Clarke DEVIL 350B 230V Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC1218 - ISS 1
CERAMIC HEATER
MODEL NO: DEVIL 350B 230V/110V
PART NO: 6920330 & 6920332

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Ceramic Heater.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
SPECIFICATIONS
Please note that the details and specifications contained herein, are correct
at the time of going to print. However, CLARKE International reserve the right
to change specifications at any time without prior notice.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
Model Number Devil 350B 230V Devil 350B110V
Part Number 6920330 6920332
Weight 7.4 kg 7.7 kg
Dimensions (L x W x H) 385 x 395 x 580mm
Rated input Current 10.5A 22A
Supply Voltage 230V/50 Hz 110V/50 Hz
Fuse Rating 13A N/A
Insulation Class IP20
Max Heat Output 2400W (1200 per element)

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
Please keep these instructions in a safe place for future reference.
1. These heaters are for INDOOR USE ONLY in well insulated spaces.
2. Do not expose the heater or power cable to rain or wet conditions. Any
water entering the heater will increase the risk of electric shock. DO NOT
use this heater in a bathroom, shower room or any other wet environment.
3. NEVER locate the heater near combustible materials such as curtains,
furniture etc. Allow at least 1 metre distance.
4. DO NOT locate the heater close to an adjacent wall or low ceiling. Allow a
distance of at least 1 metre from a wall or ceiling. Avoid placing the heater
directly below power socket outlets.
5. Take care to ensure that the wire guard cannot be covered.
6. Do not operate heater in explosive atmospheres such as in the presence of
flammable liquids, gases or dust such as in a paint spray booth or any
explosive environment.
7. Never stand the heater on a movable vehicle where it could tip over.
8. Do not allow the heating elements to become covered with dust which
could become a fire hazard. If used in a dusty workplace it should be
cleaned as described under Cleaning and Maintenance.
9. NEVER touch the heating elements for at least 15 minutes after switching
off.
10. DO NOT leave the heater unattended.
11. If children are present always use with a fireguard.
12. Store the heater out of the reach of children and do not allow persons
unfamiliar with these instructions to operate it.
13. This heater must only be located on a firm, level surface but is fitted with an
anti-tilt switch which will turn the unit off if it should tip over.
14. Always disconnect the heater from the power supply before moving it.
15. Never leave the heater unattended while in use. Turn off at night if
unattended.
ELECTRICAL SAFETY
1. Electrical appliances must match the power outlet. Never modify the plug
in any way. Do not use adaptor plugs with earthed (grounded) appliances.
Correct plugs and outlets will reduce the risk of electric shock.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
2. Do not abuse the electrical cable. Never use the cable for pulling or
unplugging the heater. Keep the cable away from sources of heat, oil,
sharp edges or moving parts. Damaged or tangled cables increase the risk
of electric shock.
3. Do not use this product with an extension cable.
4. ALWAYS disconnect from the power supply before moving the heater or
performing any cleaning or maintenance tasks.
5. Keep the power cable well away from machines and ensure an adequate
electrical supply is close at hand so that the operation is not restricted by
the length of the cable.
6. Inspect the power cable regularly for signs of damage. DO NOT use if it is
damaged and ALWAYS keep it away from the source of heat.
7. Check the heater for damage before use. Any damage should be
properly repaired or the part replaced. If in doubt, DO NOT use. Consult
your local Clarke dealer.
SERVICE & REPAIRS
1. If necessary, have your heater repaired by a qualified person using
identical replacement parts. This will ensure that the safety of the
appliance is maintained.
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECTRICAL CONNECTIONS
DEVIL 350B (230V) UNITS
The 230v model is provided with a 13 amp BS 1363 plug, fitted with a 13amp
fuse and MUST be connected to a standard, 230 Volt (50Hz) electrical supply,
preferably through a suitably fused isolator switch.
If the plug has to be changed because it is not suitable for your socket or
because of damage, it must be removed and a replacement fitted, following
the wiring instructions shown below. The old plug must be discarded safely as
insertion into a power socket could cause an electrical hazard.
The wires in the mains lead should be
wired up in accordance with the
following colour code:
• Connect the GREEN & YELLOW
wire to the plug terminal
marked with a letter E or
• Connect the BROWN wire to the
plug terminal marked a letter
“L”.
• Connect the BLUE wire to the
plug terminal marked a letter “N”.
The fuse in the plug must be replaced with one of the same rating and this
replacement must be ASTA approved to BS1362.
We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD).
DEVIL 350B (110V) UNITS
The 110V model is fitted with a 32 amp, three pin industrial plug to EN 60309
