Clarke Air CSG3KC Installation and operation manual

AIR STAPLER
MODEL: CSG3KC
Part No. 3110380
OPERATING & MAINTENANCE
INSTRUCTIONS
0506
©

2
SPECIFICATIONS
Min. Hose Size (ID) ........................................................................ 6mm (1/4”)
Air Inlet Connector ....................................................................... 10mm Quick Fit
Ave. Air Consumption .................................................................. 0.4 cfm
Operating Pressure ....................................................................... 4 - 7bar (60-100psi)
Air Pressure Max ............................................................................ 8bar (116psi)
Staple Size ...................................................................................... 20gauge/10-25mm
Magazine Capacity ..................................................................... 100
Drive Speed ................................................................................... 100 Shots/min
Sound Power Level ....................................................................... 101dBLWA
Weight ............................................................................................ 1.3kg
Dimensions LxWxH ........................................................................ 224x54.5x180.5
Part No ........................................................................................... 3110380
Please note that the details and specifications contained herein, are correct at the time of going to print. However
CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the
machine’s data plate

Please read these instructions carefully before operating the tool
Thank you for purchasing this CLARKE Air Stapler
Before using the device, please read this leaflet thoroughly and carefully follow
the instructions given. In doing so you will ensure the safety of yourself and that of
others around you, and you can also look forward it giving long and satisfactory
service.
3
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period
of 12 months from the date of purchase. Please keep your receipt as proof
of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product
can be returned to us without prior permission.
This guarantee does not effect your statutory rights.

SAFETY PRECAUTIONS
IMPORTANT
Failure to follow these precautions could result in personal injury, and/or
damage to property.
1. When operating this tool, ALWAYS wear:
a. approved impact resistant SAFETY GOGGLES. (Eye glasses are NOT safety
glasses)
b. EAR DEFENDERS
c. a good pair of INDUSTRIAL GLOVES
2. ALWAYS disconnect the tool from the air supply when not in use, and before
carrying out any maintenance
3. ALWAYS keep a safe distance between yourself and others when using the
tool.
4. ALWAYS Maintain the tool with care. Keep it clean for best/safest performance.
5. NEVER wear ill fitting clothing, remove watches and rings.
6. NEVER over-reach. Keep your proper footing and balance at all times.
7. NEVER force or misuse the tool. It will do a better and safer job at the rate for
which it was designed.
8. NEVER abuse hoses or connectors. NEVER carry a tool by the hose, or yank it
to disconnect from the air supply. Keep hoses away from heat, oil and sharp
edges. Check hoses for leaks or worn condition before use, and ensure that
all connections are secure.
9. NEVER use with an air supply greater than 8bar (110 PSI), at the tool.
10. NEVER modify the tool in any way.
11. NEVER remove any labels. Damaged labels should be replaced.
12. NEVER point the tool at anyone.
13. NEVER carry the tool with your finger on the trigger.
14. NEVER use any other type of gas to operate this tool. Use compressed air ONLY.
15. NEVER load the tool with Staples BEFORE connecting to an air supply.
16. NEVER load the tool with the trigger depressed
17. NEVER use this tool if any part is damaged. Have it inspected and repaired
by a competent technician
18. NEVER modify this tool in any way. Use it ONLY for the purpose for which it is
designed.
19, NEVER fire tool at an angle. it must be perpendicular to the work surface.
20. NEVER drive in Staples at the edge of a work surface, as the edge could fail
and fly off, endangering yourself or others in the vicinity.
4

AIR SUPPLY
WARNING!
Compressed air can be dangerous. Ensure that you are thoroughly familiar with
all precautions relating to the use of compressors and compressed air supply.
Tools of this type, operate on a wide range of air pressures. It is recommended that air
pressure be set to between 60 and 100psi. at the tool when running.
Higher pressure and unclean air will shorten the tools’ life because of faster wear, and could
be a safety hazard.
Water in the air line will cause damage to the tool, ensure it is properly maintained at all times.
The recommended procedure to connect this tool to an air supply, is shown on page11.
The air inlet used for connecting air supply, is a 10mm Quick Fit type.
Line pressure, or hose ID., should be increased to compensate for unusually long air hoses
(over 10M). Minimum hose dia. should be 6mm (1/4”) ID., and fittings should have the same
inside dimensions.
ASSEMBLY
CSG3K
OPERATION
Ensure the tool is not loaded, then, with the air supply turned OFF, connect the air line to
the Stapler at the Quick Fit coupling.
With your fingers well away from the trigger, and the tool pointed away from you, and
anyone in the vicinity, depress the magazine catch, pull out the magazine and load with
appropriate staples...as shown. Push the magazine back until it locks in position, - Your stapler
is now ready for use.
Turn ON the air supply, and check for air leaks. If any are apparent, rectify before
proceeding. Ensure the operating pressure is set to between 4-7bar (60-100psi), depending
upon the size of staple used and type of material being worked. The harder the material,
and bigger the staple, the higher the pressure.
Hold the tool so that it is at right angles to the work. Lower it so that the Safety Element
contacts the work surface, and is forced upwards. This movement releases the Trigger,
which may now be pulled, driving in the staple.
If the gun jams, ensure the air is turned OFF and the trigger pulled, before opening the
magazine to free the jammed staple. 5

MAINTENANCE
Daily before use.
1. Drain water from compressor air tank, and air line.
2. Check and clean, if necessary, the air inlet gauze filter.
3. A bottle of CLARKE Air Line Oil** is supplied with the kit. Squirt a few drops of oil
(approx. 3cc), into the air inlet.
This should be carried out regardless of whether or not an air line lubricator is
used.
During Use.
For lubricating the internal components when in operation, an air line lubricator
should be used, with Clarke Air Line Oil**, adjusted to 2 drops per minute.
If an Air line lubricator is NOT used, this procedure should be repeated after every
two to three hours of use.
Storage.
If the Stapler is to be stored, or is idle for longer than 24 hours, run a few drops of
Clarke Air Line Oil* into the air inlet before storing.
Notes
Be aware that factors other than the tool may effect its operation and efficiency
such as reduced compressor output, excessive drain on the airline, moisture or
restrictions in the line, or the use of connectors of improper size or poor condition
which will reduce air supply.
Grit or gum deposits in the tool may also reduce efficiency. This condition can be
corrected by cleaning the air strainer and flushing out the tool with gum solvent
oil, or failing this, the tool should be disassembled, thoroughly cleaned, dried and
reassembled.
If the tool runs erratically or becomes inefficient, and the air supply is sound,
dismantle the piston assembly and replace worn or damaged parts, or take the
tool to your CLARKE dealer.
**Clarke Air Line Oil is available from your CLARKE dealer part no. 3050825.
IMPORTANT:
The use of parts other than CLARKE replacement parts may result in safely
hazards, decreased tool performance and will invalidate your warranty.
6

7
ACCESSORIES
A wide range of Airline accessories is available, including Filter/Regulators. Lubricators, High
Pressure Hoses from 5 to 100 Metres, Whip hose etc. Contact your CLARKE dealer for further
information, or CLARKE International Sales Department on 01992 565333
CONSUMABLES
20 GAUGE
Length Part No:
10mm ................................ 1800405
16mm ................................ 1800407
19mm ................................ 1800409
22mm ................................ 1800411
Staples - 5.2mm Crown - 20 Gauge - Type 4J

PARTS DIAGRAM
8

PARTS LIST
No. Description Part No. No. Description Part No.
9
1 Bolt M5x20 HTCSG3KC01
2 Exhaust Cap HTCSG3KC02
3 Comprssed Spring HTCSG3KC03
4 Rectanle Washer HTCSG3KC03
5 CylinderCover HTCSG3KC05
6 O-Ring 13.7x2.4 HTCSG3KC06
7 O-Ring 31.2x2.5 HTCSG3KC07
8 Balance Valve HTCSG3KC08
9 Washer HTCSG3KC09
10 O-Ring 42.6x2.35 HTCSG3KC10
11 Collar HTCSG3KC11
12 O-Ring 30x1.8 HTCSG3KC12
13 O-Ring 29.7x3.55 HTCSG3KC13
14 Cylinder HTCSG3KC14
15 O-Ring 21x3 HTCSG3KC15
16 Piston Assembly HTCSG3KC16
17 Shock Absorber HTCSG3KC17
18 Sealing Washer HTCSG3KC18
19 Gun Body HTCSG3KC19
20 Rubber Washer HTCSG3KC20
21 Rectangle Washer HTCSG3KC21
22 Trigger Valve Seat HTCSG3KC22
23 Trigger Valve Stem HTCSG3KC23
24 O-ring 1.7x2 HTCSG3KC24
25 Trigger Valve Guide HTCSG3KC25
26 O-ring 11.2×2 HTCSG3KC26
27 Compression Spring HTCSG3KC27
28 Step Pin HTCSG3KC28
29 Trigger HTCSG3KC29
30 E-ring Ø 2.5 HTCSG3KC30
31 Safety Plate HTCSG3KC31
32 Pin 2.5x16 HTCSG3KC32
33 Slide Bracket HTCSG3KC33
34 Spring HTCSG3KC34
35 Safety Element HTCSG3KC35
36 Plate HTCSG3KC36
37 Nose Plate HTCSG3KC37
38 Gasket HTCSG3KC38
39 Safety Element Guide HTCSG3KC39
40 Bolt M5x6 HTCSG3KC40
41 Fixed Magazine HTCSG3KC41
42 Movable Magazine HTCSG3KC42
43 Pusher HTCSG3KC43
44 Guide Rod HTCSG3KC44
45 Compression Spring HTCSG3KC45
46 Bolt HTCSG3KC46
47 Pin HTCSG3KC47
48 Spring HTCSG3KC48
49 Release Catch HTCSG3KC49
50 Bolt M4x25 HTCSG3KC50
51 Gasket HTCSG3KC51
52 Lock Nut M4 HTCSG3KC52
53 Rubber Handle HTCSG3KC53
54 O-ring 36.3×3.55 HTCSG3KC54
55 End Cap HTCSG3KC55
56 Air Inlet Plug HTCSG3KC56
57 Q/Release Coupling HTCSG3KC57

11
DECLARATION OF CONFORMITY
We declare that these products comply to the following standards/directives
• BS EN 792-13: 2000
Model No: CSG3KC
Serial or Batch number: See product data plate
signature:
L. E. Fergusson
SERVICE MANAGER
For Spare Parts and Service, please contact your nearest dealer, or CLARKE
International, on one of the following numbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
or e-mail as follows:
PARTS: [email protected]
SERVICE: [email protected]
SPARE PARTS & SERVICING CONTACTS
RECOMMENDED AIR SUPPLY CONNECTION
