GB IDAN User manual

EN
IDAN
Future perFect

2
INFANT CAR SEAT USER GUIDE
READ ALL INSTRUCTIONS BEFORE USE.
TABLE OF CONTENTS
REGISTRATION AND RECALL INFORMATION ....4
WARNINGS AND IMPORTANT SAFETY
INFORMATION............................................ 513
CHILD HEIGHT AND WEIGHT LIMITS.................14
UNIQUE FEATURES OF THE GB IDAN................15
OVERVIEW OF THE LOAD LEG BASE............1617
OVERVIEW OF THE
GB IDAN INFANT CARRIER........................ 1819
USING THE INFANT CARRIER
HANDLE..........................................................20
CANOPY .........................................................21
HARNESS BUCKLE, CHEST CLIP,
ONE HANDED HARNESS ADJUSTMENT.......22
ADJUSTING THE SEAT....................................23
INFANT BODY SUPPORT................................23
SECURING THE CHILD ................................ 2425
VEHICLE SEAT LOCATION
REQUIREMENTS....................................... 26
VEHICLE SEAT BELT REQUIREMENTS......2729
USING LATCH
WHAT IS LATCH? ...................................... 30
OUTER SEATING POSITIONS.................... 30
USING LATCH GUIDES ..............................31
REMOVING AND STORING
LATCH CONNECTORS..........................3233
USING THE LOAD LEG.............................3435
ADJUSTING THE RECLINE ANGLE
USING THE BASE...................................3637

EN
3
IF THESE INSTRUCTIONS ARE NOT FOLLOWED, THE
SAFETY OF A CHILD MAY BE SEVERELY ENDANGERED.
KEEP INSTRUCTIONS FOR FUTURE USE.
INSTALLING THE BASE
USING LATCH ........................................ 3841
USING A LAP AND SHOULDER BELT..... 4245
USING A LAP BELT ONLY....................... 4649
USING THE INFANT CARRIER
WITH THE BASE..................................... 5051
ATTACHING INFANT CARRIER TO BASE..........50
RELEASING INFANT CARRIER FROM BASE.....51
INSTALLING THE INFANT CARRIER
WITHOUT THE BASE USING ONLY A LAP AND
SHOULDER BELT................................... 5255
USING ONLY A LAP AND SHOULDER BELT
ALTERNATE METHOD.......................... 5659
USING A LAP BELT ONLY....................... 6061
USING THE LINEAR SIDEIMPACT PROTECTION
LSP.......................................................6263
ADJUSTING THE RECLINE ANGLE WITHOUT
THE BASE .............................................6465
USING THE INFANT CARRIER ON AN
AIRCRAFT .............................................6667
CARE AND CLEANING.................................... 68
REMOVING THE SEAT COVER..............6869
WASHING INSTRUCTIONS.....................7071
SAFETY CHECKLIST ..................................72
NOTES ............................................................73
WARRANTY......................................................74

4
Child restraints could be recalled for safety
reasons. You must register this restraint to
be reached in a recall. Send your name,
address, e-mail address, if available, and the
restraint’s model number and manufacturing
date to:
REGISTERING YOUR CHILD RESTRAINT
Please complete the pre-paid registration
card that is attached to your child restraint
and send in the portion shown below today.
Call the U.S. Government’s Vehicle Safety
Hotline at 1-888-327-4236 (TTY:1-800-424-9153),
or go to www.NHTSA.gov
This child restraint conforms to all applicable
Federal motor vehicle safety standards. This
Restraint is Certified for Use in Motor Vehicles
and Aircraft. It is not intended to be used in
low-speed vehicles such as golf carts, ATV’s or
any other non-certified vehicle.
CERTIFICATION
FOR RECALL INFORMATION
IF YOU NEED ASSISTANCE OR HAVE QUESTIONS
If you have any questions regarding installation
of your child restraint, please contact us at:
Columbus Trading-Partners USA Inc.
Attn: ParentLink
1801 Commerce Drive
Piqua, Ohio 45356
1-844-543-2020
www.gb-online.com
Columbus Trading-Partners USA Inc.
Attn: ParentLink
1801 Commerce Drive
Piqua, Ohio 45356
or call 1-844-543-2020
or register online at:
http://register.gb-online.com/us/carseats
For helpful information regarding Child restraints:
www.NHTSA.gov
http://www.safercar.gov/parents
/CarSeats/Car-Seat-Safety.htm
www.seatcheck.org
REGISTRATION AND RECALL INFORMATION
Tear off and mail this part
Consumer: Just fill in your name and address and e-mail address.
Your Name
CHILD RESTRAINT REGISTRATION CARD
Your Street Address
State Zip Code
City
E-mail Address
RG5008
Date of Manufacture: xxxx/xx/xx
Model Number : xxxxx
Model Name : GB Idan

