CleanSpace EX User manual

CleanSpace Technology Pty Ltd
Unit 5, 39 Herbert St
T: [phone]
ABN 24 146 453 554
St Leonards NSW 2065 Australia
[e-mail]
CleanSpace EX PAF-0060
CleanSpace Ultra PAF-0070
www.cleanspacetechnology.com
USER
INSTRUCTIONS

CleanSpace Respirators USER INSTRUCTIONS
2
English
1. Contents
1. Contents ..............................................................................................................................................................2
2. Foreword..............................................................................................................................................................3
3. List of Warnings...................................................................................................................................................3
4. Special or Critical User Instructions....................................................................................................................3
5. Limitations of Use................................................................................................................................................4
6. System Components...........................................................................................................................................5
7. Controls and Indicators .......................................................................................................................................8
8. Using the CleanSpace Respirator with Half Mask..............................................................................................9
9. Using the CleanSpace Respirator with Full Face Masks................................................................................. 18
10. Entering and Exiting the Contaminated Area................................................................................................... 25
11. Working in Noisy Environments ....................................................................................................................... 26
12. Changing the Filter........................................................................................................................................... 26
13. Battery Information........................................................................................................................................... 28
14. Cleaning............................................................................................................................................................ 30
15. Recalibration..................................................................................................................................................... 31
16. Approvals.......................................................................................................................................................... 31
17. Specifications ................................................................................................................................................... 35
18. Product Warranty.............................................................................................................................................. 36
Important: Before use, the wearer must read and understand these user instructions. Keep these user
instructions for reference.
Read these instructions in conjunction with the instructions for the appropriate CleanSpace filters and
accessories.
WARNING
This product is part of a system that helps protect against certain airborne contaminants. Misuse may result in
sickness or death. For proper use, consult an Occupational Health Specialist, refer to these User Instructions, or
contact CleanSpace Technology Customer Service on [phone].
SPECIAL CONDITIONS OF USE
•The battery shall only be charged in non-hazardous areas
•Charging voltage Um+14.7V from an/via an Ex certified intrinsically safe category I (Ex ia) device
•CleanSpace Ex uses a unique charger designed for use with CleanSpace Ex only. Do not attempt to charge
your CleanSpace EX with any other charger. Do not use the Ex charger to charge any device other than
CleanSpace Ex.