and MUST be connected to a 110 volt, 1 phase 50 Hz supply through a suitably
WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY
BEFORE CONNECTING THE PRODUCT TO THE POWER SUPPLY.
WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
BLUE = NEUTRAL BROWN = LIVE YELLOW AND GREEN = EARTH.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
fused isolator switch. On no account must a 230V, 13 amp (BS1363) plug be
used.
NOTE: If a portable 110V transformer is used, make sure it has a rated
capacity sufficient to take the load of the heater.
If the heater is hard wired into the electrical system, all work must be carried
out in accordance with IEE regulations.
If in any doubt, consult a qualified electrician. DO NOT attempt any electrical
repairs yourself.
UNPACKING AND ASSEMBLY
Before assembling, please check contents against the following list and advise
your dealer immediately if any parts are missing.
• 1 x Heater
•2xLegs
• 1 x Handle
• 1 x Remote Controller (batteries not included)
• 1 x Set fixings (screwed into back of the heater)
1. Remove the 4 lower screws from
the heater and use them to attach
the legs as shown.
2. Repeat with the two remaining
screws to fit the handle as shown.
3. DO NOT use the heater without
fitting the legs.
CAUTION: TAKE CARE TO REMOVE ALL PACKAGING MATERIALS FROM
WITHIN THE FRONT OF THE HEATER. YOU WILL NEED TO RELEASE THE
SCREWS SECURING THE FRONT GRILLE IN ORDER TO DO THIS.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OPERATION
USING THE REMOTE CONTROL
All operations must be done using the
remote control.
• 2 x AAA batteries are required
and are installed as shown by
the diagram found inside the
control unit.
• The remote control must be
directed at the heater display
panel. It has a range of approx
2.5 metres and must be aimed
at the correct angle.
MANUAL OPERATION
1. Stand the heater on a firm, level
surface and following all safety
precautions, connect to a suitable
power supply.
• The heater is equipped with an
anti-tilt switch that
automatically cuts the power
off should the heater tip over. If
this happens, stand the heater
upright and it will immediately
re-set.
2. Switch on the power at the primary
switch.
• The neon indicator will illuminate.
WARNING: FOR SAFE OPERATION OF THIS HEATER IT IS ESSENTIAL TO READ
THESE INSTRUCTIONS BEFORE USE.
WARNING: PLEASE NOTE THAT THE HEATING ELEMENTS OF THIS PRODUCT
DO NOT GLOW WHILST IN OPERATION. ANY PICTURES SHOWING THIS IN
ADVERTISING MATERIAL ARE FOR ILLUSTRATION ONLY.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Set one or both secondary switches to the I (On) position as required.
• The left one controls the upper heating element and the right one
controls the lower.
4. Press the ON/OFF button on the
remote control to switch the
elements on.
• The secondary switches will
each illuminate to show that the
heating element is in use.
• The ambient room temperature
will be displayed.
5. Set the target temperature by
pressing the + and - arrow keys on
the remote control to a value
between 15°C and 45°C.
• During normal operation the bar below the temperature display
pulsates to indicate that the heater is operating.
• When the heater has reached the target room temperature, the bar
will become solid and the heater will automatically turn off. It will
resume working when the ambient temperature falls 2oC below the
target temperature.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PROGRAMMING THE TIMER
When programming, note that the selection will only remain actively
displayed for approximately 10 seconds before reverting to the beginning of
the process. If unsure what value you wish to enter, you can maintain the
display by making constant adjustments with the +/- buttons until making your
final selection.
SETTING CURRENT TIME
1. Switch the heater on with the remote control (on/off). The heating
elements can be either on or off.
2. Press the TIME button.
• SUN will flash repeatedly.
3. Use the left and right arrow buttons to choose a day.
4. Press the TIME button to go to the next step.
• The first 2 digits (HOUR) of the time display will flash.
5. Use the + and - buttons to scroll to the correct time (24 hr clock).
6. Press the TIME button to set the Minutes.
7. Use the + and - buttons to scroll to the minutes you require.
8. Press the TIME button to finish the time and day set up.
• The current time and day will show as a constant when the WEEK
TIMER is activated.
NOTE: The Time and Day setting will be lost and will need to be reset.
Once the heater is powered off completely, (either from the
power switch or wall supply) Follow steps 1 to 8 to reset the clock.
THE WEEK TIMER
• The Week Timer covers a 7 day week (Monday to Sunday). You can
program up to 3 individual “on/off” cycles each day.
• Each heating period can be set for a maximum of 24 hours in 10
minute increments. It is not possible for the program to span two
consecutive days e.g. Monday 10pm to Tuesday 2am.
If the user requires the heater to operate over the midnight period
they would have to set two programs, one for Monday and one for
Tuesday.
• The user can then also set two further programs for Tuesday if
required.

