Clas Ohlson 18-5040 User manual

ENGLISH SVENSKA NORSK SUOMI
Clock radio, Silver/Gray



Article number 18-5040, 31-4472



2

ENGLISH
2 3
Clock radio, Silver/Gray
Article number 18-5040, 31-4472
Please read the entire instruction manual before using and save it
for future use. We apologise for any text or photographic errors and
any changes in technical data. If you have any questions concerning
technical problems please contact our Customer Service Department
(see address on reverse.)
Safety
- This product must be repaired by qualied service personnel only.
- This product must not be disassembled or altered.
- Do not place this product so that it can fall into water or other
liquid. Nor should you place any objects containing liquid, such as
vases or sodas, on the product.
- Make sure the mains socket is easily accessible since the power
cord plug functions as a circuit breaker.
- Do not cover the product. Sufcient ventilation, at least 15
cm between the ventilation hole and surrounding surfaces is
necessary to prevent the device from overheating.
- Always unplug the clock radio before cleaning.
- Do not place the device in a humid, damp environment or where it
is exposed to strong vibrations.
- Always remove the battery for periods of prolonged non-use. The
battery may begin to leak and can cause damage to the device,
person or property.

ENGLISH
4
SN O OZ E
SN O OZ E
1
2
3
4
5
6
7
9
8
10
11
Buttons and functions
1. SNOOZE – Postpones alarm
2. Frequency indicator– Shows set frequency
3. SLEEP – Automatic radio shut-off
4. ALARM – Sets alarm
5. MINUTE – Sets minutes
6. HOUR – Sets hours
7. TIME – Sets time
8. Function selector – ON/OFF/AUTO
9. Volume control – VOLUME/OFF/BUZZER
10. Band selector – AM/FM
11. Frequency selector

ENGLISH
5
Getting started
Inserting backup battery
The backup battery allows the clock to retain its the time settings when
power is lost. If a backup battery is not used, the clock will reset itself
each time it is unplugged.
1. Open the battery cover on the clock radio’s underside.
2. Insert a 9-volt battery (not included) and replace the battery cover.
Always remove the battery for periods of prolonged non-use. The bat-
tery may begin to leak and can cause damage to the device, person or
property.
Plugging in the clock radio
1. Plug in the clock radio to a mains socket.
2. Make sure the mains socket is easily accessible since the power
cord plug functions as a circuit breaker.
Setting the time
When plugging in the clock radio for the rst time, 0:00 will ash on the
display. The ashing will stop once you begin setting the time.
1. Press and hold the TIME button while repeatedly pressing the
HOUR button to set the hours.
2. Press and hold TIME button while repeatedly pressing the
MINUTE button to set the minutes.

ENGLISH

Operation
Listening to the radio
1. Set the band selector to the desired band: AM or FM.
2. Turn the volume dial clockwise until you hear a click thereby
turning on the radio.
3. Set the function selector to ON.
4. Select the desired radio station with the frequency selector and
adjust the volume with the volume control.
5. Set the function selector to OFF to turn off the radio.
For FM: Unroll the wire antenna and position it to achieve the best
possible reception.
For AM: The device is equipped with a built-in antenna therefore mak-
ing the wire antenna unnecessary for AM listening. Adjust this antenna
by turning the entire device.
Setting the alarm
1. Press and hold the ALARM button while repeatedly pressing the
HOUR button to set the HOURS.
2. Press and hold the ALARM button while repeatedly pressing the
MINUTES button to set the MINUTES.
Checking the set alarm time
- Press and hold the ALARM button to see the set alarm time.
Waking up to the radio
1. Set the function selector to ON to set the desired radio station and
volume. Set the function selector to AUTO. The alarm indicator
will now shine.
2. Set the desired alarm time by following the instructions above.
3. When the alarm time has been reached, the radio will come on at
the desired station and volume.

ENGLISH
7
4. To turn off the radio, press ALARM once. The radio will be turned
off but the alarm will still be active and will start the radio again at
the same time the coming day.
5. Set the function selector to OFF if you do not want the alarm to
start the radio again the coming day. The alarm indicator will be unlit.
Waking up to the alarm signal
1. Set the function selector to AUTO. The alarm indicator will now
shine to indicate that the alarm is active.
2. Turn the volume dial clockwise until you hear a click. The radio has
now been turned off and the alarm signal deactivated.
3. When the alarm time has been reached the alarm will sound.
4. To turn off the alarm press ALARM. The alarm will turn itself off
but the alarm will still be active and will start the radio again at the
same time the coming day.
5. Set the function selector to OFF if you do not want the alarm to
start the radio again the coming day. The alarm indicator will be unlit.
Snooze
- When the alarm sounds or starts the radio, press the SNOOZE
button to activate the snooze function. The alarm signal/radio will
go silent but reactivate itself after 9 minutes.
- To turn off the alarm completely, set the function selector to OFF.
The alarm indicator will go dark.
Sleep (automatic radio shut-off)
The radio can be set to automatically shut itself off after a specied time.
1. Set the function selector to ON to set the desired radio station and
volume. Now set the function selector to OFF or AUTO.
2. Press SLEEP once. The display will show ”0:59” as long as the
button is pressed.
3. This shut-off time can be increased by keeping SLEEP pressed
and pressing the HOUR button once. The display will now show
1:59.

ENGLISH
8
4. Decrease the time for automatic shut-off by holding the SLEEP
button pressed and pressing the MINUTE button repeatedly.
Release these buttons once the display shows the desired time.
5. Press SNOOZE once to turn off the radio before automatic shut off
activates.
Care and maintenance
- Always unplug the clock radio before cleaning.
- Clean with a soft moist cloth. Never use cleaning agents or strong
solvents.
- Always remove the battery when not using the clock radio for a
prolonged period of time.
Disposal
Follow local regulations when disposing of this product. If you are
uncertain, contact your municipality.
Specications
Voltage 230 V AC, 50 Hz
Battery (backup) 1 x 6LR61 (not included)
Dimensions 130 x 160 x 45 mm

SVENSKA

Klockradio Silver/Grå
Artikelnummer 18-5040, 31-4472
Läs igenom hela bruksanvisningen före användning och spara den
sedan för framtida bruk. Vi reserverar oss för ev. text- och bildfel samt
ändringar av tekniska data. Vid tekniska problem eller andra frågor,
kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
- Produkten får endast repareras av kvalicerad servicepersonal.
- Produkten får inte demonteras eller ändras.
- Placera inte produkten så att den kan falla ner i vatten eller annan
vätska. Ställ inte heller några föremål som innehåller vätska på
produkten, t.ex. en blomvas eller läskedryck.
- Se till att uttaget där stickproppen sitter är tillgängligt
då stickproppen på apparatens nätsladd används som
frånkopplingsanordning från nätet.
- Täck inte över produkten. Tillräcklig ventilation, med ett minsta
avstånd på ca 15 cm mellan ventilationshålen och omgivande ytor,
är nödvändig för att förhindra att anläggningen blir för varm.
- Koppla alltid ifrån klockradion från elnätet före rengöring.
- Placera inte apparaten i en fuktig, dammig miljö eller där det
förekommer starka vibrationer.
- Ta alltid ur batteriet om klockan inte ska användas under längre
perioder. Batteriet kan börja läcka och orsaka skada på apparat,
person eller egendom.

SVENSKA
10
Knappar och funktioner
1. SNOOZE – Repeterad väckning
2. Frekvensindikator – Visar inställd frekvens
3. SLEEP – Insomningstimer/automatisk avstängning
4. ALARM – Ställer alarmtiden
5. MINUTE – Ställer minuter
6. HOUR – Ställer timmar
7. TIME – Ställer in tiden
8. Funktionsomkopplare – ON/OFF/AUTO
9. Volymkontroll – VOLUME/OFF/BUZZER
10. Bandomkopplare – AM/FM
11. Frekvensväljare
SN O OZ E
SN O OZ E
1
2
3
4
5
6
7
9
8
10
11