EN
5
•DO NOT place rear-facing child seat on front seat with air bag.
DEATH OR SERIOUS INJURY can occur. The back seat is the safest
place for children 12 and under.
WARNING
ADVERTENCIA
MISE EN GARDE
WARNINGS AND IMPORTANT SAFETY INFORMATION
•DO NOT use this restraint in the front seat of a vehicle equipped with an air bag. Interaction
between a rear facing restraint and air bags may cause serious injury or death. If your vehicle
has an air bag, refer to the vehicle owner’s manual for child restraint installation.
•If the rear seat of your vehicle is equipped with side air bags, refer to the following information
for proper usage.
•Vehicles built prior to the 2002 model year:
DO NOT use this restraint in a vehicle seating position equipped with a side air bag
unless authorized by the vehicle manufacturer.
Model year 2002 and newer vehicles:
Refer to your vehicle owner’s manual before placing this restraint in a seating position
equipped with a side air bag.
•DO NOT place any objects between the restraint and the side air bag, as an expanding air
bag may cause the items to strike your child.

6
•READ this Owner’s Manual carefully before first
use, and keep it for future reference.
•FOLLOW ALL INSTRUCTIONS on this child
restraint and in the written instructions stored in
slot on the bottom of the infant carrier.
•NEVER install or use this child restraint until
you have read and understand the instructions
in this manual, the labels on your child restraint
and in your vehicle Owner’s Manual. If there is
a conflict between the two, the vehicle Owner’s
Manual must be followed. Failure to follow
these instructions can result in death or serious
injury of your child in a crash.
•DO NOT ALLOW others to install or use this
child restraint unless they understand how to
correctly install and use it.
•ONLY place this child restraint REAR FACING in
a vehicle seating location allowed by the vehicle
manufacturer. Refer to your vehicle's Owner’s
Manual for information about vehicle seat belt
systems, air bags, side air bags, front passenger
side air bags and child restraint installations, to
determine allowable seating positions.
•Not every location within a vehicle may be
safe for the installation of this child restraint.
In fact, some vehicles have no seating position
that is safe for the installation of an Infant Car
Seat. Improper placement of this child restraint
within a vehicle will increase the risk of death or
serious injury.
•ACCORDING TO CRASH STATISTICS, children
are safer when properly restrained in rear
vehicle seating positions, rather than in the
front seating positions.
•The primary protection for occupants of a
vehicle in a collision is the structure of the
vehicle itself. Correctly used, this child restraint
will substantially improve the chances for
survival in most crashes.
WARNING! DEATH or SERIOUS INJURY can occur.
!

EN
7
•WHEN USED INSIDE A VEHICLE
•ONLY USE with children who weigh between
4 and 35 lb (1.8 and 15.9 kg) AND whose height
is 30 inches (76 cm) or less.
•DO NOT USE this child restraint if the top of
your child‘s head is less than 1 inch (2.5 cm)
from the top of the restraint.
•THE infant body support must be used for
infants who weigh less than 11 lbs (5kg) or
reach 3 months.
•SOME CHILDREN WITH SPECIAL NEEDS,
such as preemies or those who have tested
positive for positional apnea, may be at
increased risk of suering breathing or other
diculties in a child restraint. Please consult
a physician to determine what type of child
restraint should be used.
•DO NOT use this or any other child restraint
with a premature, low birth weight, or medically
fragile infant, until you have consulted with
your doctor. Some infants may have diculty
breathing or have other medical problems when
placed in a seated position.
•NEVER place this child restraint on a front
seat with an active airbag. DEATH or SERIOUS
INJURY may occur. The REAR seat is the safest
place for children 12 and under.
•ONLY USE this child restraint rear-facing.
•NEVER install this child restraint in vehicle seats
that face the rear or side of the vehicle.
•ALWAYS check the harness buckle to make
sure it is securely latched.
•SNUGLY ADJUST the belts provided with this
child restraint around your child.
•ALWAYS keep your child properly secured in
the harness. A snug strap should not allow any
slack. It lies in a relatively straight line without
sagging. It does not press on the child’s flesh or
push the child’s body into an unnatural position.
•NEVER use bulky clothing or blankets that will
interfere with properly positioning or tightening
the harness.
WARNING! DEATH or SERIOUS INJURY can occur.
!