CleanSpace Respirators USER INSTRUCTIONS
3
English
2. Foreword
Read all instructions and warnings in these User Instructions before using this device. Keep these User Instructions for
reference. If you have questions regarding this system, contact CleanSpace Customer Service on [phone] or e-mail
[e-mail].
3. List of Warnings
This product is part of a system that helps protect against certain airborne contaminants.
WARNING: Properly selected, used, and maintained respirators help to protect against certain airborne contaminants by reducing concentrations in
the wearer’s breathing zone. It is essential to follow all instructions and government regulations on the use of this product, including wearing the
complete respirator system during all times of exposure, in order for the product to help protect the wearer. Misuse of respirators may result in
overexposure to contaminants, and lead to sickness or death. For proper use, consult an Occupational Health Specialist, refer to these User
Instructions, or contact CleanSpace Customer Service on [phone].
No PAPR can fully protect you if you are not clean shaven. CleanSpace Respirators are not suitable for users with facial hair.
IF A SATISFACTORY FIT FACTOR CANNOT BE ACHIEVED WITH ANY OF THE MASKS, CLEANSPACE RESPIRATORS MUST NOT BE USED.
CleanSpace Respirators are a complete respiratory protection system. In addition, some combinations of components have been approved for use in
some explosive atmospheres.
Only specific combinations of components have been approved for use in explosive atmospheres. Refer to Section 16. Approvals.
The IECEx / ATEX / ETL approvals apply only when all components are IECEx / ATEX / ETL approved. If the equipment is to be used in an explosive
atmosphere, ensure proper approval exists when purchasing spare parts and accessories.
Not all components and accessories shown in this manual carry IECEx / ATEX / ETL approval.
If working in intrinsically safe environments, before each of an intrinsically safe mask - check that the black conductive coating on the mask has not
been significantly damaged.
WARNING: The battery shall only be charged in non-hazardous areas. Move out of the hazardous area before charging CleanSpace Respirators.
WARNING: Be sure to remove the Seal Check Cap before entering the contaminated area. The cap blocks the exhalation valve, preventing your exhaled
air to be expelled from the mask. Failure to remove the cap will lead to a build-up of carbon dioxide in the mask, and may result in headache or
dizziness. Never leave the cap in place for more than 2 minutes!
DO NOT REMOVE THE CLEANSPACE RESPIRATOR UNTIL YOU HAVE VACATED THE CONTAMINATED AREA unless you have pressing health reasons to
do so (for instance if you are experiencing dizziness and believe removing the respirator while leave the contaminated area may help).
IT IS ESSENTIAL THAT THE CORRECT FILTER TYPE IS SELECTED FOR THE CHOSEN APPLICATION.
If the Filter Warning Alarm is triggered (two (2) beeps repeated every second and red LED flashes), leave the contaminated area immediately and
investigate.
Using the CleanSpace Respirator after the Filter Warning Alarm has triggered can cause the flow to fall below the manufacturer’s Minimum Design
Flow, which may result in overexposure to contaminants and lead to sickness or death.
Use only CleanSpace filters with the CleanSpace Respirator. Use of other filters may result in overexposure to contaminants and lead to sickness or
death.
Do not charge the Power Unit with unapproved chargers, in enclosed cabinets without ventilation, near flammable liquids or gasses, or near sources
of high heat.
Do not use, charge, or store the device outside the recommended temperature limits.
If the Low Battery Alarm sounds (three (3) beeps repeated every second), leave the contaminated area immediately and recharge the battery.
Operating the respirator after the Low Battery Alarm has sounded can cause the flow to fall below the manufacturer’s Minimum Design Flow, and
may result in overexposure to contaminants and lead to sickness or death.
IN THE EXTREMELY RARE CIRCUMSTANCE THAT THE BATTERY IS DAMAGED AND ELECTROLYTE COMES IN CONTACT WITH EYES, FLUSH WITH WATER
IMMEDIATELY AND SEEK URGENT MEDICAL ATTENTION.
WARNING: NEVER DRY THE MASK OR EXHALATION VALVE WITH A CLOTH THAT MAY LEAVE BEHIND LINT.
Lint contamination of the exhalation valve may cause it to leak, resulting in overexposure to contaminants and lead to sickness or death.
WARNING: The Power Unit contains a battery, sensitive electronics and a motor. DO NOT immerse the Power Unit in water or use anything wetter
than a damp cloth to clean it.
WARNING: NEVER CLEAN THE FILTER WITH COMPRESSED AIR OR A BRUSH. HEPA filters are easily damaged by the use of compressed air or by
brushing.
Misuse of the CleanSpace Respirators by cleaning the filter may result in overexposure to contaminants and lead to sickness or death.
You must recalibrate the internal pressure sensor any time that the CleanSpace Respirator is exposed to changes in temperature of more than 20°C.
4. Special or Critical User Instructions
CleanSpace Respirators include a system that detects and corrects for changes in atmospheric pressure. This system requires
recalibration whenever it experiences a change in temperature of more than 20°C. Refer to Section 15 for instructions on how
to recalibrate the CleanSpace Respirator.

