Model G25CER
Vapor Management System
(For Medivators CER Endoscope Reprocessor)
Instruction Manual
Manufactured in USA for Medivators Reprocessing Systems by:
CIVCO Medical Solutions
102 First Street South
Kalona, IA 52247 USA
Tel: [phone]
Fax: [phone]
Web : WWW.CIVCO.COM

GUS®Model G25CER Instruction Manual
M0024_D 1 G25CER
Table of Contents
Labels and Symbols................................................................................................2
Environmental Conditions ......................................................................................2
Supply Ratings.........................................................................................................2
Important Information..............................................................................................3
Please Read Before Use..........................................................................................3
Intended Use......................................................................................................................................3
Instruction Manual..............................................................................................................................3
Repair and Modification .....................................................................................................................3
Precautions ........................................................................................................................................4
Disinfectant Solution...........................................................................................................................4
1 Functions...........................................................................................................5
1.1 General Information................................................................................................................5
1.2 Main Power/Ratings Plate ......................................................................................................5
1.3 Specifications and Technical Data for G25CER.....................................................................6
2 Installation and Setup ......................................................................................7
2.1 Upon Delivery.........................................................................................................................7
2.2 Installation...............................................................................................................................7
2.3 Installation – Optional Cart Mounting Plate............................................................................7
3 Operation...........................................................................................................8
3.1 Use..........................................................................................................................................8
3.2 Changing the Filter .................................................................................................................9
3.3 Cleaning the System...............................................................................................................9
4 Troubleshooting Guide ..................................................................................10
Limited Warranty....................................................................................................11

GUS®Model G25CER Instruction Manual
M0024_D 2 G25CER
Labels and Symbols
The meaning of the labels and symbols that appear on the packaging and/or the system are as
follows:
Dangerous electrical voltage
Hazardous area
Protective Grounding
Environmental Conditions
•For indoor use only.
•Altitude up to 2,000 meters.
•Temperature range: 5°C to 40°C.
•Maximum relative humidity: 80% for temperatures up to 31°C, decreasing linearly to 50% relative
humidity at 40°C.
•Main supply voltage fluctuations not to exceed +/- 10% of the nominal voltage.
•Insulation over voltage category II.
•Pollution degree 2.
Supply Ratings
110-120VAC 50/60Hz 0.5A – 2.0A
Fuse: 5x20 3.0A 250v externally mounted

GUS®Model G25CER Instruction Manual
M0024_D 3 G25CER
Important Information
Please Read Before Use
Intended Use
The GUSG25CER is designed to fit over the Medivators CER Endoscope Reprocessor.
Fumes from high-level disinfection solutions are drawn away from the user by a blower and
pass through a carbon filter system, which eliminates the fumes. No external ductwork is
needed.
Do not use the system for any purpose other than its intended use.
Instruction Manual
This instruction manual contains essential information about using the GUSSystem safely
and effectively. Before use, thoroughly review this manual and the manuals of all equipment
that will be used during the procedure. Use all equipment as instructed.
Keep this and all related instruction manuals in a safe, accessible location.
If you have any questions or comments regarding any information in this instruction manual,
please contact CIVCO Medical Solutions.
Repair and Modification
Do not modify or attempt to repair without contacting CIVCO Medical Solutions. Contact
CIVCO Medical Solutions to purchase replacement parts. Equipment damage can result
from user attempts to repair or modify system components.
Before attempting to perform routine maintenance on the system, thoroughly review and
understand this manual for complete familiarization with the system and its operation.

GUS®Model G25CER Instruction Manual
M0024_D 4 G25CER
Precautions
•Refer to instrument manufacturer’s reprocessing instructions.
•If the system is used in a manner not specified in this instruction manual, the protection
it provides may be reduced.
•Allow the system to be operated only by those individuals trained in its proper use.
•The system is designed for indoor use only.
•Patient debris and disinfectants are hazardous. Wear personal protective equipment to
guard against dangerous chemicals and potentially infectious material. During cleaning
and disinfection, wear appropriate personal protective equipment such as eye wear,
face mask, moisture-resistant clothing and chemical-resistant gloves that fit properly
and are long enough so that your skin is not exposed. Always remove contaminated
personal protective equipment before leaving the reprocessing area.
•The system’s carbon filters must be replaced every six months or sooner depending on
use.
•Disconnect the system’s power before removing the top cover plate.
•Do not replace the system’s filters unless all disinfectant has been removed from the
system.
•For additional technical assistance, call CIVCO Medical Solutions at 1-800-445-6741.
Disinfectant Solution
In the United States, only High Level Disinfectants (HLD’s) registered with the Food and
Drug Administration (FDA) as “sterilants/disinfectants,” and used according to the time,
temperature and dilution recommended by the disinfectant manufacturer are to be used for
achieving high-level disinfection. These conditions usually coincide with those
recommended by the disinfectant manufacturer for 100% kill of Mycobacterium tuberculosis.
Contact your instrument manufacturer for names of specific brands of sterilant/disinfectants
that have been tested for compatibility with your automated reprocessing system.

GUS®Model G25CER Instruction Manual
M0024_D 5 G25CER
1 Functions
1.1 General Information
The GUSVapor Management System eliminates fumes from high-level disinfectants. The blower
system pulls fumes into a patented carbon filter, where they are adsorbed and eliminated. Clean
air is returned to the room through the top louver panel.
The GUSVapor Management System is designed to remove fumes from:
•Rapicide
•Cidex and other glutaraldehyde based disinfectants
•Ortho-phthalaldehyde (OPA)
Warning: Failure to properly follow the instructions in this manual may result in
damage to the system and/or scopes.
1.2 Main Power/Ratings Plate
The main power switch is located on the inside front panel of the system. (See figure 2). The
switch is illuminated when the system is ON. The power cord plugs into a regular wall outlet. The
fuse is a type 5x20 3.0A 250v externally mounted.
Figure 1: GUS

Model G25CER
Figure 2: Main Power Switch
Main Power
On/Off Switch

GUS®Model G25CER Instruction Manual
M0024_D 6 G25CER
1.3 Specifications and Technical Data for G25CER
The ratings plate and serial number are located on the right side of the system.
Airflow:
Air treated (CFM)..........................................................................................210
Avg. Face Velocity (FPM) with door closed.................................................120
Avg. Face Velocity (FPM) with door open.....................................................78
Electrical:
Voltage ............................................................................110-120VAC 50/60hz
Current-Running with door closed........................................................ 40 watts
Current-Running with door open...........................................................75 watts
Filters:
Carbon Filter............................................................................. activated carbon
Fan/Blower:.................................................................... Automatic, two-speed
Construction:
Vapor Control Unit.................................................. powder coated carbon steel
Doors...............................................................................................clear acrylic
Side Panels and Baffle.............................................................................. HPDE
Dimensions:
Outside..............................................................32.875”H x 26.5”W x 24.0”D *
Inside......................................................................26.5” H x 25.5”W x 23.5”D
Space requirements: 36” Above countertop.
30” Overall width.
24” Countertop depth.

GUS®Model G25CER Instruction Manual
M0024_D 7 G25CER
2 Installation and Setup
2.1 Upon Delivery
Inspect the G25CER for damage. If any components are damaged or missing, or if you have any
questions, call CIVCO Medical Solutions at 1-800-445-6741. Do not use the system.
2.2 Installation
NOTE: Two people are needed to lift the G25CER
1. Remove the GUSG25CER from the shipping box by gently lifting up by the two side straps.
2. Place the unit over your Automated Reprocessing System. There must be a minimum
clearance of 1” above the unit.
3. In most cases the water and drain line for the Medivators CER Reprocessor will be located
directly behind the unit. In the event that the drain and/or the water line are located to the
side of the CER Reprocessor, drill properly sized holes using a hole saw in the side panel(s)
where necessary to connect the water and drain hoses.
4. Plug the system into a standard wall outlet.
5. Turn the system ON (see Figure 2 on page 6).
6. Open the door to check that blower switches to high speed. When the door is closed, the
blower should switch back to low speed.
7. Remove the protective covering from the acrylic doors.
2.3 Installation – Optional Cart Mounting Plate
1 Prior to removing the Medivators CER Reprocessor from the cart you must:
a) Disconnect the power from the wall and the CER Reprocessor.
b) Shut off water supply and disconnect water line from the wall. Warning: this line contains
water, drain line into a container. Leave the water line connected to the CER
Reprocessor.
c) Disconnect the three ‘solution’ lines from the back of the CER Reprocessor; leave other
ends connected to the tanks.
d) The drain line can be left installed on the back of the CER Reprocessor.
2 Remove the CER Reprocessor from the cart.
3 Place Cart Adaptor Plate on top surface of the CER cart.
4 Line up rear hose cut outs on the cart with the Cart Adaptor Plate.
5 Locate the four holes on the left and right of the Cart Adaptor Plate base.
6 Drill a 3/16 hole through the top of the cart using one of the holes as a guide.

GUS®Model G25CER Instruction Manual
M0024_D 8 G25CER
7 Place an 8-32 X 5/8 screw (supplied) through the hole and tighten with nut supplied.
8 Making sure hose cutouts are still aligned, drill three remaining holes to locate the cart top.
Secure with 8-32 x 5/8 screws and nuts.
9 Place the CER Reprocessor on the base plate. Pass the three solution lines through the hole
in the base plate and connect to the back of the CER.
10 Drill properly sized holes using a hole saw, in the side panel(s) where necessary to connect
the water and drain hoses.
11 Using two people to lift the G25CER unit by its two straps and place the unit over your
Automated Reprocessing System.
12 Adjust position of CER Reprocessor to allow cover to open adequately and the G25CER
vapor management unit’s doors to fully close.
13 Reconnect water line and plug the CER Reprocessor. and the G25CER into a regular outlet
14 Turn the G25CER on (see Figure 2 on page 6).
15 Open the door to check that blower switches to high speed. When the door is closed, the
blower should switch back to low speed.
16 Remove the protective covering from the acrylic doors.
3 Operation
3.1 Use
1. You must leave the GUSVapor Management System running whenever the automated
reprocessing system is in use.
2. With the vapor management system running, open the front acrylic door to access your
automated reprocessing system.
3. Be sure the blower system switches to high speed when the door is open.
4. Refer to the instruction manual for your automated reprocessing system for proper use.

GUS®Model G25CER Instruction Manual
M0024_D 9 G25CER
3.2 Changing the Filter
CAUTION When changing filter you must wear personal protective equipment – such as
eyewear, facemask, moisture-resistant clothing and chemical-resistant gloves.
NOTE: Contact Medivators Reprocessing Systems to order replacement filters.
1. Turn the main power switch OFF and disconnect the power cord from the electrical outlet.
2. Remove the top louver panel by unscrewing counterclockwise.
3. Remove the old filter by pulling up. Replace with new filter.
4. Put the used filter into a plastic bag and dispose of with other non-hazardous waste.
5. Replace top louver plate.
The GUSVapor Management System has a patented carbon filter that must be changed every
six months or sooner depending on use. There are no individual pre-filters to be changed.
3.3 Cleaning the System
Acrylic doors: Use only an all purpose glass cleaner. Do not use solvents or alcohol on the
acrylic.
Powder coated metal: Use mild detergent solution such as dish washing liquid and water.
Hard to clean spots may be cleaned with a mild solvent if extra care is taken.

GUS®Model G25CER Instruction Manual
M0024_D 10 G25CER
4 Troubleshooting Guide
If the GUSVapor Management System is not running, check the following:
1. Ensure that the unit is plugged into a live wall outlet.
2. Make sure the green On/Off switch is on. The switch will be illuminated when on.
3. Push the black ‘test’ button on the GFCI, located next to the On/Off switch. Then push the
red ‘reset’ button. This should restart the system and the green On/Off switch should now
be illuminated.
4. In the event that the system is still not working, you will need to check the fuse, which is
internally mounted.
5. Disconnect the plug from the wall outlet and remove the top louver panel and filter to
examine fuse. If damaged, replace with a standard 5x20 3.0Amp fuse.
6. If the System is still not working, call CIVCO Medical Solutions at 1-800-445-6741.
If you can still smell fumes from your high-level disinfectant while using the GUSVapor Management
System, check the following:
1. The system is being left on at all times while the reprocessor is in use.
2. Filters have been changed as recommended (every six months or sooner depending on
use).
3. Spills outside of the system are immediately neutralized and cleaned up.
4. No other disinfectants are being used in the room, including inside another Automated
Reprocessing System.
5. All personnel using the system have been fully trained on its use.
6. Verify that the system switches to the high-speed setting when you open the front acrylic
door.
If you need assistance, call CIVCO Medical Solutions at 1-800-445-6741.

GUS®Model G25CER Instruction Manual
M0024_D 11 G25CER
Limited Warranty
Please complete and return the attached warranty card to CIVCO Medical Solutions.
CIVCO Medical Solutions warrants the GUSVapor Control System to be free of defects in materials
and workmanship under normal use, for a period of one year from the date of delivery. This warranty
does not include filters, acrylic, or disposal pump unless it can be determined that failure is due to
defects in material or workmanship. The warranty covers the soak/rinse tubes and cups for up to one
month.
If the system is not working correctly or is defective, contact CIVCO Medical Solutions, and we will
repair or replace the unit at our option during the warranty period.
CIVCO Medical Solutions assumes no liability for consequential damages of any kind as a result of
the use or misuse of the system by the purchaser, the purchaser’s employees, or any others.
This warranty is expressly in lieu of all other warranties, guarantees, obligations or other liabilities
expressed or implied.
What is not covered by this warranty:
Conditions and damages resulting from any of the following:
•Improper installation, delivery within the facility, or maintenance.
•Any repair, modification, alteration or adjustment not authorized by the manufacturer.
•Misuse, abuse, accidents or unreasonable use.
•Incorrect electric current, voltage or supply.
•Failure to follow proper procedures for use outlined in this manual.
•Consequential or incidental damages sustained by any person as a result of any breach of
this warranty.
Some states do not allow the exclusion or limitation of consequential or incidental damages, so the
above exclusion may not apply.