8
•NEVER leave your child unattended or alone
in the vehicle, even for one minute.
•NEVER LEAVE CHILD UNATTENDED in or
around the vehicle. Vehicle backovers can
happen in any type of vehicle. Vehicles have
blind spots, the areas around the vehicle that
you can not see from the driving position.
Always check around the vehicle before
moving your vehicle.
•ALWAYS have the handle locked in Position A
while using this child restraint in a vehicle.
•Whenever possible, INSTALL the Base in a
seating position that will allow the Load Leg
to be extended into a locked position making
firm contact with the vehicle floor.
•NEVER INSTALL the Base in a seating
position where the Load Leg, even in
its shortest position, causes the base to
be pushed up above the vehicle seat. If
necessary, the base may be installed with the
Load Leg folded up underneath it.
•If using a base, ALWAYS check to make sure
the Infant Carrier is securely attached to the
Base, each time you use this restraint. After
attaching the Infant Carrier to the base, lift up
on the Infant Carrier handle to make sure that
it is securely attached to the base.
•If using a base, ONLY USE with the Load Leg
Base for Idan.
•ALWAYS Use a Linear Side-impact Protection
(L.S.P.) (see page 62-63) device on the side of
the child restraint immediately adjacent to a
vehicle door or panel.
•NEVER extend a Linear Side-impact
Protection (L.S.P.) device toward a passenger
or another child restraint.
•NEVER use this child restraint in a vehicle
seating position where it cannot be secured
tightly. A loosely installed child restraint will
not protect your child in a crash.
WARNING! DEATH or SERIOUS INJURY can occur.
!

EN
9
•NEVER LEAVE a vehicle seat back with a
folding mechanism unlocked. In the event of
a sudden stop, an unlocked vehicle seat back
could prevent this child restraint from protecting
your child.
•NEVER use this child restraint with any
motorized, or door mounted vehicle seat belts.
Your child restraint would not be properly
restrained in the event of a crash.
•NEVER use this child restraint on boats, low
speed vehicles (LSV), all-terrain vehicles (ATV),
golf carts, or any other non-certified application.
•BEFORE each use, ALWAYS check that the child
restraint is tightly secured in the vehicle seat
and does not move more than 1 inch (2.5 cm) in
any direction when checked at the belt path.
•ALWAYS check buckles and other parts for hot
surfaces before placing your child in the child
restraint. A hot surface could burn your child!
Cover an unoccupied child restraint with a
blanket when leaving it in a vehicle exposed to
sunlight.
•NEVER leave an empty child restraint
unsecured in your vehicle. This restraint must
always be secured, even when not occupied.
An unsecured child restraint could injure vehicle
occupants in a sudden stop or crash.
•If the LATCH connectors are not being used
make sure they are securely stored.
•DO NOT use this child restraint if it has been in
a crash. There may be hidden damage and it
must be replaced.
WARNING! DEATH or SERIOUS INJURY can occur.
!

10
•NEVER use this child restraint when it is older
than six (6) years. The date of manufacture can
be found on a label axed to the bottom of
the Infant Carrier, as well as the Base.
•NEVER use this child restraint if any of the
Harness or LATCH straps are cut, frayed, or
damaged in any way.
•NEVER use accessories or parts with this
child restraint other than those approved by
GB. Use of accessories or parts from other
manufacturers could alter the performance of
the child restraint.
•DO NOT USE this child restraint with inflatable
seat belts.
USING THE INFANT CARRIER
OUTSIDE A VEHICLE
•NEVER leave child unattended.
•Suocation Hazard: Infant carrier can roll
over on soft surfaces and suocate child.
NEVER place Infant Carrier on beds, sofas, or
other soft surfaces.
•Fall Hazard: Child’s activity can move carrier.
NEVER place carrier on counter tops, tables,
or any other elevated surfaces.
•ALWAYS USE the five-point harness.
•ALWAYS keep your child properly secured
in the Harness, even when using the carrier
outside of the vehicle, especially when in the
full recline position.
•MAKE SURE the handle is LOCKED in
Position A before lifting Infant Carrier by the
handle. An unlocked handle could move
unexpectedly, causing child to fall.
•Only use Infant Carrier with strollers that are
approved by the manufacturer. Refer to the
stroller Owner‘s Manual for details about how
to attach the Infant Carrier to your stroller. For
a list of compatible strollers, please visit
www.gb-online.com
WARNING! DEATH or SERIOUS INJURY can occur.
!

EN
11
•ADDITIONAL SAFETY
INFORMATION
C200_US004_01B
!!¡ADVERTENCIA!
WARNING!
Children have STRANGLED in loose or partially buckled
harness straps. Fully restrain the child even when the
carrier is used outside the vehicle.
Los niños se han ESTRANGULADO en las correas del
arnés sueltas o parcialmente abrochado. Restringir
totalmente al niño, incluso cuando el vehículo se utiliza
fuera del vehículo.
•DO NOT use on shopping carts.
WARNING! DEATH or SERIOUS INJURY can occur.
!

12
•REGISTER your child restraint with the
manufacturer. This is the best way to reach you
in the event of a recall.
•DO NOT allow children to play with this child
restraint.
•DO NOT attempt to make repairs to or
otherwise modify or tamper with this child
restraint.
•DO NOT use a used child restraint whose
history you do not know.
•NEVER allow someone else to use this child
restraint and base without also passing along
this manual to them.
•DO NOT allow children to play with vehicle seat
belts. They may create an entanglement hazard
for any child that can reach the seat belt and
may wrap it around his or her neck.
•DO NOT leave loose objects (e.g. groceries,
books, bags) in a vehicle. In the event of a
sudden stop, loose objects will keep moving,
potentially causing serious injuries.
•DO NOT carry the child restraint by the canopy
or harness adjustment strap.
•NEVER tend to your child’s needs while driving.
ALWAYS safely stop your vehicle in order to tend
to your child.
•NEVER take your child out of the infant car
seat while the vehicle is moving. Unrestrained
occupants are at a greatly increased risk of
death or serious injury in a car crash.
WARNING! DEATH or SERIOUS INJURY can occur.
!

EN
13
•NEVER USE INFANT CARRIER OR BASE
IF IT HAS DAMAGED, BROKEN
OR MISSING PARTS.
•ALWAYS REPLACE THE CHILD RESTRAINT
AND BASE AFTER A CRASH OF ANY KIND
EVEN IF IT WAS UNOCCUPIED. A crash can
cause unseen damage to the child restraint that
may not be visible.
WARNING! DEATH or SERIOUS INJURY can occur.
!

14
YOUR CHILD MUST MEET THE HEIGHT
AND WEIGHT REQUIREMENTS LISTED:
WEIGHT: 4  35 LBS. 1.8 KG15.9 KG
HEIGHT: 30 INCHES 76 CM OR LESS
CHILD’S HEAD MUST BE 1” 2.5 CM OR MORE
BELOW THE TOP OF THE SEAT AS SHOWN
The American Academy of Pediatrics recommends children
should ride rear-facing for as long as possible up to 2 years in
age, or until they reach maximum height and weight for their
seat.
CHILD HEIGHT AND WEIGHT LIMITS
Harness straps must be adjusted
to be AT or JUST BELOW child’s
shoulders
Minimum 1 inch (2.5 cm)
DEATH or SERIOUS INJURY can occur,
WARNING!
LINE MUST BE
LEVEL
WITH GROUND
WHEN
INSTALLED
WITHOUT
BASE
FRONT OF VEHICLE
SUFFOCATION HAZARD: Infant carrier can roll over on soft surfaces and
suffocate child. NEVER place carrier on beds, sofas or other soft surfaces.
FALL HAZARD: Child’s activity can move carrier. NEVER place carrier on
counter tops, tables, or any other elevated surface.
DO NOT use without instructions! call 1-844-543-2020
for a free replacement.
DO NOT use on shopping carts.
•Use only in a rear-facing position when using it in the vehicle.
•Use only with children who weigh between 4 - 35 lbs (1.8 - 15.9 kg)
and whose height is 30 inches (76 cm ) or less.
•Snugly adjust the belts provided with this child restraint around your child.
•Secure this child restraint with the vehicle’s child restraint anchorage system
(LATCH), if available, or with a vehicle belt.
•Follow all instructions on this child restraint and in the written instructions
located in a pocket on the bottom of the infant carrier.
•Register your child restraint with the manufacturer.
•NEVER leave child unattended.
•The infant body support must be used for infants who weigh less than 6lbs (2.7kg)
Always use
harness AT
or JUST
BELOW
the child’s
shoulders
Head 1” (2.5 cm ) from
top of seat
1”
LAP / SHOULDER BELT
CLICK!
LAP BELT ONLY
Part Number : LB0172
Title : label-carseat-gb-idan-rnhsta-2050-Eng
Size : 9.7 x 3.6 in
Color : BLACK, YELLOW 803C, RED PMS 186C, GREEN 360C
Material: permanent pressure sensitive
Location : on childs right side of shell
LABEL INFORMATION
LB0172