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
• Always ensure that the heating elements are switched to the ON
position when in Timer mode.
SETTING THE WEEK TIMER
SETTING THE DAY AND PROGRAM
1. Press the WEEK TIMER button on the remote control.
• Monday will start to flash.
2. Press the left and right arrow keys to select the day you want your program
to start and press the WEEK TIMER button to confirm.
• Program 1 [01] will now flash.
3. Use the + and - buttons to select the program you want to set and press the
WEEK TIMER button to confirm.
• The programs will be displayed as 01, 02 and 03.
• The first two digits of the clock will flash and the word ON will be
displayed.
4. Use the + and - arrow keys to select the starting hour and press the WEEK
TIMER button to confirm.
• The second set of digits will flash.
5. Use the + and - arrow keys to select the starting minutes and press the WEEK
TIMER button to confirm.
• The display will show OF and the first two digits of the clock will flash.
You can now set the time the heater will turn off.
6. Use the + and - arrow keys to select the finishing hour and press the WEEK
TIMER button to confirm.
• The second set of digits will flash.
7. Use the + and - arrow keys to select the finishing minutes (in increment of
10) and press the WEEK TIMER button to confirm.
SETTING FURTHER PROGRAMS
1. Repeat the above steps to program each individual program/day.
ACTIVATING THE TIMER FUNCTION
1. To activate the TIMER mode press the TIMER On/Off button.
• The Day and Time will be shown on the display.
2. To turn the heater off press the TIMER On/Off button. The day and time will
be removed from the display and only temperature will be shown.

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
TO CLEAR A PROGRAM
1. To clear a program press the WEEK TIMER button once scroll to the day that
needs to be reset using the left and right arrows.
2. Press and hold the TIMER On/Off button for approximately 3 to 4 seconds.
• A beep will be heard from the heater and the time for that program
will show 00:00. The program is then ready to be set once again.
ECO MODE
Press the ECO button once to activate ECO mode.
• Only ambient room temperature will be displayed.
• Other lights on the display will switch off.

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CLEANING & MAINTENANCE
Always allow the heater to cool down for at least 15 minutes and disconnect it
from the mains supply before performing any maintenance tasks.
PERIODICALLY
1. Inspect the power cable for damage. Undue heat will cause the cable to
stiffen and crack. If this is found, have the cable replaced. Check your
cable routing and ensure it is well away from the heat source.
2. Should the heater become dirty, disconnect it from the power supply,
remove the front guard and wipe the reflector and elements with a clean
damp cloth. DO NOT use abrasive cleaners. Take care that no moisture
enters the heater.
3. Refer to your CLARKE dealer if internal maintenance is required.
4. When storing the heater, allow it to cool down before storing it in a dry, well
ventilated place.
ELEMENT REPLACEMENT
Ceramic heating elements are long lasting and should not need replacing
under normal circumstances. Should this become necessary take the heater
to your Clarke dealer.

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FAULT FINDING
SYMPTOM PROBLEM SOLUTION
Heater does not
operate, although
plugged in and
switched on.
Plug is loose/bad
connection.
Remove the plug & check
the connection of the plug
and socket.
Fuse blown. Replace if necessary and
investigate the cause. If the
fuse blows repeatedly,
consult your Clarke dealer.
No power at socket
outlet.
Insert the plug into a
suitable socket.
Tilt safety switch is
disabling the heater.
Ensure heater is upright. If
the switch does not re-set,
consult your Clarke dealer.
Heater does not
respond to remote
controller
Batteries defective. Replace batteries.
Controller is out of
range or not pointing
at the display panel.
Move closer or try different
angles of pointing the
controller at the heater.

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS DIAGRAM
A selection of suitable extension leads & plugs is available from your nearest
CLARKE dealer, for further information, contact your nearest dealer, or
telephone CLARKE International Sales department on 01992 565300.
No Description No
1 Front Guard 9 Tip-Over Switch
2 M6x15 Pan Head Screw 10 Switch Assembly
3 Top Panel 11 Casing
4 Ceramic Heat Element 12 Screw
5NeonIndicatorLamp 13 Power Cable & Plug
6 Reflector Panel 14 Cable Clamp
7 No10 x12 Pan Screw 15 Leg
8Handle 16EndPlug
n/a Remote Control Unit

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY
