatch
Switching ON/OFF
-
Split/Reset
Alarm monitor
--
Switching
Analog 2display Switching
Analog 2 display
Start/Stop
To Alarm
adjustment mode
To Local Time
adjustment mode
-
Lamp turns on
To Dual Time Mode | To Stopwatch Mode | To Time Mode
Always indicates current time (hours, minutes)
or
indicates local time as reference display Hour
Hours, Minutes,
Temperature Memo
Hours, Minutes
Seconds, L Mark
Minutes, Seconds
1/1000 seconds
ALM
DU.T ST.W
Indicates either SEC (Seconds), ALM (Alarm),
or DU.T (Dual time) ST.W
(Stopwatch)

3. Switching Modes
Each press on button <@ switchesthe desired mode.The current mode can be
confirmed by the Mode Mark (arrow).
Each press on button® switchesthe Analog 2 display. The currentdisplaycan
be confirmed by the Analog 2 identificationmark (A).
<Switching Mode: Press Button <§)>
Time Calendar
<DATE>
Alarm
<ALM>
<TIME>
Ji1 ®
Stopwatch
<STW>
Dual Time
<DUT>
* The thermometer measurement is shown in the Calendar mode.

<Switching Analog 2 display: Press Button ®>
Seconds
<SEO
Alarm Time
<ALM>
Local Time
<DU.T>
®*® '
i| ®
Analog 2: Indicates one of these from "Seconds (time)", "AlarmTime" or "Local
Time" as reference display.

4. Setting Time <TIME>
[Normal Time Display]
\ i / ^ ,/ \ i /
Dfl^t * °^
"S
'JO
35
]•
Second
Hour, Minute
Chime ON Mark
<SettingTime>
(1) Press and holdbutton® for2 sec
onds or more while in normal Time
display. The "Seconds" will start
flashing, indicating that the watch
is in adjustment mode.
(2) Each press on button® inadjust
ment mode changes flashing sec
tion in the order of [Second -*
Minute -* Hour-* 12-hour/24-hour
-+ Analog 1 adjustment -+ Analog
2 adjustment].
(3) Press button ®to adjust flashing
section. (Press and holdbutton®
for rapid advancement.)

• Toadjustthe seconds, press button®to return the settingto "00"seconds to
start.
• Each press on button ®switches the watch between 12-hour and 24-hour
system.
• Each press on button® adjusts Analog1 ("Hour" and "Mimute" blinksimulta
neously) in 1/3 minute (20-second intervals) in clockwise direction. Adjust the
Analog 1 indication to
show the same time as the digital indication.
• Each press on button ® adjusts Analog2 ("00" and "Analog2 identification
mark" blink simultaneously) in clockwise direction in 1-division intervals. Set
to the 0-second position (12 o'clock).
(4) Press button <§) to returnto normalTime display.
• The "Second" indication of Analog 2 is interlocked with the "Second" indi
cation of the digital time.
• Make sure that the AM (A)/PM (P) indication is correct when setting the
time in the 12-hour display system.
• Auto-Return to the normal Time display will be activated when the watch
is left in the adjustment mode (flashing display) for more than 2 minutes.
• Instant Manual Return to normal Time display can be made by pressing
button <@) inTime adjustment mode.

<Chime ON/OFF>
Press and hold button ®for2 secondsormore during the normal Time display
to switch chime between ON and OFF. When the Chime is ON, the Chime ON
mark (CHI)is displayed below the mode mark indication.
Chime ON
^
E5E
»i*
Chime OFF
10

5. Setting Calendar <DATE>
In the Calendar mode, the temperature measurement indication is shown in the
digital display.
[Normal Calendar Display]
]
\ i r
«=aa.
u inf 5U
]«
2ML5-
Temperature
Day, Date —'
<Setting Calendar>
(1) Press and holdbutton® for2 sec
onds or more while in normal Cal
endar mode. The "Month" will start
flashing in the lower part of digital
display, indicating that the watch is
in adjustment mode.
(2) Each press on button® inadjust
ment mode changes flashing sec
tion in the order of [Month -* Date
-Year].
(3) Press button ® to adjust flashing
section. (Press and hold button ®
for rapid advancement.)
(4) Press button@ to returnto normal
Calendar display.
11

12
• Inthe Calendar adjustment mode, Analog 2 display always shows the sec
onds.
• Year and month are only indicated during adjustments.
• Year can be set from 1999 through 2099.
• Day of the week is automatically set with adjustment of Year, Month and
Date.
•Auto-Return to normal Calendar display willbe activated when the watch is
left in adjustment mode (flashing display) for more than 2 minutes.
• When Calendar is set to a non-existent date (e.g., February 30), display will
automatically show the first day of next month when returned to normal
display.
•Month-end adjustments including a leap year are not necessary since it is
programmed in the way of full auto calendar.
• Instant Manual Return to normal Calendar display can be made by pressing
button (0) inadjustment mode.

6. How to Use Thermometer
This thermometer can measure the temperature inthe following two ways.
The temperature scale can be switched between Celsius (°C)and Fahrenheit
(T).
Temperature Measurement in the Calendar Mode
When button © is pressed to switch tothe Calendarmode,the temperatureis
always measured whilethe Calendar mode display is shown. Buttonoperation
allows you to change the measuring interval (measurement each minute or each
second).
Alarm Time Temperature Measurement
The temperature is automaticallymeasured and retained as a temperature memo
at the alarm time
set in the Alarm mode. The recorded temperature memo is
indicated in the Alarm mode untilthe temperature is again recorded at the time
of the next alarm or until a new alarm time is set.
13

<Changing the Temperature Measuring lnterval>
Each press on button®inthe Calendar mode switches the measuring interval
between measurement each second or measurement each minute. The "*C" or
"°F mark flashes in the selected measuring interval. However, when measure
ment each second is selected, the measuring interval automatically returns to
measurement each minute after about 3 minutes of measurement each second.
^Temperature Measurement Range and Measurement Accuracy>
14
Celsius ('C) Fahrenheit (*F)
Display temperature range
-9.9°C~+59.9*C
14T-139T
Display unit
0.1 *C
1°F
Measurement accuracy
20'C~30*C:±1#C
-5'C~+40,C:±2,C
68°F~86T:±2T
23'F~104"F:±4T

Precautions for Temperature Measurement*
• When measuring the temperature whilethe watch is worn, the body tempera
ture will affect the measurement. Tomeasure the temperature accurately, take
offthe watch and leave itto be acclimatizedto the temperature environment
to be measured forat least20 to30 minutes. Thetimethatthe watchrequires
to acclimatize to the temperature environment varies withtemperature differ
ences and locations.
• Do not use the watch for measuring temperatures outside the temperature
ranges indicated inthe table on the previous page. Using the watch when the
temperature is extremely high or low may cause damage.
<How to Switch Between the Celsius and Fahrenheit Scales>
Inthe Calendar mode, press button® for3 seconds or more whilebutton ®is
pressed to switch between Celsius and Fahrenheit indication.
(The indicationis not switched ifbutton® is pressed first.)
[Celsius Display] [Fahrenheit Display]
15

7. How to Use Alarm <ALM>
Once this alarm has been set (ON), the alarm will sound for about 20 seconds
every day at the same time. When the alarm is set, the temperature is automati
cally measured at the set alarm time and displayed as a temperature memo.
16
[Normal Alarm Display (ON)]
\-rr
I / I X ^
TOJE-s
k
®
ms-JH-yWm
'5--3D
St3i
]«
Temperature Memo
Set Time
Alarm ON Mark
<Setting Alarm>
(1) Press and holdbutton® in Alarm
mode for 2 seconds or more.
"Hours" starts flashing and be
comes an adjustment mode.
(2) Press button ® to adjust the
"Hour". (Press and holdbutton®
for rapid advancement.)
(3) When button® is pressed while
the "Hour" flashes, the "Minute"
starts flashing.
(4) Press button ®to adjust the
"Minute".
(5) Press button© to returnto nor
mal display.

' In the Alarm adjustment mode, Analog 2 display shows the alarm set time
as reference display.
When the time mode is indicated as a 12-hour system, the alarm time is
also indicated as a12-hour system indication. Pay attention to the AM (A)
and PM (P) indications when setting the alarm.
rAuto-Return to normal Alarm display willbe activated
when the watch is left
in
adjustment mode (flashing display) for more than 2 minutes.
'Instant Manual Return to normal Alarm display can be made by pressing
button (0)inAlarmadjustment mode.
' The recorded temperature memo is indicated until the temperature is again
recorded at the next set time or until a new alarm is set.
17