EN
15
LINEAR SIDE-IMPACT
PROTECTION
(LSP) SYSTEM
A unique blocker arm,
combined with deep
side wings lined with
thick energy-absorbing
EPS foam and an
adjustable headrest
forms the Side Impact Protection System. This
system has been optimized to protect and greatly
reduce any forces on your baby in the event of a
side impact crash.
LOAD LEG
The European-style Load Leg
prevents the seat from rotating
forward, allowing the seat to
support the baby’s head, neck,
and body. It also transfers much
of the energy to the vehicle’s
floor, decreasing forces on your
baby up to 50%!
NO-RETHREAD
HARNESS
The no-rethread harness
adjusts the harness height
through eleven positions
without the need for
rethreading.
Super eaSy and TighT™
(SEAT) INSTALLATION
The GB Idan Belt Tensioner uses GB's SEAT
Technology to achieve a quick and secure
installation every time, whether you choose to
use LATCH or
vehicle belts.
UNIQUE FEATURES OF THE GB IDAN

16
Belt Guide
Locking Lever
Infant Carrier
Attachment Lock
Infant Carrier
Attachment Catch
Infant Carrier Release
Load Leg
Load Leg Adjustment
Handle
Green Safety Button
Belt Tensioning Plate
Steel Chassis
LATCH Strap
Tensioning Loop
Leveling Foot
Load Leg Foot
Level Indicator
(hidden)
OVERVIEW OF THE LOAD LEG BASE
FRONT VIEW
22–35 lb
10–15.9 kg
4–22 lb
1,8–10 kg
4–22 lb
1,8–10 kg
22–35 lb
10–15,9 kg

EN
17
LATCH Guides
LATCH Strap
Adjuster
Belt Tensioning
Plate
Leveling Foot
(fully extended)
LATCH Connector
Storage
Level Adjustment
Handle
LATCH
Connector
Locking Lever
OVERVIEW OF THE LOAD LEG BASE
REAR VIEW

18
TOP VIEW
Harness Buckle
Harness Straps
Harness Adjustment Strap
Harness Adjustment Button
Buckle Pad
Canopy
Carry Handle
Infant Body Support
Headrest
No Rethread
Harness Adjuster
(top of headrest)
Shoulder Pads (removable)
Lap Belt Guide
L.S.P. device
(stored)
Chest Clip
Carry Handle
Adjustment Button
OVERVIEW OF THE GB IDAN INFANT CARRIER

EN
19
BOTTOM
VIEW
Shoulder Belt Guide
Harness
Base Attachment Rod
Owner's
Manual
(Stored)
Base Attachment Rod
L.S.P. device (stored)
OVERVIEW OF THE GB IDAN INFANT CARRIER

20
There are 4positions:
- Carrying / vehicle position A,
- Middle positions B  C,
- Stationary position D.
To adjust, squeeze handle adjustment buttons
on both sides , then rotate the handle.
The handle will lock into position.
You should hear a click when the handle
button is engaged and handle is locked into
position. ALWAYS CHECK to make sure
handle is locked into place after adjusting.
WARNING
ADVERTENCIA
MISE EN GARDE
HANDLE
ALWAYS make sure the handle is securely
locked in the upright carrying position A
before carrying.
ONLY USE POSITION A in the vehicle.
Never hang toys or other objects from handle
when using child restraint in a vehicle as they
could seriously injure a child in a sudden stop
or crash.
BA
C
D
a
a
USING THE INFANT CARRIER