CleanSpace Respirators USER INSTRUCTIONS
4
English
5. Limitations of Use
Use the CleanSpace Respirator strictly in accordance with these User Instructions. DO NOT modify or alter this product.
▪DO NOT USE for respiratory protection against unknown atmospheric contaminants, when concentrations of
contaminants are unknown, or immediately dangerous to life or health (IDLH).
▪Do not use if the oxygen concentration is below 19.5%.
▪Do not remove the CleanSpace Respirator until you have left the contaminated area, unless you have pressing health
reasons to do so, (for instance you are experiencing dizziness and believe removing the respirator while leaving the
contaminated area may help).
▪Only suitable for use by clean-shaven personnel. Facial hair under the seal reduces protection and is not permitted.
▪Unless used with a CleanSpace Full Face Mask, the CleanSpace respirator DOES NOT PROTECT YOUR EYES. In conditions
that may damage or irritate eyes, use protective eyewear.
▪Only use CleanSpace approved filters and accessories.
▪Do not use the CleanSpace Respirator unless it is powered and running normally.
▪Do not use the CleanSpace Respirator while it is connected to the charger.
▪Do not use in airborne contaminant concentrations above those specified by your national regulations.
▪Only for use by trained personnel.
▪Filters need to be changed regularly. The frequency of filter changes depends on CleanSpace Respirator use and on the
concentration of contaminants in the environment.
▪Do not use for escape purposes.
▪National regulations may impose specific limitations on the use of filters depending on the filter class and the facemask
used.
LEAVE THE CONTAMINATED AREA IMMEDIATELY IF:
▪CleanSpace Respirator warning lights or sounds activate for the Low Battery Alarm or the Blocked Filter Alarm
▪Any part of the respirator is damaged
▪Air flow into the mask decreases or stops
▪Breathing becomes difficult or increased resistance occurs
▪You feel dizzy or your airway is irritated
▪You can taste or smell contaminants
Your CleanSpace Respirator is suitable for use in the following atmospheric conditions:
▪Temperature: -10°C to 45°C (Note: Explosive atmospheres approvals apply up to maximum ambient temperature of
40°C).
▪Relative humidity: 0 to 90% non-condensing.
The CleanSpace Respirator will stop functioning if its internal temperature rises above 60°C (ambient 50°C) or falls below -
10°C.
If the CleanSpace Respirator has become contaminated with a substance requiring special decontamination procedures, it
should be sealed in a suitable container until it can be decontaminated.
Do not disassemble the CleanSpace Respirator case. There are no user serviceable parts inside.
Failure to follow all instructions on the use of this product may render the warranty void.
Failure to use the CleanSpace Respirator properly during times of exposure may lead to adverse effects on the wearer’s health.

CleanSpace Respirators USER INSTRUCTIONS
5
English
WARNING
This product is part of a system that helps protect against certain airborne contaminants. Misuse may result in
sickness or death. For proper use, consult an Occupational Health Specialist, refer to these User Instructions, or
contact CleanSpace Technology Customer Service on [phone].
6. System Components
CleanSpace Respirator is a complete respiratory protection system. Only specific combinations of components have been
approved for use in some explosive atmospheres. Not all of the components shown below have been approved for use in
explosive atmospheres. Refer to Section 16. Approvals below for details.
1A PAF-0064
Half Mask –Small, EX
2A PAF-0035
Filter P3 TM3 P SL R Standard
3A PAF-0065, 67 & 72
Filter Cover, Ultra & Ex
1B PAF-0062
Half Mask –Medium, EX
2B PAF-0037
Filter P3 TM3 P SL R High Capacity
3B PAF-0038
Filter Adaptor (large case filters)
1C PAF-0063
Half Mask –Large, EX
2C PAF-1037
Filter HEPA/HE High Capacity
3C PAF-0078
Conductive Filter Adaptor, EX
1D PAF-0033
Half Mask –Small
2D PAF-1003
Filter HEPA/HE High Capacity
4A PAF-0073
Head Harness- Half mask
1E PAF-1010
Half Mask –Medium
2E PAF-0091
Combined filter ABE1P3 (AU)
4B PAF-1016
Head Harness –Full Face
1F PAF-0027
Half Mask –Large
2F PAF-0076
Combined filter ABEK1P3 (AU)
5 PAF-0034, 60, 70
Power Unit 2, EX & Ultra
1G PAF-1014
Full Face Mask (M/L)
2G PAF-0050
Combined filter TM3 A1 P SL R (EU)
6A PAF-1028
Neck support (Small)
1H PAF-1106
Full Face Mask (S)
2H PAF-0051
Combined filter TM3 ABE1 P SL R (EU)
6B PAF-1012
Neck Support (Medium)
2I PAF-0052
Combined filter TM3 ABEK1 P SL R
6C PAF-1013
Neck Support (Large)
2J PAF-0077
Combined filter TM3 A2 P SL R (EU)
7A PAF-1005
Flow Test Cap
7B 1101
Battery Chargers 2,Ultra & EX
7C PAF-1009
Seal Check Cap
*NOTE: Not all filters are available in all markets.
Figure 1 - System Components

CleanSpace Respirators USER INSTRUCTIONS
6
English
COMPONENTS OF THE CLEANSPACE RESPIRATOR
Throughout these User Instructions, reference is made to various components of the CleanSpace Respirator. Familiarise
yourself with these components before reading the rest of the User Instructions. See Figure 1 –System Components.
Mask AirClip
Power Unit AirClip
Mask Release
Button
Adjust Button
Bellows

CleanSpace Respirators USER INSTRUCTIONS
7
English
Exhalation Valve on Half Masks
Exhalation Valve
Shower Cover
Hoop
Filter Cover
Filter Cover Pin

CleanSpace Respirators USER INSTRUCTIONS
8
English
7. Controls and Indicators
All controls and indicators are located on the keypad.
POWER BUTTON
This button is used to switch between the three (3) operating Modes: “Off”, “Standby”, and “On”.
i) Off Mode is when the green battery indicator lights are off, the motor is not running, and there is no
airflow to the mask. The CleanSpace Respirator automatically switches to Off Mode after three (3) minutes in
standby mode with no breathing sensed.
ii) Standby Mode is when the green battery indicator light(s) are on, the motor is not running, and there is no airflow to the
mask. If the CleanSpace Respirator is in Off Mode, it will switch to Standby Mode when the Power Button is pressed. The
CleanSpace Respirator will automatically switch to Standby Mode within ten (10) seconds of the user doffing the respirator.
iii) On Mode is when the CleanSpace Respirator is being worn, the motor is running, and there is airflow to the mask. If the
CleanSpace Respirator is in Standby Mode, it will switch to On Mode when breathing is detected, or the Power Button is
pressed.
To conserve battery life when not being worn, the CleanSpace Respirator is designed to automatically switch from On Mode to
Standby Mode, and then to Off Mode.
Note: The CleanSpace Respirator switches to On Mode when the respirator is in Standby Mode and breathing is detected. The
CleanSpace Respirator can only switch into On Mode from Standby Mode.
FLOW TEST BUTTON
The Flow Test Button measures the rate of flow produced by the CleanSpace Respirator to ensure it is able to
deliver the minimum design flow. When the CleanSpace Respirator is in Standby Mode (not On Mode), pressing
the Flow Test Button initiates Flow Test. This lasts about 5 seconds.
Refer to Section 9 for instructions on running the flow test.
BATTERY INDICATOR LIGHTS
The CleanSpace Respirator is equipped with a battery charge indicator comprised of three (3) battery
indicator lights. The battery is fully charged when the charger is connected to the Power Unit and all three
(3) lights are solid green. A fully charged Power Unit has a minimum of four (4) hours operating time.
The CleanSpace Respirator should be fully charged before use.
The CleanSpace Respirator will operate with one (1), two (2), or three (3) green battery indicator lights illuminated. When all
battery lights extinguish, the Power Unit had less than on (1) hour of operation remaining. It is recommended that the
CleanSpace Respirator be charged before use.
For approximate operating times, refer to Section 13. Battery Information.
LOW BATTERY ALARM
The Low Battery Alarm is triggered when the battery charge decreases beyond level at which it may not be able to supply the
manufacturer’s Minimum Design Flow. The Low Battery Alarm consists of three (3) beeps, repeated once per second and all
battery indicator lights extinguish.
If the Low Battery Alarm is triggered, you must leave the contaminated area immediately and recharge the battery.

CleanSpace Respirators USER INSTRUCTIONS
9
English
The Low Battery Alarm cannot be muted.
Battery life is strongly affected by work rate, atmospheric pressure, and other factors. The approximate operating times
stated in Section 13. Battery Information are typical for moderate work rates at sea level. Actual operating times may vary
widely.
FILTER WARNING ALARM
The Filter Warning Alarm is triggered if the filter is blocked. The Filter Warming Alarm consists of two (2) beeps,
repeated once per second, and the red LED flashes.
The Filter Warning Alarm can be muted for 15 minutes by pressing the Power Button once.
If the Filter Warning Alarm is triggered, you must move out of the contaminated area IMMEDIATELY and change the filter.
8. Using the CleanSpace Respirator with Half Mask
MASK FITTING FOR HALF MASK
Intrinsically Safe
NOT –Intrinsically Safe
PAF-0064 EX Half Mask Small
PAF-0062 EX Half Mask Medium
PAF-0063 EX Half Mask Large
PAF-0033 Half Mask Small
PAF-1010 Half Mask Medium
PAF-0027 Half Mask Large
Determine the correct mask size and achieve a good fit prior to using the CleanSpace Respirator.
Mask fitting must be carried out by a specialist / designated mask fitter. The fit must be confirmed by a quantitative fit test.
To carry out a quantitative fit test the specialist / designated mask fitter will require the PAF-0025 PortaCount Adaptor and
the accompanying S005-7174 Quantitative Fit Test Instructions. The PortaCount Adaptor is an accessory that fits between the
mask and exhalation valve, allowing the air in the mask to be sampled.
No PAPR can fully protect you if you are not clean shaven. CleanSpace Respirator is not suitable for users with facial hair.
MASK SELECTION GUIDELINES
No set of guidelines can ensure a good fit. Fit must be confirmed with a quantitative fit test. The table below is a guideline
for the specialist / designated mask fitter.

CleanSpace Respirators USER INSTRUCTIONS
10
English
Once an acceptable mask fit has been achieved, and then confirmed with a quantitative fit test, the table below may be used
as a record.
Name
Mask Size
Neck Support
Small / Medium / Large (Circle one)
Date of Quantitative Fit Test
Fit Factor achieved
IF A SATISFACTORY FIT FACTOR CANNOT BE ACHIEVED WITH ANY OF THE MASKS, CLEANSPACE RESPIRATORS MUST NOT BE
USED.
WARNING
If a satisfactory quantitative fit factor or a qualitative test pass cannot be achieved with either mask, the
CleanSpace Respirator must not be used.
Satisfactory quantitative fit factor results are as follows.
Test Type
Half Mask
Full Face Mask
Power On
1000
1000
Power Off
100
500
USING THE CLEANSPACE RESPIRATOR WITH HALF MASK
Complete the following steps each time you use CleanSpace Respirator with Half Mask.

CleanSpace Respirators USER INSTRUCTIONS
11
English
Prior to entering a potentially contaminated area, the following inspection must be performed.
STEP 1 –INSPECT THE CLEANSPACE RESPIRATOR
•Visually inspect all the CleanSpace Respirator components, (Power Unit, mask, harness, filter adaptor, and filter). If any
components are missing or damaged, replace them only with approved CleanSpace Respirator parts before proceeding.
Check the top and bottom case of the Power Unit, and the Filter Adaptor (if fitted) for cracks or other damage. Do not use
the CleanSpace Respirator if there is any damage.
•Remove the filter and inspect it carefully. The seal must be clean, and free from damage of any kind. If necessary, the seal
and housing can be cleaned with a cloth dampened with water. (The filter media must not be exposed to water). Inspect
the surfaces behind the filter carefully for any sign that dust has leaked past a damaged seal. If dust is found, replace the
filter. The filter media must not be cracked or show any sign of damage. Inspect the filter carefully for any sign that it has
sustained an impact or been scratched. If any sign of impact or scratching is found, discard the filter. If the filter inspection
is satisfactory fit the filter and check that it is secure (refer to Section 12 Changing the Filter).
WARNING: NEVER CLEAN THE FILTER WITH COMPRESSED AIR OR A BRUSH. HEPA FILTERS ARE EASILY DAMAGED BY THE USE
OF COMPRESSED AIR OR BY BRUSHING.
Misuse of the CleanSpace Respirator by cleaning the filter may result in overexposure to contaminants and lead to sickness
or death.
•Inspect that the battery has enough charge to complete the work period by pressing the Power Button. The Battery
Indicator Light(s) will illuminate to indicate the approximate charge. Refer to Section 7 Controls and Indicators. A full
charge is recommended.
•Inspect both bellows for cuts or holes. Check that the bellows have not become distorted as this may obstruct the air
supply.
•Inspect the mask to ensure that there are no cracks, tears, or dirt. The mask should not be warped.
•Inspect the exhalation valve for damage or dirt. If dirt is present, remove the exhalation valve cover. Remove any
contaminants that could affect the seal of the valve. Check that the valve seat is clean. Reinstall the exhalation valve
cover. If the valve is damaged, replace the exhalation valve.
•Inspect the harness for damage.
STEP 2 –RECALIBRATE THE POWER UNIT
The CleanSpace Respirator contains a system that detects and corrects for changes in atmospheric pressure. This system
requires recalibration whenever a change in temperature of more than 20°C is experienced.
Recalibration procedure:
1. With no mask attached, place the Power Unit on a flat surface with the keypad facing up.
2. With the Power Unit in standby mode (one or more Battery Indicator Light(s) illuminated), press and hold both the Power
Button and the FLOW TEST Button.
3. When both the blue and red indicator lights illuminate, release both buttons.
4. Do not move the Power until the red and blue indicator lights extinguish; approximately(10 –15 seconds).
5. Recalibration is complete.
The CleanSpace Respirator automatically recalibrates the system any time it is left undisturbed in Standby Mode for more
than 20 seconds.
STEP 3 –TEST FLOW RATE ON THE POWER UNIT
The Flow Test verifies that the machine is able to deliver the Manufacturer’s Minimum Design Flow of 120 litres/minute.
1. Fit the yellow Flow Test Cap to the LEFT bellow. Note: the Power Unit depicted below has the Filter Adaptor fitted. The
Flow Test procedure is the same regardless of filter configuration.

CleanSpace Respirators USER INSTRUCTIONS
12
English
2. Ensure the Flow Test Cap and the filter inlet are unobstructed. Place the CleanSpace Respirator on a flat surface with the
keypad facing up.
3. Place the Power Unit in Standby Mode. Press and release the Flow Test button.
4. The CleanSpace Respirator runs the Flow Test automatically. The Power Unit will operate and air will be discharged from
the Flow Test Cap.
5. After completion of the Flow Rate Test, the Battery Indicator Lights illuminate to display the result.
Refer to the table below.
LIGHTS
Meaning
3 Lights:
PASS - Excellent (Flow >180 l/min)
2 Lights:
PASS - Good
1 Light:
PASS - Acceptable
ALL LIGHTS
FLASH
FAIL - (Flow <120 l/min)
Do not use the CleanSpace Respirator until a new filter has been fitted and / or battery charged and
the Flow Test has been repeated with a PASS result.
Reset the CleanSpace respirator by pressing the Power Button. Fully charge the battery and / or replace
the filter. Repeat the flow test. If the CleanSpace respirator continues to FAIL the Flow Test, with a new
filter fitted and battery, do not use until it has been evaluated. Contact CleanSpace Technology.
6. Remove the yellow Flow Test Cap and store for later use.
STEP 4 - DON THE CLEANSPACE RESPIRATOR WITH HALF MASK
NOTE: Please this step in its entirety prior to donning the CleanSpace Respirator.
Collect the Power Unit, mask, neck support and harness. Ensure the mask and neck support are the correct size.
Fit the neck support to the Power Unit.
FAILURE to fit the Flow Test
Cap to the LEFT bellow will
FAIL the Flow Test, even if
the filter is clean and the
battery is fully charged.

CleanSpace Respirators USER INSTRUCTIONS
13
English
The CleanSpace Respirator comes supplied with two neck
supports:
▪PAF-1028 NECK SUPPORT SMALL
▪PAF-1012 NECK SUPPORT MEDIUM
▪PAF-1013 NECK SUPPORT LARGE
Select the appropriate size neck support.
The neck support has keyhole openings at each end which
snap over buttons on the Power Unit. Place the neck support
in position against the buttons and then press firmly towards
the Power Unit until the buttons engage in the keyhole
openings.
Fit a mask to the Power Unit
•The left hand mask arm is open, whilst the right one
is closed. The figure on the right highlights the left
hand (open) mask arm.
•Connect the left hand mask arm to the left hand
Power Unit bellow. The left hand Power Unit bellow.
is on the same side as the “POWER” button.
•
Ensure the AirClip is securely fastened as shown in Figure B below.
Figure A. Connect the left hand mask arm with the
bellow.
Figure B. Mask fastened to Power Unit. Note: connection is on
the left hand side
IMPORTANT: Ensure the mask is the right way up. The
pointed nose section of the mask must face up in the
same direction as the keypad. See Figure on the right.
Leave the other mask arm and bellow unattached until
you don the CleanSpace respirator.
Fit the harness to the mask

CleanSpace Respirators USER INSTRUCTIONS
14
English
Orient the harness ensuring there
is a clip with a keyhole next to
each arm of the mask and the rear
harness strap is toward the Power
Unit.
Attach the harness to the mask on
both sides.
Familiarise yourself with the Adjust Buttons and the Mask
Release Buttons.
Extend both bellows to their longest setting.
Mask Release Button and Adjust Button
Press the Adjust Button on the Power Unit and pull on the
bellows to extend.

CleanSpace Respirators USER INSTRUCTIONS
15
English
Switch the Power Unit to
Standby Mode. Briefly press
the Power Button once. The
Battery Indicator Light(s)
should illuminate.
Place the Power Unit behind
your neck with the mask
attached on the left-hand
side.
Ensure the head harness is
above the mask and not
tangled.
Connect the right-hand Mask
AirClip to the right-hand
Power Unit AirClip.
Locate the hook on the end of
the harness rear strap. Pull
the rear strap back over your
head.
Connect the hook to the loop
located on the filter cover of
the Power Unit.
The rear strap supports the
weight of the Power Unit.

CleanSpace Respirators USER INSTRUCTIONS
16
English
Adjust Power Unit Position.
Adjust the rear strap to set the height of the Power Unit.
For most users, wearing the Power Unit level is
comfortable.
Adjust the fit of the mask. Ensure no leaks mask and face.
To loosen the mask, press the adjust button and extend the
bellow. on the bellow.
To tighten the mask, place one hand against the back of the
Power Unit, and the other on the mask. Push the Power
Unit and the mask towards each other. You will hear a
series of clicks as the bellows tighten.
Ensure the bellows are adjusted symmetrically.
Mask Fit Requirements
No Gaps: There should be no visible gaps between mask and face.
No Creases: If the mask is overtightened, or is too large for the face, creases may appear near the mouth, or in the
centre of the bottom of the cushion. Loosen the mask, or try a smaller mask.
No gaps while looking down: Ensure no gaps exist between the bridge of the nose and the mask. Also check that the
mask has not come loose around the chin. If gaps appear, try to fit the chin further into the mask, accurately positioning
in the chin well. If that does not work, try a smaller mask.
No air blowing into the eyes: Ensure there is no air blowing into the eyes. If there is, try tightening the mask, or
loosening the harness slightly. If this does not work, try a different size mask.
Not uncomfortably tight: A good fit should be achieved without the mask being uncomfortably tight. Beyond a certain
point, tightening makes the fit worse, not better. If the bellows are visibly curving outward, they should be loosened.

CleanSpace Respirators USER INSTRUCTIONS
17
English
STEP 5 –CHECK MASK SEAL
A fit check must be conducted every time you wear the CleanSpace Respirator. Locate the red Seal Check Cap (PAF-1009). Fit
the Seal Check Cap over mask exhalation cap. The Seal Check Cap should snap into place. See figure below.
•Ensure the Seal Check Cap is security fitted. No air should be escaping from the exhalation valve.
•Breathe normally.
•Check for leaks by feeling around the edges of the mask. Exhale firmly to raise the air pressure in the mask.
If still unsure whether a leak is present, wetting fingers may make it easier to detect.
•If necessary, tighten the mask. To tighten the mask, place one hand against the back of the Power Unit, and the other on
the mask. Push the Power Unit and the mask towards each other. You will hear a series of clicks as the bellows tighten.
•Ensure the bellows are adjusted symmetrically.
Do not overtighten the bellows! If the front of the mask starts to cave in, the fit is too tight, leaks may appear. Press the Adjust
Buttons to loosen.
After adjusting, check for leaks again
Tilt head up, down, left, and right, checking for leaks in each position. Adjust if necessary.
Once no leaks are detected, the mask seal check is complete.
IF A SATISFACTORY FIT CANNOT BE ACHIEVED, DO NOT ENTER THE CONTAMINATED ZONE
Remove the Seal Check Cap by gently twisting the handle so that one side of the cap comes loose from the exhalation valve.
Be careful not to dislodge the exhalation valve cover. See figure on the following page.
NEVER LEAVE THE SEAL CHECK CAP IN PLAE FOR MORE THAN TWO (2) MINUTES!

CleanSpace Respirators USER INSTRUCTIONS
18
English
The Seal Check Cap must be removed before entering the contaminated area. The cap blocks the exhalation valve, making it
more difficult for your exhaled air to be expelled from the mask. Failure to remove the cap will lead to a buildup of carbon
dioxide in the mask, which could result in headache or dizziness.
Never leave the Cap in place for more than 2 minutes!
9. Using the CleanSpace Respirator with Full Face Mask
MASK FITTING –FULL FACE MASK
NOT –Intrinsically Safe
PAF-1106 Full Face Mask Small
PAF-1014 Full Face Mask Medium
Determine the correct mask size and achieve a good fit prior to using the CleanSpace Respirator.
Mask fitting must be carried out by a specialist / designated mask fitter. The fit must be confirmed by a quantitative fit test.
To carry out a quantitative fit test the specialist / designated mask fitter will require the S005-7174 Quantitative Fit Test
Instructions.
No PAPR can fully protect you if you are not clean shaven. CleanSpace Respirator is not suitable for users with facial hair.
MASK SELECTION GUIDELINES
No set of guidelines can ensure a good fit. Fit must be confirmed with a quantitative fit test.
The test is performed using a machine that compares the concentration of particles in the mask with that in the surrounding
atmosphere. One example is the PortaCount Respiratory Fit Tester, made by TSI Incorporated. CleanSpace Full Face Masks
come with a built-in sampling port and a sampling ball accessory which make it quick and easy to carry out a fit test.
To set up for the test, do the following. Firstly, we recommend you remove the inner mask as that makes access easier.

CleanSpace Respirators USER INSTRUCTIONS
19
English
With the mask off your face, pull the
orange plug from the Sensing Ball
socket.
Locate the Sensing Ball which
was supplied with your mask.
Fit the Sensing Ball. Push it all the way in.
Note that there are small fins on the stem of
the ball to ensure the correct orientation.
Raise the rain cover.
Remove the sealing plug from
the fit test port.
Fit the mask sensing tube to the fit test port
(on a TSI PortaCount it is the clear tube).
Re-fit the inner mask. The inner mask is an essential part of the Full Face Mask and is required to complete the fit test. Don the
mask and begin the test, following the protocol provided with the fit testing machine. A CleanSpace Respirator with a clean
filter, a full battery, and the Power Unit on, should achieve a fit factor above 1000. If your result is below 1000, adjust the
mask and try again.
WARNING
If a satisfactory quantitative fit factor or a qualitative test pass cannot be achieved with either mask, the
CleanSpace Respirator must not be used.
Satisfactory quantitative fit factor results are as follows.
Test Type
Half Mask
Full Face Mask
Power On
1000
1000
Power Off
100
500
On completion of the fit test, the Full Face Mask must be prepared for use as follows.
Remove the Sensing Ball from the
Sensing Ball socket. Refit the orange
plug to the Sensing Ball Socket,
pushing it all the way in.
Remove the sensing tube from the fit
test port. Refit the plug to the fit test
port.
Lower the rain cover.

CleanSpace Respirators USER INSTRUCTIONS
20
English
WARNING
A negative pressure seal check must be performed in order to ensure that the test port plug is fitted
correctly after use of the on-board fit test ports. Refer to section 9, Step 4.
WARNING
Using the Full Face Mask with the rain cover raised can cause the exhalation valve to vibrate, which
may cause a buzzing noise. For correct operation, the rain cover should be lowered.
No PAPR can fully protect you if you are not clean shaven. CleanSpace Respirator is not suitable for users with facial hair.
Once you have achieved an acceptable mask fit and confirmed it with a quantitative fit test, record your information in the
table below.
Name
Mask Type
Neck Support
N/A
Date of Quantitative Fit Test
Fit Factor on Test
IF A SATISFACTORY FIT FACTOR CANNOT BE ACHIEVED WITH ANY OF THE MASKS, THE CLEANSPACE RESPIRATOR MUST NOT
BE USED.
USING THE CLEANSPACE RESPIRATOR WITH FULL FACE MASK
Complete the following steps each time you use CleanSpace Respirator with FULL FACE MASK.
Prior to entering a potentially contaminated area, the following inspection must be performed.
STEP 1 –INSPECT THE CLEANSPACE RESPIRATOR
•Visually inspect all the CleanSpace Respirator components, (Power Unit, mask, harness, filter adaptor, and filter). If any
components are missing or damaged, replace them only with approved CleanSpace Respirator parts before proceeding.
Check the top and bottom case of the Power Unit, and the Filter Adaptor (if fitted) for cracks or other damage. Do not use
the CleanSpace Respirator if there is any damage.
•Remove the filter and inspect it carefully. The seal must be clean, and free from damage of any kind. If necessary, the seal
and housing can be cleaned with a cloth dampened with water. (The filter media must not be exposed to water). Inspect
the surfaces behind the filter carefully for any sign that dust has leaked past a damaged seal. If dust is found, replace the
